Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Model Year High Performance Genuine Engine Oil Audi Genuine 5W-40 (502.00 / 505.00)
A3 2019-20 0W-20 (508.00 / 509.00) Part Number:
A3 FWD 2.0T 2017-20 0W-20 (508.00 / 509.00) Bulk: G -E55-540-1B-DSP
S3 2019-20 0W-30 (504.00 / 507.00) Drum: G -E55-540-1Q-DSP
RS 3 2017-20 0W-30 (504.00 / 507.00) Quart: G -E55-540-1D-DSP
A3 2.0 TDI 2010–13, ’15 0W-30 (504.00 / 507.00) Warranty Info / DMS Stocking Part Number:
A4, A4 allroad® 2021 0W-20 (504.00 / 507.00) SAGA Part: G 052167S0
A4, A4 allroad® 2019-20 0W-30 (504.00 / 507.00)
A4 FWD 2018-21 0W-20 (508.00 / 509.00) Audi Genuine 0W-20 (508.00 / 509.00)
A4 ultra® 2017 0W-20 (508.00 / 509.00) Part Number:
S4 2018-21 0W-20 (508.00 / 509.00) Bulk: G -E60-020-1B-DSP
A5 2021 0W-20 (508.00 / 509.00) Drum: G -E60-020-1D-DSP
A5 2019-20 0W-30 (504.00 / 507.00) Quart: G -E60-020-1Q-DSP
S5 2018-21 0W-20 (508.00 / 509.00) Warranty Info / DMS Stocking Part Number:
RS 5 2018-21 0W-30 (504.00 / 507.00) SAGA Part: G E52577S0
A6 2.0T 2020-21 0W-20 (508.00 / 509.00)
A6 3.0T 2019-21 0W-20 (508.00 / 509.00) Audi Genuine 0W-30 (504.00 / 507.00) + (505.01)
S6 2020-21 0W-30 (504.00 / 507.00) Part Number:
RS 6 2021 0W-40 (511.00) Bulk: G -E55-030-1B-DSP
A6 3.0 TDI 2014–2016 0W-30 (504.00 / 507.00) Drum: G -E55-030-1D-DSP
A7 2019-21 0W-20 (508.00 / 509.00) Quart: G -E55-030-1Q-DSP
A7 2.0 PHEV 2021 0W-20 (508.00 / 509.00) Warranty Info / DMS Stocking Part Number:
S7 2020-21 0W-30 (504.00 / 507.00) SAGA Part: G E52545S0
RS 7 2021 0W-40 (511.00)
A7 3.0 TDI 2014–2016 0W-30 (504.00 / 507.00) Audi Genuine 0W-40 (511.00)
A8L 3.0T 2019-21 0W-20 (508.00 / 509.00) Part Number:
A8L PHEV 2021 0W-20 (508.00 / 509.00) Quart: G -E55-040-1Q-DSP
A8L 4.0T 2019-21 0W-30 (504.00 / 507.00) Warranty Info / DMS Stocking Part Number:
S8 2021 0W-30 (504.00 / 507.00) SAGA Part:
A8 3.0 TDI 2014–2016 0W-30 (504.00 / 507.00)
Q5 2.0T 2019-21 0W-20 (508.00 / 509.00) Audi Genuine 10W-60 (501.01 / 505.00)
Q5 PHEV 2020-21 0W-20 (508.00 / 509.00) Part Number:
SQ5 2018-21 0W-20 (508.00 / 509.00) Quart: G -E52-160-1Q-DSP
Q5 3.0 TDI 2014–2016 0W-30 (504.00 / 507.00) Warranty Info / DMS Stocking Part Number:
Q7 2.0T 2019-21 0W-30 (504.00 / 507.00) SAGA Part: G E521601QDSP
Q7 3.0T 2020-21 0W-20 (508.00 / 509.00)
Q7 3.0T 2019 0W-30 (504.00 / 507.00)
SQ7 4.0T 2020-21 0W-40 (511.00)
Q7 3.0 TDI 2014–2016 0W-30 (504.00 / 507.00)
Q8 2019-21 0W-20 (508.00 / 509.00)
SQ8 2020-21 0W-40 (511.00)
RS Q8 2020-21 0W-40 (511.00)
R8 all variants 2020-21 0W-30 (504.00 / 507.00)
R8 all variants 2017-18 5W-40 (502.00 / 505.00)
R8 V10, R8 V10 Plus 2014–2015 10W60 (501.01 / 505.00)
R8 GT / GT Spyder 2012–2013 10W60 (501.01 / 505.00)
TT 2019-21 0W-20 (508.00 / 509.00)
TTS 2019-21 0W-30 (504.00 / 507.00)
TT RS 2018-21 0W-30 (504.00 / 507.00)
RS 3 | S3 | A3
Version 7 - 7/21/2021
Engine Oil Overview Chart: Specialty engine oils
Audi High Performance Genuine Engine Oil 5W-40 (502.00 / 505.00) is the most commonly used engine oil for servicing Audi vehicles,
however there are four additional oils engineered to meet specific application requirements. This chart is designed to help parts and
service teams recognize the applications outside of 5W-40. As always, please reference ElsaPRO for the latest information.
S4 | A4 Q7 Q8 R8 TT RS 5 | S5 | A5
“Audi,” “allroad,” “ultra” and the four rings logo are registered trademarks of AUDI AG. All other trademarks are the property of their respective owners. ©2021 Audi of America, Inc. Printed in
the U.S.A.
S6 | A6 RS 7 | S7 | A7 A8 SQ5 | Q5
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Cautions & Warnings
Page 1 of 3
© 2018 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other
intellectual property rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of
this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
Version 2.0
Please read these WARNINGS and CAUTIONS before proceeding with maintenance and
repair work. You must answer that you have read and you understand these WARNINGS and
CAUTIONS before you will be allowed to view this information.
If you lack the skills, tools and equipment, or a suitable workshop for any procedure described
in this manual, we suggest you leave such repairs to an authorized Audi retailer or other
qualified shop. We especially urge you to consult an authorized Audi retailer before beginning
repairs on any vehicle that may still be covered wholly or in part by any of the extensive
warranties issued by Audi.
Disconnect the battery negative terminal (ground strap) whenever you work on the fuel system
or the electrical system. Do not smoke or work near heaters or other fire hazards. Keep an
approved fire extinguisher handy.
Audi is constantly improving its vehicles and sometimes these changes, both in parts and
specifications, are made applicable to earlier models. Therefore, part numbers listed in this
manual are for reference only. Always check with your authorized Audi retailer parts
department for the latest information.
Any time the battery has been disconnected on an automatic transmission vehicle, it will be
necessary to reestablish Transmission Control Module (TCM) basic settings using the Audi
Factory Approved Scan Tool (ST).
Never work under a lifted vehicle unless it is solidly supported on stands designed for the
purpose. Do not support a vehicle on cinder blocks, hollow tiles or other props that may
crumble under continuous load. Never work under a vehicle that is supported solely by a jack.
Never work under the vehicle while the engine is running.
For vehicles equipped with an anti-theft radio, be sure of the correct radio activation code
before disconnecting the battery or removing the radio. If the wrong code is entered when the
power is restored, the radio may lock up and become inoperable, even if the correct code is
used in a later attempt.
If you are going to work under a vehicle on the ground, make sure that the ground is level.
Block the wheels to keep the vehicle from rolling. Disconnect the battery negative terminal
(ground strap) to prevent others from starting the vehicle while you are under it.
Do not attempt to work on your vehicle if you do not feel well. You increase the danger of
injury to yourself and others if you are tired, upset or have taken medicine or any other
substances that may impair you or keep you from being fully alert.
Never run the engine unless the work area is well ventilated. Carbon monoxide (CO) kills.
Always observe good workshop practices. Wear goggles when you operate machine tools or
work with acid. Wear goggles, gloves and other protective clothing whenever the job requires
working with harmful substances.
Tie long hair behind your head. Do not wear a necktie, a scarf, loose clothing, or a necklace
when you work near machine tools or running engines. If your hair, clothing, or jewelry were to
get caught in the machinery, severe injury could result.
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Cautions & Warnings
Page 2 of 3
© 2018 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other
intellectual property rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of
this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
Version 2.0
Do not re-use any fasteners that are worn or deformed in normal use. Some fasteners are
designed to be used only once and are unreliable and may fail if used a second time. This
includes, but is not limited to, nuts, bolts, washers, circlips and cotter pins. Always follow the
recommendations in this manual - replace these fasteners with new parts where indicated,
and any other time it is deemed necessary by inspection.
Illuminate the work area adequately but safely. Use a portable safety light for working inside or
under the vehicle. Make sure the bulb is enclosed by a wire cage. The hot filament of an
accidentally broken bulb can ignite spilled fuel or oil.
Friction materials such as brake pads and clutch discs may contain asbestos fibers. Do not
create dust by grinding, sanding, or by cleaning with compressed air. Avoid breathing
asbestos fibers and asbestos dust. Breathing asbestos can cause serious diseases such as
asbestosis or cancer, and may result in death.
Finger rings should be removed so that they cannot cause electrical shorts, get caught in
running machinery, or be crushed by heavy parts.
Before starting a job, make certain that you have all the necessary tools and parts on hand.
Read all the instructions thoroughly, do not attempt shortcuts. Use tools that are appropriate to
the work and use only replacement parts meeting Audi specifications. Makeshift tools, parts
and procedures will not make good repairs.
Catch draining fuel, oil or brake fluid in suitable containers. Do not use empty food or
beverage containers that might mislead someone into drinking from them. Store flammable
fluids away from fire hazards. Wipe up spills at once, but do not store the oily rags, which can
ignite and burn spontaneously.
Use pneumatic and electric tools only to loosen threaded parts and fasteners. Never use these
tools to tighten fasteners, especially on light alloy parts. Always use a torque wrench to tighten
fasteners to the tightening torque listed.
Keep sparks, lighted matches, and open flame away from the top of the battery. If escaping
hydrogen gas is ignited, it will ignite gas trapped in the cells and cause the battery to explode.
Be mindful of the environment and ecology. Before you drain the crankcase, find out the
proper way to dispose of the oil. Do not pour oil onto the ground, down a drain, or into a
stream, pond, or lake. Consult local ordinances that govern the disposal of wastes.
The air-conditioning (A/C) system is filled with a chemical refrigerant that is hazardous. The
A/C system should be serviced only by trained automotive service technicians using approved
refrigerant recovery/recycling equipment, trained in related safety precautions, and familiar
with regulations governing the discharging and disposal of automotive chemical refrigerants.
Before doing any electrical welding on vehicles equipped with anti-lock brakes (ABS),
disconnect the battery negative terminal (ground strap) and the ABS control module
connector.
Do not expose any part of the A/C system to high temperatures such as open flame.
Excessive heat will increase system pressure and may cause the system to burst.
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Cautions & Warnings
Page 3 of 3
© 2018 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other
intellectual property rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of
this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
Version 2.0
When boost-charging the battery, first remove the fuses for the Engine Control Module (ECM),
the Transmission Control Module (TCM), the ABS control module, and the trip computer. In
cases where one or more of these components is not separately fused, disconnect the control
module connector(s).
Some of the vehicles covered by this manual are equipped with a supplemental restraint
system (SRS), that automatically deploys an airbag in the event of a frontal impact. The airbag
is operated by an explosive device. Handled improperly or without adequate safeguards, it can
be accidentally activated and cause serious personal injury. To guard against personal injury
or airbag system failure, only trained Audi Service technicians should test, disassemble or
service the airbag system.
Do not quick-charge the battery (for boost starting) for longer than one minute, and do not
exceed 16.5 volts at the battery with the boosting cables attached. Wait at least one minute
before boosting the battery a second time.
Never use a test light to conduct electrical tests of the airbag system. The system must only
be tested by trained Audi Service technicians using the Audi Factory Approved Scan Tool (ST)
or an approved equivalent. The airbag unit must never be electrically tested while it is not
installed in the vehicle.
Some aerosol tire inflators are highly flammable. Be extremely cautious when repairing a tire
that may have been inflated using an aerosol tire inflator. Keep sparks, open flame or other
sources of ignition away from the tire repair area. Inflate and deflate the tire at least four times
before breaking the bead from the rim. Completely remove the tire from the rim before
attempting any repair.
When driving or riding in an airbag-equipped vehicle, never hold test equipment in your hands
or lap while the vehicle is in motion. Objects between you and the airbag can increase the risk
of injury in an accident.
I have read and I understand these Cautions and Warnings.
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3/10/2020
MY 2020 Audi Normal Load Condition (up to three people)
a)
Tire Pressure Table
A3 Sedan 2.0L: Front Rear
225/40 R18 92Y High Performance 35 32
225/45 R17 91H All Season 33 30
225/40 R18 92H All Season 36 33
235/35 R19 91Y High Performance 33 30
S3 Sedan 2.0L: Front Rear
225/40 R18 92Y High Performance 38 35
225/40 R18 92H All Season 38 35
235/35 R19 91Y High Performance 39 36
RS 3 Sedan: 2.5L: Front Rear
235/35 R19 91Y High Performance 39/44
b)
35/39
b)
255/30 R19 91Y High Performance 39/44
b)
-
A3 e-tron Sportback 1.4L: Front Rear
205/55 R16 91V High Performance 35 35
225/40 R18 92Y High Performance 33 33
225/45 R17 91H All Season 38 38
225/40 R18 92H All Season 36 36
A4 2.0L (190 hp): Front Rear
225/50 R17 94Y High Performance 30 28
245/40 R18 93Y High Performance 30 28
225/50 R17 94H All Season 30 28
245/40 R18 97H All Season 35 32
245/35 R19 93Y High Performance 35 32
A4 2.0L (252 hp): Front Rear
225/50 R17 94Y High Performance 30 28
245/40 R18 93Y High Performance 30 28
225/50 R17 94H All Season 30 28
245/40 R18 97H All Season 35 32
245/35 R19 93Y High Performance 36 33
S4 3.0L: Front Rear
245/40 R18 97H All Season 35 32
245/40 R18 97Y High Performance 36 33
255/35 R19 96Y High Performance 39 35
A4 allroad 2.0L: Front Rear
225/55 R17 97Y High Performance 32 29
245/45 R18 96Y High Performance 32 29
245/45 R18 100H All Season 32 32
245/40 R19 98Y High Performance 35 32
A5 Coupe 2.0L: Front Rear
225/50 R17 94Y High Performance 32 29
225/50 R17 94H All Season 32 29
245/40 R18 93Y High Performance 32 29
245/40 R18 97H All Season 32 32
255/35 R19 96Y High Performance 32 32
265/30 R20 94Y High Performance 33 33
S5 Coupe 3.0L: Front Rear
245/40 R18 97H All Season 35 32
245/40 R18 97Y High Performance 36 33
255/35 R19 96Y High Performance 38 35
265/30 R20 94Y High Performance 41 38
A5 Cabriolet 2.0L: Front Rear
225/50 R17 94Y High Performance 32 29
245/40 R18 93Y High Performance 32 29
255/35 R19 96Y High Performance 35 32
225/50 R17 94H All Season 35 32
245/40 R18 97H All Season 35 32
265/30 R20 94Y High Performance 35 32
S5 Cabriolet 3.0L: Front Rear
245/40 R18 97Y High Performance 38 35
245/40 R18 97H All Season 38 35
255/35 R19 96Y High Performance 39 36
265/30 R20 94Y High Performance 42 39
A5 Sportback 2.0L: Front Rear
225/50 R17 94Y High Performance 32 29
245/40 R18 93Y High Performance 32 29
245/40 R18 97H All Season 32 32
255/35 R19 96Y High Performance 32 32
265/30 R20 94Y High Performance 33 33
S5 Sportback 3.0L: Front Rear
245/40 R18 97H All Season 35 32
245/40 R18 97Y High Performance 36 33
255/35 R19 96Y High Performance 38 35
265/30 R20 94Y High Performance 41 38
a) Two people in the front, one person in the rear
b) The value before the forward slash applies to vehicles with a maximum speed up to 155 mph (250 km/h); the value after the slash
is for up to 174 mph (280 km/h). If vehicle has a top speed of 174 mph (250 km/h), it has the Dynamic Plus Package which can be
identified by PR Code PAB
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3/10/2020
A6 2.0L: Front Rear
245/45 R19 102H All Season 32 32
255/40 R20 101H All Season 32 32
255/40 R20 101Y High Performance 32 32
255/35 R21 98Y High Performance 32 32
A6 3.0L: Front Rear
245/45 R19 102H All Season 32 32
255/40 R20 101H All Season 33 32
255/40 R20 101Y High Performance 32 32
255/35 R21 98Y High Performance 33 32
S6 2.9L: Front Rear
255/40 R20 101Y High Performance 35 32
255/35 R21 98Y High Performance 39 36
A7 3.0L: Front Rear
245/45 R19 102H All Season 32 32
255/40 R20 101H All Season 33 32
255/40 R20 101Y High Performance 32 32
255/35 R21 98Y High Performance 33 32
S7 4.0L: Front Rear
255/40 R20 101Y High Performance 36 33
255/35 R21 98Y High Performance 41 38
A8L 3.0L: Front Rear
255/45 R19 104H All Season 35 32
255/45 R19 104Y High Performance 35 32
265/40 R20 104H All Season 35 32
265/40 R20 104Y High Performance 35 32
275/35 R21 103Y High Performance 35 32
A8L 4.0L: Front Rear
255/45 R19 104H All Season 38 33
255/45 R19 104Y High Performance 35 32
265/40 R20 104H All Season 38 33
265/40 R20 104Y High Performance 35 32
275/35 R21 103Y High Performance 35 32
A8L 3.0L TFSI e: Front Rear
255/45 R19 104H All Season 36 36
255/45 R19 104Y High Performance 35 35
265/40 R20 104H All Season 36 36
265/40 R20 104Y High Performance 35 35
S8 4.0L: Front Rear
265/40 R20 104Y High Performance 38 33
265/35 R21 101Y High Performance 42 36
275/35 R21 103Y High Performance 39 35
e-tron: Front Rear
255/55 R19 111H All Season 39 42
255/50 R20 109H All Season 35 38
265/45 R21 108H All Season 35 38
Q3 2.0L: Front Rear
215/65 R17 99H All Season 38 38
235/55 R18 100H All Season 33 33
235/55 R18 100V High Performance 33 33
235/50 R19 99H All Season 33 33
235/50 R19 99V High Performance 33 33
255/45 R19 104Y High Performance 33 33
255/40 R20 101Y High Performance 33 33
Q5 2.0L: Front Rear
235/60 R18 103H All Season 29 29
235/55 R19 101H All Season 29 29
255/45 R20 101H All Season 29 29
255/45 R20 101W All Season 29 29
255/40 R21 102Y High Performance 32 32
Q5 2.0L TFSI e: Front Rear
235/60 R18 103H All Season 30 30
235/55 R19 101H All Season 30 30
255/45 R20 101H All Season 30 30
255/45 R20 101W All Season 30 30
SQ5 3.0L: Front Rear
255/45 R20 101H All Season 33 30
255/45 R20 101W All Season 36 33
255/40 R21 102Y High Performance 33 33
Q7 2.0L 4-cylinder: Front Rear
255/60 R18 108H All Season 32 32
285/45 R20 112Y High Performance 32 32
285/45 R20 112H All Season 32 32
255/55 R19 111H All Season 32 32
285/40 R21 109Y High Performance 32 32
285/40 R21 109H All Season 32 32
MY 2020 Audi Normal Load Condition (up to three people)
a)
Tire Pressure Table
(continued)
a) Two people in the front, one person in the rear
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3/10/2020
Q7 3.0L 6-cylinder: Front Rear
285/45 R20 112Y High Performance 32 32
255/60 R18 108H All Season 32 32
285/45 R20 112H All Season 32 32
285/40 R21 109Y High Performance 32 32
255/55 R19 111H All Season 32 32
285/40 R21 109H All Season 32 32
SQ7 4.0L 8-cylinder: Front Rear
285/45 R20 112Y High Performance 35 35
285/40 R21 109Y High Performance 35 35
285/40 R21 109H All Season 35 35
Q8 3.0L 6-cylinder: Front Rear
275/50 R20 113H All Season 32 35
285/45 R21 113H All Season 32 35
285/45 R21 113Y High Performance 32 35
285/40 R22 110H All Season 35 38
285/40 R22 110Y High Performance 35 38
285/35 R23 107Y High Performance 32 32
SQ8 4.0L 8-cylinder Front Rear
285/45 R21 113Y High Performance 32 35
285/40 R22 110Y High Performance 35 38
285/35 R23 107Y High Performance 35 35
RS Q8 4.0L
b)
Front Rear
295/40 ZR22 112Y 155 mph (250 km/h) 32 32
295/40 ZR22 112Y 174 mph (280 km/h) 38 38
295/40 ZR22 112Y 190 mph (305 km/h) 41 41
295/35 ZR23 108Y 155 mph (250 km/h) 36 36
295/35 ZR23 108Y 174 mph (280 km/h) 44 44
295/35 ZR23 108Y 190 mph (305 km/h) 46 46
R8 Coupe 5.2L 10 cylinder: Front Rear
245/35 ZR19 93Y High Performance 44 ---
295/35 ZR19 104Y High Performance --- 42
Michelin
245/30 ZR20 90Y High Performance
41 ---
R8 Coupe 5.2L 10 cylinder: (continued) Front Rear
Michelin
305/30 ZR20 103Y High Performance
--- 36
Pirelli
245/30 ZR20 90Y High Performance
48 ---
Pirelli
305/30 ZR20 103Y High Performance --- 44
R8 Spyder 5.2L 10 cylinder: Front Rear
245/35 ZR19 93Y High Performance 46 ---
295/35 ZR19 104Y High Performance --- 44
Michelin
245/30 ZR20 90Y High Performance
45 ---
Michelin
305/30 ZR20 103Y High Performance
--- 39
Pirelli
245/30 ZR20 90Y High Performance 49 ---
Pirelli
305/30 ZR20 103Y High Performance
--- 45
TT Coupe 2.0L: Front Rear
245/45 R17 95Y High Performance 32 29
245/40 R18 93H All Season 32 29
245/40 R18 93Y High Performance 32 29
245/35 R19 93Y High Performance 35 32
255/30 R20 92Y High Performance 35 32
TTS Coupe 2.0L: Front Rear
245/35 R19 93Y High Performance 35 32
255/30 R20 92Y High Performance 35 32
TT RS Coupe 2.5L: Front Rear
245/35 R19 93Y High Performance 33/36
c)
29
255/30 R20 92Y High Performance 35 29
TT Roadster 2.0L: Front Rear
245/45 R17 95Y High Performance 32 29
245/40 R18 93H All Season 32 29
245/40 R18 93Y High Performance 32 29
245/35 R19 93Y High Performance 35 32
255/30 R20 92Y High Performance 35 32
MY 2020 Audi Normal Load Condition (up to three people)
a)
Tire Pressure Table
(continued)
a) Two people in the front, one person in the rear
b) The tire pressure depends on the maximum permitted speed for your vehicle.
c) The value before the forward slash applies to vehicles with a maximum speed up to 155 mph (250 km/h); the value after the slash
is for up to 174 mph (280 km/h)
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Cautions & Warnings
Page 1 of 3
© 2018 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other
intellectual property rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of
this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
Version 2.0
Please read these WARNINGS and CAUTIONS before proceeding with maintenance and
repair work. You must answer that you have read and you understand these WARNINGS and
CAUTIONS before you will be allowed to view this information.
If you lack the skills, tools and equipment, or a suitable workshop for any procedure described
in this manual, we suggest you leave such repairs to an authorized Audi retailer or other
qualified shop. We especially urge you to consult an authorized Audi retailer before beginning
repairs on any vehicle that may still be covered wholly or in part by any of the extensive
warranties issued by Audi.
Disconnect the battery negative terminal (ground strap) whenever you work on the fuel system
or the electrical system. Do not smoke or work near heaters or other fire hazards. Keep an
approved fire extinguisher handy.
Audi is constantly improving its vehicles and sometimes these changes, both in parts and
specifications, are made applicable to earlier models. Therefore, part numbers listed in this
manual are for reference only. Always check with your authorized Audi retailer parts
department for the latest information.
Any time the battery has been disconnected on an automatic transmission vehicle, it will be
necessary to reestablish Transmission Control Module (TCM) basic settings using the Audi
Factory Approved Scan Tool (ST).
Never work under a lifted vehicle unless it is solidly supported on stands designed for the
purpose. Do not support a vehicle on cinder blocks, hollow tiles or other props that may
crumble under continuous load. Never work under a vehicle that is supported solely by a jack.
Never work under the vehicle while the engine is running.
For vehicles equipped with an anti-theft radio, be sure of the correct radio activation code
before disconnecting the battery or removing the radio. If the wrong code is entered when the
power is restored, the radio may lock up and become inoperable, even if the correct code is
used in a later attempt.
If you are going to work under a vehicle on the ground, make sure that the ground is level.
Block the wheels to keep the vehicle from rolling. Disconnect the battery negative terminal
(ground strap) to prevent others from starting the vehicle while you are under it.
Do not attempt to work on your vehicle if you do not feel well. You increase the danger of
injury to yourself and others if you are tired, upset or have taken medicine or any other
substances that may impair you or keep you from being fully alert.
Never run the engine unless the work area is well ventilated. Carbon monoxide (CO) kills.
Always observe good workshop practices. Wear goggles when you operate machine tools or
work with acid. Wear goggles, gloves and other protective clothing whenever the job requires
working with harmful substances.
Tie long hair behind your head. Do not wear a necktie, a scarf, loose clothing, or a necklace
when you work near machine tools or running engines. If your hair, clothing, or jewelry were to
get caught in the machinery, severe injury could result.
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Cautions & Warnings
Page 2 of 3
© 2018 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other
intellectual property rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of
this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
Version 2.0
Do not re-use any fasteners that are worn or deformed in normal use. Some fasteners are
designed to be used only once and are unreliable and may fail if used a second time. This
includes, but is not limited to, nuts, bolts, washers, circlips and cotter pins. Always follow the
recommendations in this manual - replace these fasteners with new parts where indicated,
and any other time it is deemed necessary by inspection.
Illuminate the work area adequately but safely. Use a portable safety light for working inside or
under the vehicle. Make sure the bulb is enclosed by a wire cage. The hot filament of an
accidentally broken bulb can ignite spilled fuel or oil.
Friction materials such as brake pads and clutch discs may contain asbestos fibers. Do not
create dust by grinding, sanding, or by cleaning with compressed air. Avoid breathing
asbestos fibers and asbestos dust. Breathing asbestos can cause serious diseases such as
asbestosis or cancer, and may result in death.
Finger rings should be removed so that they cannot cause electrical shorts, get caught in
running machinery, or be crushed by heavy parts.
Before starting a job, make certain that you have all the necessary tools and parts on hand.
Read all the instructions thoroughly, do not attempt shortcuts. Use tools that are appropriate to
the work and use only replacement parts meeting Audi specifications. Makeshift tools, parts
and procedures will not make good repairs.
Catch draining fuel, oil or brake fluid in suitable containers. Do not use empty food or
beverage containers that might mislead someone into drinking from them. Store flammable
fluids away from fire hazards. Wipe up spills at once, but do not store the oily rags, which can
ignite and burn spontaneously.
Use pneumatic and electric tools only to loosen threaded parts and fasteners. Never use these
tools to tighten fasteners, especially on light alloy parts. Always use a torque wrench to tighten
fasteners to the tightening torque listed.
Keep sparks, lighted matches, and open flame away from the top of the battery. If escaping
hydrogen gas is ignited, it will ignite gas trapped in the cells and cause the battery to explode.
Be mindful of the environment and ecology. Before you drain the crankcase, find out the
proper way to dispose of the oil. Do not pour oil onto the ground, down a drain, or into a
stream, pond, or lake. Consult local ordinances that govern the disposal of wastes.
The air-conditioning (A/C) system is filled with a chemical refrigerant that is hazardous. The
A/C system should be serviced only by trained automotive service technicians using approved
refrigerant recovery/recycling equipment, trained in related safety precautions, and familiar
with regulations governing the discharging and disposal of automotive chemical refrigerants.
Before doing any electrical welding on vehicles equipped with anti-lock brakes (ABS),
disconnect the battery negative terminal (ground strap) and the ABS control module
connector.
Do not expose any part of the A/C system to high temperatures such as open flame.
Excessive heat will increase system pressure and may cause the system to burst.
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Cautions & Warnings
Page 3 of 3
© 2018 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other
intellectual property rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of
this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
Version 2.0
When boost-charging the battery, first remove the fuses for the Engine Control Module (ECM),
the Transmission Control Module (TCM), the ABS control module, and the trip computer. In
cases where one or more of these components is not separately fused, disconnect the control
module connector(s).
Some of the vehicles covered by this manual are equipped with a supplemental restraint
system (SRS), that automatically deploys an airbag in the event of a frontal impact. The airbag
is operated by an explosive device. Handled improperly or without adequate safeguards, it can
be accidentally activated and cause serious personal injury. To guard against personal injury
or airbag system failure, only trained Audi Service technicians should test, disassemble or
service the airbag system.
Do not quick-charge the battery (for boost starting) for longer than one minute, and do not
exceed 16.5 volts at the battery with the boosting cables attached. Wait at least one minute
before boosting the battery a second time.
Never use a test light to conduct electrical tests of the airbag system. The system must only
be tested by trained Audi Service technicians using the Audi Factory Approved Scan Tool (ST)
or an approved equivalent. The airbag unit must never be electrically tested while it is not
installed in the vehicle.
Some aerosol tire inflators are highly flammable. Be extremely cautious when repairing a tire
that may have been inflated using an aerosol tire inflator. Keep sparks, open flame or other
sources of ignition away from the tire repair area. Inflate and deflate the tire at least four times
before breaking the bead from the rim. Completely remove the tire from the rim before
attempting any repair.
When driving or riding in an airbag-equipped vehicle, never hold test equipment in your hands
or lap while the vehicle is in motion. Objects between you and the airbag can increase the risk
of injury in an accident.
I have read and I understand these Cautions and Warnings.
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$52.99
Viewed 67 Times Today
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$52.99
Models covered:
- Audi A4 30 TDI 6MT (122 HP)
- Audi A4 30 TDI 7AT (136 HP)
- Audi A4 35 TDI S tronic 7AT (163 HP)
- Audi A4 40 TDI Quattro S tronic 7AT (190 HP)
- Audi A4 45 TDI Quattro tiptronic 8AT (231 HP)
- Audi A4 50 TDI V6 Quattro tiptronic 8AT (286 HP)
- Audi A4 35 TSFI S tronic 6MT (150 HP)
- Audi A4 35 TSFI S tronic 7AT (150 HP)
- Audi A4 40 TSFI S tronic 7AT (190 HP)
- Audi A4 45 TFSI Quattro S tronic 7AT (245 HP)
This 2023 Audi A4 Service & Repair Manual is a comprehensive resource for both professional mechanics and DIY enthusiasts. It covers your specific model and its variants, providing troubleshooting and replacement procedures, step-by-step instructions, clear images, and exploded-view illustrations.
Regular maintenance is essential for the durability of your vehicle. This manual equips you with the manufacturer's recommended troubleshooting charts and replacement procedures, enabling you to save on repairs, increase reliability, and perform maintenance effectively.
With this repair manual, you can address issues and replace components, including wiring diagrams, torque specs, and exploded-view illustrations. The manufacturer's troubleshooting charts facilitate quick issue identification based on specific symptoms, making it user-friendly for beginners.
Whether you're a weekend DIY’er or a professional mechanic, this 2023 Audi A4 Service & Repair Manual is the go-to solution for maintaining and repairing Audi vehicles, saving you thousands on repairs and maintenance costs.
Compatible with various electronic devices, including PC & Mac computers, Android and Apple smartphones & tablets, this manual is easily accessible and printable, requiring only Adobe Reader (free).
