7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Anti-Lock Brake Safety Precautions file:///C:/in856565.html 1/1 Back To Article GENERAL INFORMATION Anti-Lock Brake Safety Precautions * PLEASE READ THIS FIRST * This article is intended for general information purposes only. This information may not apply to all makes and models. If vehicle is equipped with Anti-Lock Brake System (ABS), refer to appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES section for description, operation, depressurizing, testing, system bleeding, trouble shooting and servicing of specific system. ANTI-LOCK BRAKE SAFETY PRECAUTIONS WARNING: Failure to depressurize ABS could lead to physical injury. NEVER open a bleeder valve or loosen a hydraulic line while ABS is pressurized. NEVER disconnect or reconnect any electrical connectors while ignition is on. Damage to ABS control unit may result. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI- LOCK BRAKE SYSTEM article in the BRAKES section. Only use specially designed brake hoses/lines on ABS equipped vehicles. DO NOT tap on speed sensor components (sensor, sensor rings). Sensor rings must be pressed into hubs, NOT hammered into hubs. Striking these components can cause demagnetization or a loss of polarization, affecting the accuracy of the speed signal returning to the ABS control unit. DO NOT mix tire sizes. Increasing the width, as long as tires remain close to the original diameter, is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings. DO NOT contaminate speed sensor components with grease. Only use recommended coating, when system calls for an anti-corrosion coating. When speed sensor components have been removed, ALWAYS check sensor-to-ring air gaps when applicable. These specifications can be found in each appropriate article. ONLY use recommended brake fluids. DO NOT use silicone brake fluids in an ABS equipped vehicle. When installing transmission devices (CB's, telephones, etc.) on ABS equipped vehicles, DO NOT locate the antenna near the ABS control unit (or any control unit). Disconnect all on-board computers, when using electric welding equipment. DO NOT expose the ABS control unit to prolonged periods of high heat (185 Â°F/85Â°C for 2 hours is generally considered a maximum limit).

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Clutch Trouble Shooting file:///C:/in436340.html 1/2 Back To Article GENERAL INFORMATION Clutch Trouble Shooting * PLEASE READ THIS FIRST * NOTE: This is GENERAL information. This article is not intended to be specific to any unique situation or individual vehicle configuration. For model- specific information see appropriate articles where available. ALL MODELS NOTE: This is GENERAL information. This article is not intended to be specific to any unique situation or individual vehicle configuration. For model- specific information see appropriate articles where available. CLUTCH TROUBLE SHOOTING Problem & Possible Cause Action Clutch Chatters/Grabs Incorrect Pedal Adjustment Adjust Free Play Worn Input Shaft Spline Replace Input Shaft Binding Pressure Plate Replace Pressure Plate Binding Throw-Out Lever Check Throw-Out Lever, Check Throw- Out Bearing, Check Bearing Retainer Uneven Pressure Plate Contact With Flywheel Align/Replace Worn Parts Transmission Misaligned Align Transmission Worn Pressure Plate Replace Clutch Assembly Oil-Saturated Disc Replace Clutch Assembly, Repair Oil Leak Loose Engine Mounts Replace Engine Mounts Clutch Pedal Sticks Down Clutch Cable Binding Replace Clutch Cable Weak Pressure Plate Springs Replace Clutch Assembly Binding Clutch Linkage Lubricate Linkage Broken Clutch Pedal Return Spring Replace Return Spring Clutch Will Not Release Oil-Saturated Disc Replace Clutch Assembly, Repair Oil Leak Defective Disc Face Replace Clutch Assembly Disc Sticking on Input Shaft Splines Replace Disc/Input Shaft Binding Pilot Bearing Replace Pilot Bearing Faulty Clutch Master Cylinder Replace Master Cylinder

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Clutch Trouble Shooting file:///C:/in436340.html 2/2 Problem & Possible Cause Action Faulty Clutch Slave Cylinder Replace Slave Cylinder Blown Clutch Hose Replace Hose Sticky Throw-Out Bearing Sleeve Clean/Lube Sleeve Clutch Cable Binding Replace Clutch Cable Broken/Loose Bellhousing Check Bellhousing Rattling/Squeaking Broken Throw-Out Lever Return Spring Replace Return Spring Faulty Throw-Out Bearing Replace Throw-Out Bearing Faulty Clutch Disc Replace Clutch Disc Faulty Pilot Bearing Replace Pilot Bearing Worn Throw-Out Bearing Replace Throw-Out Bearing Dry Bearing Retainer Slide For Throw-Out Bearing Sleeve Lubricate Slide Slipping Faulty Pressure Plate Replace Clutch Assembly Worn Clutch Disc Replace Clutch Assembly Incorrect Alignment Realign Clutch Assembly Faulty Clutch Slave Cylinder Replace Slave Cylinder No Pedal Pressure Leaky Hydraulic System Check Clutch Master Cylinder, Check Clutch Slave Cylinder Check Clutch Hose Broken Clutch Cable Replace Clutch Cable Faulty Throw-Out Lever Replace Throw-Out Lever Broken Clutch Linkage Repair Clutch Linkage Noisy Clutch Pedal Faulty Safety Switch Check/Replace Switch Noisy Self-Adj. Ratchet Replace Ratchet Dry Throw-Out Bearing Replace Throw-Out Bearing Dry Pilot Bearing Replace Pilot Bearing Worn Input Shaft Replace Input Shaft

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Commonly Used Abbreviations file:///C:/in702588.html 1/20 Back To Article GENERAL INFORMATION Commonly Used Abbreviations * PLEASE READ THIS FIRST * NOTE: This article is intended for general information purposes only. This information may not apply to all makes and models. Not all abbreviations are covered as manufacturers add new ones every day. "A" A Amperes ABS Anti-Lock Brakes ABRS Air Bag Restraint System AC Alternating Current A/C Air Conditioning ACCS A/C Cycling Switch ACCUM Accumulator ACCY Accessory ACT Air Charge Temperature Sensor ADJ Adjust or Adjustable ADV Advance AFS Airflow Sensor

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Commonly Used Abbreviations file:///C:/in702588.html 2/20 AI Air Injection AIR or A.I.R. Air Injection Reactor AIS Air Injection System Alt. Alternator or Altitude Amp./amp/amps Ampere ASCS Air Suction Control Solenoid ASD Auto Shutdown ASDM Air Bag System Diagnostic Module ASV Air Suction Valve A/T Automatic Transmission/Transaxle ATC Automatic Temperature Control ATDC After Top Dead Center ATF Automatic Transmission Fluid ATS Air Temperature Sensor Aux. Auxiliary Avg. Average AXOD

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Commonly Used Abbreviations file:///C:/in702588.html 3/20 Automatic Transaxle Overdrive (Ford Models Only) "B" BAC By-Pass Air Control BAP Barometric Absolute Pressure Sensor BARO Barometric Batt. Battery Bbl. Barrel (Example: 4-Bbl.) BCM Body Control Module BHP Brake Horsepower BMAP Barometric and Manifold Absolute Pressure Sensor BOO Brake On-Off Switch B/P Backpressure BPS Barometric Pressure Sensor BPT Backpressure Transducer BTDC Before Top Dead Center BTSI Brake Transmission Shift Interlock BTU British Thermal Unit BVSV

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Commonly Used Abbreviations file:///C:/in702588.html 4/20 Bimetallic Vacuum Switching Valve "C" Â° C Celsius (Degrees) Calif. California CANP Canister Purge CARB California Air Resources Board CAT Catalytic Converter CB Circuit Breaker CBD Closed Bowl Distributor cc cubic centimeter CCC Close Coupled Catalyst CCC Computer Command Control CCD Computer Controlled Dwell CCOT Cycling Clutch Orifice Tube CCW Counterclockwise CDI Capacitor Discharge Ignition CEC Computerized Engine Control CID

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Commonly Used Abbreviations file:///C:/in702588.html 5/20 Cubic Inch Displacement cm Centimeter CMP Camshaft Position Sensor CO Carbon Monoxide CO 2 Carbon Dioxide Cont. Continued CONV Convertible CP Canister Purge CKP Crankshaft Position Sensor CTS Coolant Temperature Sensor Cu. In. Cubic Inch CVC Constant Vacuum Control CV Check Valve or Constant Velocity CW Clockwise CYL or Cyl. Cylinder C 3 I Computer Controlled Coil Ignition C 4 Computer Controlled Catalytic Converter

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Commonly Used Abbreviations file:///C:/in702588.html 6/20 "D" "D" Drive DC Direct Current Or Discharge DDD Dual Diaphragm Distributor Def. Defrost Defog. Defogger DERM Diagnostic Energy Reserve Module DFI Digital Fuel Injection Diag. Diagnostic DTC Diagnostic Trouble Code DIC Driver Information Center DIS Distributorless Ignition System DIST Distribution DLC Data Link Connector DOC Diesel Oxidation Catalyst DOHC Double Overhead Cam DOT Department of Transportation

7/24/2019 MITCHELL 1 ARTICLE - GENERAL INFORMATION Commonly Used Abbreviations file:///C:/in702588.html 7/20 DPF Diesel Particulate Filter DRB-II Diagnostic Readout Box DVOM Digital Volt-Ohmmeter "E" EACV Electric Air Control Valve EATX Electronic Automatic Transaxle EBCM Electronic Brake Control Module EBL Electronic Back Light ECM Engine Control Module ECT Engine Coolant Temperature Sensor EDIS Electronic Distributorless Ignition System EEC Electronic Engine Control EECS Evaporative Emission Control System EEPROM Electronically Erasable PROM EFE Early Fuel Evaporation EGO Exhaust Gas Oxygen Sensor EGR Exhaust Gas Recirculation
