Massey Ferguson 5400 CONTENTS - i
Introduction - Specifications
01 - Introduction - Specifications
CONTENTS
1A10 - Using the manual
1B10 - SPECIFICATIONS - General specifications
1B11 - SPECIFICATIONS - Forward speeds
1B12 - SPECIFICATIONS - Dimensions
1B13 - SPECIFICATIONS - Capacities
1C10 - Miscellaneous
Massey Ferguson 5400 CONTENTS - ii
Introduction - Specifications
Massey Ferguson 5400 - Issue 4.a
1A10.1
Using the manual
1A10 - Using the manual
CONTENTS
A . General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
B. Structure of the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
C. Service tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
D. Repairs and parts replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Massey Ferguson 5400 - Issue 4.a
1A10.2
Using the manual
Massey Ferguson 5400 - Issue 4.a
1A10.3
Using the manual
A . General
The purpose of this manual is to assist Dealers and
Agents in the efficient installation, maintenance and
repair of AGCO equipment. Carrying out the
procedures as detailed, together with the use of
special tools where appropriate, will enable the
operations to be completed within the time stated in
the repair time schedule.
B . Structure of the manual
Page numbering
This manual is divided into chapters and sections, each
page containing the following information:
Example: 10A12.1
10 = chapter
A12 = section
1 = page number within the section
The issue number is indicated at the bottom of the
page.
Summaries
For quick reference, each chapter starts with a table of
contents, listing the various sections included in that
chapter.
Meaning of references
(...): identification of parts and components
Amendments
Modified pages will be edited using the same page
numbering as the preceding pages—only the issue
number changes.
The old pages should be destroyed.
C . Service tools
Where the use of a service tool is necessary to carry
out an operation, the tool reference is mentioned with
the relevant instruction.
Tool drawings for locally made tools are given at the
end of the relevant sections.
D . Repairs and parts replacement
When parts have to be replaced, it is essential that only
genuine AGCO parts are used.
The following points are of particular importance when
carrying out repairs and fitting replacement parts and
accessories.
Tractor safety may be compromised if non-genuine
parts are fitted.
Legislation in certain countries prohibits the fitting of
parts that do not comply with the tractor
manufacturer’s specifications. Torque wrench setting
figures given in the workshop manual must be strictly
adhered to. Locking devices must be fitted where
specified. If the efficiency of a locking device is
impaired during removal, it must be replaced.
The tractor warranty may be invalidated if non-genuine
AGCO parts are fitted. All AGCO spare parts are
guaranteed by the manufacturer. AGCO Dealers and
Agents are required to supply genuine service parts
only.
Massey Ferguson 5400 - Issue 5.a
1B10.1
SPECIFICATIONS - General specifications
1B10 - SPECIFICATIONS - General specifications
CONTENTS
A. General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Massey Ferguson 5400 - Issue 5.a
1B10.2
SPECIFICATIONS - General specifications
Massey Ferguson 5400 - Issue 5.a
1B10.3
SPECIFICATIONS - General specifications
A . General specifications
Model 5425
Engine
DIN power (hp) 65
DIN power (Kw) 49
Brand PERKINS
Type 1104C-44
Number of
cylinders/displacement (l)
4/4.4
Turbo No
Intercooler No
Injection pump Bosch VE10
Fan Viscostatic
Alternator 80 A / 120 A
Gearbox
Gearbox model GBA20/GBA25
Clutch/shuttle Dry clutch/mechanical reverse shuttle
Wet clutch/Power Shuttle
Number of discs 5 pads (mechanical reverse shuttle)
4 forward discs/3 reverse discs
(GBA20 Power Shuttle)
6 forward discs/6 reverse discs
(GBA25 Power Shuttle)
Type Speedshift (GBA20)/Dyna 4 (GBA25)
Creeper unit 4/1 Options
Creeper unit 14/1 Options
Rear axle
Axle model GPA20
Final drives ND
Axle shaft Ø 76 mm
Flanged shaft Standard
Brake discs per trumpet
housing
1
Hand brake discs 3
Differential lock Dog clutch
Linkage
Stabilisers Telescopic / without
Multi-hole drawbar Options
3-point linkage Cat. 2, hook or ball type (*)
Clevis hitch Standard or assisted
Automatic clevis hitch Standard or assisted
Semi-mounted trailer
hitch
Stud or auto-hitch (*)
Swinging drawbar Standard
Roller type swinging
drawbar
Options
Power take-off
Type Interchangeable / shiftable shaft
540/1000/eco Optional (*)
Number of clutch discs 4
PTO brake Hydraulics
Proportional PTO Options
Front power take-off Options
Front axle
Model DANA AG 85 (720/520)
Type Fixed
Rotational direction Clockwise
Clutch Multidisc
Factor K 1.369 (GBA20)/1.363 (GBA25)
Swivelling mudguard
(4WD)
Options
2WD Optional (standard track width/wide track width)
Front linkage (optional) 2.5 T
Hydraulics
Open Centre 57 l/min Standard
Open Centre 100 l/min Options
Orbitrol steering 100 cc
Brake master cylinder Standard
Braking assistance No
Trailer brake Optional (*)
Auxiliary spool valves 0 - 4 mechanical
Joystick Mechanical
Couplers Decompression
Electronics
Transmission control AUTOTRONIC 5 (if Power Shuttle)
Without (if mechanical reverse shuttle)
Linkage controller EHRB/AUTOTRONIC 5
Draft sensors 1
Sensor capacity 4 T
Datatronic Without
Fieldstar Options
Cab
Rear-view mirrors Standard / Telescopic (optional)
Air conditioning Manual (optional)
Windscreen Standard / Opening (optional)
Standard bonnet Standard
Sloping bonnet Options
Standard roof Standard
High-visibility roof Options
Slimline roof Options
Platform Options
Reference (*): according to country
Massey Ferguson 5400 - Issue 5.a
1B10.4
SPECIFICATIONS - General specifications
Model 5435
Engine
DIN power (hp) 75
DIN power (Kw) 56
Brand PERKINS
Type 1104C-44T
Number of
cylinders/displacement (l)
4/4.4
Turbo Yes
Intercooler No
Injection pump Bosch VE10
Fan Viscostatic
Alternator 80 A / 120 A
Gearbox
Gearbox model GBA20/GBA25
Clutch/shuttle Dry clutch/mechanical reverse shuttle
Wet clutch/Power Shuttle
Number of discs 5 pads (mechanical reverse shuttle)
4 forward discs/3 reverse discs
(GBA20 Power Shuttle)
6 forward discs/6 reverse discs
(GBA25 Power Shuttle)
Type Speedshift (GBA20)/Dyna 4 (GBA25)
Creeper unit 4/1 Options
Creeper unit 14/1 Options
Rear axle
Axle model GPA20
Final drives ND
Axle shaft Ø 76 mm
Flanged shaft Standard
Brake discs per trumpet
housing
1
Hand brake discs 3
Differential lock Dog clutch
Linkage
Stabilisers Telescopic / without
Multi-hole drawbar Options
3-point linkage Cat. 2, hook or ball type (*)
Clevis hitch Standard or assisted
Automatic clevis hitch Standard or assisted
Semi-mounted trailer
hitch
Stud or auto-hitch (*)
Swinging drawbar Standard
Roller type swinging
drawbar
Options
Power take-off
Type Interchangeable / shiftable shaft
540/1000/eco Optional (*)
Number of clutch discs 4
PTO brake Hydraulics
Proportional PTO Options
Front power take-off Options
Front axle
Model DANA AG 85 (720/520)
Type Fixed
Rotational direction Clockwise
Clutch Multidisc
Factor K 1.369 (GBA20)/1.363 (GBA25)
Swivelling mudguard
(4WD)
Options
2WD Optional (standard track width/wide track width)
Front linkage (optional) 2.5 T
Hydraulics
Open Centre 57 l/min Standard
Open Centre 100 l/min Options
Orbitrol steering 100 cc
Brake master cylinder Standard
Braking assistance No
Trailer brake Optional (*)
Auxiliary spool valves 0 - 4 mechanical
Joystick Mechanical
Couplers Decompression
Electronics
Transmission control AUTOTRONIC 5 (if Power Shuttle)
Without (if mechanical reverse shuttle)
Linkage controller EHRB/AUTOTRONIC 5
Draft sensors 1
Sensor capacity 4 T
Datatronic Without
Fieldstar Options
Cab
Rear-view mirrors Standard / Telescopic (optional)
Air conditioning Manual (optional)
Windscreen Standard / Opening (optional)
Standard bonnet Standard
Sloping bonnet Options
Standard roof Standard
High-visibility roof Options
Slimline roof Options
Platform Options
Reference (*): according to country
