Workshop Manual
Audi A2 2001 ➤ , Audi A3 1997 ➤ ,
Audi A3 2004 ➤ ,
Audi A3 Cabriolet 2008 ➤ ,
Audi A4 1995 ➤ , Audi A4 2001 ➤ ,
Audi A4 Cabriolet 2003 ➤ ,
Audi A6 1998 ➤ , Audi A6 2005 ➤ ,
Audi A8 1994 ➤ , Audi A8 2003 ➤ ,
Audi TT 1999 ➤
Fitting instructions: retrofitting key-operated switch to
deactivate airbag on front passenger side
Edition 08.2008
Service
Service Department. Technical Information
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
List of Workshop Manual Repair Groups
Repair Group
69 - Passenger protection
Technical information should always be available to the foremen and mechanics, because their
careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and
safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a
matter of course, be observed.
Service
All rights reserved.
No reproduction without prior agreement from publisher.
Copyright © 2015 Audi AG, Ingolstadt 001EBA00020
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Contents
69 - Passenger protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 Overview of retrofitting options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Notes and overview of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.2 Overview of components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Deactivating/activating airbag on front passenger side (Audi A2 2001 ▸) . . . . . . . . . . . . . . 8
4 Retrofitting key-operated switch (Audi A3 1997 ▸ from week 27/1999 onwards) . . . . . . . . 9
4.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.2 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.3 Installing new glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.4 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 12
5 Retrofitting key-operated switch (Audi A3 2004 ▸ including Audi A3 Sportback and Audi A3
Cabriolet 2008 ▸) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1 Removing and installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.3 Routing and securing glove box wiring harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.4 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.5 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 18
6 Retrofitting key-operated switch (Audi A4 1995 ▸ from chassis no. 8DXA 200 001
onwards) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.3 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.4 Installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.5 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 27
7 Retrofitting key-operated switch (Audi A4 2001 ▸ up to week 35/2004 including Audi S4 and
Audi S4 Cabriolet) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.3 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.4 Retrofitting wiring harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.5 Installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.6 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 33
8 Retrofitting key-operated switch (Audi A4 2001 ▸ from week 36/2004 onwards including Audi
S4 and Audi S4 Cabriolet) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.3 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.4 Retrofitting wiring harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.5 Installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.6 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 43
9 Retrofitting wiring harnesses 8E1 970 XXX (Audi A4 2001 ▸) . . . . . . . . . . . . . . . . . . . . . . 45
9.1 Notes on and preparation for retrofitting wiring harnesses (8E1 970 XXX) . . . . . . . . . . . . 45
9.2 Routing wiring harnesses (8E1 970 XXX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.3 Connecting wiring harnesses 8E1 970 XXX to multi-pin connector for airbag control unit J234
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9.4 Assembly work, coding airbag control unit J234 and interrogating fault memories of control
units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
10 Retrofitting key-operated switch (Audi A4 Cabriolet 2003 ▸) . . . . . . . . . . . . . . . . . . . . . . . . 57
11 Retrofitting key-operated switch (Audi A6 1998 ▸ from week 36/1998 onwards including Audi
Allroad, except vehicles with V8 engine) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
11.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
Contents i
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
11.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
11.3 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
11.4 Installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
11.5 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 62
12 Retrofitting key-operated switch (Audi A6 2005 ▸) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
12.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
12.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
12.3 Installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
12.4 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 69
13 Retrofitting key-operated switch (Audi A8 1994 ▸, gradual introduction from approx. week
41/1998 onwards, with front and side or front and curtain airbag) . . . . . . . . . . . . . . . . . . . . 73
13.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
13.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
13.3 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
13.4 Installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
13.5 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 77
14 Retrofitting key-operated switch (Audi A8 2003 ▸) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
14.1 Removing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
14.2 Converting glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
14.3 Installing key-operated switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
14.4 Installing glove box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
14.5 Installing warning lamp for airbag deactivated on front passenger side . . . . . . . . . . . . . . . . 83
14.6 Installing trim panel with switch module (right-side) with warning lamp for airbag deactivated
on front passenger side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
15 Retrofitting key-operated switch (Audi TT 1999 ▸, Coupé/Roadster) . . . . . . . . . . . . . . . . . . 85
16 Coding airbag control unit J234 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
17 Adapting airbag control unit J234 (Audi A6 2005 ▸) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
ii Contents
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
69 – Passenger protection
1 Overview of retrofitting options
Model Vehicle
no.
Retrofitting possible
yes no
Audi A2 2001 ▸ 8Z Deactivation/activation of
airbag on front passenger
side ⇒ page 8
Audi A3 1997 ▸ from week 27/1999 on‐
wards
8L ⇒ page 9
Audi A3 2004 ▸ 8P ⇒ page 14
Audi A3 Sportback 8P ⇒ page 14
Audi A3 Cabriolet 8P ⇒ page 14
Audi A4 1995 ▸ from chassis no.: 8DXA
200 001
8D ⇒ page 24
Audi A4 2001 ▸ up to week 35/2004 8E ⇒ page 29
Audi S4 8E ⇒ page 29
Audi A4 2001 ▸ from week 36/2004 on‐
wards
8E ⇒ page 39
Audi S4 8E ⇒ page 39
Audi A4 Cabriolet 2003 ▸ 8H ⇒ page 57
Audi S4 Cabriolet ▸ up to week 35/2004 QB ⇒ page 29
Audi S4 Cabriolet ▸ from week 36/2004
onwards
QB ⇒ page 39
Audi A6 1998 ▸ from week 36/1998 on‐
wards
4B ⇒ page 58
Audi A6 with V8 engine 4B ⇒ page 58
Audi Allroad 4B ⇒ page 58
Audi Allroad with V8 engine 4B ⇒ page 58
Audi S6 4B ⇒ page 58
Audi RS 6 4B ⇒ page 58
Audi A6 2005 ▸ 4F ⇒ page 64
Audi A8 1994 ▸ from approx.
week 41/1998 onwards
4D ⇒ page 73
Audi A8 2003 ▸ 4E ⇒ page 79
Audi TT 1999 ▸ (Coupé/Roadster) 8N ⇒ page 85
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
1. Overview of retrofitting options 1
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2 Notes and overview of components
2.1 General information
WARNING
When retrofitting key-operated switch to deactivate airbag on
front passenger side -E224- and warning lamp for airbag de‐
activated on front passenger side -K145- , observe safety
precautions for working on airbags ⇒ General body repairs,
interior; Rep. Gr. 69 .
WARNING
Before handling the airbag units (e.g. unplugging the electrical
connector) the mechanic must discharge static electricity by
briefly touching the door striker plate, or similar.
♦ It should be noted that retrofitting the key-operated switch to
deactivate airbag on front passenger side -E224- is not pos‐
sible/necessary for all vehicle models ⇒ page 1 .
♦ After retrofitting key-operated switch to deactivate airbag on
front passenger side -E224- , airbag control unit -J234- must
be re-coded ⇒ page 86 . On Audi A6 2005 ▸, airbag control
unit -J234- must be adapted ⇒ page 87 .
♦ A functional test must be performed after retrofitting the key-
operated switch to deactivate airbag on front passenger side
-E224- and the warning lamp for airbag deactivated on front
passenger side -K145- . Deactivate the airbag (front passen‐
ger side); warning lamp for airbag deactivated on front pas‐
senger side -K145- must light constantly.Then activate the
airbag (front passenger side); warning lamp for airbag deacti‐
vated on front passenger side -K145- must go out.
♦ After retrofitting the key-operated switch to deactivate airbag
on front passenger side -E224- and the warning lamp for air‐
bag deactivated on front passenger side -K145- , interrogate
and erase the fault memories of all control units. To do so, use
a suitable vehicle diagnostic, testing and information system,
e.g. vehicle diagnostic, testing and information system -VAS
5051B- .
♦ After airbag or belt tensioner has been triggered, it is only
possible to retrofit the key-operated switch to deactivate air‐
bag on front passenger side -E224- after the airbag control unit
-J234- has been renewed.
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
2 Rep. Gr.69 - Passenger protection
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2.2 Overview of components
2.2.1 Notes on overview of components
Note
♦ Only the first 6 positions in the part number are given in the
list of “Components required”. The other positions are marked
“XXX”. No information on component and/or colour versions
is given.
♦ The full part number can be found in the ⇒ Electronic parts
catalogue “ETKA” . Attention is to be paid to the information
contained in the part numbers relating to component and/or
colour versions, e.g. indices or the combination of indices and
numbers.
♦ Refer to the ⇒ Electronic parts catalogue “ETKA” to check that
the part numbers given are for components suitable for instal‐
lation in the vehicle.
♦ Note that the warning lamp for airbag deactivated on front
passenger side -K145- is also referred to as “PASSENGER
AIRBAG OFF” lamp.
♦ Most of the components required have two different designa‐
tions in the following list:
Designation without brackets ⇒ Electronic parts catalogue
“ETKA” .
Designation with brackets ⇒ Current flow diagrams, Electrical
fault finding and Fitting locations
2.2.2 Audi A3 1997 ▸ from week 27/1999 on‐
wards
Notes on overview of components ⇒ page 3
Components required
♦ 4B0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 107 857 XXX Lock cylinder without key
♦ 8L0 947 XXX Interior and reading light for vehicles with front
passenger's airbag deactivation option ( front interior light -
W1- with warning lamp for airbag deactivated on front pas‐
senger side -K145- )
♦ 8L1 857 XXX Glove box (passenger side) for vehicles with
front passenger's airbag deactivation option
2.2.3 Audi A3 2004 ▸ (including Audi A3
Sportback)
Notes on overview of components ⇒ page 3
Components required
♦ 4B0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
2. Notes and overview of components 3
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ 5P0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 8E0 947 XXX Interior and reading light for vehicles with front
passenger's airbag deactivation option ( front interior light -
W1- with warning lamp for airbag deactivated on front pas‐
senger side -K145- )
♦ 8P0 919 XXX Airbag warning lamp ( warning lamp for airbag
deactivated on front passenger side -K145- )
♦ 8P0 919 XXX Airbag warning lamp for vehicles with double
DIN radio cut-out 182 x 112 mm ( warning lamp for airbag de‐
activated on front passenger side -K145- )
♦ 8P0 971 XXX Wiring harness for glove box light
2.2.4 Audi A4 1995 ▸ from chassis no. 8DXA
200 001 onwards
Notes on overview of components ⇒ page 3
Components required
♦ 4B0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 107 857 XXX Lock cylinder without key
♦ 8D1 857 XXX Cover only for: key-operated switch for deacti‐
vating airbag on front passenger side (left-hand-drive vehi‐
cles)
♦ 8D0 947 XXX Interior and reading light for vehicles with front
passenger's airbag deactivation option ( front interior light -
W1- with warning lamp for airbag deactivated on front pas‐
senger side -K145- )
2.2.5 Audi A4 2001 ▸ up to week 35/2004 (in‐
cluding Audi S4)
Notes on overview of components ⇒ page 3
Components required
♦ 8E0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 4B0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 5P0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 107 857 XXX Lock cylinder without key
♦ 8E0 947 XXX Interior and reading light for vehicles with front
passenger's airbag deactivation option ( front interior light -
W1- with warning lamp for airbag deactivated on front pas‐
senger side -K145- )
♦ 8E1 919 XXX Airbag warning lamp ( warning lamp for airbag
deactivated on front passenger side -K145- ), left-hand-drive
vehicles
♦ 8E2 919 XXX Airbag warning lamp ( warning lamp for airbag
deactivated on front passenger side -K145- ), right-hand-drive
vehicles
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
4 Rep. Gr.69 - Passenger protection
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ 8E0 971 XXX Wiring harness for glove box light
♦ 8E1 970 XXX Wiring harness (between airbag control unit -
J234- and warning lamp for airbag deactivated on front pas‐
senger side -K145- )
2.2.6 Audi A4 2001 ▸ from week 36/2004 on‐
wards (including Audi S4)
Notes on overview of components ⇒ page 3
Components required
♦ 5P0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 8E1 919 XXX Airbag warning lamp ( warning lamp for airbag
deactivated on front passenger side -K145- ), left-hand-drive
vehicles
♦ 8E2 919 XXX Airbag warning lamp ( warning lamp for airbag
deactivated on front passenger side -K145- ), right-hand-drive
vehicles
♦ 8E0 971 XXX Wiring harness for glove box light
♦ 8E1 970 XXX Wiring harness (from airbag control unit -J234-
to warning lamp for airbag deactivated on front passenger side
-K145- and connector of supply lead/wiring harness for glove
box)
2.2.7 Audi A6 1998 ▸ from week 36/1998 on‐
wards (including Audi Allroad, except
vehicles with V8 engine)
WARNING
There is no provision for retrofitting the key-operated switch to
deactivate airbag on front passenger side -E224- on vehicles
with V8 engine (Audi A6, Audi Allroad, Audi S6 and Audi RS
6).
Notes on overview of components ⇒ page 3
Components required
♦ 4B0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 8E0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 4B0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 107 857 XXX Lock cylinder without key for vehicles with front
passenger's airbag deactivation option
♦ 4B1 857 XXX Cover (left-hand-drive vehicles)
♦ 4B2 857 XXX Cover (right-hand-drive vehicles)
♦ N 904 997 02 Oval head bolt with double thread 3x10 (2x)
♦ 4B0 947 XXX Interior light for vehicles with front passenger's
airbag deactivation option ( front interior light -W1- with warn‐
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
2. Notes and overview of components 5
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
ing lamp for airbag deactivated on front passenger side -
K145- )
♦ 4B1 971 XXX Wiring harness for glove box light
2.2.8 Audi A6 2005 ▸
Notes on overview of components ⇒ page 3
Components required
♦ 1K0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 4F1 857 XXX Mounting for vehicles with front passenger's air‐
bag deactivation option (left-hand-drive vehicles)
♦ 4F2 857 XXX Mounting for key-operated switch to deactivate
airbag on front passenger side (right-hand-drive vehicles)
♦ N 909 365 01 Torx socket self-tapping screw 3x12 (2x)
♦ 4F0 919 XXX Airbag warning lamp ( warning lamp for airbag
deactivated on front passenger side -K145- )
♦ 4F1 820 XXX Fresh-air vent (centre), left-hand-drive vehicles
♦ 4F2 820 XXX Fresh-air vent (centre), right-hand-drive vehicles
♦ 4F0 971 XXX Wiring harness for glove box light
2.2.9 Audi A8 1994 ▸, gradual introduction
from approx. week 41/1998 onwards
(with front and side or front and curtain
airbag)
Notes on overview of components ⇒ page 3
Components required
♦ 4D0 919 XXX Key-operated switch for deactivation of front
passenger's airbag ( key-operated switch to deactivate airbag
on front passenger side -E224- )
♦ 107 857 XXX Lock cylinder without key for vehicles with front
passenger's airbag deactivation option
♦ 4D1 857 XXX Trim for key-operated switch to deactivate air‐
bag on front passenger side (left-hand-drive vehicles)
♦ 4D2 857 XXX Trim for key-operated switch to deactivate air‐
bag on front passenger side (right-hand-drive vehicles)
♦ 4B0 947 XXX Interior light for vehicles with front passenger's
airbag deactivation option ( front interior light -W1- with warn‐
ing lamp for airbag deactivated on front passenger side -
K145- )
♦ 4D0 971 XXX Wiring harness for glove box light
♦ 4D0 857 XXX Cover for vehicles with front passenger's airbag
deactivation option (hinge trim)
♦ 4D1 857 XXX Cover for vehicles with front passenger's airbag
deactivation option (cable duct cover), left-hand-drive vehicles
♦ 4D0 857 XXX Cover for vehicles with front passenger's airbag
deactivation option (cable duct cover), right-hand-drive vehi‐
cles
♦ N 903 474 02 Oval head self-tapping screw 4x12 (2x)
Audi A2 2001 ➤ , Audi A3 1997 ➤ , Audi A3 2004 ➤ , Audi A3 Cabriolet 20 ...
Fitting instructions: retrofitting key-operated switch to deactivate airbag on front passenger side -
Edition 08.2008
6 Rep. Gr.69 - Passenger protection
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$52.99
Viewed 32 Times Today
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$52.99
The 2007 Audi A4 Avant Download Service & Repair Manual is a comprehensive guide to maintaining and repairing your Audi A4 Avant. This manual is specifically designed for the 2007 model year and covers all aspects of service and repair.
- Includes detailed instructions for performing routine maintenance tasks such as oil changes, tire rotations, and brake inspections.
- Covers troubleshooting and diagnostic procedures for common issues that may arise with your vehicle.
- Provides step-by-step instructions for repairing major components, including the engine, transmission, electrical system, and more.
- Offers wiring diagrams and electrical schematics to assist with troubleshooting electrical issues.
- Provides torque specifications and tightening sequences for all fasteners used on the vehicle.
Whether you are a professional mechanic or a do-it-yourself enthusiast, the 2007 Audi A4 Avant Download Service & Repair Manual is an essential tool for maintaining and repairing your vehicle. With detailed instructions and illustrations, this manual will help you keep your Audi running smoothly for years to come.
