2013 Hyundai ELANTRA COUPE (JK) G 1.8 MPI Service & Repair Manual

ELANTRA COUPE(JK) > 2013 > G 1.8 MPI > General Information - Identification Number Locations Click to see large image... Identification Number Description Vehicle Identification Number Click to see large image... 1. World Manufacturer Identifier (WMI) – KMH : Passenger vehicle (in Korea) – 5NP : Passenger vehicle (in U.S.A.) 2. Vehicle line – D : ELANTRA COUPE 3. Model ＆ Series – F : Low grade (L) – G : Middle-Low grade (GL) – H : Middle grade (GLS, JSL, TAX) – J : Middle-High grade (HGS) – K : High grade (TOP) 4.Body/Cabin type, Gross Vehicle Weight Rating - 1 : Limousine - 2 : Sedan - 2 door - 3 : Sedan - 3 door - 4 : Sedan - 4 door - 5 : Sedan - 5 door - 6 : Coupe - 7 : Convertible - 8 : Wagon - 9 : Commercial Van - 0 : Pick-Up 5. Restraint system, Brake system Code Seat belt Front air bag Knee air bag Side air bag Curtain air bag Driver''s Passenger''s Driver''s Passenger''s 1st row 2nd row 3rd row 1st row 2nd row 3rd row A ○ ○ ○ × × ○ × × ○ ○ × B ○ ○ ○ × × × × × × × × C ○ ○ ○ × × ○ × × ○ ○ ○ D ○ ○ ○ × × ○ ○ × ○ ○ × E ○ ○ × × × × × × × × × F ○ ○ ○ × × ○ × × × × × J ○ ○ ○ ○ × ○ ○ × ○ ○ × L ○ ○ ○ ○ × ○ × × ○ ○ × N ○ × × × × × × × × × × 6. Engine type – E : Gasoline engine 1.8(Nu MPI) 7. Check digit or Driver’s side & Transmission – Check digit : 0 ~ 9, x

8. Model year – C : 2012, D : 2013, E : 2014 ... 9. Plant of production – H : Alabama (U.S.A.) – U : Ulsan (Korea) 10. Vehicle production sequence number – 000001 ~ 999999 Paint Code Code Color NKA Phantom Black RBC Ceramic White N3S Sleek Silver N5S Hyper Silver S7U Santorini Blue S2R Tomato Red P7N Bronze Engine Number Click to see large image... 1. Engine fuel - G : Gasoline 2. Engine range - 4 : 4 cycle 4 cylinder 3. Engine development order and capacity - N : Nu engine 4. Engine Capacity - B : 1797 (MPI engine) 5. Model year - C : 2012, D : 2013, E : 2014 ... 6. Plant of production - A : Asan (Korea) - B : Beijing (China) - H : Hwasung (Korea) - K : Montgomery (U.S.A) - M : Chennai (India) - P : Poseung (Korea) - S : Sohari (Korea) - T : Izmit (Turkey) - U : Ulsan (Korea) - W : Shandong (China) - Z : Zilina (Slovakia) - 1 : Yancheng (China) 7. Engine production sequence number - 000001 ~ 999999 Transaxle Number Manual Click to see large image... 1. Model

- W : M6CF3-1 2. Model year - C : 2012, D : 2013, E : 2014 ... 3. Plant of production - U : Ulsan 4. Final gear ratio - E : 4.188 5. Spare 6. Transaxle production sequence number - 000001 ~ 999999 Automatic Click to see large image... 1. Model - NA : A6GF1 2. Model year - C : 2012, D : 2013, E : 2014 ... 3. Gear ratio - P : 3.065 4. Detailed classification - A : Nu 1.8 MPI 5. Spare 6. Transaxle production sequence number - 000001 ~ 999999 Warning / Caution Label Locations Click to see large image... 1. Fan caution 2. Radiator cap caution 3. Battery caution Battery Caution Label Description Click to see large image... Warning / Caution Label (Cont''d) A. Keep lighted cigarettes and all other flames or sparks away from the battery. B. Wear eye protection when charging or working near a battery. Always provide ventilation when working in an enclosed space. • When lifting a plastic-cased battery, excessive pressure on acid to leak resulting in personal injury. Lift with a battery carrier or with your hands on opposite corners. • Never attempt to change the battery when the battery cables are connected. • The electrical ignition system works with high voltage. Never touch these components with the engine running or the ignition switched on. C. Keep batteries out of the reach of children because batteries contain highly corrosive SULFURIC ACID. Do not allow battery acid to contact your skin, eyes, clothing or paint finish.

D. If any electrolyte gets into your eyes, flush your eyes with clean water for at least 15 minutes and get immediate medical attention. If possible, continue to apply water with a sponge or cloth until medical attention is received. If electrolyte gets on your skin, throughly wash the contacted area. If you feel a pain or a burning sensation, get medical attention immediately. E. Always read the following instructions carefully when handing a battery. F. Hydrogen, which is a highly combustible gas, is always presents in battery cells and may explode if ignited. G. An improperly disposed battery can be harmful to the environment and human health. Always confirm local regulations for battery disposal. Handling And Storage The Battery Battery Itself • Batteries should be stored in cool, dry (27 degrees Celsius) places and out of direct sunlight. • MF batteries are tightly sealed to prevent acid leakage. However, tilting the battery to an angle of 45 degrees can cause acid to leak through the vents on the sides. Therefore, batteries should always be stored in their upright positions. Prevent placing any aqueous or solid (i.e. conductors) bodies on top of the battery. • It is extremely dangerous to use tools, such as hammers, on the battery terminals when connecting cables to the mounted battery. Battery on Vehicle • When storing the vehicle for long periods of time, make sure to remove the memory fuse at junction box to prevent natural discharging. • Also, run the engine for battery charging within 1 month if the memory fuse wasn''t removed from the start of vehicle storing. If the memory fuse was removed, run the engine for battery charging within 3 months from the start of vehicle storing. After reconnecting or recharging a discharged battery, the ESC OFF indicator may illuminate. In this case, turn the handle half way to the left and right whilst the ignition switch is in the ON position. Then, restart the engine after the ignition is OFF. The ESC OFF indicator may turn OFF. If the ESC OFF indicator does not turn OFF, have the system checked refering to DTC. (Refer to the BR group.) Lift And Support Points When heavy rear components such as suspension, fuel tank, spare tire, tailgate and trunk lid are to be removed, place additional weight in the luggage area before hoisting. When substantial weight is removed from the rear of the vehicle, the center of gravity may change and can cause the vehicle to tip forward on the hoist. • Since each tire/wheel assembly weights approximately 30lbs (14kg), placing the front wheels in the luggage area can assist with the weight distribution. • Use the same support points to support the vehicle on safety stands.

1. Place the lift blocks under the support points as shown in the illustration. 2. Raise the hoist a few inches (centimeters) and rock the vehicle to be sure it is firmly supported. 3. Raise the hoist to full height to inspect the lift points for secure support. Click to see large image... Towing If the vehicle needs to be towed, call a professional towing service. Never tow vehicle with just a rope or chain. It is very dangerous. Click to see large image... Click to see large image... Emergency Towing There are three popular methods of towing a vehicle : – The operator loads the vehicle on the back of truck. This is best way of transporting the vehicle. – The tow truck uses two pivoting arms that go under the tires of the driving axle and lift them off the ground. The other two wheels remain on the ground. – The tow truck uses metal cables with hooks on the ends. These hooks go around parts of the frame or suspension, and the cables lift that end of the vehicle off the ground. The vehicle''s suspension and body can be seriously damaged if this method of towing is attempted. If the vehicle cannot be transported by flat-bed, should be towed with the wheels of the driving axle off the ground and do the following : Manual Transaxle • Release the parking brake. • Shift the Transaxle to neutral Automatic Transaxle • Release the parking brake. • Start the engine. • Shift to [D] position, then [N] position. • Turn off the engine. • The vehicle equipped with full-time 4WD should be only transported on a flat-bed. • The CVT vehicles should be only transported on a flat-bed or towed by wheel lift towing which the wheels of the driving axle are lifted off the ground. • Improper towing preparation will damage the transaxle. Follow the procedure above exactly. If you cannot shift the transaxle or start the engine(automatic transaxle), your vehicle must be transported on a flatbed. • It is the best to tow vehicle no farther than 30km (19miles), and keep the speed below 50km/h (30mph). (For the CVT and full-time 4WD (CVT/AT) vehicles, limit the towing distance and speed to 1.5km (1 mile) and 15km/h (10 mph).) • Trying to lift or tow your vehicle by the bumpers will cause serious damage to the vehicle. The bumpers are not designed to support the vehicle''s weight. Tightening Torque Table Of Standard Parts BOLT (Nominal diameter) NUT (Nominal diameter) Click to see large image... Click to see large image... BOLT/NUT Normal screw Torque Nm (kg.m, Ib-ft) Nominal diameter. (mm) Pitch [mm (in.) ] 4T 8T 10T Click to see large image... Click to see large image... Click to see large image... Click to see large image... M5 0.8 (0.031) 2.0 ~ 3.0 (0.2 ~ 0.3, 1.4 ~ 2.2) 4.9 ~ 6.9 (0.5 ~ 0.7, 3.6 ~ 5.1) 7.8 ~ 10.8 (0.8 ~ 1.1, 5.8 ~ 8.0)

M6 1 (0.039) 2.9 ~ 4.9 (0.3 ~ 0.5, 2.2 ~ 3.6) 8.8 ~ 12.7 (0.9 ~ 1.3, 6.5 ~ 9.4) 13.7 ~ 18.6 (1.4 ~ 1.9, 10.1 ~ 13.7) M8 1.25 (0.049) 8.8 ~ 11.8 (0.9 ~ 1.2, 6.5 ~ 8.7) 22.6 ~ 30.4 (2.3 ~ 3.1, 16.6 ~ 22.4) 33.3 ~ 44.1 (3.4 ~ 4.5, 24.6 ~ 32.5) M10 1.5 (0.059) 16.7 ~ 22.6 (1.7 ~ 2.3, 12.3 ~ 16.6) 45.1 ~ 60.8 (4.6 ~ 6.2, 33.3 ~ 44.8) 65.7 ~ 88.3 (6.7 ~ 9.0, 48.5 ~ 65.1) M12 1.75 (0.068) 29.4 ~ 39.2 (3.0 ~ 4.0, 21.7 ~ 28.9) 78.5 ~ 105.9 (8.0 ~ 10.8, 57.9 ~ 78.1) 114.7 ~ 154.9 (11.7 ~ 15.8, 84.6 ~ 114.3) M14 2 (0.078) 47.1 ~ 63.7 (4.8 ~ 6.5, 34.7 ~ 47.0) 125.5 ~ 169.7 (12.8 ~ 17.3, 92.6 ~ 125.1) 183.4 ~ 249.1 (18.7 ~ 25.4, 135.3 ~ 183.7) M16 2 (0.078) 73.5 ~ 100.0 (7.5 ~ 10.2, 54.2 ~ 73.8) 197.1 ~ 266.7 (20.1 ~ 27.2, 145.4 ~ 196.7) 288.3 ~ 390.3 (29.4 ~ 39.8, 212.7 ~ 287.9) M20 2.5 (0.098) 144.2 ~ 195.2 (14.7 ~ 19.9, 106.3 ~ 143.9) 396.2 ~ 535.4 (40.4 ~ 54.6, 292.2 ~ 394.9) 565.8 ~ 764.9 (57.7 ~ 78.0, 417.3 ~ 564.2) M24 3 (0.118) 249.1 ~ 337.3 (25.4 ~ 34.4, 183.7 ~ 248.8) 687.4 ~ 929.7 (70.1 ~ 94.8, 507.0 ~ 685.7) 975.8 ~ 1320.0 (99.5 ~ 134.6, 719.7 ~ 973.6) M30 3.5 (0.137) 499.2 ~ 674.7 (50.9 ~ 68.8, 368.2 ~ 497.6) 1372.9 ~ 1858.4 (140.0 ~ 189.5, 1012.6 ~ 1370.7) 1956.4 ~ 2647.8 (199.5 ~ 270.0, 1443.0 ~ 1952.9) BOLT/NUT Thin screw Torque Nm (kg.m, Ib-ft) Nominal diameter. (mm) Pitch [mm (in.) ] 4T 8T 10T Click to see large image... Click to see large image... Click to see large image... Click to see large image... M5 0.5 (0.019) 2.0 ~ 3.0 (0.2 ~ 0.3, 1.4 ~ 2.2) 5.9 ~ 8.8 (0.6 ~ 0.9, 4.3 ~ 6.5) 8.8 ~ 12.7 (0.9 ~ 1.3, 6.5 ~ 9.4) M6 0.75 (0.029) 3.9 ~ 4.9 (0.4 ~ 0.5, 2.9 ~ 3.6) 9.8 ~ 13.7 (1.0 ~ 1.4, 7.2 ~ 10.1) 14.7 ~ 20.6 (1.5 ~ 2.1, 10.8 ~ 15.2) M8 1 (0.039) 8.8 ~ 11.8 (0.9 ~ 1.2, 6.5 ~ 8.7) 24.5 ~ 32.4 (2.5 ~ 3.3, 18.1 ~ 23.9) 35.3 ~ 48.1 (3.6 ~ 4.9, 26.0 ~ 35.4) M10 1.25 (0.049) 17.7 ~ 23.5 (1.8 ~ 2.4, 13.0 ~ 17.4) 47.1 ~ 63.7 (4.8 ~ 6.5, 34.7 ~ 47.0) 69.6 ~ 94.1 (7.1 ~ 9.6, 51.4 ~ 69.4) M12 1.25 (0.049) 32.4 ~ 44.1 (3.3 ~ 4.5, 23.9 ~ 32.5) 86.3 ~ 117.7 (8.8 ~ 12.0, 63.7 ~ 86.8) 127.5 ~ 172.6 (13.0 ~ 17.6, 94.0 ~ 127.3) M14 1.5 (0.059) 51.0 ~ 69.6 (5.2 ~ 7.1, 37.6 ~ 51.4) 136.3 ~ 185.3 (13.9 ~ 18.9, 100.5 ~ 136.7) 201.0 ~ 271.6 (20.5 ~ 27.7, 148.3 ~ 200.4) M16 1.5 (0.059) 79.4 ~ 107.9 (8.1 ~ 11.0, 58.6 ~ 79.6) 211.8 ~ 286.4 (21.6 ~ 29.2, 156.2 ~ 211.2) 311.8 ~ 421.7 (31.8 ~ 43.0, 230.0 ~ 311.0) M20 1.5 (0.059) 163.8 ~ 221.6 (16.7 ~ 22.6, 120.8 ~ 163.5) 448.2 ~ 607.0 (45.7 ~ 61.9, 330.5 ~ 447.7) 639.4 ~ 864.9 (65.2 ~ 88.2, 471.6 ~ 638.0) M24 2 (0.078) 276.5 ~ 373.6 (28.2 ~ 38.1, 204.0 ~ 275.6) 759.0 ~ 1026.8 (77.4 ~ 104.7, 559.8 ~ 757.3) 1080.7 ~ 1462.2 (110.2 ~ 149.1, 797.1 ~ 1078.4) M30 2 (0.078) 562.9 ~ 762.0 (57.4 ~ 77.7, 415.2 ~ 562.0) 1553.4 ~ 2102.5 (158.4 ~ 214.4, 1145.7 ~ 1550.8) 2210.4 ~ 2991.0 (225.4 ~ 305.0, 1630.3 ~ 2206.1) Flange BOLT (Nominal diameter) Flange NUT (Nominal diameter)

Click to see large image... Click to see large image... Flange BOLT/NUT Normal screw Torque Nm (kg.m, Ib-ft) Nominal diameter. (mm) Pitch [mm (in.) ] 4T 8T 10T Click to see large image... Click to see large image... Click to see large image... Click to see large image... M5 0.8 (0.031) 2.0 ~ 2.9 (0.2 ~ 0.3, 1.4 ~ 2.2) 5.9 ~ 7.8 (0.6 ~ 0.8, 4.3 ~ 5.8) 8.8 ~ 11.8 (0.9 ~ 1.2, 6.5 ~ 8.7) M6 1 (0.039) 3.9 ~ 4.9 (0.4 ~ 0.5, 2.9 ~ 3.6) 9.8 ~ 13.7 (1.0 ~ 1.4, 7.2 ~ 10.1) 14.7 ~ 19.6 (1.5 ~ 2.0, 10.8 ~ 14.5) M8 1.25 (0.049) 8.8 ~ 11.8 (0.9 ~ 1.2, 6.5 ~ 8.7) 24.5 ~ 32.4 (2.5 ~ 3.3, 18.1 ~ 23.9) 35.3 ~ 48.1 (3.6 ~ 4.9, 26.0 ~ 35.4) M10 1.5 (0.059) 17.7 ~ 24.5 (1.8 ~ 2.5, 13.0 ~ 18.1) 48.1 ~ 65.7 (4.9 ~ 6.7, 35.4 ~ 48.5) 70.6 ~ 96.1 (7.2 ~ 9.8, 52.1 ~ 70.9) M12 1.75 (0.068) 31.4 ~ 43.1 (3.2 ~ 4.4, 23.1 ~ 31.8) 84.3 ~ 113.8 (8.6 ~ 11.6, 62.2 ~ 83.9) 123.6 ~ 167.7 (12.6 ~ 17.1, 91.1 ~ 123.7) M14 2 (0.078) 51.0 ~ 68.6 (5.2 ~ 7.0, 37.6 ~ 50.6) 135.3 ~ 182.4 (13.8 ~ 18.6, 99.8 ~ 134.5) 198.1 ~ 268.7 (20.2 ~ 27.4, 146.1 ~ 198.2) M16 2 (0.078) 79.4 ~ 107.9 (8.1 ~ 11.0, 58.6 ~ 79.6) 212.8 ~ 288.3 (21.7 ~ 29.4, 157.0 ~ 212.7) 311.8 ~ 421.7 (31.8 ~ 43.0, 230.0 ~ 311.0) Flange BOLT/NUT Thin screw Torque Nm (kg.m, Ib-ft) Nominal diameter. (mm) Pitch [mm (in.) ] 4T 8T 10T Click to see large image... Click to see large image... Click to see large image... Click to see large image... M5 0.5 (0.019) 2.9 ~ 2.9 (0.3 ~ 0.3, 2.2 ~ 2.2) 6.9 ~ 8.8 (0.7 ~ 0.9, 5.1 ~ 6.5) 9.8 ~ 13.7 (1.0 ~ 1.4, 7.2 ~ 10.1) M6 0.75 (0.029) 3.9 ~ 5.9 (0.4 ~ 0.6, 2.9 ~ 4.3) 10.8 ~ 14.7 (1.1 ~ 1.5, 8.0 ~ 10.8) 16.7 ~ 21.6 (1.7 ~ 2.2, 12.3 ~ 15.9) M8 1 (0.039) 9.8 ~ 12.7 (1.0 ~ 1.3, 7.2 ~ 9.4) 26.5 ~ 35.3 (2.7 ~ 3.6, 19.5 ~ 26.0) 38.2 ~ 52.0 (3.9 ~ 5.3, 28.2 ~ 38.3) M10 1.25 (0.049) 19.6 ~ 25.5 (2.0 ~ 2.6, 14.5 ~ 18.8) 51.0 ~ 68.6 (5.2 ~ 7.0, 37.6 ~ 50.6) 75.5 ~ 102.0 (7.7 ~ 10.4, 55.7 ~ 75.2) M12 1.25 (0.049) 35.3 ~ 48.1 (3.6 ~ 4.9, 26.0 ~ 35.4) 94.1 ~ 126.5 (9.6 ~ 12.9, 69.4 ~ 93.3) 138.3 ~ 186.3 (14.1 ~ 19.0, 102.0 ~ 137.4) M14 1.5 (0.059) 55.9 ~ 75.5 (5.7 ~ 7.7, 41.2 ~ 55.7) 148.1 ~ 200.1 (15.1 ~ 20.4, 109.2 ~ 147.6) 216.7 ~ 293.2 (22.1 ~ 29.9, 159.8 ~ 216.3) M16 1.5 (0.059) 86.3 ~ 116.7 (8.8 ~ 11.9, 63.7 ~ 86.1) 229.5 ~ 309.9 (23.4 ~ 31.6, 169.3 ~ 228.6) 336.4 ~ 455.0 (34.3 ~ 46.4, 248.1 ~ 335.6) 1) The torques shown in the table are standard values under the following conditions. • Nuts and bolts are made of galvanized steel bar. • Galvanized plain steel washers are inserted. • All nuts, bolts and plain washers are dry. 2) The torques shown in the table are not applicable.

• When spring washers, toothed washers and the like are inserted. • If plastic parts are fastened. • If self-tapping screws or self-locking nuts are used. • If threads and surfaces are coated with oil. Meaning Of Symbols There are five primary symbols used to complement illustrations. These symbols indicate the part to apply such materials during service. Symbol Meaning Click to see large image... Do not reuse the part. Replace a new one. Click to see large image... Apply engine oil or transmission oil to the part. Click to see large image... Apply automatic transmission fluid (ATF) to the part. Click to see large image... Apply grease to the part. Click to see large image... Apply sealant to the part. General Service Information Protection Of The Vehicle Always be sure to cover fenders, seats, and floor areas before starting work. The support rod must be inserted into the hole near the edge of the hood whenever you inspect the engine compartment to prevent the hood from falling and causing possible injury. Make sure that the support rod has been released prior to closing the hood. Always check to be sure the hood is firmly latched before driving the vehicle. Preparation Of Tools And Measuring Equipment Be sure that all necessary tools and measuring equipment are available starting work. Special Tools Use special tools when they are required. Click to see large image... Removal Of Parts First find the cause of the problem and then determine whether removal or disassembly before starting the job. Click to see large image... Disassembly If the disassembly procedure is complex, requiring many parts to be disassembled, all parts should be disassembled in a way that will not affect their performance or external appearance. 1) Inspection of parts Each part, when removed, should be carefully on suspected for malfunction, deformation, damage, and other problems. Click to see large image... 2) Arrangement of parts All disassembled parts should be carefully arranged for effective reassembly. Be sure to separate and correctly identify the parts to be replaced from those that will be used again. Click to see large image... 3) Cleaning parts for reuse All parts to be used again should be carefully and thoroughly cleaned by an appropriate method. Click to see large image... Parts

When replacing parts, use HYUNDAI genuine parts. Click to see large image... Replacement Standard values, such as torques and certain adjustments, must be strictly observed in the reassembly of all parts. If removed, the following parts should always be replaced with new ones. 1) Oil seals 2) Gaskets 3) O-rings 4) Lock washers 5) Cotter pins (split pins) 6) Plastic nuts Click to see large image... Depending on their location. 7) Sealant should be applied to gaskets. 8) Oil should be applied to the moving components of parts. 9) Specified oil or grease should be applied to the prescribed locations (oil seals, etc) before assembly. Click to see large image... Adjustment Use gauges and testers to adjust correctly the parts to standard values correctly. Electrical System 1. Be sure to disconnect the battery cable from the negative (-) terminal of the battery. 2. Never pull on the wires when disconnecting connectors. 3. Locking connectors will click when the connector is secure. 4. Handle sensors and relays carefully. Be careful not to drop them against other parts. Click to see large image... Rubber Parts And Tubes Always prevent gasoline or from touching rubber parts or tubing. Click to see large image... Measuring Body Dimensions 1. Basically, all measurements in this manual are taken with a tracking gauge. 2. When a measuring tape is used, check to be sure there is no elongation, twisting or bending. 3. For measuring dimensions, both projected dimensions and actual - measurement dimensions are used in this manual. Dimensions Projected 1. These are the dimensions measured when the measurement points are projected from the vehicle''s surface, and are the reference dimensions used for used for body alterations. 2. If the length of the tracking gauge probes is adjustable, measure it by lengthening one of two probes as long as the different value in height of the two surface. Click to see large image... Measuring Actual Dimensions 1. These dimensions indicate the actual linear distance between measurement points, and are used as the reference dimensions when a tracking gauge is used for measurement. 2. First adjust both probes to the same length (A=A'') before measurement. Check the probes and gauge itself to make sure there is no free play. Click to see large image...

Measurement Point Measurements should be taken at the center of the hole. Click to see large image... Checking Cables And Wires 1. Check the terminal for tightness. 2. Check terminals and wires for corrosion from battery electrolyte, etc. 3. Check terminals and wires for open circuits. 4. Check wire insulation and coating for damage, cracks and degrading. 5. Check the conductive parts of terminals for contact with other metallic parts (vehicle body and other parts). 6. Check grounded parts to verify that there is complete continuity between their attaching bolt(s) and the vehicle''s body. 7. Check for incorrect wiring. 8. Check that the wiring is so clamped to the prevent contact with sharp corners of the vehicle body, etc. or hot parts (exhaust manifold, etc.) 9. Check that the wiring is clamped firmly to provide enough clearance from the fan pulley, fan belt and other rotating or moving parts. 10. Check that the wiring has a little space so that it can vibrate between fixed and moving parts such as the vehicle body and the engine. Click to see large image... Check Fuses A blade type fuse test taps provided to allow checking the fuse itself without removing if from the fuse box. The fuse is good if the test lamp lights up when one lead is connected to the test taps (one at a time) and the other lead is grounded. (Turn the ignition switch so that the fuse circuit becomes operative) Click to see large image... Servicing The Electrical System 1. Prior to servicing the electrical system, be sure to turn off the ignition switch and disconnect the battery ground cable. In the course of MFI or ELC system diagnosis, when the battery cable is removed, any diagnostic trouble code retained by the computer will be cleared. There fore, if necessary, record the diagnostic data before removing the battery cable. Click to see large image... 2. Attach the wiring harnesses with clamps so that there is no slack. However, for any harness which passes the engine or other vibrating parts of the vehicle, allow some slack within a range that does not allow the engine vibrations to cause the harness to come into contact with any of the surrounding parts and then secure the harness by using a clamp. Click to see large image... 3. If any section of a wiring harness interferes with the edge of a parts, or a corner, wrap the section of the harness with tape or something similar in order to protect if from damage. Click to see large image... 4. When installing any parts, be careful not to pinch or damage any of the wiring harness. Click to see large image... 5. Never throw relays, sensors or electrical parts, or expose them to strong shock. Click to see large image... 6. The electronic parts used in the computer, relays, etc. are readily damaged by heat. If there is a need for service operations that may cause the temperature to exceed 80°C (176°F), remove the electronic parts before hand. Click to see large image... 7. Loose connectors cause problems. Make sure that the connectors are always securely fastened. Click to see large image...
