BACKUP Service Manual ECLIF=SE/ ECI-I’SE 1997 Volume 2 Electrical FOREWORD This Service Manual has been prepared with the latest service information available at the time of publication. It is subdivided into various group categories and each section contains diagnostics, disassembly, repair, and installation procedures along with complete specifications and tightening references. Use of this manual will aid in properly performing any servicing necessary to maintain or restore the high levels of performance and reliability designed into these outstanding vehicles. This BACKUP DSM manual IS to be used ONLY as a BACKUP. Please DO NOT REDISTRIBUTE WHOLE SECTIONS. This BACKUP was sold to you under the fact that you do indeed OWN a GENUINE DSM MANUAL. It CANNOT BE considered a REPLACEMENT (Unless your original manual was lost or destroyed.) Please See README.N or README.HTML for additional Information. Thank you. G~mm~emymanual@hotma~l.com II WE SUPPORT VOLUNTARY TECHNICIAN CERTIFICATION THROUGH II General ......................... Component Locations ........... Configuration Diagrams ......... Circuit Diagrams ................ Engine Electrical ............... Chassis Electrical .............. Alphabetical Index ............. NOTE: For information concerning all compo- nents other than the electrical system, refer to Volume 1 “Chassis & Body” of this paired Service Manual. A MITSUBISHI MOTOR SALES OF AMERIC Inc. Mitsubishi Motors Corporation resewes the right to make changes in design or to make additions to or improvements in its products without imposing any obligations upon itself to install them on its products previously manufuctured. @ 1996 Mitsubishi Motors Corporation Printed in U.S.A.

: “_i _a ! - ‘, ? i ‘20 ‘ ” :. ;: < ‘) ,_,’ ‘1 .

/.’ ). i ,‘, ,(G’ . . -. . “.. _ ..‘ i -

2 GENERAL - Harness Connector Inspection Harness connector’ Harness for checking the contact pressure of connector pins A 01 A0579 -I HARNESS CONNECTOR <INSPECTION ooiooa9oo48 CONNECTOR CONTINUITY AND VOLTAGE TEST Follow the steps below to avoid causing poor connector contact and/or reduced waterproof performance of connectors when checking ,@ontinu/ty and/or voltage at connectors of waterproof connectors.. “a (1) If checking is performed with the circuit in the state of continuity, be sure to use the special tool (harness connector). Never insert a test bar from the harness side, because to do so will reduce the waterproof performance and result in corrosion. (2) If the connector is disconnected for checking and the facing part is the female pin side, the harness for checking the contact pressure of connector pins should be used. Never force the insertion of a test bar, because to do so will cause poor or .improper, contact. (3) If the facing part is the male pin side, contact the test bar directly to the pins. Care must be taken not to short-circuit the connector pins. IMPROPER TERMINAL ENGAGEMENT CHECK When the terminal stopper of the connector is out of order, engagement of the male and female terminals becomes improper even when the connector itself is engaged perfectly and terminal sometimes slips out to rear side of connector. Make sure, that each terminal does not come off the connector by pulling each harness wire. CONNECTOR TERMINAL ENGAGEMENT AND DISENGAGEMENT A connector that engages loosely can be repaired by removing the female terminal from the connector housing and raising its lance to establish securer engagement. Removal of the connector terminal used for MFI and ELC4 AK control circuit can be done in the following manner. COMPUTER CONNECTOR (1) Insert a screwdriver [1.4 mm (.06 in.) width] as shown in the figure, disengage front holder, and remove it. . . . , &i :,” TSB Revision ‘I

GENERAL -’ Harness Connector Inspdibn Housing lance 16R1321 P Needle II 16R1322 Ho&sing lance 16Rl323 16Rl324 (2); Insert the harness terminal tv,Je repaired deeR jnt&Jffe conneqtor from harness side- and%.nold it t&T:, I” :’ I ,+ #‘,i * (3) Insert the tip of Rhe screwdriver [1.4 mm ~(.06’in.)‘~k%kh”] into the connector as sho$nin the figure, raise the housing .lance slightly with it, and ‘pull”,out, the harness. ..; Caution I ,; “, T6ol ‘No. 753787-l supplied b;i AM$c&$ ,&kc! instead of screwdriver. ,. ,,” ,,. ,‘I .L, ,’ ; ._ . . _ ” ,,.:r,. < ., ‘. , -I_’ _ , ^ ,_ _ (4) Insert a needle through .the hole provided on tfe terminal _“I and raise the centact paint of the male terminal. _’ ROUND WATERPROOF Ci)NNEC’$fk - ..‘.I ,+ (1). Remove the waterproofYkap by using a screv$$&r. : (2) Insert the tip of the screM$friver [1.4 mm (06 In.) ?r 2.0 mm (.08 in.) width] into the connec$r as shown tn the figure, raise the housing lance slightly, with it, and pull I--_ _=-. I ““’ TSB Revision (3), Insert a screwdriver through the hdie provided en terminal and raise the contact point of the male tern’ -2 ,’ 1 :, ,” .i ,‘,,
