SECTION 00 -- GENERAL -- CHAPTER 1 1 GENERAL INSTRUCTIONS IMPORTANT NOTICE All maintenance and repair work described in this manual must be performed exclusively by NEW HOLLAND service technicians, in strict accordance with the instructions given and using any specific tools necessary. Anyone performing the operations described herein without strictly following the instructions is personally re- sponsible for any eventual injury or damage to property. BATTERY Before carrying out any kind of service operations, disconnect and isolate the battery negative lead, unless other- wise requested for specific operations (e.g.: operations that require the engine running). Once the specific operation has been completed, disconnect the lead in order to complete the operation. SHIMMING For each adjustment operation, select adjusting shims and measure individually using a micrometer, then add up the recorder values. Do not rely on measuring the entire shimming set, which may be incorrect, or the rated value indicated for each on shim. ROTATING SHAFT SEALS For correct rotating shaft seal installation, proceed as follows: -- before assembly, allow the seal to soak in the oil it will be sealing for at least thirty minutes; -- thoroughly clean the shaft and check that the working surface on the shaft is not damaged; -- position the sealing lip facing the fluid; with hydrodynamic lips, take into consideration the shaft rotation direction and position the grooves so that they will deviate the fluid towards the inner side of the seal; -- coat the sealing lip with a thin layer of lubricant (use oil rather than grease) and fill the gap between the sealing lip and the dust lip on double lip seals with grease; -- insert the seal in its seat and press down using a flat punch, do not tap the seal with a hammer or mallet; -- whilst inserting the seal, check that the it is perpendicular to the seat; once settled, make sure that it makes contact with the thrust element, if required; -- to prevent damaging the seal lip on the shaft, position a protective guard during installation operations. O--RING SEALS Lubricate the O--RING seals before inserting them in the seats, this will prevent them from overturning and twisting, which would jeopardise sealing efficiency. SEALING COMPOUNDS Apply one of the following sealing compounds on the mating surfaces marked with an X: LOCTITE 518, LOC- TITE 5205, SUPERBOND 559 MASCHERPA or BETABLOCK A272M GURIT ESSEX. Before applying the sealing compound, prepare the surfaces as follows: -- remove any incrustations using a metal brush; -- thoroughly de--grease the surfaces using one of the following cleaning agents: trichlorethylene, petrol or a water and soda solution. BEARINGS When installing bearings it is advised to: -- heat the bearings to 80 to 90 ° C (176 to 194 ° F) before fitting on the shafts; -- allow the bearings to cool before installing them from the outside. SPRING PINS When fitting split socket spring pins, ensure that the pin notch is positioned in the direction of the force required to stress the pin. Spiral spring pins do not require special positioning.

2 SECTION 00 -- GENERAL -- CHAPTER 1 SPARE PARTS Only use original NEW HOLLAND spare parts bearing the logo shown below. 1 Only original spare parts guarantee the same quality, duration and safety as they are the same parts that are assembled during production. Only original NEW HOLLAND parts can offer this guarantee. When ordering spare parts, always provide the following information: -- tractor model (commercial name) and frame number; -- engine type and number; -- part number of the ordered part, which can be found in the Microfiches or the Spare Parts Catalogue, used for order processing. TOOLS The tools that NEW HOLLAND propose and illustrate in this manual are: -- specifically researched and designed for use with NEW HOLLAND tractors; -- essential for reliable repair operations; -- accurately built and rigorously tested so as to offer efficient and long--lasting operation. By using these tools, Repair Personnel will benefit from: -- operating in optimal technical conditions; -- obtaining the best results; -- saving time and effort; -- working in safe conditions. NOTE Wear limit values indicated for certain parts are recommended, but not binding. The terms front, rear, right-- hand and left--hand (when referred to different parts) are intended as seen from the driving position with the tractor in the normal direction of movement. MOVING THE TRACTOR WITH THE BATTERY REMOVED External power supply cables should only be connected to the respective positive and negative cable terminals, using efficient clamps that guarantee adequate and secure contact. Disconnect all services (lights, windshield wipers, etc.) before starting the tractor. If the tractor electrical system requires checking, carry out operations with the power supply connected. Once checking is completed, disconnect all services and switch off the power supply before disconnecting the cables.

SECTION 00 -- GENERAL -- CHAPTER 1 3 SAFETY REGULATIONS WARNING AND DANGER SYMBOL This warning symbol points out important messages concerning your safety. Carefully read the following safety regulations and observe advised precautions in order to avoid potential hazards and safeguard your health and safety. In this manual the symbol is accompanied by the following key--words: WARNING -- Warnings concerning unsuitablerepair operations that may jeopardise the safety of Repair personnel. DANGER -- Specific warnings concerning potential hazards for operator safety or for other persons directly or indirectly involved. ACCIDENT PREVENTION Most accidents or injuries that occur in workshops are the result of non--observance of simple and fun- damental safety regulations. For this reason, IN MOST CASES THESE ACCIDENTS CAN BE AVOIDED by foreseeing possible causes and conse- quently acting with the necessary caution and care. Accidents may occur with all types of machine, re- gardless of how well the machine in question was designed and built. A careful and judicious service technician is the best guarantee against accidents. Precise observance of the most basic safety rule is normally sufficient to avoid many serious accidents. DANGER. Never carry out any cleaning, lubrication or maintenance operations when the engine is running. SAFETY REGULATIONS GENERAL GUIDELINES -- Carefully follow specified repair and maintenance procedures. -- Do not wear rings, wristwatches, jewellery, un- buttoned or loose articles of clothing such as: ties, torn clothing, scarves, open jackets or shirts with open zips that may remain entangled in moving parts. It is advised to wear approved safety clothing, e.g.: non--slip footwear, gloves, safety goggles, helmets, etc. 2 -- Do not carry out repair operations with someone sitting in the drivers seat, unless the person is a trained technician who is assisting with the operation in question. -- Do not operate the machine or use any of the implements from different positions, other than the drivers seat. -- Do not carry out operations on the machine with the engine running, unless specifically indicated. -- Stop the engine and check that the hydraulic cir- cuits are pressure--free before removing caps, covers, valves, etc. -- All repair and maintenance operations must be carried out using extreme care and attention. -- Service steps and platforms used in the workshop or elsewhere should be built according to standard accident prevention regulations. -- Disconnect the batteries and label all controls to indicate that the tractor is being serviced. Any parts that are to be raises must be locked in position. -- Do not check or fill fuel tanks, accumulator batteries, nor use starting liquid when smoking or near naked flames, as these fluids are inflammable. -- Brakes are inoperative when manually released for repair or maintenance purposes. Use blocks or similar devices to control the machine in these conditions. -- The fuel nozzle should always be in contact with the filling aperture. Maintain this position until filling operations are completed in order to avoid possible sparks caused by the accumulation of static electricity.

4 SECTION 00 -- GENERAL -- CHAPTER 1 -- Only use specified towing points for towing the tractor. Connect parts carefully. Make sure that all pins and/or locks are secured in position before applying traction. Never remain near the towing bars, cables or chains that are operating under load. -- Transport tractors that cannot be driven using a trailer or a low--loading platform trolley, if available. -- When loading or unloading the tractor from the trailer (or other means of transport), select a flat area capable of sustaining the trailer or truck wheels. Firmly secure the tractor to the truck or trailer and lock the wheels in the position used by the carrier. -- Electric heaters, battery--chargers and similar equipment must only be powered by auxiliary power supplies with efficient ground insulation to avoid electrical shock hazards. -- Always use suitable hoisting or lifting devices when raising or moving heavy parts. -- Take extra care if bystanders are present. -- Never pour gasoline or diesel oil into open, wide or low containers. -- Never use gasoline, diesel oil or other inflammable liquids as cleaning agents. Use non--inflammable, non toxic commercially available sol- vents. -- Wear safety goggles with side guards when cleaning parts with compressed air. -- Limit the air pressure to a maximum of 2.1 bar (31 PSI), according to local regulations. -- Do not run the engine in confined spaces without suitable ventilation. -- Do not smoke, use naked flames, or cause sparks in the area when fuel filling or handling highly inflammable liquids. -- Never use naked flames for lighting when working on the machine or checking for leaks. -- All movements must be carried out carefully when working under, on or near the tractor. Wear protective equipment: helmets, goggles and special footwear. -- When carrying out checks with the engine running, request the assistance of an operator in the drivers seat. The operator must maintain visual contact with the service technician at all times. -- If operating outside the workshop, position the tractor on a flat surface and lock in position. If working on a slope, lock the tractor in position. Move to a flat area as soon as is safely possible. -- Damaged or bent chains or cables are unreliable. Do not use them for lifting or towing. Always use suitable protective gloves when handling chains or cables. -- Chains should always be safely secured. Make sure that the hitch--up point is capable of sustaining the load in question. Keep the area near the hitch--up point, chains or cables free of all bystanders. -- Maintenance and repair operations must be carried out in a CLEAN and DRY area. Eliminate any water or oil spillage immediately. -- Do not create piles of oil or grease--soaked rags as they represent a serious fire hazard. Always store rags in a closed metal container. Before starting the tractor or implements, make sure that the drivers seat is locked in position. Also check that there are no persons within the tractor or implement range of action. -- Empty pockets of all objects that may fall unob- served into the tractor parts. -- In the presence of protruding metal parts, use protective goggles or goggles with side guards, helmets, special footwear and gloves. -- When welding, use protective safety devices: tinted safety goggles, helmets, special overalls, gloves and footwear. All persons present in the area where welding is taking place must wear tinted goggles. NEVER LOOK DIRECTLY AT THE WELDING ARC WITHOUT SUITABLE EYE PROTECTION. -- Metal cables tend to fray with repeated use. Al- ways use suitable protective devices (gloves, goggles, etc.) when handling cables. -- Handle all parts carefully. Do not put your hands or fingers between moving parts. Wear suitable safety clothing -- safety goggles, gloves and shoes.

SECTION 00 -- GENERAL -- CHAPTER 1 5 START UP -- Never run the engine in confined spaces that are not equipped with adequate ventilation for exhaust gas extraction. -- Never place the head, body, limbs, feet, hands or fingers near fans or rotating belts. ENGINE -- Always loosen the radiator cap slowly before removing it to allow any remaining pressure in the system to be discharged. Filling up with coolant should only be carried out with the engine stopped or idling (if hot).. -- Never fill up with fuel when the engine is running, especially if hot, in order to prevent the outbreak of fire as a result of fuel spillage. -- Never check or adjust fan belt tension when the engine is running. Never adjust the fuel injection pump when the tractor is moving. -- Never lubricate the tractor when the engine is running. ELECTRICAL SYSTEMS -- If it is necessary to use auxiliary batteries, re- member that both ends of the cables must be connected as follows: (+) with (+) and (--) with (--). Avoid short--circuiting the terminals. GAS RE- LEASED FROM BATTERIES IS HIGHLY IN- FLAMMABLE. During charging, leave the battery compartment uncovered to improve ventilation. Never check the battery charge using jumpers (metal objects placed on the terminals). Avoid sparks or flames near the battery zone. Do not smoke to prevent explosion hazards. -- Before servicing operations, check for fuel or current leaks. Eliminate any eventual leaks before proceeding with work. -- Never charge batteries in confined spaces. Make sure that there is adequate ventilation in order to prevent accidental explosion hazards as a result of the accumulation of gases released during charging operations. -- Always disconnect the batteries before performing any kind of servicing on the electrical system. HYDRAULIC SYSTEMS -- A liquid leaking from a tiny hole may be almost invisible but, at the same time, be powerful enough to penetrate the skin. Therefore, NEVER USE HANDS TO CHECK FOR LEAKS but use a piece of cardboard or wood for this purpose. If any liquid penetrates skin tissue, call for medical aid immediately. Failure to treat this condition with correct medical procedure may result in serious infection or dermatosis. -- In order to check the pressure in the system use suitable instruments. WHEELS AND TIRES -- Make sure that the tires are correctly inflated at the pressure specified by the manufacturer. Periodically check the rims and tires for damage. -- Stand away from (at the side of) the tire when checking inflation pressure. -- Only check pressure when the tractor is un- loaded and the tires are cold, to avoid incorrect readings as a result of over--pressure. Do not use parts of recovered wheels as incorrect welding brazing or heating may weaken and eventually cause damage to the wheel. -- Never cut or weld a rim mounted with an inflated tire. -- To remove the wheels, lock both the front and rear tractor wheels. After having raised the tractor, position supports underneath, according to regulations in force. -- Deflate the tire before removing any objects that may be jammed in the tire tread. -- Never inflate tires using inflammable gases, as this may result in explosions and injury to bystanders. REMOVAL AND RE--FITTING -- Lift and handle all heavy parts using suitable hoisting equipment. Make sure that parts are sus- tained by appropriate hooks and slings. Use the hoisting eyebolts for lifting operations. Extra care should be taken if persons are present near the load to be lifted. -- Handle all parts carefully. Do not put your hands or fingers between parts. Wear suitable safety clothing -- safety goggles, gloves and shoes. -- Avoid twisting chains or metal cables. Always wear safety gloves when handling cables or chains.

6 SECTION 00 -- GENERAL -- CHAPTER 1 CONSUMABLES PARTS TO BE FILLED QUANTITY liter (gal.) NEW HOLLAND RECOMMENDED PRODUCT NEW HOLLAND SPECIFICATION INTERNATIONAL SPECIFICATION Cooling system: without cab .............. 10.0 (2.64) Water and liquid AMBRA AGRIFLU 50% + 50% Water and liquid Antifreeze Fleetguard ES Coolant EG (Ethylene Glycol) 50% + 50% SAE1941 ASTM D4985 (EG) Fuel tank: .... 65 (17.17) Decanted and filtered fuel oil -- -- Crankcase sump: without filter: ............. with filter: ................ 6.7 (1.77) 7.5 (1.98) AMBRA Break-In Engine Oil (10W40) AMBRA SUPER GOLD HSP Engine Oil (15W40) NH Break-In Engine Oil (10W40) NH Super Premium (15W40) Engine Oil API SE/CC 10W40 API CH-4/SS CCMC 04 UNI 20153 MIL-L2104C ACEA E3/E5 Brake control circuit ...... 0.7 (0.18) 0.5 (0.13) AMBRA BRAKE LHM Mineral Brake Oil NH Brake Oil (86541699DS) ISO 7308 Front axle: axle case ................ TN55 lateral final drives without brakes (each) ....... TN55 lateral final drives with brakes (each) ............ TN65, TN70 and TN75 lateral final drives without brakes (each) ............... TN65, TN70 and TN75 lateral final drives with brakes (each) .................. 4.5 (1.19) 0.8 (0.21) 1.3 (0.34) 1.0 (0.26) 1.5 (0.40) AMBRA MULTI G134 Hydraulic Oil NH 134D Hydraulic Oil API GL4 ISO 32/46 SAE 10W--30 Rear transmission (bevel gear pair, lateral final drives and brakes), gearbox, hydraulic lift, power take--off and hydrostatic steering: .. 42 (11.10) Compression cups ....... -- AMBRA GR9 Multipurpose Grease NH Super Premium MP Lithium Grease (86506331) NLGI 2

SECTION10 -- ENGINE -- CHAPTER1 1 SECTION10 -- ENGINE Chapter1 -- Engine CONTENTS Section Description Page 10 000 General specifications 2 ......................................................... Data 5 ......................................................................... Torque settings 22 .............................................................. Tools 23 ....................................................................... Cross--sectional views 25 ........................................................ Lubrication and cooling system diagrams 27 ........................................ Troubleshooting 29 .............................................................. 10 001 10 Engine, Removal--Installation 33 .................................................. 10 001 30 Compression test 35 ............................................................ 10 001 54 Engine, Removal--Assembly 36 ................................................... 10 414 10 Coolant Pump and Alternator Drive Belt -- Tension adjustment 72 ...................... 10 101 53 Valve guides, Replacement 73 .................................................... 10 101 60 Injector holder casing, Replacement 76 ............................................ 10 102 70 Front engine oil seal, Removal--Installation 78 ...................................... 10 106 12 Valve clearance adjustment 80 ................................................... 10 126 10 Fuel tank, Removal--Installation 82 ................................................ 10 218 30 Engine injectors, Removal--Installation 84 .......................................... 10 246 14 Bosch injection pump, Removal--Installation, timing and air bleed check 86 ............. 10 254 44 Exhaust pipe, Removal--Installation 92 ............................................. 10 402 11 Coolant pump, Removal--Installation, with radiator removed 93 ........................ 10 402 28 Coolant pump, Overhaul 94 ...................................................... 10 402 30 Thermostat, Removal--Installation 95 .............................................. 10 406 10 Radiator, Removal--Installation 97 .................................................

2 SECTION10 -- ENGINE -- CHAPTER1 GENERAL SPECIFICATIONS Engine type: -- Hp TN 55 -- type 8035.05B.529 ..................................... See data page 6--7 -- Hp TN 65 -- type 8035.05R.539 ..................................... See data page 8--9 -- Hp TN 70 -- type 8035.25R.520 ..................................... See data page 97 -- Hp TN 75 -- type 8035.25.529 ....................................... See data page 10--11 Cycle ............................................................... diesel, 4--stroke Fuel injection ........................................................ direct No. of in--line cylinders ................................................ 3 Cylinder liners ....................................................... dry force--fitted in cylinder block Piston diameter: -- Hp TN 55 ........................................................ 104 mm (4.09 inches) -- Hp TN 65 ........................................................ 104 mm (4.09 inches) -- Hp TN 70 ........................................................ 104 mm (4.09 inches) -- Hp TN 75 ........................................................ 104 mm (4.09 inches) Piston stroke ........................................................ 115 mm (4.53 inches) Total displacement: -- Hp TN 55 ........................................................ 2931 cm 3 (0.77 gallons) -- Hp TN 65 ........................................................ 2931 cm 3 (0.77 gallons) -- Hp TN 70 ........................................................ 2931 cm 3 (0.77 gallons) -- Hp TN 75 ........................................................ 2931 cm 3 (0.77 gallons) Compression ratio, models TN 55 and TN 65 ............................. 17:1 normal intake Compression ratio, model TN 70 and TN 75 .............................. 16.5:1 turbocharged Maximum power: -- Hp TN 55 ........................................................ 37 kW (50 HP) -- Hp TN 65 ........................................................ 44 kW (60 HP) -- Hp TN 70 ........................................................ 51 kW (70 HP) -- Hp TN 75 ........................................................ 53 kW (72 HP) Max. power speed .................................................... 2300 rpm Max. torque speed: model TN 55 ....................................... 1400 rpm Max. torque speed: model TN 65 ....................................... 1400 rpm Max. torque speed: model TN 70 ....................................... 1400 rpm Max. torque speed: model TN 75 ....................................... 1400 rpm Number of main bearings .............................................. 4 Sump pan ........................................................... structural, cast iron (continued)

SECTION10 -- ENGINE -- CHAPTER1 3 (continued) GENERAL SPECIFICATIONS Lubrication ........................................... forced, with gear pump 1st 50 hr oil (Break-in Engine Oil) ......................... 10W-40 -- API SE/CC 10W-40 After 50 hr oil (AMBRA SUPER GOLD HSP Engine Oil) ..... 15W-40 -- API CH-4/SD Pump drive ............................................ camshaft Engine speed/oil pump speed ratio ....................... 2:1 Oil cleaning ............................................ mesh screen on oil pick--up and filter cartridge in delivery line Normal oil pressure. Ideal pressure readings obtained at Oil Pan Temperature of 100 °C ± 5 °C (212 °F ± 9 °F) TN 55 and TN 65 at min ERPM (650 ± 25) ................. * > .69 bar (> 9.94 psi) TN 55 and TN 65 at max ERPM (2475 ± 25) ............... * > 2.94 to 3.92 bar (> 42.6 to 56.8 psi) TN 70 and TN 75 at min ERPM (650 ± 25) ................. * > 1.08 bar (> 15.62 psi) TN 70 and TN 75 at max ERPM (2500 ± 25) * > 1.96 bar (> 28.4 psi) Pressure relief valve .................................... built into pump housing Valve opening pressure ................................. 3.5 bar (50.8 psi) For further lubrication technical data ...................... See page 19 Cooling system ....................................... water circulation Radiator on models TN 55, TN 65 ........................ 3--row vertical pipes with copper fins Radiator on model TN 70 and TN 75 ...................... 4--row vertical pipes with copper fins Fan, attached to coolant pump pulley ..................... 6--blade steel exhauster fan Coolant pump .......................................... centrifugal vane--type Engine speed/coolant pump speed ratio ................... 1:1.25 Temperature control .................................... thermostat Coolant thermometer ................................... coloured scale divided into 3 sections Temperature ranges corresponding to each section: -- initial white section .................................. 30 o to 65 o C (86 o to 149 o F) -- middle green section (normal working conditions) ........ 65 o to 105 o C (149 o to 221 o F) -- final red section .................................... 105 o to 115 o C (221 o to 239 o F) For further cooling system data .......................... See page 19 Rev counter .......................................... incorporated in control panel Operating system ...................................... from gear on camshaft Hour counter calibrated for engine speed of ............... 1800 rpm (continued overleaf) * > means greater than

4 SECTION10 -- ENGINE -- CHAPTER1 (continued) GENERAL SPECIFICATIONS Timing ............................................... overhead valves operated camshaft located in engine block through tappets, pushrods and rockers; camshaft is driven by the crankshaft through helical gears Inlet: -- start: before TDC ................................... 12 o -- end: after BDC ..................................... 31 o Exhaust: -- start: before BDC ................................... 50 o -- end: after TDC ...................................... 16 o Valve clearance for timing check .......................... 0.45 mm (0.02 inches) Valve clearance for normal running (engine cold): -- inlet ............................................... 0.30 ± 0.05 mm (0.01 ± 0.002 inches) -- exhaust ............................................ 0.30 ± 0.05 mm (0.01 ± 0.002 inches) For further timing data .................................. See page 16 Fuel system Air cleaning ............................................ dual cartridge dry air filter, with clogged filter indicator with centrifugal pre--filter and automatic dust ejector Fuel supply pump ...................................... double diaphragm Fuel filtering ........................................... through wire filter in fuel supply pump, and replaceable cartridge on delivery line to injection pump Minimum fuel flow rate with pump shaft rotating at 1600 rpm . 100 litres/hour (26.42 gallons/hour) Operated by eccentric cam .............................. on camshaft BOSCH injection pump .................................. distributor type All--speed governor, incorporated in pump: BOSCH ............................................... centrifugal counterweights Automatic advance regulator, incorporated in pump: BOSCH ............................................... hydraulic For further fuel system data: For fixed advance (pump setting for start of delivery before TDC) -- Pressure setting -- Injection order, and other information regarding the BOSCH pump ................... refer to the data for the relevant engine type in the table on page 2
