Land Rover North America, Inc. Land Rover Canada SERVICE BULLETIN CIRCULATION: Bulletin: SWA05-03 Dealer Principal Sales Guide Section: Warranty Centre Manager X Parts Professional Date: 09 February 2005 Sales Manager Warranty Admin X Model: LR3 Business Manager Service Advisor X Parts Manager Technician X Applicable to: USA/CDA Service Manager X Page: 1 of 5 Attachment Maintenance Table Issued by: Land Rover North America, Inc., 555 MacArthur Blvd, Mahwah, NJ 07430 Land Rover Canada, 8 Indell Lane, Bramalea ON, L6T 4H3 Subject: LR3 Complimentary Scheduled Maintenance Land Rover is pleased to announce the Complimentary Scheduled Maintenance Program for all 2005 Model Year LR3 vehicles. The maintenance program applies to eligible vehicles during the New Vehicle Limited Warranty period only and is fully transferable. This program lowers the cost of ownership for LR3 customers and increases service retention for Retailers. Maintenance Schedule check lists containing details of the items included in the Complimentary Scheduled Maintenance Program can be found in the 2005MY Passport to Service booklet or on InfoTrail. Normal wear items and service adjustments are not covered by the Land Rover New Vehicle Warranty nor are they covered within the maintenance program. These limitations are identified in the 2005MY Passport to Service booklet. The reimbursement information, program codes and option codes, are contained in the attached tables for the United States and Canada. • Parts required to complete the services will be reimbursed at Land Rover suggested retail prices. • The maintenance parts are not subject to additional handling charges. • Labor will be reimbursed at your Warranty Labor Rate. • Labor operation numbers and times are shown on the attached table along with allowances for engine oil, hazardous waste removal and miscellaneous fluids. NOTE: Each service requires the replacement of the engine oil drain plug washer, part number 1005593. Currently, this part is not available as a separate part. Until the washer becomes available, Land Rover will reimburse for the replacement of the engine oil drain plug assembly (1013938) which includes the washer. When part number 1005593 becomes available, Land Rover will publish an ALERT advising the date on which the reimbursement schedule will change to the washer only, in stead of the drain plug assembly.

of 5 SWA0503.doc 2005 LR3 Free Scheduled Maintenance - USA - OPTION G L111 First Service LR3 ( 7,500 miles) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.67 0.5 1 Drain Plug 1013938 Miscellaneous Expense $ 34.00 * L112 Second Service LR3 (15,000 miles) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.15 1.5 1 Drain Plug 1013938 1 Pollen Filter JKR500020 Miscellaneous Expense $ 34.00 * L113 Third Service LR3 (22,500 miles) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.67 0.5 1 Drain Plug 1013938 Miscellaneous Expense $ 34.00 * L114 Fourth Service LR3 ( 30,000 miles) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.30 2.1 1 Drain Plug Washer 1005593 1 Pollen Filter JKR500020 Miscellaneous Expense $ 34.00 * L115 Fifth Service LR3 ( 37,500 miles) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.22 0.5 1 Drain Plug Washer 1005593 Miscellaneous Expense $ 34.00 *

of 5 SWA0503.doc L116 Sixth Service LR3 ( 45,000 miles) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.48 1.7 1 Drain Plug Washer 1005593 1 Pollen Filter JKR500020 Miscellaneous Expense $ 53.71 * * Definition of Misc Expense Amounts * L111 - L115 Amount Misc Fluids $ 5.00 Hazardous Waste Removal $ 5.00 Engine Oil - 8 Qts. $ 24.00 Total $ 34.00 * * L116 Amount Misc Fluids $ 5.00 Hazardous Waste Removal $ 5.00 Engine Oil - 8 Qts. $ 24.00 Brake Fluid - 3 $ 19.71 Total $ 53.71

of 5 SWA0503.doc NOTE: All dollar amounts are shown with the exchange rate US $ * 1.482 = CND $ Miles must be changed to Km 2005 LR3 Free Scheduled Maintenance - Canada - OPTION H L111 First Service LR3 ( 7,500 miles - 12,000 Km) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.67 0.5 1 Drain Plug 1013938 Miscellaneous Expense $ 50.39 * L112 Second Service LR3 (15,000 miles - 24,000 Km) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.15 1.5 1 Drain Plug 1013938 1 Pollen Filter JKR500020 Miscellaneous Expense $ 50.39 * L113 Third Service LR3 (22,500 miles - 36,000 Km) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.67 0.5 1 Drain Plug 1013938 Miscellaneous Expense $ 50.39 * L114 Fourth Service LR3 ( 30,000 miles - 48,000 Km) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.30 2.1 1 Drain Plug Washer 1005593 1 Pollen Filter JKR500020 Miscellaneous Expense $ 50.39 *

of 5 SWA0503.doc L115 Fifth Service LR3 ( 37,500 miles - 60,000 Km) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.22 0.5 1 Drain Plug Washer 1005593 Miscellaneous Expense $ 50.39 * L116 Sixth Service LR3 ( 45,000 miles - 72,000 Km) Quantity Part Part Number SRO Time 1 Oil Filter V8 4508334 03.10.48 1.7 1 Drain Plug Washer 1005593 1 Pollen Filter JKR500020 Miscellaneous Expense $ 79.60 * * Definition of Misc Expense Amounts * L111 - L115 Amount US $ Amount CND $ Misc Fluids $ 5.00 $ 7.41 Hazardous Waste Removal $ 5.00 $ 7.41 Engine Oil - 8 Qts. $ 24.00 $ 35.57 Total $ 34.00 $ 50.39 * * L116 Amount US $ Amount CND $ Misc Fluids $ 5.00 $ 7.41 Hazardous Waste Removal $ 5.00 $ 7.41 Engine Oil - 8 Qts. $ 24.00 $ 35.57 Brake Fluid - 3 $ 19.71 $ 29.21 Total $ 53.71 $ 79.60
