2010 SPECIFICATIONS INDEX Equinox, Terrain SPECIFICATIONS INDEX EQUINOX & TERRAIN SPECIFICATIONS INDEX System Specification/Procedure Air Conditioning Service REFRIGERANT SYSTEM SPECIFICATIONS Torque FASTENER TIGHTENING SPECIFICATIONS Wheel Drive Shaft Spindle Nut Front 205 N.m (151 lb ft) Rear 205 N.m (151 lb ft) Battery BATTERY USAGE Brakes Bleeding Sequence RR, LF, LR, RF Disc Brakes Service Specifications DISC BRAKE COMPONENT SPECIFICATIONS Torque FASTENER TIGHTENING SPECIFICATIONS Drum Brakes Service Specifications NA Torque NA Charging Generator GENERATOR USAGE Torque FASTENER TIGHTENING SPECIFICATIONS Drive Belts Adjustment NA Drive Belt Routing 2.4L See figure under DRIVE BELT REPLACEMENT 3.0L See figure under DRIVE BELT REPLACEMENT Engine Cooling General Service Specifications SPECIFICATIONS Radiator Cap Pressure Printed on cap Thermostat R & I 2.4L NA 3.0L ENGINE COOLANT THERMOSTAT HOUSING REMOVAL Water Pump R & I GMC Terrain & Equinox

2.4L WATER PUMP REMOVAL 3.0L WATER PUMP REMOVAL Engine Mechanical 2.4L Compression ENGINE COMPRESSION TEST Oil Pressure Minimum @ 1,000 RPM @ 90°C (194°F) 206.84-482.63 kPa (30-70 psi) Overhaul ENGINE MECHANICAL SPECIFICATIONS Torque FASTENER TIGHTENING SPECIFICATIONS 3.0L Compression ENGINE COMPRESSION TEST Oil pressure Minimum @ idle 69 kPa (10 psi) @ 2,000 RPM 138 kPa (20 psi) Overhaul ENGINE MECHANICAL SPECIFICATIONS (LF1) Torque FASTENER TIGHTENING SPECIFICATIONS Fluid Specifications See FLUIDS under MAINTENANCE/FLUIDS tab. From within Manager or Service Writer, click the "30/60/90 Interval" or "Maint." button. Flywheel/Flex Plate/Drive Plate Torque 2.4L First Pass 53 N.m (39 lb ft) Final Pass 25 degrees 3.0L First Pass 30 N.m (22 lb ft) Final Pass 45 degrees Fuel System Pressure Specification 276-448 kPa (40-65 psi) Fuel Pressure Test Procedure 2.4L FUEL SYSTEM DIAGNOSIS 3.0L FUEL SYSTEM DIAGNOSIS Fuel Filter Location Fuel Filter is part of Fuel Tank Fuel Pump Module Fuel Filter R & I 2.4L FUEL TANK FUEL PUMP MODULE REPLACEMENT 3.0L FUEL TANK FUEL PUMP MODULE REPLACEMENT Ignition Firing Order & Cylinder Identification FIRING ORDER & CYLINDER IDENTIFICATION Ignition Wires (Resistance) NA Ignition Wires (Routing) NA Spark Plug 2.4L Gap 1.0 mm (0.035 in)

Torque 20 N.m (15 lb ft) 3.0L Gap 1.1 mm (0.043 in) Torque 20 N.m (15 lb ft) Starting Starter BATTERY INSPECTION/TEST Torque FASTENER TIGHTENING SPECIFICATIONS Wheel Alignment Adjustment Specifications WHEEL ALIGNMENT SPECIFICATIONS Torque FASTENER TIGHTENING SPECIFICATIONS Wheel & Tire Wheel Lug Nut Torque (See Tightening Pattern under wheel and tire INSTALLATION PROCEDURE 190 N.m (140 lb ft)

2010 DTC INDEX Equinox & Terrain ORDERED DIAGNOSTIC TROUBLE CODES EQUINOX & TERRAIN DIAGNOSTIC TROUBLE CODE (DTC) LIST DTC DTC Descriptor Diagnostic Procedure B0000 Vehicle Speed Information Circuit Not Plausible DTC B0000 B0012 Driver Frontal Deployment Loop Stage 1 DTC B0012 or B0013 B0013 Driver Frontal Deployment Loop Stage 2 DTC B0012 or B0013 B0014 Driver Side Deployment Loop DTC B0014 - B0045 B0015 Driver Seat Belt Pretensioner Deployment Loop DTC B0014 - B0045 B0016 Left Roof Rail Deployment Loop 1 DTC B0014 - B0045 B0018 Left Roof Rail Deployment Loop 2 DTC B0014 - B0045 B0019 Passenger Frontal Deployment Loop Stage 1 DTC B0014 - B0045 B001A Driver Pretensioner Deployment Loop 2 DTC B001A or B001B B001B Passenger Seat Belt Pretensioner Deployment Loop 2 DTC B001A or B001B B0020 Passenger Frontal Deployment Loop Stage 2 DTC B0014 - B0045 B0021 Passenger Side Deployment Loop DTC B0014 - B0045 B0022 Passenger Seat Belt Pretensioner Deployment Loop DTC B0014 - B0045 B0023 Right Roof Rail Deployment Loop 1 DTC B0014 - B0045 B0025 Right Roof Rail Deployment Loop 2 DTC B0014 - B0045 B0052 Deployment Commanded DTC B0052 B0074 Passenger Occupant Classification Sensor Circuit DTC B0074 B0081 Passenger Presence System DTC B0081 (SDM) or DTC B0081 (Passenger Presence Detection Module) B0083 Front End Impact Sensor 1 DTC B0083 - B0088 B0084 Front End Impact Sensor 2 DTC B0083 - B0088 B0158 Outside Air Temperature Sensor Circuit DTC B0158 B0163 Passenger Compartment Temperature Sensor Circuit DTC B0163 or B0183 B0173 Upper Left Duct Air Temperature Sensor Circuit DTC B0173, B0178, or B3933

B0178 Lower Left Duct Air Temperature Sensor Circuit DTC B0173, B0178, or B3933 B0183 Solar Load Sensor Circuit DTC B0163 or B0183 B0193 Front Blower Motor Speed Circuit DTC B0193 with C67 or DTC B0193 with C68 B0228 Left Recirculate Position Feedback Circuit DTC B0228, B0413, B1395, or B374A with automtaic or DTC B0228, B0413, B1395, or B374A with manual B0283 Electric Rear Defrost Circuit DTC B0283 B0413 Main Temperature Control Feedback Circuit DTC B0228, B0413, B1395, or B374A with automtaic or DTC B0228, B0413, B1395, or B374A with manual B0550 Odometer Circuit General Memory Malfunction DTC B0550 B0685 Security System Indicator Circuit DTC B0685 B071F Transmission Range Indicator DTC B071F B0958 Parking Aid Rear Sensor Left Corner Circuit DTC B0958, B0959, B0960, or B0961 B0959 Parking Aid Rear Sensor Left Middle Circuit DTC B0958, B0959, B0960, or B0961 B0960 Parking Aid Rear Sensor Right Middle Circuit DTC B0958, B0959, B0960, or B0961 B0961 Parking Aid Rear Sensor Right Corner Circuit DTC B0958, B0959, B0960, or B0961 B096A Hazard Lamps Switch Backlight Circuit DTC B096A B098D Parking Aid Rear Display Indicator 1 Circuit DTC B098A - B098F B098E Parking Aid Rear Display Indicator 2 Circuit DTC B098A - B098F B098F Parking Aid Rear Display Indicator 3 Circuit DTC B098A - B098F B1000 Electronic Control Unit DTC B1000 B1001 Option Configuration DTC B1001 DTC B1001 B1015 Vehicle Identification Number Information Malfunction DTC B1015 B1019 System Malfunction Incorrect Component Installed DTC B1019 Lift Gate Module DTC B1019

B101D ECU Hardware DTC B101D B101E ECU Software DTC B101E B1020 Auxiliary Electronic Control Unit Performance DTC B1020 B125C Satellite Antenna 1 Circuit DTC B125C B1271 Theft Protection Active DTC B1271 B1278 Left Auxiliary Input Signal Circuit DTC B1278 or B1279 B1279 Right Auxiliary Input Signal Circuit DTC B1278 or B1279 B1287 Amplifier Control Signal Circuit DTC B1287 B1288 Video Display Mode Control Signal DTC B1288 B1289 Video Display Brightness Control Signal DTC B1289 B1325 Device Power Circuit DTC B1325 B1370 Control Module Ignition ON and Start Circuit DTC B1370 DTC B1370 - B1379, B1380 - B1389, or B1440 - B1443 B1380 Control Module Ignition Accessory Circuit DTC B1370 - B1379, B1380 - B1389, or B1440 - B1443 B138A Control Module Voltage Reference Output Circuit DTC B138A B1395 Control Module Voltage Reference Output Circuit DTC B0228, B0413, B1395, or B374A with automatic or DTC B0228, B0413, B1395, or B374A with manual DTC B1395 DTC B1395 B1405 Control Module Voltage Reference Output 2 Circuit DTC B1405 B1441 Control Module Ignition OFF, RUN, and Start Circuit DTC B1370 - B1379, B1380 - B1389, or B1440 - B1443 B1445 Control Module Voltage Output Circuit DTC B1445 B144A RUN Power Relay Circuit DTC B144A B144B RUN/CRNK Relay Circuit DTC B144B B147F Battery Saver Relay Reset Secondary Circuit DTC B147F B1480 Battery Rundown Protection Circuit DTC B1480 B1516 Battery Current Sensor DTC B1516 B1517 Battery Voltage DTC B1517 B151A Low Battery Capacity Detected DTC B151A B1527 High Parasitic Load Detected DTC B1527 B1529 Control Module Voltage Reference Output 5 Circuit DTC B1529

B153A Liftgate Latch Switch Signal Circuit Performance DTC B153A B153E Power Liftgate Angle Sensor DTC B153E B153F Liftgate Object Sensor Signal Circuit DTC B153F B154A Driver Mirror Internal Malfunction DTC B154A or B154B B154B Passenger Mirror Internal Malfunction DTC B154A or B154B B1735 Seat Front Up Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1740 Seat Front Down Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1745 Seat Rear Up Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1750 Seat Rear Down Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1755 Seat Assembly Forward Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1760 Seat Assembly Rearward Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1815 Seat Recline Forward Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1820 Seat Recline Rearward Switch Circuit DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815, or B1820 B1825 Driver Seat Recline Position Sensor Circuit DTC B1825, B2355, B2365, or B2375 B1925 Left Seat Cushion Heater Sensor Circuit DTC B1925 or B2170 (Without Memory) or DTC B1925 or B2170 (With Memory) B2170 Right Seat Cushion Heater Sensor Circuit DTC B1925 or B2170 (Without Memory) or DTC B1925 or B2170 (With Memory) B2345 Seat Heater Disable Circuit DTC B2345 (Without Memory) or DTC B2345 (With Memory) B2355 Driver Seat Front Vertical Position Sensor Circuit DTC B1825, B2355, B2365, or B2375 B2365 Driver Seat Rear Vertical Position Sensor Circuit DTC B1825, B2355, B2365, or B2375 B2375 Driver Seat Assembly Horizontal Position Sensor Circuit DTC B1825, B2355, B2365, or B2375 B2425 Left Seat Cushion Heater Circuit DTC B2425 or B2430 (Without Memory) or DTC B2425 or B2430 (With Memory) B242A Seat Heaters Common Circuit DTC B242A (Without Memory) or DTC B242A (With Memory) B2430 Right Seat Cushion Heater Circuit DTC B2425 or B2430 (Without Memory) or DTC B2425 or B2430 (With Memory) B2455 Cellular Phone Microphone Circuit DTC B2455 B2462 Global Positioning System Signal DTC B2462 (OnStar/Navigation GPS Antenna)

B2470 Cellular Phone Antenna Circuit DTC B2470 B2476 Cellular Phone Select Service Switch DTC B2476 or B2482 B2482 Cellular Phone Select Service Switch DTC B2476 or B2482 B2485 Wireless Communication Antenna Circuit DTC B2485 B2494 Liftgate Handle Switch Circuit DTC B2494 (Power Liftgate) or DTC B2494 (Manual Liftgate) B2495 Liftgate Latch Control Circuit DTC B2495 B252C Child Security Lock Circuit DTC B252C B2530 Front Fog Lamps Control Circuit DTC B2530 B2545 Backup Lamps Circuit DTC B2545 B2555 Passenger Compartment Lamp Control Circuit DTC B2555 B2575 Headlamps Control Circuit DTC B2575 or B2699 B257A Headlamp Switch Input Signals Correlation Malfunction DTC B257A B257B Lighting Control Switch Signal DTC B257B B2580 Headlamps High Beam Control Circuit DTC B2580 B2585 Left Park Lamps Control Circuit DTC B2585 or B3867 B258A Low Beam Control Circuit DTC B258A B2600 Left Daytime Running Lamps Control Circuit DTC B2600 B2605 Right Daytime Running Lamps Control Circuit DTC B2605 B260A Backlight and Display Dimming Request Circuit DTC B260A B2625 Display Dimming Pulse Width Modulation Output Circuit DTC B2625 B2645 Ambient Light Sensor Circuit DTC B2645 B2652 Passenger Compartment Dimming 3 Circuit DTC B2652 B2699 Right Headlamp Control Circuit DTC B2575 or B2699 B270A Park Lock Solenoid Control Circuit DTC B270A B2740 Front Fog Lamp Stitch Circuit DTC B2740 B2745 Traction Control Switch Circuit DTC B2745 B2750 Horn Relay Secondary Circuit DTC B2750 B2955 Security Sensor Data Circuit DTC B2955 B3006 Hood Ajar Circuit DTC B3006 B302A Mobile Telephone Communications Interface Requested Immobilization DTC B302A B3031 Security Controller in Learn Mode DTC B3031 B3055 No Transponder Modulation or No Transponder Malfunction DTC B3055

B3060 Unprogrammed Transponder Identification Code Received DTC B3060 B3101 Keyless Entry Data Link Circuit DTC B3101 B3105 Keyless Entry System Key Fobs DTC B3105 B3106 Keyless Entry Data Link DTC B3106 B3109 Keyless Entry Transmitter 1 Battery DTC B3109 - B3113 B3110 Keyless Entry Transmitter 2 Battery DTC B3109 - B3113 B310D Keyless Entry Transmitter 6 Battery DTC B310D - B310F B310E Keyless Entry Transmitter 7 Battery DTC B310D - B310F B310F Keyless Entry Transmitter 8 Battery DTC B310D - B310F B3111 Keyless Entry Transmitter 3 Battery DTC B3109 - B3113 B3112 Keyless Entry Transmitter 4 Battery DTC B3109 - B3113 B3113 Keyless Entry Transmitter 5 Battery DTC B3109 - B3113 B3125 Driver Door Only Unlock Circuit DTC B3125, B3130, or B3135 B3130 All Doors Unlock Circuit DTC B3125, B3130, or B3135 B3135 All Doors Lock Circuit DTC B3125, B3130, or B3135 B3140 Driver Unlock Switch Circuit DTC B3140 or B3150 B3150 Driver Lock Switch Circuit DTC B3140 or B3150 B316B Driver Window Switch DTC B316B, B317A, B318A, or B319A B317A Passenger Window Switch DTC B316B, B317A, B318A, or B319A B318A Left Rear Window Switch DTC B316B, B317A, B318A, or B319A B319A Right Rear Window Switch DTC B316B, B317A, B318A, or B319A B324A Rear Cargo Door Unlock Motor Circuit DTC B324A B3567 Info Display Select Switch Circuit DTC B3567 B3596 Hazard Lamps Request Circuit DTC B3596 B3600 Passenger Compartment Dimming Request Signal Circuit DTC B3600 B3622 Steering Wheel Controls Signal Circuit DTC B3622 B3650 High Beam Request Signal Circuit Performance - Signal Invalid DTC B2585 or B3867 B3664 Sunroof Position Select Switch High Signal Circuit DTC B3664 B3697 Sunroof Actuator DTC B3697 B369C Sunroof Ventilation Position Select Switch Circuit DTC B369C B370B Rear Wiper Function Control Circuit DTC B370B B3715 Windshield Wiper Relay Circuit DTC B3715 or B3875 B374A Air Flow Control Feedback Circuit DTC B0228, B0413, B1395, or B374A with automatic or DTC B0228, B0413, B1395, or B374A with manual

B3794 Cruise Control Function Request Circuit DTC B3794 B3806 High Beam and Headlamp Flash Select Circuit DTC B3806 B3811 Rear Washer Relay Circuit DTC B3811 B3867 Right Park Lamps Control Circuit DTC B2585 or B3867 B3873 Front Washer Relay Circuit DTC B3873 B3875 Windshield Wiper High Speed Relay Circuit DTC B3715 or B3875 B3881 Tail Lamp Circuit DTC B3881 or B3882 B3882 Right Tail Lamp Circuit DTC B3881 or B3882 B3883 License Plate Lamp Circuit DTC B3883 B3884 Center High Mounted Brake Lamp Circuit DTC B3884 B3887 Trailer Left Turn Signal Circuit DTC B3887 or B3888 B3888 Trailer Right Turn Signal Circuit DTC B3887 or B3888 B388A Trailer Park Lamps Circuit DTC B388A B3890 Trailer Backup Lamps Circuit DTC B3890 B3902 Incorrect Immobilizer Identifier Received DTC B3902 B3920 Group 1 Seat Motors Common Circuit DTC B3920 B3930 Child Security Lock Motors Circuit DTC B3930 B3933 Air Conditioning Evaporator Temperature Sensor Circuit DTC B3933 with C67 or DTC B0173, B0178, or B3933 B3935 Transponder Authentication Malfunction DTC B3935 B3948 Left Front Turn Signal Circuit DTC B3948 or B3949 B3949 Right Front Turn Signal Circuit DTC B3948 or B3949 B3950 Left Rear Turn Signal Circuit DTC B3950 or B3951 B3951 Right Rear Turn Signal Circuit DTC B3950 or B3951 B396A Liftgate Motor Control Circuit DTC B396A B396C Liftgate Mode Switch Circuit DTC B396C B396D Front Liftgate Actuator Switch Circuit DTC B396D B396E Rear Liftgate Actuator Switch Circuit DTC B396E B3976 Unconfigured Transponder DTC B3976 B3984 Device 1 Environment Identifier Not Programmable DTC B3984 C0000 Vehicle Speed Information Circuit Invalid Data DTC C0000 C0035 Left Front Wheel Speed Sensor Circuit DTC C0035, C0040, C0045, or C0050 C0040 Right Front Wheel Speed Sensor Circuit DTC C0035, C0040, C0045, or C0050 C0045 Left Rear Wheel Speed Sensor Circuit DTC C0035, C0040, C0045, or C0050
