2008 Mazda TRIBUTE (CZ) Service & Repair Manual

00-001/09 - MULTI-MODEL - ENGINE CAUTION FOR NEW VEHICLE STORAGE SI107438 TSB NUMBER: 00-001/09 For Internal Mazda Corporate Use Only DESCRIPTION APPLICABLE MODEL(S)/VINS 2008-2010 MX-5 2008-2010 RX-8 2008-2010 Mazda3 2008-2010 Mazda5 2008-2010 Mazda6 2008-2010 CX-7 2008-2010 CX-9 2008-2010 Tribute 2008-2010 Tribute Hybrid 2008-2009 B-Series CAUTION Take caution when starting new vehicles in inventory. Engine damage can occur if engine is not started properly. Engine oil on friction components such as the cylinder bore, piston rings, crank and camshaft journals, etc., may thin or dry out completely during long- term storage. As a result, it may take some time before oil from oil pump reaches all friction components. The following procedures must be used during Pre Delivery Inspections and long-term storage of new vehicles in inventory. MAINTENANCE PROCEDURE 1. Operate engine and warm it up at least once every two months of storage. 2. Do not race the engine for the ﬁrst 30 seconds after engine start up. Instead, allow engine to idle for at least 30 seconds after start up. This will allow proper lubrication of all friction components. 3. If battery is discharged, do not jump start engine. Charge the battery off the car. Proceed to Step 2 after charging the battery. 4. Keep engine speed below 3,000 rpm during driving and while parked.

00-005/18 - VEHICLE WARRANTY / SERVICE / MAINTENANCE PROCEDURES SI106983 TSB NUMBER: 00-005/18 TSB ISSUE DATE 09/14/2018 BULLETIN NOTES This bulletin supersedes the previously issued bulletin(s) listed below. The changes are noted in Red. Previous TSBs:Issued Dates: 00-002/09 11/17/09 00-001/07 07/05/07 APPLICABLE MODEL(S)/VINS 2008-2010 Tribute HYBRID For Internal Mazda Corporate Use Only DESCRIPTION A very limited number of Tribute Hybrid vehicles were produced during the 2008-2010 MY. These special vehicles were sold ONLY in the state of California by Dealers who chose to be “Mazda Certified Hybrid” dealers. At the time of launch, their technicians received specialized training to safely perform service and maintenance on these vehicles. With the discontuation of the Tribute Hybrid, Mazda did not require these dealers to continue to be Mazda Certified Hybrid dealers, therefore all repairs or maintenance on Tribute Hybrid vehicles must be sublet to a Ford Certified Hybrid dealer. IMPORTANT: ALL REPAIRS OR MAINTENANCE ON TRIBUTE HYBRID VEHICLES MUST BE SUBLET TO A FORD CERTIFIED HYBRID DEALER.

TRIBUTE HYBRID VEHICLE INFORMATION For easy identiﬁcation all hybrid vehicles will be equipped with the following: “Hybrid” nameplate “Green Leaf Globe” badge on tailgate. “Green Leaf Globe” badge on both front fenders. Unique left rear quarter glass with traction battery air intake (2008-2009 MY only). MAZDA BADGE REMOVED FROM LIFTGATE (starting 2010 MY).

TRIBUTE HYBRID WARRANTY REPAIR INFORMATION ALL WARRANTY REPAIRS ON TRIBUTE HYBRID VEHICLES MUST BE SUBLET TO A FORD CERTIFIED HYBRID DEALER. INSIDE THE UNITED STATES Any Hybrid vehicle requiring warranty repairs: The vehicle must be taken to the nearest Ford Certified Hybrid dealer. After determining the nearest Ford Certified Hybrid dealer, the Mazda dealer can assist with arranging transport of vehicle to (and from) that dealer. Mazda will reimburse the dealer for the covered warranty repairs from the Ford Certified Hybrid dealer. Any other charges including towing and rental vehicles must be approved prior to repair. NOTE: Since the Tribute warranty is through Mazda and not Ford, when a Tribute Hybrid vehicle is being taken to a Ford Certified Hybrid dealer for repair, the Mazda dealer will need to contact the Ford dealer to receive permission to bring the vehicle in for repair, schedule an appointment time and make arrangements for payment of the repairs. Mazda will reimburse the Mazda dealer for the repair charges as outlined in the Mazda Warranty Polices & Procedures Manual Policy 3.41, (Hybrid Vehicle Unique Component Warranty). OUTSIDE THE UNITED STATES NOTE: Hybrid customers who travel with their vehicle outside the United States should be advised of the following information in case vehicle repair becomes necessary at that time. IN CANADA: The vehicle must be taken to the nearest “Ford Certified Hybrid dealer”. After determining the nearest “Ford Certified Hybrid dealer”, the Mazda dealer in Canada can contact the CEC to assist with arranging transport of vehicle to (and from) that dealer. Mazda will reimburse the dealer for the covered warranty repairs from the “Ford Certified Hybrid dealer”. Any other charges including towing and rental vehicles must be approved prior to repair. NOTE: Since the Tribute warranty is through Mazda and not Ford, when a Tribute Hybrid vehicle is being taken to a “Ford Certified Hybrid dealer” for repair, the Mazda dealer will need to contact the Ford dealer to receive permission to bring the vehicle in for repair, schedule an appointment time and make arrangements for payment of the repairs. Mazda will reimburse the Mazda dealer for the repair charges as outlined in the Mazda Warranty Polices & Procedures Manual Policy 3.41, (Hybrid Vehicle Unique Component Warranty).

IN MEXICO: Should warranty repair become necessary while the vehicle is in Mexico, the hybrid customer will be responsible to return the vehicle back into the U.S. to the nearest Mazda dealer. WARRANTY ASSISTANCE FOR TRIBUTE HYBRID VEHICLES NOTE: This Service Bulletin is for information purposes only. No parts or warranty claim information is included.

00-001/08 - SPECIAL TOOL SHIPMENT - FEBRUARY 2008 SI108507 TSB NUMBER: 00-001/08 For Internal Mazda Corporate Use Only DESCRIPTION APPLICABLE MODEL(S)/VINS 1998-2008 B-Series 1998-2003 Protege 2002-2003 Protege5 2003 Protegespeed 1998-2005 Miata 2004-2005 Mazdaspeed MX-5/Miata 1998-2002 626 1998-2002 Millenia 1998-2006 MPV 2001-2006 Tribute 2008 Tribute 2008 Tribute Hybrid 2003-2008 Mazda6 2006-2007 Mazdaspeed6 2004-2008 Mazda3 2007-2008 Mazdaspeed3 2004-2008 RX-8 2006-2008 Mazda5 2006-2008 MX-5 2007-2008 CX-7 2007-2008 CX-9

DESCRIPTION Mazda will ship to all dealers one (1) laminated application chart for Evaporative Emissions Fuel Filler Neck and Fuel Caps. This application chart will be shipped to your dealers during February 2008. PRICING Part Number Description Pricing 9999-SST-EVAPCHARTApplication Chart - Evaporative Emissions Fuel Filler Neck and Fuel CapsNo charge BILLING INFORMATION No charge for the laminated application chart. SHIPPING INFORMATION Laminated application chart will be sent via US mail. OBTAINING ADDITIONAL TOOLS You can download additional copies through MGSS under Service Tools. SPECIAL SERVICE TOOL (SST) AND USAGE PART NUMBER/NAME: 9999-SST-EVAPCHART Application Chart - Evaporative Emissions Fuel Filler Neck and Fuel Cap APPLICABLE MODELS: MULTI-MODEL 1998 to 2008. USAGE: To show model applications for the evaporative fuel ﬁller neck and fuel cap. Secure the laminated application chart to the current MRT/Evaporative Emissions Tester (134-01049). OVERVIEW USAGE

00-005/07 - SPECIAL SERVICE TOOL SHIPMENT - OCTOBER 2007 SI108531 TSB NUMBER: 00-005/07 For Internal Mazda Corporate Use Only DESCRIPTION APPLICABLE MODEL(S)/VINS 2002-2006 MPV 2004-2008 Mazda3 2003-2008 Mazda6 2006-2008 MX-5 2005-2006 & 2008 Tribute 2000-2008 B-Series Truck DESCRIPTION / PRICING In support of current models, Mazda will ship to all dealers one (1) new Special Service Tool (SST). The SST will be shipped automatically by Mazda’s tool vendor, America Kowa Seiki (AKS) during October 2007. The following SST is the latest addition to the Mazda Required Tool (MRT) list: AKS95952 Oil Filter Wrench Set $26.58 BILLING INFORMATION Tool(s) will be automatically invoiced to your dealer parts account statement. Do not send your payment to America Kowa Seiki. SHIPPING INFORMATION Tool(s) will be shipped via UPS ground to your service department October 2007. Please advise your shipping/receiving personnel of this tool shipment. OBTAINING ADDITIONAL TOOLS To order additional SSTs, submit orders using Mazda Tool and Equipment website. You can logon to Mazda Tool and Equipment website at: http://dealers.mazdausa.com CUSTOMER SERVICE INFORMATION For warranty or product information call America Kowa Seiki (AKS) at 877-768-6657. Customer service representatives are available from 7:30 AM until 7:00 PM CST, Monday through Friday. SPECIAL SERVICE TOOL (SST) & USAGE

PART NUMBER: Oil Filter Wrench Set AKS95952 (Set of 2) NAME: Oil Filter Wrench AKS73150 (75mm x 15 ﬂutes) (1 of 2) APPLICAB LE MODELS: 2005-06 & 08 Tribute (2.3L) 2004-08 Mazda3 (2.0L) 2006-08 MX-5 (2.0L) 2000-08 B-Series Truck (2.3L) USAGE: For use with Mazda oil ﬁlters. OVERVIEW: USAGE:

PART NUMBER: AKS95952 (Set of 2) NAME: Oil Filter Wrench AKS93360 (93mm x 36 ﬂutes) (2 of 2) APPLICAB LE MODELS: 2005-06 & 08 Tribute (3.0L) 2002-06 MPV (3.0L) 2003-08 Mazda6 (3.0L) 2000-08 B-Series Truck (3.0L) USAGE: For use with Mazda oil ﬁlters. OVERVIEW: USAGE: OIL FILTER WRENCH APPLICATION CHART
