2006-2014 Ford Edge Service & Repair Manual

2008 ENGINE 3.5L - Edge & MKX SPECIFICATIONS MATERIAL SPECIFICATIONS GENERAL SPECIFICATIONS Item Specification Fill Capacity Motorcraft High Performance Engine RTV Silicone TA-357 WSE-M4G323-A6 - Motorcraft Metal Surface Prep ZC-31-A - - Motorcraft Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) WSS-M97B51-A1 - Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent WSS-M2C930-A 5.2L (5.5 qt) includes filter change Silicone Gasket Remover ZC-30 - - Thread Sealant with PTFE TA-24 WSK-M2G350-A2 - Item Specification Engine Displacement 3.5L (4V) (214 CID) No. cylinders 6 Bore/stroke 92.5/86.7 mm (3.641/3.413 in) Fire order 1-4-2-5-3-6 Oil pressure Minimum 30 psi @ 1,500 rpm with engine at normal operating temperature Spark plug AYSF-22FM Gap = 1.29-1.45 mm (0.051-0.057 in) Compression ratio 10.3:1 Engine weight (without accessory drive components) 161 kg (355 lb) Engine and transaxle weight (without accessory 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

drive components) 260.8 kg (575 lb) Cylinder Head and Valve Train Cylinder head gasket surface flatness a Combustion chamber volume 55.84 cc (3.41 CI) Valve tappet clearance - intake 0.15-0.25 mm (0.006-0.01 in) Valve tappet clearance - exhaust 0.300-0.400 mm (0.0118-0.0157 in) Valve guide bore inner diameter 5.519-5.549 mm (0.217-0.218 in) Valve stem diameter - intake 5.479-5.497 mm (0.2157-0.2164 in) Valve stem diameter - exhaust 5.466-5.484 mm (0.2151-0.2159 in) Valve stem-to-guide clearance - intake 0.022-0.070 mm (0.0008-0.0027 in) Valve stem-to-guide clearance - exhaust 0.035-0.083 mm (0.0013-0.032 in) Valve head diameter - intake 36.82-37.18 mm (1.44-1.46 in) Valve head diameter - exhaust 30.82-31.18 mm (1.21-1.22 in) Valve face runout 0.05 mm (0.0001 in) Valve face angle 90.50-91.50 degrees Valve seat width - intake 1.3-1.5 mm (0.051-0.059 in) Valve seat width - exhaust 1.4-1.6 mm (0.055-0.062 in) Valve seat runout 0.04 mm (0.0001 in) MAX Valve seat angle 89.0-91.0 degrees Valve spring free length (approx.) 48.4 mm (1.90 in) Valve spring compression pressure (N @ spec. length) 510 N @ 27.32 mm (115 lbs @ 1.08 in) Valve spring installed height 37.0 mm (1.45 in) Valve spring installed height pressure (N @ spec. length) 235 N @ 37.0 mm (53 lbs @ 1.45 in) Valve spring installed pressure - service limit 10% force loss @ specified height Camshaft Theoretical valve lift @ 0 lash 9.6798 mm (0.38 in) Lobe lift - intake 9.6798 mm (0.38 in) Lobe lift - exhaust 9.6798 mm (0.38 in) 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

Allowable lobe lift loss 0.062 mm (0.0024 in) Camshaft journal bore inside diameter - 1st journal 31.0375-31.0625 mm (1.221-1.222 in) Camshaft journal bore inside diameter - intermediate journals 25.9875-26.0125 mm (1.023-1.024 in) Camshaft bearing outside diameter - 1st journal 30.993-31.013 mm (1.2202-1.2209 in) Camshaft bearing outside diameter - intermediate journals 25.937-25.963 mm (1.021-1.022 in) Camshaft journal-to-bearing clearance, 1st journal - service limit 0.070 mm (0.0027 in) MAX Camshaft journal-to-bearing clearance, intermediate journals - service limit 0.0755 mm (0.0029 in) MAX Runout 0.040 mm (0.0015 in) MAX End play - standard 0.032-0.170 mm (0.0012-0.0066 in) End play - service limit 0.190 mm (0.00748 in) MAX Cylinder Block Cylinder bore diameter - grade 1 - Cylinder bore diameter - grade 2 - Cylinder bore diameter - grade 3 - Cylinder bore maximum taper - Cylinder bore maximum out-of-round - limit - Cylinder bore maximum out-of-round - service limit - Main bearing bore inside diameter 72.400-72.424 mm (2.8503-2.8513 in) Head gasket surface flatness - Head gasket surface finish - Crankshaft Main bearing journal diameter 67.5 mm (2.657 in) Main bearing journal maximum taper 0.004 mm (0.00015 in) Main bearing journal maximum out-of-round 0.006 mm (0.00023 in) Main bearing journal-to-cylinder block clearance - Connecting rod journal diameter 55.983-56.003 mm (2.204-2.205 in) Connecting rod journal maximum taper 0.004 mm (0.00015 in) Connecting rod journal maximum out-of-round 0.006 mm (0.00023 in) Crankshaft maximum end play 0.101-0.291 mm (0.0039-0.0114 in) Piston and Connecting Rod Piston diameter - single grade 92.476-92.490 mm (3.6407-3.6413 in) Piston-to-cylinder bore clearance 0.010 to 0.044 mm (0.0003-0.0017 in) Piston ring end gap - compression (top, gauge 0.15-0.25 mm 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

diameter) (0.0059-0.0098 in) Piston ring end gap - compression (bottom, gauge diameter) 0.30-0.55 mm (0.0118-0.0216 in) Piston ring end gap - oil ring (steel rail, gauge diameter) 0.15-0.45 mm (0.0059-0.0177 in) Piston ring groove width - compression (top) 1.230-1.25 mm (0.0484-0.0492 in) Piston ring groove width - compression (bottom) 1.530-1.55 mm (0.0602-0.0610 in) Piston ring groove width - oil ring 2.53-2.55 mm (0.0996-0.1003 in) Piston ring width - upper comp ring 1.17-1.19 mm (0.0460-0.0468 in) Piston ring width - lower comp ring 1.47-1.49 mm (0.0578-0.0586 in) Piston ring-to-groove clearance (upper and lower compression rings) 0.040-0.080 mm (0.0015-0.0031 in) Piston pin bore diameter 23.002-23.006 mm (0.9055-0.9057 in) Piston pin diameter 22.998-23.000 mm (0.9054-0.9055 in) Piston pin length 55.975 mm (2.203 in) Piston pin-to-piston fit 0.002 to 0.008 mm (0.00007-0.0003 in) Piston-to-connecting rod clearance 2.7 mm (0.1 in) Connecting rod-to-pin clearance - standard 0.007-0.021 mm (0.0002-0.0008 in) Connecting rod-to-pin clearance - service limit - Connecting rod pin bore diameter 23.007-23.019 mm (0.905-0.906 in) Connecting rod length (center-to-center) 152.68 mm (6.01 in) Connecting rod maximum allowed bend 0.038 mm (0.0014 in) Connecting rod maximum allowed twist 0.050 mm (0.0019 in) Connecting rod bearing bore diameter - grade 1 59.866-59.872 mm (2.3569-2.3571 in) Connecting rod bearing bore diameter - grade 2 59.873-59.879 mm (2.3572-2.3574 in) Connecting rod bearing bore diameter - grade 3 59.880-59.886 mm (2.3574-2.3577 in) Connecting rod bearing-to-crankshaft clearance - Connecting rod side clearance (assembled to crank) - standard 0.175-0.425 mm (0.0068-0.0167 in) Connecting rod side clearance (assembled to crank) - 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

a Refer to the appropriate procedure in this service information. TORQUE SPECIFICATIONS - service limit Description Nm lb-ft lb-in A/C compressor bolts and nut 25 18 - A/C compressor stud 9 - 80 A/C pressure tube fitting nuts 8 - 71 A/C tube bracket bolt 8 - 71 Accessory drive belt tensioner bolts 11 8 - Battery cable power feed cable nut 8 - 71 Block heater 40 30 - Camshaft bearing cap bolts a - - - Camshaft position (CMP) sensor bolts 10 - 89 Camshaft sprocket bolts a - - - Catalytic converter bracket bolt 55 41 - Catalytic converter bracket nut 40 30 - Catalytic converter bracket-to-converter bolts 20 15 - Catalytic converter bracket-to-engine block bolts 48 35 - Catalytic converter nuts 40 30 - Catalytic converter-to-exhaust manifold studs 25 18 - Coolant pump bolts a - - - Crankshaft rear seal retainer plate bolts a - - - Crankshaft position (CKP) sensor bolt 10 - 89 CKP sensor heat shield nuts 10 - 89 Crankshaft pulley bolt a - - - Cylinder block drain plug (large) 40 30 - Cylinder block drain plug (small) b - - - Cylinder head bolts a - - - Cylinder head temperature (CHT) sensor 10 - 89 Degas bottle bolts 9 - 80 Engine front cover bolts a - - - Engine lifting eye bolts 24 18 - Engine mount brace bolt and nut 20 15 - Engine mount bracket bolts a - - - Engine mount studs 18 13 - Engine mount-to-engine nuts 63 46 - Engine mount-to-frame bolts 90 66 - 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

Engine oil filter c - - - Engine oil pressure (EOP) switch 18 13 - Engine roll-restrictor heat shield nut 11 8 - Engine roll restrictor-to-subframe through bolt 103 76 - Engine roll restrictor-to-transaxle through bolt 90 66 - Exhaust manifold heat shield bolts 14 10 - Exhaust manifold nuts a - - - Exhaust manifold studs 12 9 - Exhaust pipe clamp 40 30 - Exhaust Y-pipe nuts 40 30 - Flexplate bolts 80 59 - Front halfshaft nut 350 258 - Fuel rail bolts 10 - 89 Generator bolt and nut 47 35 - Generator B+ terminal nut 6 - 53 Ground wire-to-body bolt 10 - 89 Ground wire-to-engine bolt 10 - 89 Halfshaft carrier bearing bracket bolts - all wheel drive (AWD) 40 30 - Halfshaft carrier bearing bracket bolts and stud bolt - front wheel drive (FWD) 55 41 - Heated oxygen sensor (HO2S) 48 35 - Heat shield nut and bolt 10 - 89 Ignition coil-on-plug bolts 7 - 62 Intermediate steering shaft bolt 23 17 - Knock sensor (KS) bolts 20 15 - Lower ball joint bolts 55 41 - Lower bumper nuts 9 - 80 Lower intake manifold bolts b - - - Oil cooler bolts 10 - 89 Oil filter adapter large bolt 57 42 - Oil filter adapter small bolt 10 - 89 Oil pan bolts a - - - Oil pan drain plug 27 20 - Oil pan-to-transaxle bolts 48 35 - Oil pump bolts 10 - 89 Oil pump screen and pickup tube bolts 10 - 89 Power steering cooler bracket bolt 9 - 80 Power steering pressure (PSP) tube bracket banjo bolt 48 35 - Power steering pump bolts 24 18 - Power steering reservoir nuts 8 - 71 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

a Refer to the appropriate procedure in this service information. b Tighten to 20 Nm (15 lb-ft) plus an additional 180 degrees. c Tighten to 5 Nm (44 lb-in) plus an additional 180 degrees. DESCRIPTION AND OPERATION ENGINE Power transfer unit (PTU) 90 66 - PTU bracket bolts 70 52 - Radio interference capacitor-to-cowl nut 10 - 89 Radio interference capacitor-to-engine front cover nut 10 - 89 Rear driveshaft-to-PTU flange bolts 70 52 - Spark plugs 15 11 - Stabilizer bar link nuts 90 66 - Starter bolt and stud bolt 27 20 - Starter B+ terminal nut 12 9 - Starter S-terminal nut 5 - 44 Subframe bracket bolts 90 66 - Subframe nuts 133 98 - Thermostat housing bolts 10 - 89 Tie-rod end nuts 48 35 - Timing chain guide bolts 10 - 89 Timing chain tensioner bolts 10 - 89 Torque converter-to-flexplate bolts 55 41 - Transaxle bracket bolts 90 66 - Transaxle bracket plate bolts 90 66 - Transaxle mount bracket nuts 63 46 - Transaxle mount through bolt and nut 175 129 - Transaxle-to-engine bolts 48 35 - Upper intake manifold bolts b - - - Upper intake manifold bracket-to-engine bolt 10 - 89 Upper intake manifold-to-bracket bolt 10 - 89 Valve cover bolts and stud bolts b - - - Variable camshaft timing (VCT) assembly bolts b - - - VCT housing bolts a - - - VCT solenoid bolts 10 - 89 Wiring harness retainer bolt and stud bolt 10 - 89 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

The 3.5L (4V) is a V-6 engine with the following features:  Dual overhead camshafts  Four valves per cylinder  Sequential multi-port fuel injection Sequential Multi-Port Fuel Injection (SFI)  An aluminum lower intake manifold and a composite upper intake manifold  Aluminum cylinder heads  An aluminum, 60-degree V-cylinder block  Timing chain driven coolant pump  Variable Camshaft Timing (VCT) system  The electronic ignition system with 6 ignition coils Identification For quick identification, refer to the safety certification decal.  The decal is located on the LH front door lock face panel.  An engine identification label is also attached to the engine.  The symbol code on the identification tag identifies each engine for determining parts usage; for instance, engine displacement in liters or cubic inch displacement and model year. Exhaust Emission Control System Operation and required maintenance of the exhaust emission control devices used on this engine is covered in the Introduction - Gasoline Engines article. Induction System The SFI provides the fuel/air mixture needed for combustion in the cylinders. The 6 solenoid-operated fuel injectors:  are mounted between the fuel rail and the intake manifold.  meter fuel into the air intake stream in accordance with engine demand.  are positioned so that their tips direct fuel just ahead of the engine intake valves. Valve Train The valve train uses direct acting mechanical buckets (DAMB). The camshaft lobes are positioned directly above mechanical buckets which are positioned on top of the valves. Variable Camshaft Timing (VCT) System The VCT system changes intake camshaft timing dependent on engine speed, load and oil temperature. Oil pressure advances and retards camshaft timing to improve low-speed and high-speed engine performance, 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

engine idle quality and exhaust emissions. PCV System All engines are equipped with a closed-type PCV system recycling the crankcase vapors to the upper intake manifold. Lubrication System The engine lubrication system is of the force-feed type in which oil is supplied under full pressure to the crankshaft, connecting rod bearings, timing chain tensioners and VCT solenoids. The flow of oil to the valve tappets and valve train is controlled by a restricting orifice located in the head gaskets. Oil Pump The lubrication system is designed to provide optimum oil flow to critical components of the engine through its entire operating range. The heart of the system is a positive displacement internal gear oil pump. Generically, this design is known as a gerotor pump, which operates as follows:  The oil pump is mounted on the front face of the cylinder block.  The inner rotor is piloted on the crankshaft post and is driven through flats on the crankshaft.  System pressure is limited by an integral, internally-vented relief valve which directs the bypassed oil back to the inlet side of the oil pump.  Oil pump displacement has been selected to provide adequate volume to make sure of correct oil pressure both at hot idle and maximum speed.  The relief valve calibration protects the system from excessive pressure during high-viscosity conditions.  The relief valve is designed to provide adequate connecting rod bearing lubrication under high- temperature and high-speed conditions. Cooling System The engine cooling system includes the following:  Radiator  Timing chain driven coolant pump  Electric fan assembly(s)  Degas bottle (aids in maintaining the correct volume of engine coolant)  Coolant thermostat  Coolant hoses Engine Cylinder Identification 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX

Fig. 1: Engine Cylinder Identification Courtesy of FORD MOTOR CO. DIAGNOSTIC TESTS ENGINE For basic engine mechanical concerns, refer to ENGINE SYSTEM - GENERAL INFORMATION article. For driveability concerns, refer to the Introduction - Gasoline Engines article. GENERAL PROCEDURES VALVE CLEARANCE CHECK 1. Remove the valve covers. For additional information, refer to Valve Cover - LH and Valve Cover - RH . 2. Use a feeler gauge to measure the clearance of each valve and record its location. A midrange clearance is the most desirable:  Intake: 0.15-0.25 mm (0.006-0.01 in)  Exhaust: 0.300-0.400 mm (0.0118-0.0157 in) NOTE: The valve clearance must be measured with the camshaft at base circle. The engine will have to be rotated with the crankshaft pulley bolt to bring each valve to base circle. 2008 Ford Edge SE 2008 ENGINE 3.5L - Edge & MKX
