OPTIMA(TF/QF) > 2013 > G 2.0 T-GDI > General Information General Information > General Information > General Information Identification Number Locations Identification Number Description Vehicle Identification Number

1. World Manufacturer Identifier (WMI) - KNA (Korea) : Passenger vehicle, MPV(Multipurpose Passenger Vehicle)/SUV(Sports Utility Vehicle)/RV(Recreational Vehicle) - 5XX (U.S.A) : Passenger vehicle 2. Vehicle line - G : OPTIMA 3. Model & Series - L : Low grade (L) - M : Middle-Low grade (GL) - N : Middle grade (GLS, JSL, TAX) - P : Middle-High grade (HGS) - R : High grade (TOP) 4. Body/Cabin type, Gross Vehicle Weight Rating - 1 : Limousine - 2 : Sedan - 2 door - 3 : Sedan - 3 door - 4 : Sedan - 4 door - 5 : Sedan - 5 door - 6 : Coupe - 7 : Convertible - 8 : Wagon - 9 : Commercial Van - 0 : Pick-Up 5. Restraint system, Brake system Code Seat belt Front air bag Knee air bag Side air bag Curtain air bag Driver's Passenger's Driver's Passenger's 1st row 2nd row 3rd row 1st row 2nd row 3rd row A ○ ○ ○ × × ○ × × ○ ○ × B ○ ○ ○ × × × × × × × × C ○ ○ ○ × × ○ × × ○ ○ ○ D ○ ○ ○ × × ○ ○ × ○ ○ × E ○ ○ × × × × × × × × × F ○ ○ ○ × × ○ × × × × × N ○ × × × × × × × × × × H ○ ○ ○ ○ × ○ × × ○ ○ ○ 6. Engine type - 6 : Gasoline engine 2.0 (Theta-II T-GDI) - 7 : Gasoline engine 2.4 (Theta-II GDI) 7. Check digit or Driver’s side & Transmission - Check digit : 0 ~ 9, × tomsn048@gmail.com

8. Model year - B : 2011, C : 2012, D : 2013, E : 2014 … 9. Plant of production - 5 : Hwasung (Korea) - G : Georgia (U.S.A) 10. Vehicle production sequence number - 000001 ~ 999999 Paint Code TF Code Color SWP Snow White Pearl 3D Bright Silver ABP Aurora Black ABT Platinum Graphite STM Satin Metal IR Dark Cherry K3R Temptation Red LC Light Graphite K3U Abyss Blue K3N Golden Beat QF Code Color SWP Snow White Pearl 3D Bright Silver EB Ebony Black IM Titanium Silver STM Satin Metal IR Dark Cherry IY Spicy Red HO Santorini Blue DO Metal Bronze Engine Number 1. Engine fuel - G : Gasoline

2. Engine range - 4 : 4 cycle 4 cylinder 3. Engine development order and capacity - K : Theta engine (Gasoline) 4. Engine Capacity - H : 1998cc (T-GDI) - J : 2359cc (GDI) 5. Production year - B : 2011, C : 2012, D : 2013, E : 2014 … 6. Plant of production - A : Asan (Korea) - B : Beijing (China) - H : Hwasung (Korea) - K : Montgomery (U.S.A) - M : Chennai (India) - P : Poseung (Korea) - S : Sohari (Korea) - T : Izmit (Turkey) - U : Ulsan (Korea) - W : Shandong (China) - Z : Zilina (Slovakia) - 1 : Yancheng (China) 7. Engine production sequence number - 000001 ~ 999999 Transaxle Number Manual 1. Model - S : M6GF2 (Theta-II 2.4 GDI) 2. Production year - B : 2011, C : 2012, D : 2013, E : 2014 … 3. Plant of production - J :Hwaseong (Korea) 4. Final gear ratio - B : 4.333 / 3.250 (Theta-II 2.4 GDI) 5. Transaxle production sequence number - 000001~999999 Automatic tomsn048@gmail.com

1. Model - BA : A6LF2 (Theta-II 2.0 T-GDI) - FA : A6MF2 (Theta-II 2.4 GDI) 2. Production year - B : 2011, C : 2012, D : 2013, E : 2014 … 3. Final gear ratio - B : 2.885 (Theta-II 2.0 T-GDI) - N : 2.885 (Theta-II 2.4 GDI) 4. Detailed classification - B : Theta-II 2.4 GDI / 2.0 T-GDI 5. Spare 6. Transaxle production sequence number - 000001~999999 Warning / Caution Label Locations 1. Radiator cap caution 2. Fan caution 3. Battery caution Battery Caution Label Description
