DESCRIPTION AND OPERATION
Identification Codes
The vehicle identification number (VIN) is a 17-digit combination of letters and numbers. The VIN is
stamped on a metal tab riveted on the instrument panel top upper left of the dash. The VIN number is
also found on the vehicle certification (VC) label.
Vehicle Identification Number
The first three vehicle identification number (VIN) positions are the world manufacturer identifier.
1FM — Ford Motor Company, USA, multi-purpose vehicle.
1FT — Ford Motor Company, USA, truck, completed vehicle.
1FD — Ford Motor Company, USA, incomplete vehicle.
SECTION 100-01: Identification Codes 2000 Econoline Workshop Manual
Item Description
1 World manufacturer identifier
2 Brake type and gross vehicle weight rating (GVWR)
3 Vehicle line, series, body type
4 Engine type
5 Check digit
6 Model year
7 Assembly plant
8 Production sequence number
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
1FC — Ford Motor Company, USA, basic (stripped) chassis.
1FB — Ford Motor Company, USA, bus.
1FF — Ford Motor Company, USA, motor vehicle equipment without engine/powertrain (Glider).
2FM — Ford Motor Company, Canada, multi-purpose vehicle.
2FT — Ford Motor Company, Canada, truck, completed vehicle.
2FD — Ford Motor Company, Canada, incomplete vehicle.
2FC — Ford Motor Company, Canada, basic (stripped) chassis.
2FB — Ford Motor Company, Canada, bus.
2FF — Ford Motor Company, Canada, motor vehicle equipment without engine/powertrain
(Glider).
3FB — Ford Motor Company, Mexico, bus.
3FC — Ford Motor Company, Mexico, basic (stripped) chassis.
3FE — Ford Motor Company, Mexico, incomplete vehicle.
3FM — Ford Motor Company, Mexico, multi-purpose vehicle.
3FT — Ford Motor Company, Mexico, truck, completed vehicle.
The fourth VIN position is the vehicle brake type and GVW code (all vehicles use hydraulic brakes).
R — 6,001-7,000 pounds GVWR with driver and front passenger second generation air bags.
P — 7,001-8,000 pounds GVWR with driver and front passenger second generation air bags.
V — 8,001-8,500 pounds GVWR with driver and front passenger second generation air bags.
H — 8,501-9,000 pounds GVWR.
N — 8,501-9,000 pounds GVWR with driver and front passenger second generation air bags.
J — 9,001-10,000 pounds GVWR.
S — 9,001-10,000 pounds GVWR with driver and front passenger second generation air bags.
K — 10,001-14,000 pounds GVWR.
W — 10,001-14,000 pounds GVWR with driver and front passenger second generation air
bags.
L — 14,001-16,000 pounds GVWR.
X — 14,001-16,000 pounds GVWR with driver and front passenger second generation air bags.
M — 16,001-19,500 pounds GVWR.
A — 16,001-19,500 pounds GVWR with driver and front passenger second generation air bags.
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
Positions 5 through 7 indicate vehicle line, series and body type.
E11 — E-150 Club Wagon.
E14 — E-150 cargo van.
E24 — E-250 cargo van.
S24 — E-250 Super Duty cargo van.
E31 — E-350 Club Wagon.
S31 — E-350 Super Duty Club Wagon.
E34 — E-350 cargo van.
S34 — E-350 Super Duty cargo van.
E27 — E-250 commercial cutaway.
E29 — E-250 stripped chassis.
E35 — E-350 base cutaway.
E39 — E-350 commercial stripped chassis.
E45 — E-450 Super Duty base cutaway.
E49 — E-450 Super Duty stripped chassis.
The eighth VIN position is the engine displacement and number of cylinders.
S — 6.8L, EFI, V10, Gas.
F — 7.3L, OHV, DI Turbo, V8, Diesel.
2 — 4.2L, OHV, EFI, V6, Gas.
W — 4.6L, Modular SOHC, EFI, V8, Gas (Romeo).
6 — 4.6L, Modular SOHC, EFI, V8, Gas (Windsor).
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
M — 5.4L, SOHC, V8, Natural Gas.
L — 5.4L, SOHC, EFI, V8, Gas.
The ninth VIN position is a check digit.
The tenth VIN position is the model year code.
Y — 2000.
The eleventh VIN position is the assembly plant code.
S — Allen Park (Allen Park, Michigan)
H — Lorain (Lorain, Ohio)
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
The last six VIN positions are an alphanumeric code for the vehicle build sequence. This is also the
vehicle serial and warranty number.
A00001-E99999 — Ford Division
Vehicle Certification (VC) Label
Item Description
1 Exterior paint code
2 Region code
3 Domestic special order code
4 Wheel base code
5 Brake code
6 Interior trim code
7 Tape/paint pinstripe code
8 Radio code
9 Axle code
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
The vehicle certification (VC) label contains the manufacturer name, the month and year of
manufacture, the certification statement, and the VIN. It also includes gross vehicle weight ratings
(GVWR).
Vehicle Certification (VC) Label — Incomplete Vehicle (Typical)
Paint Codes
The first set of numbers listed indicate the primary body color. The second set of numbers listed
indicate a two-tone or accent color. All colors are base coat/clear coat.
B2 — Harvest Gold.
PA — Deep Jewel Green.
LL — Deep Wedgewood Blue.
M7 — Light Blue Metallic.
UA — Ebony.
YN — Silver Metallic.
FL — Toreador Red.
FY — Woodland Green.
YZ — Oxford White.
B4 — Chestnut Brown.
Radio Codes
7 — AM/FM stereo with clock.
G — Delete radio chassis only. AM/FM stereo, all other components installed.
9 — AM/FM stereo cassette with clock.
R — Delete radio chassis only, AM/FM cassette, all other components installed.
Y — Radio delete.
8 — AM/FM premium stereo with cassette.
D — Delete radio chassis only, AM/FM premium cassette, all other components installed.
10 Transmission code
11 Spring code
12 Powertrain calibration information
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
K — AM/FM stereo cassette with CD player.
Axle Codes
The following lists the gear ratios on axles.
19 — 3.55, non-limited slip, E-150.
H9 — 3.55, limited slip, E-150.
24 — 3.73, non-limited slip, E-250 regular and extended wheel base.
B4 — 3.73, limited slip, E-250 regular and extended wheel base.
35 — 4.09, non-limited slip, E-250 regular and extended wheel base.
C5 — 4.09, limited slip, E-250 regular and extended wheel base.
32 — 4.10 non-limited slip, E-250/E-350 regular and extended wheel base, single rear wheels,
over 8,500 pounds GVW.
C2 — 4.10, limited slip, E-250/E-350 regular and extended wheel base, single rear wheels, over
8,500 pounds GVW.
34 — 3.73, non-limited slip, E-250/E-350 regular and extended wheel base, single rear wheels,
over 8,500 pounds GVW.
C4 — 3.73, limited slip, E-250/E-350 regular and extended wheel base, single rear wheels, over
8,500 pounds GVW.
39 — 3.55, non-limited slip, E-250/E-350 regular and extended wheel base, single rear wheels,
over 8,500 pounds GVW.
C9 — 3.55, limited slip, E-250/E-350 regular and extended wheel base, single rear wheels, over
8,500 pounds GVW.
52 — 4.10, non-limited slip, E-350 regular and extended wheel base, dual rear wheels, over
8,500 pounds GVW.
E2 — 4.10, limited slip, E-350 regular and extended wheel base, dual rear wheels, over 8,500
pounds GVW.
56 — 4.10, non-limited slip, E-350 regular and extended wheel base, single rear wheels, over
8,500 pounds GVW.
E6 — 4.10, limited slip, E-350 regular and extended wheel base, single rear wheels, over 8,500
pounds GVW.
81 — 4.63, non-limited slip, dual rear wheels, over 8,500 pounds GVW.
82 — 4.10, non-limited slip, dual rear wheels, over 8,500 pounds GVW.
81 — 4.63, E-450 over 8,500 pounds GVW.
82 — 4.10, E-450 over 8,500 pounds GVW.
Transmission Codes
E — Four-speed automatic with overdrive (4R100) with 4.2L and 4.6L engines.
U — Four-speed automatic with overdrive (4R70W).
9 — Four-speed automatic with overdrive (4R100), diesel engine.
Spring Codes
The following lists available spring codes.
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
Front Springs
Base part number — 5310 (RH/LH).
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
S
T
U
V
Z
Rear Springs
Base part number — 5560 (RH/LH).
C
N
P
R
S
7
G
6
Interior Trim Codes
The following lists the interior trim and interior color codes.
Interior Trim
A — Hampton Vinyl (bucket seats).
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
E — Camden Cloth (captain's chairs).
C — Stockton/Cloth (bucket seats).
F — Camden Cloth (captain's chairs), Chateau.
X — No trim available (seat not included).
Interior Color Codes
2 — Medium Graphite.
D — Denim Blue.
N — Medium Parchment.
Tape Stripe Codes
A — Silver/Red/Titanium (Chateau appearance package).
Powertrain Calibration Information
NOTE: Powertrain calibration information is limited to a maximum of five characters per line on the
vehicle certification label. Because of this, calibration identification consisting of more than five
characters will wrap to the second line on the VC label.
Powertrain calibration information is printed in the lower right corner of the vehicle certification label.
Only the base calibration information is printed. Revision levels will not appear, however, they can be
found in On Line Automotive Service Information System (OASIS). For the current model year, Ford
Motor Company is using three different protocols which describe powertrain base calibration. These
protocols are designed to provide worldwide standardization for vehicle calibration. If the electronic
calibration strategy has been used since 1998 and carried into the current model year, Protocol 1 will
be used. Refer to Protocol 1 below. If the electronic calibration strategy has been used since 1999 and
is carried into the current model year, Protocol 2 will be used. Refer to Protocol 2 below. For new
electronic calibration strategies for the current model year, use Protocol 3. Refer to Protocol 3 below.
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
For a detailed listing of applicable codes, refer to the Powertrain Control/Emissions Diagnosis (PC/ED)
manual.
Protocol 1
Model year is as follows:
8 — Model year 1998 (indicates the model year calibration was introduced).
Engine codes are as follows:
DS — 7.3L, Direct Injection Turbo Diesel, V-8.
VG — 7.5L, EFI, normally aspirated, V-8.
Protocol 2
Item Description
1 Model year (model year in which calibration strategy was first introduced)
2 Engine code
3 Engine revision level
Item Description
1 Model year (model year in which calibration strategy was first introduced)
2 Engine code
3 Transmission code
4 Emission standard (designates the specific country emission standard)
03.05. 2012 file:///C:/Ford/2000-2004/tsocache/SHEF_5868/SYM~us~en...
