2007 Lincoln Navigator Service & Repair Manual

Identification Codes Printable View (623 KB) Vehicle Identification Number (VIN) Vehicle Identification Number (VIN) Locator The vehicle identification number (VIN) is a 17-digit combination of letters and numbers. The VIN is stamped on a metal tab riveted to the instrument panel, top upper left of the dash. The VIN number is also found on the vehicle certification (VC) label. SECTION 100-01: Identification Codes 2007 Expedition/Navigator Workshop Manual DESCRIPTION AND OPERATION Procedure revision date: 08/10/2006 Item Description 1 World manufacturer identifier (WMI) 2 Brake type and gross vehicle weight rating (GVWR) 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

World Manufacturer Identifier (WMI) The first 3 vehicle identification number (VIN) positions are the world manufacturer identifier. 1FM — Ford Motor Company, USA, multi-purpose vehicle 5LM — Lincoln, USA, multi-purpose vehicle 5L1 — Lincoln, USA, multi-purpose vehicle (limousine) Brake Type and Gross Vehicle Weight Rating (GVWR) The fourth VIN position is the vehicles brake type and gross vehicle weight rating (GVWR) code. All vehicles use hydraulic brakes. F — 7,001-8,000 pounds GVWR with driver and front passenger air bags and driver and front passenger side impact air curtains P — 7,001-8,000 pounds GVWR with driver and front passenger air bags Vehicle Line and Series 3 Vehicle line and series 4 Engine type 5 Computer-generated check digit 6 Model year 7 Assembly plant 8 Production sequence number 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

Positions 5 through 7 indicate vehicle line and series. K15 — Expedition EL, 4x2, XLT K16 — Expedition EL, 4x4, XLT K17 — Expedition EL, 4x2, Eddie Bauer K18 — Expedition EL, 4x4, Eddie Bauer K19 — Expedition EL, 4x2, Limited K20 — Expedition EL, 4x4, Limited U15 — Expedition, 4x2, XLT U16 — Expedition, 4x4, XLT U17 — Expedition, 4x2, Eddie Bauer U18 — Expedition, 4x4, Eddie Bauer U19 — Expedition, 4x2, Limited U20 — Expedition, 4x4, Limited U27 — Navigator, 4x2 U28 — Navigator, 4x4 Engine Type The eighth VIN position is the engine displacement and number of cylinders. 5 — 5.4L, SOHC, EFI, 3V, V-8, gas Computer-Generated Check Digit 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

The ninth VIN position is a government-assigned, computer-generated check digit. Model Year The tenth VIN position is the model year code. 7 — 2007 Assembly Plant The eleventh VIN position is the assembly plant code. • L — Michigan Truck (Wayne, Michigan) Vehicle Build Sequence 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

The last 6 VIN positions are an alphanumeric code for the vehicle build sequence. This is also the vehicle serial and warranty number. A00001-F99999 — Ford Division J00001-L99999 — Lincoln Division Vehicle Certification (VC) Label Vehicle Certification (VC) Label Locator The vehicle certification (VC) label contains the manufacturer name, the month and year of manufacture, the certification statement and the VIN. It also includes gross vehicle weight ratings (GVWR). 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

Exterior Paint Code Item Description 1 Exterior paint code 2 Region code 3 Domestic special order code 4 Wheelbase code 5 Interior trim code 6 Tape/paint pinstripe code 7 Radio code 8 Axle code 9 Transmission code 10 Spring code 11 Powertrain calibration information 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

Paint codes may be listed as a 2-part code. The first set of characters listed indicate the vehicle primary body color. The second set of characters listed (if applicable) indicate a 2-tone or accent body color. All colors are base coat/clear coat. DX — Dark Blue Pearl G2 — Redfire G3 — Pueblo Gold G5 — Alloy Gray JP — Silver Birch Metallic PG — Dark Amethyst PV — White Chocolate (tri-coat) T5 — Dark Copper UA — Ebony YZ — Oxford White Wheelbase 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

119 — 119 inch (3,023 mm) wheelbase 131 — 131 inch (3,327 mm) wheelbase Interior Trim Interior trim codes are listed as a 2-part code. The first character identifies the trim type. The second character identifies the interior trim color. Trim Type 1 — Verona leather, 40/40 captain's chairs — Expedition 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...

2 — Verona leather, 40/40 captain's chairs — Expedition 3 — Verona leather, 40/40 captain's chairs with accent — Expedition F — Beck cloth captain's chairs — Expedition M — Adobe/Beck cloth, 40/60 split bench seat — Expedition T — Premium/Soho leather, 40/40 captain's chairs — Navigator Interior Trim Color C — Camel Tan L — Medium Light Stone W — Charcoal Black Tape/Paint Stripe Tape and paint stripe codes do not apply. Radio Type 24.09.2002 file://C:\TSO\tsocache\SUPER10-45B629E_1148\S7J~us~en~file=S7J01001.htm~ge...
