Introducing the 2015 Kia Cadenza — a premium sedan that combines sophisticated exterior styling, a luxurious interior, and exhilarating performance. Its many technologically advanced features include a multimedia interface with voice-command navigation 3 and available features such as Advanced Smart Cruise Control 1 * and Blind-Spot Detection with Lane Change Assist. 1 * A 293-hp, 3.3L Gasoline Direct Injection (GDI) V6 engine delivers exceptional performance, while its finely tuned suspension system provides a smooth, quiet ride and precise handling. To help ensure your peace of mind, Cadenza incorporates the latest advanced safety systems including Vehicle Stability Management, Electronic Stability Control and a Brake Assist System. A Premium sedAn thAt hAs it All 1, 3* See Features page for availability and page 23 for endnotes. Not all optional features are available on all trims. CADENZA PREMIUM MODEL SHOWN. Some features may vary.

Cadenza delivers exhilarating performance and precise handling. Technologically advanced available features ranging from Advanced Smart Cruise Control 1 * to Blind-Spot Detection with Lane Change Assist 1 * help keep you in command at all times. A 3.3L Gasoline Direct Injection (GDI) V6 engine gen- erates 293 horsepower for dynamic acceleration. Its six-speed, Sportmatic ® transmission allows you to choose between automatic mode or, for sportier driving, clutch-free manual shifting with steering-wheel-mounted paddle shifters. In addition, Cadenza’s finely tuned suspension system ensures a remarkably smooth ride, while sound-absorbing insulation throughout the vehicle reduce, block and absorb road noise. resPonsive & insPiring PerformAnce 1 * See Features page for availability and page 23 for endnotes. Not all optional features are available on all trims. CADENZA PREMIUM MODEL SHOWN. Some features may vary.

emPowering you with AdvAnced technology Cadenza utilizes the latest technology to elevate every aspect of your driving experience. Standard amenities such as a voice-command navigation 3 system with Rear-Camera Display 1 and a Back-Up Warning System 1 help keep you in control. In addition, features such as a premium Infinity ®4 surround-sound audio system with 12 speakers for rich audio performance let you and your passengers enjoy every moment you spend traveling. 1, 3, 4, * See Features page for availability and page 23 for endnotes. Not all optional features are available on all trims. CADENZA PREMIUM MODEL SHOWN. Some features may vary. 3 4 1. REAR-CAMERA DISPLAY 1 conveniently see things behind your vehicle that you might not see by looking over your shoulder. 2. BACk-uP wARnIng SYStEM 1* A sonar system is concealed in the rear bumper. when you back up, an audible warning is given if the system detects objects behind your vehicle. 3. SuPERVISIOn tFt LCD InStRuMEnt CLuStER A high-visibility vehicle information screen and lcd gauges offer easy, at-a-glance reading in a variety of ambient light conditions. the cluster is included on cadenza Premium. 4. HYDROPHOBIC gLASS* to help improve visibility in rainy weather, front side windows with available hydrophobic glass instantly repel water. InFInItY ®4 AuDIO SYStEM A premium infinity ®4 surround-sound audio system with 12 speakers delivers exceptional audio entertainment, surrounding driver and passengers with crisp, balanced sound.

1, 3, 4, 8, 10 * See Features page for availability and page 23 for endnotes. Not all optional features are available on all trims. CADENZA PREMIUM MODEL SHOWN. Some features may vary. What could be simpler than using your voice or a touch screen to control the onboard navigation and entertainment systems on your new Cadenza? All Cadenza models are equipped with Kia’s multimedia interface, combining a dynamic display and brilliant graphics with touch screen and speech recognition technology for precise control of multiple systems and functions. luXury connected. tOuCH-SCREEn tECHnOLOgY A bright, 8-inch lcd touch screen features smartphone-like controls that respond with a touch of your finger. MEDIA AnD MuSIC IntEgRAtIOn the interface provides hands-free connectivity for your Bluetooth ®8 -enabled cell phone and supports digital music streaming from iPod ®10 or usB-connected music sources, as well as the system’s internal hard drive. your music is accompanied by extra-large album artwork on the screen. REARVIEw CAMERA DISPLAY 1 when you shift into reverse, the multimedia interface automatically displays a high-resolution image from the vehicle’s rearview camera. like an extra set of eyes, it shows you what you might not see in the rearview mirror or by looking over your shoulder. PREMIuM AuDIO SYStEM IntEgRAtIOn the multimedia interface is fully integrated with cadenza’s premium infinity ®4 Audio system – a concert-hall-quality system featuring 12 precisely placed speakers, including a subwoofer, centre channel speaker and external amplifier. OnBOARD nAVIgAtIOn 3 cadenza’s standard onboard navigation system is also fully integrated with the multimedia interface. call-up a destination, find a point of interest or type in an address on the touch screen and cadenza will take you there.

With luxurious appointments and a roomy cabin, Cadenza is designed to satisfy the most demanding driver. Spacious seating invites everyone to relax and travel in first-class accommodations. The heated and power- adjustable front seats are designed to provide an ideal balance of comfort and support. Leather seat trim, chrome accents throughout the interior and beautiful wood-grain style trim further add to Cadenza’s sophistication and refinement. A sPAcious & luXurious PrivAte retreAt CADENZA PREMIUM MODEL SHOWN. Some features may vary.

designed for oPtimum comfort Cadenza’s elegant interior is appointed with luxurious features that take comfort to the next level. For distinctive styling and a soft, inviting feel, premium Nappa leather seat trim* is available. Other available refinements include air-cooled front seats,* a power-adjustable driver’s seat-cushion extension* and a power rear-window sunshade.* *See Features page for availability. Not all optional features are available on all trims. CADENZA PREMIUM MODEL SHOWN. Some features may vary. 1 3 4 1. DuAL-ZOnE AutOMAtIC tEMPERAtuRE COntROL temperature control allows the driver and front passenger to adjust temperature settings to create their own climate zones. rear-seat passengers can adjust a separate ventilation outlet. 2. HEAtED StEERIng wHEEL* driving during colder months is more pleasant with the available heated steering wheel. 3. POwER REAR-wInDOw SunSHADE* rear-seat passengers can enjoy a cool and comfortable drive with an available power rear-window sunshade. 4. POwER SEAt-CuSHIOn ExtEnSIOn* An available power-adjustable driver’s seat-cushion extension is a welcome luxury, providing extra support and allowing drivers to select their own custom comfort settings. MEMORY SEttIngS* An available memory system remembers two drivers’ preferences, recalling stored positions for the driver’s seat, outside mirrors and power- adjustable steering column. PAnORAMIC SunROOF* Brighten any drive with the available panoramic sunroof. it includes a power-retractable sunshade for enhanced convenience.

AdvAnced sAfety systems to helP hAndle uneXPected conditions BRAkE ASSISt SYStEM (BAS) if BAs detects emergency braking, based on how quickly you step on the brake pedal, it instantly applies full braking force, which helps shorten your overall stopping distance. tRACtIOn COntROL SYStEM (tCS) when tcs senses wheel spin during acceleration, it uses engine power and brake force to transfer power to the wheels that have the most traction. ELECtROnIC StABILItY COntROL (ESC) esc monitors your vehicle’s response during emergency maneuvers. it then controls the engine and brakes to help keep your cadenza on course. VEHICLE StABILItY MAnAgEMEnt (VSM) vsm is a safety feature that adds steering direction control capability. it intervenes when appropriate to help the driver regain control of the vehicle. HILL-StARt ASSISt COntROL (HAC) to help keep you from rolling back- ward when starting off on a steep hill, hAc automatically holds the brake pressure for two seconds after you take your foot off the brake pedal. ELECtROnIC BRAkE-FORCE DIStRIButIOn (EBD) to help maintain more consistent braking as vehicle loads and weight distribution change, eBd adjusts the front-to-rear balance of brake pressure. The Cadenza features advanced active safety systems designed to help give you peace of mind every time you drive. † Each one is engineered to help you maintain control, even in harsh road conditions and in some emergency situations. These safety systems are designed to function automatically, leaving you free to focus on safe driving. †No system, no matter how advanced, can compensate for all driver error and/or driving conditions. Always drive responsibly. CADENZA PREMIUM MODEL SHOWN. Some features may vary.

The Cadenza is equipped with passive safety systems designed to help minimize injury when certain traffic accidents are unavoidable. An advanced airbag system helps protect driver and passengers with dual front, front and rear seat-mounted side, and full-length side-curtain airbags. Cadenza wraps all of this — and you — in a protective, high-strength, tensile steel-reinforced body that absorbs impact energy to help protect you in case of a collision. designed to Protect driver And PAssengers EIgHt ADVAnCED AIRBAgS 5 dual front airbags, full-length side curtain airbags and front and rear seat- mounted side airbags are managed by an advanced sensor system that can even respond in certain rollover situations. AIRBAg & SEAtBELt SEnSORS this advanced system monitors the severity of certain impacts, the presence of a front passenger and seat-belt use, and then controls airbag inflation accordingly. FROnt SEAt-BELt PREtEnSIOnERS Pretensioners have been designed to tighten the front seat belts in the event of certain collisions. this helps to reduce the likelihood of injuries. HIgH-StREngtH, tEnSILE StEEL-REInFORCED BODY cadenza’s body structure is reinforced with extensive amounts of high- strength tensile steel. this material is lighter and stronger than traditional steel, helping protect passengers while reducing overall weight. FROnt & REAR CRuMPLE ZOnES front and rear crumple zones are specially engineered to help absorb and dissipate impact energy, helping to preserve the structural integrity of the entire passenger compartment in certain collisions. REAR CHILD-SAFEtY DOOR LOCkS rear child-safety door locks help prevent the doors from being opened accidentally, which is important when small children are passengers. with the doors in the locked position, they can only be opened from the outside. 5. See page 23 for endnotes. Not all optional features are available on all trims. Some features may vary.

Kia is committed to producing world- class vehicles that suit most every driving need. This promise has led to the development of stylish vehicles with a remarkable combination of precision engineering, outstanding performance, innovative features and advanced safety systems — and Cadenza stands as an extraordinary example of this commitment. Kia’s dedication to quality and value has also been widely recognized 6 — one reason why Kia has been honoured as a top 100 brand in Interbrand’s Best Global Brands 2013 report. 7 delivering on A Promise 6, 7. See page 23 for endnotes. StunnIng DESIgn cadenza takes its place alongside K900 as one of Kia’s Premium line of vehicles that — under the direction of renowned President and chief design officer Peter schreyer — has captured worldwide attention for interior and exterior styling. Kia vehicles represent the passionate collaboration of designers who have created a distinctive look that makes every Kia recognizable at first sight. ExtEnSIVE RESEARCH AnD DEVELOPMEnt Kia’s r&d procedures are rigorous and exhaustive. At proving grounds around the world, vehicles undergo unrelenting tests. A world-class wind tunnel provides testing in winds up to 200 km/h. utilizing heavy-rain-and-snowfall testing chambers and a road simulator, Kia puts its vehicles through punishing tests as part of a commitment to develop exceptionally durable and safe vehicles. StRIngEnt tEStIng to deliver automobiles with exceptional performance and unsur- passed comfort, Kia combines new technologies with materials such as high-strength tensile steel. in addition, cadenza’s parts and material testing included high-tech virtual analysis to deliver superior performance and long-lasting quality in real-world conditions. COMMItMEnt tO nORtH AMERICA Kia motors has invested over $1.1 billion in its manufacturing plant in west Point, georgia. utilizing the latest manufacturing processes and state-of-the-art robotics, the plant recently produced its one millionth vehicle after less than four years of operation. the sorento crossover is currently being built at this plant for the canadian market. together with on-site and local suppliers, the georgia facility is responsible for the creation of more than 14,000 jobs in west Point and the surrounding areas. it’s all part of Kia motors’ commitment to north America — a commitment that is sure to grow and strengthen in the years ahead. PREMIuM wARRAntY PROgRAM true to the luxury vehicle class, your new Kia Premium vehicle ownership includes complimentary scheduled maintenance. refer to page 23 of this brochure for further warranty information. K900 V8 Elite international model shown.
