Canon NP6350/NP6250/NP6251/NP6551 Parts Catalog

This is a comprehensive parts catalog for the Canon NP6350, NP6250, NP6251, and NP6551 models. It covers a wide range of components and assemblies, making it an essential resource for both professional mechanics and DIY enthusiasts.

• Assembly Location Diagram
• Special Tools
• External Covers, Panels, etc.
• Machine Front Plate
• Internal Components 1, 2, and 3
• Machine Rear Plate 1 and 2
• Machine Bottom Plate
• Power Cord Terminal Assembly (100/115/120V and 220/240V)
• Control Panel Assembly
• Counter Assembly
• Fixing Exhaust Fan Assembly
• Developing Fan Assembly
• Feeder Fan Assembly
• Machine Exhaust Fan Assembly
• Scanner Cooling Fan Assembly
• Lens Mount Assembly
• Vertical Path Drive Assembly
• Paper Pick-Up Drive Assembly
• Duplexing Drive Assembly
• Main Drive Assembly
• Re-Pick Up Drive Assembly
• Cassette Pick-Up Drive Assembly
• Duplexing Feed Drive Assembly
• Waste Toner Drive Assembly
• Cassette
• 1.5K Right Paper Stock Assembly
• 1.5K Left Paper Stock Assembly
• Cassette Heater Assembly (Accessory)
• Upper Cassette Pick-Up Assembly
• Lower Cassette Pick-Up Assembly
• Deck Right Pick-Up Assembly
• Deck Left Pick-Up Assembly
• Multi Feed Assembly
• Multi Feed Tray Assembly
• Fixing/Feeder Frame Assembly
• Registration/Transfer Assembly
• Feeder Assembly
• Holding Tray Assembly
• Re-Pick Up Assembly
• Inlet Paper Guide Assembly
• Side Limit Assembly
• Feed Roller/Separation Belt Assembly
• Internal Delivery Upper Assembly
• External Delivery Upper Assembly
• Duplexing Feeder Assembly
• Mirror Assembly 1 and 2
• Photo-Sensitive Drum Assembly
• Primary Corona Assembly
• Pre-Transfer Corona Assembly
• Transfer/Separate Corona Assembly
• AP Kit Assembly
• Hopper Assembly
• Developing Assembly
• Separation Claw Drive Assembly
• Waste Toner Assembly
• Fixing Assembly
• DC Power Supply PCB Assembly
• Control Panel PCB Assembly
• Control Panel Inverter PCB Assembly
• DC Controller PCB Assembly
• Potential Measuring PCB Assembly
• H.V. Transformer PCB Assembly

Additionally, it includes a list of connectors, standard fasteners, and a numerical index for easy reference. The manual is in PDF format, totaling 269 pages and is compatible with all versions of Windows, Mac, iOS, and Android devices. It is fully indexed and bookmarked by topic, allowing for quick searches within each chapter. The high-quality Adobe document ensures clear and precise printing, with the option to print the entire manual or select specific pages. Zooming in on diagrams and pictures provides detailed views of every part.

Instant access to the manual eliminates shipping costs and waiting time, as it can be received via secure payment processing methods. Accepted payment options include all major credit/debit cards and PayPal.
