2009 Ford Fusion - DE (CD338) Service & Repair Manual

100-00 Service Information 2009 Fusion/Milan/MKZ DESCRIPTION AND OPERATION Procedure revision date: 04/30/2012 Symbols Glossary Symbols are used inside the graphics and in the text area to enhance the information. Movement Symbols Movement symbols provide detailed information to a required component movement. These component movements can be rotational or 1-3 dimensional movements. Item Description 1 Minor component movement clockwise or counterclockwise 2 Major component movement clockwise or counterclockwise 3 Component movement to the left, right, up, or down

Item Description 4 Component movement towards or away 5 3 dimensional component movement 6 2 dimensional component movement 7 3 dimensional component rotation 8 3 dimensional component cycling Turn Symbols Turn symbols are used to provide further information on the direction or angle of component turns. Item Description 1 Turn the component clockwise through 45° 2 Turn the component counterclockwise through 45°

Item Description 3 Turn the component clockwise through 90° 4 Turn the component counterclockwise through 90° 5 Turn the component clockwise through 180° 6 Turn the component counterclockwise through 180° 7 Turn the component clockwise through 2 complete turns 8 Turn the component counterclockwise through 2 complete turns Steering Wheel Symbols Steering wheel symbols are used to provide further information to a required steering wheel position or steering column lock status.

Item Description 1 Steering wheel in straight ahead position 2 Steering column locked 3 Steering column unlocked 4 Rotate steering wheel 90° left from center 5 Rotate steering wheel 90° right from center 6 Turn steering wheel fully counterclockwise to stop

Item Description 7 Turn steering wheel fully clockwise to stop Body Types Body type symbols are used to identify different body configurations. Item Description 1 3, 4, 5-door body style 2 Wagon body style 3 Sport Utility Vehicle (SUV) body style 4 Coupe body style 5 Convertible body style 6 Van body style

Item Description 7 3, 4, 5-door body style - Top View 8 Wagon body style - Top View 9 Underbody view 10 Right-hand drive (RHD) vehicle 11 Left-hand drive (LHD) vehicle Gearshift Lever Position Symbols Gearshift lever position symbols are used to show the gear position required for the procedure.

Item Description 1 Set the selector lever to the park (P) position 2 Set the selector lever to the reverse (R) position 3 Set the selector lever to the neutral (N) position 4 Set the selector lever to the drive (D) position 5 Set the selector lever with manual shift option to the drive (D) position 6 Set the selector lever with manual shift option to the manual (M) position

Item Description 7 Set the selector lever with manual shift option to the shift down (-) position 8 Set the selector lever with manual shift option to the shift up (+) position 9 Set the manual shift lever to the neutral (N) position 10 Set the manual shift lever to indicated gear position (all possible gears shown here) Screwdriver Symbols The screwdriver symbols are used to indicate which screwdriver bit is required for the procedure step.

Item Description 1 Screwdriver 2 Phillips or cross-bladed screwdriver 3 Flat-bladed screwdriver 4 Hexagonal or Allen screwdriver 5 TORX screwdriver

Plier Symbols The plier symbols are used to indicate which plier is required for the procedure step. Item Description 1 Combination pliers 2 Side cutter pliers 3 Internal snap-ring pliers
