DESCRIPTION AND OPERATION
Identification Codes
The vehicle identification number (VIN) for registration purposes is stamped onto the body on the right-
hand side floor panel.
The vehicle identification number is also located on the vehicle certification label. The vehicle
certification label is positioned on the left-hand B-pillar above the latch.
The visible VIN (label) is fastened to the instrument panel. It is positioned close to the windshield glass
on the left-hand side of the vehicle and is visible from the outside.
Visible VIN (label)
Vehicle Identification Number (VIN)
SECTION 100-01: Identification Codes 2001 Focus Workshop Manual
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
Vin Position 1, 2, and 3
Item Part Number Description
1 - World manufacturer identifier
2 - Manufacturer specification
3 - Line, series, body type
4 - Check digit
5 - Vehicle model year
6 - Production sequence number
7 - Assembly plant
8 - Engine type
9 - Restraint system type
World Manufacturer Identifier
Codes Manufacturer Make Type
1FA Ford Motor Company, USA Ford Passenger vehicle
1FM Ford Motor Company, USA Ford MPV
1FT Ford Motor Company, USA Ford Truck (complete vehicle)
1FD Ford Motor Company, USA Ford Incomplete vehicle
1FC Ford Motor Company, USA Ford Basic (stripped) Chassis
1FB Ford Motor Company, USA Ford Bus
1FF Ford Motor Company, USA Ford Motor vehicle equipment W/O Engine/Powertrain
(glider)
1ME Ford Motor Company, USA Mercury Passenger vehicle
1MH Ford Motor Company, USA Mercury Incomplete vehicle
1LN Ford Motor Company, USA Lincoln Passenger vehicle
1LJ Ford Motor Company, USA Lincoln Incomplete vehicle
1ZV Auto Alliance International, Inc Ford Passenger vehicle
1ZW Ford Motor Company, USA Mercury Passenger vehicle
2FA Ford Motor Company of
Canada, Ltd.
Ford Passenger vehicle
2FM Ford Motor Company of
Canada, Ltd.
Ford MPV
2FT Ford Motor Company of
Canada, Ltd.
Ford Truck (complete vehicle)
2FD Ford Motor Company of
Canada, Ltd.
Ford Incomplete vehicle
2FC Ford Motor Company of
Canada, Ltd.
Ford Basic (stripped) chassis
2FB Ford Motor Company of
Canada, Ltd.
Ford Bus
2FF Ford Motor Company of
Canada, Ltd.
Ford Motor vehicle equipment (W/O Engine/
Powertrain (Glider)
2ME Ford Motor Company of Mercury Passenger vehicle
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
VIN Position 4
VIN Position 5
Canada, Ltd.
2MH Ford Motor Company of
Canada, Ltd.
Mercury Incomplete vehicle
3FA Ford Motor Company (Mexico) Ford Passenger vehicle
3FB Ford Motor Company (Mexico) Ford Bus
3FC Ford Motor Company (Mexico) Ford Basic (stripped) chassis
3FE Ford Motor Company (Mexico) Ford Incomplete vehicle
3FM Ford Motor Company (Mexico) Ford MPV
3FT Ford Motor Company (Mexico) Ford Truck (complete vehicle)
3ME Ford Motor Company (Mexico) Mercury Passenger vehicle
4F2 Ford Motor Company, USA Mazda MPV
4F3 Ford Motor Company, USA Mazda Incomplete vehicle
4F4 Ford Motor Company, USA Mazda Truck (complete vehicle)
4M2 Ford Motor Company, USA Mercury MPV
4M3 Ford Motor Company, USA Mercury Incomplete vehicle
4M4 Ford Motor Company, USA Mercury Truck (complete vehicle)
4N2 Ford Motor Company, USA Nissan MPV
4N3 Ford Motor Company, USA Nissan Incomplete vehicle
4N4 Ford Motor Company, USA Nissan Truck complete vehicle
KNJ Kia Motors Inc. Korea Ford Passenger vehicle (imported aspire)
Restraint System Type
Code Description
B Active belts (all positions)
F Active belts (all positions) and front air bags (driver and passenger)
H Active belts (all positions) and front and side air bags (driver and passenger)
Manufacturer Specification
Code Vehicle
M Passenger
vehicle
Lincoln, Mercury, North American Vehicles
P Passenger
vehicle
Ford North American vehicles
T Passenger
vehicle
All passenger vehicles imported from outside North America or non-Ford built
passenger vehicle marketed by Ford in North America
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
VIN Position 6 and 7
VIN Position 8
VIN Position 9
VIN position 9 is a check digit
VIN Position 10
VIN Position 11
Line, Series and Body Type
Code Line Series Additional Optional Exterior Nameplate Body Type Body Code
30 Focus ECO - 3-door ECO
31 Focus ZX3 - 3-door ZX3
33 Focus LX - 4-door LX4
34 Focus SE - 4-door SE4
36 Focus ZTS - 4-door LTS
38 Focus SE - wagon SEW
Engine Type
Code Displacement Liters Displacement CID Cylinders Fuel Manufacturer
P 2.0 SPI 121 4 Gasoline Ford
3 2.0 Zetec 121 4 Gasoline Ford
Year of Manufacture
Code Year of Manufacture
Y 2000
1 2001
2 2002
3 2003
4 2004
5 2005
Assembly Plant
Code Assembly Plant
A Atlanta: Hapeville, Georgia
B Oakville: Oakville, Ontario
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
VIN Position 12 through 17
Vehicle Certification (VC) Label (Typical)
The vehicle certification label also contains the 17 character vehicle identification number. This number
is used for warranty identification of the vehicle.
Vehicle Certification Label
D Ohio: Avon Lake, Ohio
F Dearborn: Dearborn, Michigan
G Chicago: Chicago, Illinois
H Lorain: Lorain, Ohio
J IMMSA: Monterrey, Mexico
K Kansas City: Claycomo, Missouri
N Norfolk: Norfolk, Virginia
P Twin Cities: St. Paul, Minnesota
R Hermosillo: Hermosillo, Mexico
T Edison: Edison, New Jersey
U Louisville: Louisville, Kentucky
W Wayne: Wayne, Michigan
X St. Thomas: Talbotville, Ontario
Y Wixom: Wixom, Michigan
Z St. Louis: Hazelwood, Missouri
5 AAI: Flat Rock, Michigan
6 Mazda-Kia: Kyrung Ki-Do Korea
Production Sequence Number
Sequence Number
100,001 through 599,999 - Ford Division Vehicles
600,001 through 999,999 - Lincoln and Mercury Division vehicles
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
Exterior Paint Color Codes
Item
Part
Number Description
1 - Name and location of manufacturer
2 - Gross vehicle weight ratings in pounds (LB) and
Kilograms (KG)
3 - Accessory reserve load codes
4 - District/special order codes
5 - Sales region codes
6 - Suspension identification
7 - Transmission/transaxle codes
8 - Axle ratio codes
9 - Radio type codes
10 - Tape stripe/paint stripe codes
11 - Interior trim codes (first code letter = fabric and seat
type, second code letter = color
12 - Brake type codes
13 - Exterior paint codes
14 - Vehicle identification number
15 - Rear gross axle weight ratings in pounds (LB) and
Kilograms (KG)
16 - Front gross axle weight ratings in pounds (LB) and
Kilograms (KG)
17 - Build date
Code Color
TS Silver Frost
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
Interior Trim (Fabric) Codes
Brake Type Codes
Interior Color
BL Harvest Gold
FL Toreador Red
K6 Atlantic Blue
SU Amazon Green
BG Bright Amber
LV Light Sapphire Blue
YZ Performance White
E4 Vermillion Solid
UA Ebony Solid
MK Twilight Blue
K7 Bright Atlantic Blue
Code Trim Scheme Fabric Seat Type Trim Color
DA Shadow/Oasis Sport seat Medium dark graphite
DW Shadow/Oasis Sport seat Midnight black
EA Finnesse/Oasis Individual Medium dark graphite
EW Finnesse/Oasis Individual Midnight black
EH Finnesse/Oasis Individual Medium parchment
CA Kirk/Oasis Individual Medium dark graphite
CH Kirk/Oasis Individual Medium parchment
8A Leather/Leather Individual Medium dark graphite
8H Leather/Leather Individual Medium parchment
Code Brake Type
2 Anti-lock brakes (ABS)
Non-ABS, FR disk/RR drum
Code Trim Color
A Medium Dark Graphite
W Midnight Black
H Medium Parchment
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
Axle Ratio Codes
Transaxle Codes
Code Axle Ratio
II 3:61 SPI Manual
NN 3:693 SPI Automatic
UU 3:820 SPI Manual
WW 3:904 SPI Automatic
Code Axle Ratio
5 iB5 Manual
A FN Automatic
M MTX75 Manual
30.01. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_4704/S1Y~us~en~...
DESCRIPTION AND OPERATION
Jacking
Jacking Points
WARNING: Always position the vehicle on a hard level surface. If the vehicle must be
jacked up on a soft surface use load spreading blocks under the jack. Always use a chock at
the wheel diagonally opposite the jack. Failure to follow these instructions may result in
personal injury.
CAUTION: It is not recommended that the vehicle is jacked or lifted on the rear
suspension crossmember. If the vehicle must be lifted on the crossmember, make sure that the
jack or lift is positioned centrally. Failure to follow these instructions will result in deformation
of the closing plate which will weaken the crossmember.
Before commencing any repairs that involve jacking the vehicle, it is essential that the following
instructions are fully understood.
It is important that only the correct jacking and support locations are used at all times.
The vehicle may be lifted by positioning a floor jack under the outer rocker panel and supported by
vehicle axle stands. The location is identified behind a removable cover (if equipped), a notch in the
outer rocker panel indicates where the jack should be positioned. Use a cushioned pad, if possible, to
avoid damaging body paint.
SECTION 100-02: Jacking and Lifting 2001 Focus Workshop Manual
