SHARP AR-5012 LASER COPIER Parts GUIDE

This is a parts guide for the SHARP AR-5012 LASER COPIER. The manual covers the following:

• Exteriors
• Original cover unit
• Operation pane
• Side door unit
• Optical frame
• LSU unit
• Delivery paper guide unit
• Middle frame
• Base plate unit 1
• Base plate unit 2
• Fusing unit
• Drive unit
• Single manual paper feeding cover unit
• Socket holder unit
• Single manual paper feeding unit
• 250 sheets tray
• TC case unit
• Harness
• Process unit
• DV cartridge unit
• Packing material & accessories
• Operation PWB
• MCU PWB
• DC power supply PWB (200V Series)
