00-005/07 - SPECIAL SERVICE TOOL SHIPMENT - OCTOBER 2007
SI108531
TSB NUMBER: 00-005/07
For Internal Mazda Corporate Use Only
DESCRIPTION
APPLICABLE MODEL(S)/VINS
2002-2006 MPV
2004-2008 Mazda3
2003-2008 Mazda6
2006-2008 MX-5
2005-2006 & 2008 Tribute
2000-2008 B-Series Truck
DESCRIPTION / PRICING
In support of current models, Mazda will ship to all dealers one (1) new Special Service Tool (SST). The SST will be shipped automatically
by Mazda’s tool vendor, America Kowa Seiki (AKS) during October 2007.
The following SST is the latest addition to the Mazda Required Tool (MRT) list:
AKS95952 Oil Filter Wrench Set $26.58
BILLING INFORMATION
Tool(s) will be automatically invoiced to your dealer parts account statement. Do not send your payment to America Kowa Seiki.
SHIPPING INFORMATION
Tool(s) will be shipped via UPS ground to your service department October 2007. Please advise your shipping/receiving personnel of this
tool shipment.
OBTAINING ADDITIONAL TOOLS
To order additional SSTs, submit orders using Mazda Tool and Equipment website. You can logon to Mazda Tool and Equipment website at:
http://dealers.mazdausa.com
CUSTOMER SERVICE INFORMATION
For warranty or product information call America Kowa Seiki (AKS) at 877-768-6657. Customer service representatives are available
from 7:30 AM until 7:00 PM CST, Monday through Friday.
SPECIAL SERVICE TOOL (SST) & USAGE
PART
NUMBER:
Oil Filter
Wrench
Set
AKS95952
(Set of 2)
NAME:
Oil Filter
Wrench
AKS73150
(75mm x
15 flutes)
(1 of 2)
APPLICAB
LE
MODELS:
2005-06 &
08 Tribute
(2.3L)
2004-08
Mazda3
(2.0L)
2006-08
MX-5
(2.0L)
2000-08
B-Series
Truck
(2.3L)
USAGE:
OVERVIEW: USAGE:
For use
with Mazda
oil filters.
PART
NUMBER:
AKS95952
(Set of 2)
NAME:
Oil Filter
Wrench
AKS93360
(93mm x
36 flutes)
(2 of 2)
APPLICAB
LE
MODELS:
2005-06 &
08 Tribute
(3.0L)
2002-06
MPV
(3.0L)
2003-08
Mazda6
(3.0L)
2000-08
B-Series
Truck
(3.0L)
USAGE:
For use
with Mazda
oil filters.
OVERVIEW:
USAGE:
OIL FILTER WRENCH APPLICATION CHART
MODEL YEAR APPLICABLE MODEL OIL FILTER WRENCH (TOOL NUMBER)
2001-2004 Tribute 2.0L & 3.0L AKS76300
2005-2006 & 2008 Tribute 2.3L AKS73150
2005-2006 & 2008 Tribute 3.0L AKS93360
2008 Tribute Hybrid 2.3L AKS76140
2002-2006 MPV AKS93360
2003-2008 Mazda6 2.3L AKS76140
2003-2008 Mazda6 3.0L AKS93360
2006-2007 Mazdaspeed6 AKS76140
2004-2008 Mazda3 2.0L AKS73150
2004-2008 Mazda3 2.3L AKS76140
2007-2008 Mazdaspeed3 AKS76140
2006-2008 Mazda5 AKS76140
2004-2008 RX-8 AKS65140
2007-2008 CX-7 AKS76140
2007-2008 CX-9 AKS76300
1999-2005 Miata AKS65140
2006-2008 MX-5 AKS73150
2004-2005 Mazdaspeed MX-5 AKS65140
2000-2008 B-Series Truck
AKS76300
AKS73150
AKS93360
00-001/08 - SPECIAL TOOL SHIPMENT - FEBRUARY 2008
SI108507
TSB NUMBER: 00-001/08
For Internal Mazda Corporate Use Only
DESCRIPTION
APPLICABLE MODEL(S)/VINS
1998-2008 B-Series
1998-2003 Protege
2002-2003 Protege5
2003 Protegespeed
1998-2005 Miata
2004-2005 Mazdaspeed MX-5/Miata
1998-2002 626
1998-2002 Millenia
1998-2006 MPV
2001-2006 Tribute
2008 Tribute
2008 Tribute Hybrid
2003-2008 Mazda6
2006-2007 Mazdaspeed6
2004-2008 Mazda3
2007-2008 Mazdaspeed3
2004-2008 RX-8
2006-2008 Mazda5
2006-2008 MX-5
2007-2008 CX-7
2007-2008 CX-9
DESCRIPTION
Mazda will ship to all dealers one (1) laminated application chart for Evaporative Emissions Fuel Filler Neck and Fuel Caps. This application
chart will be shipped to your dealers during February 2008.
PRICING
Part Number Description Pricing
9999-SST-EVAPCHARTApplication Chart - Evaporative Emissions Fuel Filler Neck and Fuel CapsNo charge
BILLING INFORMATION
No charge for the laminated application chart.
SHIPPING INFORMATION
Laminated application chart will be sent via US mail.
OBTAINING ADDITIONAL TOOLS
You can download additional copies through MGSS under Service Tools.
SPECIAL SERVICE TOOL (SST) AND USAGE
PART NUMBER/NAME:
9999-SST-EVAPCHART Application
Chart - Evaporative Emissions Fuel Filler
Neck and Fuel Cap
APPLICABLE MODELS:
MULTI-MODEL 1998 to 2008.
USAGE:
To show model applications for the
evaporative fuel filler neck and fuel
cap. Secure the laminated application
chart to the current MRT/Evaporative
Emissions Tester (134-01049).
OVERVIEW USAGE
00-001/05 - MULT. MODELS - WDS PTU BATTERY WARRANTY AND ORDER
INFORMATION
SI108504
TSB NUMBER: 00-001/05
For Internal Mazda Corporate Use Only
DESCRIPTION
APPLICABLE MODEL(S)/VINS
1997-2003 Protege
2002-2003 Protege5
1997-2005 Miata
1997-2002 626
1995-2002 Millenia
1997-1998 MPV
2000-2005 MPV
2004-2005 Mazda3
2004-2005 RX-8
2003-2005 Mazda6
2001-2005 Tribute
1995-2005 B-Series Truck
DESCRIPTION
Mazda Worldwide Diagnostic System (WDS) PTU batteries are not covered by the system’s 1-year extension agreement. WDS support
information was communicated in the “WDS Support Extension Program” documentation sent to all dealers as part of the 1-year
extension agreement. The WDS PTU batteries are considered a consumable item and most have been in use for several years. WDS PTU
batteries are available for purchase on Mazda Tool and Equipment website.
PARTS INFORMATION
Part Number Description Qty. Notes
418-F402 WDS PTU Battery Pack 1 Available on Mazda Tool and Equipment website
NOTE: Replacement batteries carry a 13 month warranty.
