2011 Ford Escape - M7 Service & Repair Manual

100-00 Service Information 2011 Escape, Mariner, Escape Hybrid, Mariner Hybrid DESCRIPTION AND OPERATION Procedure revision date: 10/05/2012 Symbols Glossary Symbols are used inside the graphics and in the text area to enhance the information. Movement Symbols Movement symbols provide detailed information to a required component movement. These component movements can be rotational or 1-3 dimensional movements. Item Description 1 Minor component movement clockwise/counterclockwise 2 Major component movement clockwise/counterclockwise 3 Component movement to the left/right/up/down

Item Description 4 Component movement towards/away 5 3 dimensional component movement 6 2 dimensional component movement 7 3 dimensional component rotation 8 3 dimensional component cycling Turn Symbols Turn symbols are used to provide further information on the direction or angle of component turns. Item Description 1 Turn the component clockwise through 45° 2 Turn the component counterclockwise through 45°

Item Description 3 Turn the component clockwise through 90° 4 Turn the component counterclockwise through 90° 5 Turn the component clockwise through 180° 6 Turn the component counterclockwise through 180° 7 Turn the component clockwise through 2 complete turns 8 Turn the component counterclockwise through 2 complete turns Steering Wheel Symbols Steering wheel symbols are used to provide further information to a required steering wheel position or steering column lock status.

Item Description 1 Steering wheel in straight ahead position 2 Steering column lock locked 3 Steering column lock unlocked 4 Turn the steering wheel to the 90° left position 5 Turn the steering wheel to the 90° right position 6 Turn the steering wheel to the left-hand end position

Item Description 7 Turn the steering wheel to the right-hand end position Body Types Body type symbols are used to identify different body configurations. Item Description 1 3, 4, 5-door body style 2 Wagon body style 3 Sport utility vehicle body style 4 Coupe body style 5 Convertible body style 6 Van body style

Item Description 7 3, 4, 5-door body style - Top View 8 Wagon body style - Top View 9 Underbody view 10 Right-hand drive (RHD) vehicle 11 Left-hand drive (LHD) vehicle Gearshift lever and selector lever position symbols Gearshift lever and selector lever position symbols are used to show the lever position that is required to be selected to carry out a procedure step.

Item Description 1 Replaced by symbol 9 2 Replaced by symbol 10 3 Replaced by symbol 11 4 Replaced by symbol 12 5 Replaced by symbol 12 6 Replaced by symbol 14

Item Description 7 Replaced by symbol 15 8 Replaced by symbol 16 9 Set the selector lever to the park (P) position 10 Set the selector lever to the reverse ( R ) position 11 Set the selector lever to the neutral (N) position 12 Set the selector lever to the drive (D) position 13 Set the selector lever to the drive (S) position 14 Set the selector lever to the drive (M) position 15 Set the selector lever to the drive (-) position 16 Set the selector lever to the drive (+) position 17 Set the gearshift lever to the neutral (N) position 18 Further gearshift lever positions that may appear in Illustrations Screwdriver symbols The screwdriver symbols are used to show which screwdriver bit is recommended to carry out a procedure step.

Item Description 1 Screwdriver 2 Cross bladed screwdriver 3 Flat-bladed screwdriver 4 Hexagonal screwdriver 5 TORX screwdriver

Pliers Symbols The plier symbols are used to show which pliers is recommended to carry out a procedure step. Item Description 1 Combination pliers 2 Side cutter pliers 3 Securing ring - inner
