OTHER TYPES OF PARTS
Metric identification schemes vary by type of part, most often a variation of that used for bolts and nuts. Note
that many types of English and Metric fasteners carry no special identification if they are otherwise unique.
ENGLISH SYSTEM
Grade 1 or 2 Grade 5 Grade 8
English bolts: Identification marks on the bolt head represent Rockwell hardness. Generally, the bolt’s
grade is equal to the number of marks plus two. The higher the grade, the stronger the bolt.
METRIC SYSTEM
4.6 4.8 5.8 8.8 9.8 10.9
Metric bolts: Identification class numbers on bolt heads represent tensile strength. Higher numbers indicate
stronger bolts. Common metric fastener bolt strength properties are 9.8 and 10.9.
BOLT STRENGTH IDENTIFICATION
HEX NUT STRENGTH IDENTIFICATION
ENGLISH SYSTEM METRIC SYSTEM
Identification dots represent Rockwell hardness. The
nut’s grade is equal to the number of dots plus two.
The higher the grade, the stronger the nut.
METRICS
CLASS
10.9
CLASS
9.8
CLASS
8.8
–Stamped U-Nuts
–Studs, Large studs may carry the property class number.
Smaller studs use a geometric code on the end.
Identification class numbers on nuts represent tensile
strength. Higher numbers indicate stronger nuts. Nuts
may also have blue finish or paint daub on hex flat.
9
–Tapping, thread forming and certain
other case hardened screws.
2 MET
Grade 5 Grade 8
Revision 1, 8/10/2000
DESCRIPTION MULTIPLY BY FOR METRIC EQUIVALENT
Acceleration ft/s
2
0.3048 m/s
2
in/s
2
0.0254 m/s
2
Torque lb-in 0.11298 N
.
m
lb-ft 1.3558 N
.
m
Power horsepower 0.746 kW
Pressure or Stress inches of water 0.2491 kPa
psi 6.895 kPa
psi 0.069 bar
Energy or Work BTU 1055.0 Joules(J)
lb-ft 1.3558 Joules(J)
kiloWatt-hour 3,600,000 Joules(J)
or 3.6 x 10
6
Light foot candle 10.764 lumens/square meter (lm/m
2
)
Fuel Performance miles/gal 0.4251 kilometers/liter (km/L)
gal/mile 2.3527 liters/kilometer (L/km)
Velocity mph 1.6093 kilometers/hour (km/h)
Length inch 25.4 mm
foot 0.3048 m
yard 0.9144 m
mile 1.609 km
Area square inch (in
2
) 645.2 mm
2
6.45 cm
2
square ft (ft
2
) 0.0929 m
2
square yard 0.8361 m
2
Volume cubic inch (in
3
) 16387.0 mm
3
16.387 cm
3
0.0164 liters (L)
quart 0.9464 liters (L)
gallon 3.7854 liters(L)
cubic yard 0.7646 m
3
Mass pound 0.4536 kg
ton 907.18 kg
ton 0.9078 tonne (t)
Force kilogram 9.807 N
ounce 0.2780 N
pound 4.448 N
Temperature degree Farenheit (ËšF) (ËšF-32) 0.556 degree Celsius (ËšC)
METRICS
ENGLISH/METRIC CONVERSION
Revision 1, 8/10/2000
