2012-2016 Range Rover Evoque 2.2L TD4 & 2.0L GTdi Service & Repair Manual

Published: 11-May-2011 General Information - Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions Description and Operation WARNINGS: Fuel may not give adequate warning before toxic or harmful effects arise. Exposure to fuel can be harmful and can cause severe health damage or death. Extreme care must be exercised when handling hot fluids. Always wash off spilled fluids from affected areas of skin immediately. Highly flammable mixtures are always present and may ignite when working on fuel systems. Do not allow naked flames, sparks or lighted substances to come near fuel related components. Fuel must not be used as a cleaning agent. Keep fuel containers tightly closed, out of direct sunlight and in a cool area. Keep away from heat sources, ignition sources and oxidizing agents. SKIN CONTACT: Excessive or prolonged skin contact with diesel fuel may cause serious skin disorders including skin cancer. SKIN CONTACT: Fuel is mildly irritating to the skin and may cause dermatitis due to defatting effect. Remove contaminated clothing. Wash affected areas of skin with soap and water. Seek medical attention for any persistent skin irritation or abnormality. Wash contaminated clothing before reuse. EYE CONTACT: Fuel is mildly irritating to the eyes. Flush with plenty of running water, blinking as often as possible. Do not force the eyelid open. Seek medical attention for any persistent eye irritation or abnormality. SWALLOWED: Fuel is moderately toxic and tends to foam on vomiting. If drawn into the lungs, inflammation may develop. Do not induce vomiting. If spontaneous vomiting occurs place the victim in a forward position to reduce the risk of fuel being drawn into the lungs. Give nothing by mouth. If breathing but unconscious, place in the recovery position. If breathing has stopped, apply artificial respiration. Seek immediate medical attention. INHALED: Fuel is toxic to the respiratory and other body systems. Exposure may result in various symptoms including drowsiness, unconsciousness or severe health damage. Move a victim to fresh air. Keep a victim warm and at rest. If unconscious, place in the recovery position. If not breathing, apply artificial respiration. Give cardiac massage if necessary. Seek immediate medical attention. CAUTIONS: Fuel injection equipment is manufactured to very precise tolerances and fine clearances. It is essential that absolute cleanliness is observed when working with these components. Make sure that the workshop area in which the vehicle is being worked on is as clean and as dust free as possible.

Published: 15-May-2013 General Information - Supplemental Restraint System (SRS) Health and Safety Precautions Description and Operation WARNINGS: Only qualified technicians are allowed to work on pyrotechnic components. INHALED: Exposure to pyrotechnic residue may cause low blood pressure, severe headache, irritation of mucous membranes, fainting, shortness of breath or rapid pulse. Move a victim to fresh air. Seek immediate medical attention. EYE CONTACT: Exposure to unburned pyrotechnic residue may cause irritation, burning and etching of the eyes. Flush immediately with plenty of cold running water for at least 15 minutes. Seek immediate medical attention. EYE CONTACT: Exposure to burned pyrotechnic residue may cause irritation, burning and etching of the eyes. Flush immediately with diluted boric acid solution. Seek immediate medical attention. SKIN CONTACT: Unburned pyrotechnic residue may be rapidly absorbed through the skin in toxic quantities. Wash immediately with plenty of soap and water. Seek medical attention. SKIN CONTACT: Burned pyrotechnic residue may be rapidly absorbed through the skin in toxic quantities. Wash with plenty of water. Do not use soap. Seek medical attention. SWALLOWED: Unburned pyrotechnic residue is extremely toxic. If conscious drink plenty of water then induce vomiting. Seek immediate medical attention. If unconscious, or in convulsions do not attempt to induce vomiting or give anything by mouth. Seek immediate medical attention. SWALLOWED: Burned pyrotechnic residue is extremely toxic. Drink plenty of water and seek immediate medical attention. The deployment key must only be accessible to authorized personnel. Make sure that the deployment key remains removed from the deployment equipment except during deployment. If permenantly disabling or enabling the passenger air bag a new seat belt for vehicles without or with a passenger air bag must be installed. Undeployed pyrotechnic components must not be deployed in the vehicle. Pyrotechnic components must be deployed following local regulations. Check thoroughly that no loose objects can be spread during the deployment of pyrotechnic components. Pyrotechnic components must be transported following local regulations. Never carry out any electrical measurement on disconnected, undeployed pyrotechnic components. Pyrotechnic components must not be disassembled. Pyrotechnic components are not interchangeable between vehicles. Always carry a live air bag module away from the body with the air bag or trim cover pointing upwards. Live air bag modules must be placed in a suitable cage when removed from the vehicle. The air bag or trim cover must be facing upwards.

Do not install a rearward facing child safety seat to the passenger seat with an activated passenger air bag. CAUTIONS: Pyrotechnic components must not be subjected to temperatures higher than 110°C. Never install aftermarket accessories to the vehicle on or adjacent to the supplemental restraint system module.

Published: 20-Jun-2011 General Information - Diagnostic Trouble Code (DTC) Index DTC: Audio Amplifier Module (AAM) Description and Operation Audio Amplifier Module (AAM) CAUTION: Diagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not guarantee confirmation of a fault, and may also cause additional faults in the vehicle being tested and/or the donor vehicle NOTES: If the control module or a component is suspect and the vehicle remains under manufacturer warranty, refer to the warranty policy and procedures manual (section B1.2), or determine if any prior approval programme is in operation, prior to the installation of a new module/component. Generic scan tools may not read the codes listed, or may read only 5-digit codes. Match the 5 digits from the scan tool to the first 5 digits of the 7-digit code listed to identify the fault (the last 2 digits give extra information read by the manufacturer-approved diagnostic system) When performing voltage or resistance tests, always use a digital multimeter accurate to three decimal places and with a current calibration certificate. When testing resistance, always take the resistance of the digital multimeter leads into account Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests Inspect connectors for signs of water ingress, and pins for damage and/or corrosion If diagnostic trouble codes are recorded and, after performing the pinpoint tests, a fault is not present, an intermittent concern may be the cause. Always check for loose connections and corroded terminals Where an 'on demand self-test' is referred to, this can be accessed via the 'diagnostic trouble code monitor' tab on the manufacturers approved diagnostic system The table below lists all Diagnostic Trouble Codes (DTCs) that could be logged in the Audio Amplifier Module, for additional Diagnosis and Testing information refer to the relevant Diagnosis and Testing Section. For additional information, refer to: Information and Entertainment System (415-01 Information and Entertainment System, Diagnosis and Testing). DTC Description Possible Cause Action B128A-11 Speaker #13 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left co-axial surround speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128A-12 Speaker #13 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left co-axial surround speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128A-13 Speaker #13 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left co-axial surround speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128A-1ASpeaker #13 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left co-axial surround speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128A-1E Speaker #13 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left co-axial surround speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect

DTC Description Possible Cause Action B128B-11 Speaker #14 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right co-axial surround speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128B-12 Speaker #14 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right co-axial surround speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128B-13 Speaker #14 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right co-axial surround speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128B-1ASpeaker #14 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right co-axial surround speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128B-1E Speaker #14 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right co-axial surround speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128C-11 Speaker #15 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check front center speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128C-12 Speaker #15 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check front center speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128C-13 Speaker #15 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check front center speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128C-1ASpeaker #15 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check front center speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B128C-1E Speaker #15 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check front center speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A01-11 Speaker #1 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check left front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for short to ground. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A01-12 Speaker #1 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check left front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for short to power. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A01-13 Speaker #1 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check left front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for open circuit. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component

DTC Description Possible Cause Action is suspect B1A01-1ASpeaker #1 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check left front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for short circuit. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A01-1E Speaker #1 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check left front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for open circuit, high resistance or short circuit. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A02-11 Speaker #2 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front bass speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A02-12 Speaker #2 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front bass speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A02-13 Speaker #2 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front bass speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A02-1ASpeaker #2 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front bass speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A02-1E Speaker #2 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front bass speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A03-11 Speaker #3 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check right front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for short to ground. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A03-12 Speaker #3 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check right front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for short to power. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A03-13 Speaker #3 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check right front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for open circuit. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A03-1ASpeaker #3 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check right front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for short circuit. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect

DTC Description Possible Cause Action B1A03-1E Speaker #3 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, on a premium & high line system check right front tweeter circuits, on a low line system check mid range speaker and tweeter circuits for open circuit, high resistance or short circuit. Check speaker for short circuit, open circuit. if no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A04-11 Speaker #4 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front bass speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A04-12 Speaker #4 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front bass speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A04-13 Speaker #4 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front bass speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A04-1ASpeaker #4 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front bass speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A04-1E Speaker #4 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front bass speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A05-11 Speaker #5 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear tweeter speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A05-12 Speaker #5 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear tweeter speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A05-13 Speaker #5 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear tweeter speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A05-1ASpeaker #5 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear tweeter speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A05-1E Speaker #5 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear tweeter speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A06-11 Speaker #6 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear bass speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A06-12 Speaker #6 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear bass speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect

DTC Description Possible Cause Action B1A06-13 Speaker #6 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear bass speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A06-1ASpeaker #6 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear bass speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A06-1E Speaker #6 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left rear bass speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A07-11 Speaker #7 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear tweeter speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A07-12 Speaker #7 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear tweeter speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A07-13 Speaker #7 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear tweeter speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A07-1ASpeaker #7 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear tweeter speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A07-1E Speaker #7 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear tweeter speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A08-11 Speaker #8 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear bass speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A08-12 Speaker #8 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear bass speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A08-13 Speaker #8 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear bass speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A08-1ASpeaker #8 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear bass speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A08-1E Speaker #8 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right rear bass speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect

DTC Description Possible Cause Action B1A09-11 Speaker #9 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front mid range speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A09-12 Speaker #9 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front mid range speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A09-13 Speaker #9 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front mid range speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A09-1ASpeaker #9 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front mid range speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A09-1E Speaker #9 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left front mid range speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A10-11 Speaker #10 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front mid range speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A10-12 Speaker #10 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front mid range speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A10-13 Speaker #10 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front mid range speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A10-1ASpeaker #10 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front mid range speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A10-1E Speaker #10 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right front mid range speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A11-11 Speaker #11 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left sub-woofer speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A11-12 Speaker #11 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left sub-woofer speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A11-13 Speaker #11 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left sub-woofer speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect

DTC Description Possible Cause Action B1A11-1ASpeaker #11 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left sub-woofer speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A11-1E Speaker #11 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check left sub-woofer speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A12-11 Speaker #12 - circuit short to ground Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right sub-woofer speaker circuits for short to ground. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A12-12 Speaker #12 - circuit short to battery Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right sub-woofer speaker circuits for short to power. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A12-13 Speaker #12 - circuit open Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right sub-woofer speaker circuits for open circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A12-1ASpeaker #12 - circuit resistance below threshold Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right sub-woofer speaker circuits for short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1A12-1E Speaker #12 - circuit resistance out of range Wiring harness fault Speaker fault Audio amplifier fault Refer to electrical circuit diagrams, check right sub-woofer speaker circuits for open circuit, high resistance, or short circuit. Check speaker for short circuit, open circuit. If no harness or speaker fault suspect audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1297-01 Digital Headphone Module - General Electrical Failure Wiring harness fault Infra-red headphone transmitter module fault Audio amplifier fault NOTE: Applies to vehicles with Digital wireless headphones installed only Refer to electrical circuit diagrams and check data signal circuits between the audio amplifier and the infra-red transmitter module for short circuit. Confirm power and ground supplies are present at the module. Repair wiring harness as required. Clear DTC and retest system. If fault resets suspect (1) infra-red transmitter module, (2) audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect B1297-13 Digital Headphone Module - circuit open Wiring harness fault Infra-red headphone transmitter module fault Audio amplifier fault NOTE: Applies to vehicles with Digital wireless headphones installed only Refer to electrical circuit diagrams and check data signal circuits between the audio amplifier and the infra-red transmitter module for open circuit. Confirm power and ground supplies are present at the module. Repair wiring harness as required. Clear DTC and retest system. If fault resets suspect (1) infra-red transmitter module, (2) audio amplifier module. Refer to the Warranty Policy and Procedures manual if a module/component is suspect U2300-54 Central Configuration - missing calibration Configuration missing Check/amend the car configuration file using the manufacturer approved diagnostic system U2300-56 Central Configuration - invalid / incomplete configuration Vehicle configuration file error Check the vehicle is configured correctly using the manufacturer approved diagnostic system
