DESCRIPTION AND OPERATION
Identification Codes
The vehicle identification number (VIN) is a 17-digit combination of letters and numbers. The VIN is
stamped on a metal tab riveted on the instrument panel, top upper left of the dash. The VIN number is
also found on the vehicle certification (VC) label.
Vehicle Identification Number
The first three vehicle identification number (VIN) positions are the world manufacturer identifier.
1FT — Ford Motor Company, USA, truck, completed vehicle
2FT — Ford Motor Company, Canada, truck, completed vehicle
3FT — Ford Motor Company, Mexico, truck, completed vehicle
SECTION 100-01: Identification Codes 1999 F150/250 Workshop Manual
Item Description
1 World manufacturer identifier
2 Brake type and gross vehicle weight rating (GVWR)
3 Vehicle line, series, body type
4 Engine type
5 Check digit
6 Model year
7 Assembly plant
8 Production sequence number
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
The fourth VIN position is the vehicle brake type and GVW code (all vehicles use hydraulic brakes).
3 — 6,600 pounds, F-250 under 8,500 pounds GVWR
Z — 5,001-6,000 pounds with second generation air bags
R — 6,001-7,000 pounds with second generation air bags
P — 7,001-8,000 pounds with second generation air bags
D — 5,001-6,000 pounds with first generation air bags
E — 6,001-7,000 pounds with first generation air bags
F — 7,001-8,000 pounds with first generation air bags
Positions 5 through 7 indicate vehicle line, series and body type.
F07 — F-150 Regular Cab, 4x2 (Flareside)
F08 — F-150 Regular Cab, 4x4 (Flareside)
F17 — F-150 Regular Cab, 4x2 (Styleside)
F18 — F-150 Regular Cab, 4x4 (Styleside)
F27 — F-250 Regular Cab, 4x2 (Styleside)
F28 — F-250 Regular Cab, 4x4 (Styleside)
X07 — F-150 SuperCab, 4x2 (Flareside)
X08 — F-150 SuperCab, 4x4 (Flareside)
X17 — F-150 SuperCab, 4x2 (Styleside)
X18 — F-150 SuperCab, 4x4 (Styleside)
X27 — F-250 SuperCab, 4x2 (Styleside)
X28 — F-250 SuperCab, 4x4 (Styleside)
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
The eighth VIN position is the engine displacement and number of cylinders.
2 — 4.2L, OVH, EFI, V6 Gas
W — 4.6L, Modular SOHC, EFI, V8, Gas
M — 5.4L, SOHC, Natural Gas
Z — 5.4L, Bi-Fuel (NGV/Propane)
3 — 5.4L, 2V, SOHC, SFI, V8, Gas
L — 5.4L, 2V, SOHC, EFI, V8, Gas
The ninth VIN position is a check digit.
The tenth VIN position is the model year code.
X — 1999
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
The eleventh VIN position is the assembly plant code.
L — Michigan Truck (Wayne, Michigan)
S — Allen Park (Allen Park, Michigan)
C — Ontario Truck (Oakville, Ontario)
E — Kentucky Truck (Jefferson County, Kentucky)
K — Kansas City (Claycomo, Missouri)
N — Norfolk (Norfolk, Virginia)
M — Cuautitlan (Cuautitlan, Mexico)
The last six VIN positions are an alphanumeric code for the vehicle build sequence. This is also the
vehicle serial and warranty number.
A00000-E99999 — Ford Division
Vehicle Certification (VC) Label
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
The vehicle certification (VC) label contains the manufacturer name, the month and year of
manufacture, the certification statement, and the VIN. It also includes gross vehicle weight ratings
(GVWR).
Vehicle Certification (VC) Label — Canada (Typical)
Item Description
1 Exterior paint code
2 Region code
3 Domestic special order code
4 Wheelbase code
5 Brake code
6 Interior trim code
7 Tape/paint pinstripe code
8 Radio code
9 Axle code
10 Transmission code
11 Spring code
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
Paint Codes
Refer to the paint manufacturer code book for information.
Radio Codes
7 — AM/FM stereo with clock
9 — AM/FM stereo cassette with clock
K — AM/FM stereo cassette with CD player
Y — Delete standard radio with clock
G — Delete radio chassis only, AM/FM stereo, all other components installed (F-Series,
Ranger, Econoline)
8 — Electronic, Premium AM/FM stereo cassette
5 — Electronic, Premium AM/FM stereo cassette
Axle Codes
The following lists the gear ratios on axles.
18 — 3.08, non-limited slip, F-150
19 — 3.55, non-limited slip, F-150, F-250
26 — 3.73, non-limited slip, F-150, F-250
27 — 3.31, non-limited slip, F-150, F-250
28 — 3.73, non-limited slip, F-150, F-250
H9 — 3.55, limited slip, F-150, F-250
B6 — 3.73, limited slip, F-150, F-250
Transmission Codes
E — Four-speed automatic overdrive (4R100)
M — Five-speed manual overdrive (Mazda M5R2-C)
U — Four-speed automatic (AODE-W/4R70W)
7 — Four-speed automatic (NAAO 4R100)
Spring Codes
The following lists available spring codes.
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
Front Springs
Base part number — 5310 (RH/LH)
Torsion Bars
Base part number — 5B326 (RH)
Base part number — 5B327 (LH)
Load Leveling Suspension
P
Rear Springs
Base part number — 5560
Interior Trim Codes
The following lists the interior trim and interior color codes.
Interior Trim
V — Vinyl bench
C — Cloth bench
F — Cloth captain's chairs with console
M — Cloth 60/40
A — Vinyl full bench
H — Leather captain's chairs with console
E — Leather 40/60
Interior Color Codes
X — Medium Prairie Tan
2 — Medium Graphite
T — Dark Graphite
R — Dark Denim
Tape Stripe Codes
D — Silver Metallic/Medium Platinum Metallic
E — Light Prairie Tan/Medium Palomino (XL and XLT)
G — Deep Crystal Blue/Light Portofino (XL and XLT)
H — Silver Metallic/Deep Crystal Blue (XL and XLT)
J — Light Prairie Tan/Medium Palomino (XL and XLT)
K — Deep Crystal Blue/Gold Metallic (XL and XLT)
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
L — Deep Crystal Blue (upper), Medium Dark Woodrose (lower), Lariat
M — Jewel Green/Gold Metallic (upper and lower) Lariat
N — Toreador/Gold Metallic (upper and lower) Lariat
B — Blue Sport (STX Package)
X — Tapestripes deleted
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
DESCRIPTION AND OPERATION
Jacking
WARNING: The electrical power to the air suspension system must be shut down prior to
hoisting, jacking or towing an air suspension vehicle. This can be accomplished by turning off
the air suspension switch located in the RH kick panel area. Failure to do so may result in
unexpected inflation or deflation of the air springs which may result in shifting of the vehicle
during these operations.
WARNING: Do not run the engine when jacking the vehicle. The wheels contacting the
ground could cause the vehicle to move.
WARNING: Support the vehicle prior to performing any procedure requiring the vehicle to
be jacked off the ground.
WARNING: Make sure the jack and jack stands are properly located to prevent the vehicle
from falling.
WARNING: Wheel chocks should be used to prevent the vehicle from rolling and falling
off the jack.
CAUTION: Never use a halfshaft as a lifting point.
Jacking Points — Front, 4x4
The jacking point is a raised boss located on the front suspension lower arm (3079).
Jacking Points — Front, 4x2
SECTION 100-02: Jacking and Lifting 1999 F150/250 Workshop Manual
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
The jacking point is a flat portion on the frame indicated by the arrow cut out. The jacking point is
located behind the front tire and wheel assembly.
Jacking Points — Rear
CAUTION: Never use the differential housing as a lifting point.
The rear jacking points are located on the rear axle (4001).
11.01. 2012 file:///C:/Ford/1996-1999/tsocache/SHEF_5460/SX1~us~en~...
