Canon NP6035 / NP6028 / NP6230 Parts Catalog
Lifetime Access
Lifetime Access
Description
This is a parts catalog for the Canon NP6035 / NP6028 / NP6230.
Manual Contents:
- Assembly Location Diagram
- Special Tools
- External Covers, Panels, etc.
- Machine Front Plate
- Internal Components 1, 2, and 3
- Machine Rear Plate
- Power Cord Terminal Assembly (100/115/120V and 220/240V)
- Control Panel Assembly
- Copyboard Cover Assembly
- Counter Assembly
- Exhaust Fan Assembly
- Scanner Cooling Fan Assembly
- Lens Mount Assembly
- Scanner Motor Assembly
- Main Motor Assembly
- Drum Drive Assembly
- Cleaning Belt Drive Assembly
- Cassette
- Cassette Heater Assembly (Option)
- Paper Pick-Up Assembly
- Registration Guide Assembly
- Multi Feed Assembly
- Multi Feed Tray Assembly
- Feeder Assembly
- Delivery Assembly
- Mirror Assembly 1 and 2
- Blank Exposure Assembly
- Drum Kit
- Transfer Corona Assembly
- Transfer Guide Assembly
- Hopper Assembly
- Developing Assembly
- Fixing Assembly
- Fixing Roller Cleaning Assembly
- DC Power Supply PCB Assembly
- 5V Power Supply PCB Assembly
- Control Panel PCB Assembly
- DC Controller PCB Assembly
- Motor Driver PCB Assembly
- AE Sensor Assembly
Additional Sections:
- List of Connectors
- List of Standard Fasteners
- Numerical Index
Model Specification: Canon NP6035 / NP6028 / NP6230
Total Pages: 207
File Format: PDF
Language: English
Compatibility: All Versions of Windows & Mac, APP ISO, iPhone, iPad, Android, etc.
This manual is in PDF format. The Service Manual is fully indexed and bookmarked by topic, providing easy navigation. It is an original Adobe document, ensuring high quality and perfect printing. The PDF can be searched quickly to find information in every chapter. Users have the option to print the entire manual or select specific pages. Additionally, the manual allows zooming in on diagrams or pictures for better visibility of every part.
Whether for professional mechanics or DIY enthusiasts, this manual simplifies repair jobs with easy-to-follow step-by-step instructions and detailed pictures covering all areas of repair.
All Service Repair Manuals are instant PDF downloads, eliminating shipping costs and waiting time for physical copies. Upon payment completion via the secure processor, the manual is instantly accessible. Accepted payment methods include all major credit/debit cards and PayPal.
