ACC-1 ACCELERATOR CONTROL SYSTEM B ENGINE CONTENTS C D E F G H I J K L M SECTION ACC A ACC Edition; 2004 September 2005 G35 Sedan ACCELERATOR CONTROL SYSTEM PRECAUTIONS ......................................................... 2 Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT BELT PRE-TEN- SIONER” ................................................................. 2 ACCELERATOR CONTROL SYSTEM ...................... 3 Removal and Installation ......................................... 3 REMOVAL ............................................................ 3 INSTALLATION .................................................... 3 INSPECTION AFTER INSTALLATION ................. 3
ACC-2 PRECAUTIONS Edition; 2004 September 2005 G35 Sedan PRECAUTIONS PFP:00001 Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT BELT PRE-TENSIONER” ABS009RB The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the SRS and SB section of this Service Man- ual. WARNING: ● To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be per- formed by an authorized NISSAN/INFINITI dealer. ● Improper maintenance, including incorrect removal and installation of the SRS, can lead to per- sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS section. ● Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.
ACCELERATOR CONTROL SYSTEM ACC-3 C D E F G H I J K L M A ACC Edition; 2004 September 2005 G35 Sedan ACCELERATOR CONTROL SYSTEM PFP:18005 Removal and Installation ABS000JI REMOVAL 1. Disconnect accelerator pedal position sensor harness connector. 2. Loosen nuts, and remove accelerator pedal assembly. CAUTION: ● Do not disassemble accelerator pedal assembly. Do not remove accelerator pedal position sen- sor from accelerator pedal assembly. ● Avoid impact from dropping etc. during handling. ● Be careful to keep accelerator pedal assembly away from water. INSTALLATION Install in the reverse order of removal. INSPECTION AFTER INSTALLATION ● Make sure that accelerator pedal moves smoothly within the whole operation range. ● Make sure that accelerator pedal securely returns to the original position. ● For the electrical inspection of accelerator pedal position sensor, refer to EC-598, " DTC P2122, P2123 APP SENSOR " , EC-605, " DTC P2127, P2128 APP SENSOR " and EC-619, " DTC P2138 APP SEN- SOR " . CAUTION: When harness connector of accelerator pedal position sensor is disconnected, perform “Acceler- ator Pedal Released Position Learning”. Refer to EC-88, " Accelerator Pedal Released Position Learning " . 1. Accelerator pedal assembly PBIC2080E
ACC-4 ACCELERATOR CONTROL SYSTEM Edition; 2004 September 2005 G35 Sedan
