Kubota L3410DT L3410GST L3410HST Tractor Illustrated Master Parts List Manual
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
Instructions for Parts Books
The heading at the top of the page will be the same for the picture of the parts at it is for the page with the part
numbers.
Definition of column headings on part number pages:
REF.No The number refering to the part on the picture page of the parts book.
Part No. The number assigned to this part at the time of printing the parts book.
Description Discription of part.
Q'ty Quanity of part used on that page.
S.No. Serial number range of the equipment that this part will fit.
>= Your serial number should be greater than or equal to the number shown.
<= Your serial number should be lesser than or equal to the serial number shown.
I/C Interchangeability of part shown.
The part shown will work for the older and later serial number.
# The part shown is not interchangable with the other serial number.
new for old
old for new
Remarks Notes about this particulart part. Sometimes this may say except [FR] or [CA]
Note about Country Codes:
The parts books we use in the United States of America may also contain information about a part that would be
different in another country. It is important that you are aware of the country codes in some instances.
Symbol Country
A United States of America
CA Canada
FR France
GR Greece
PO Portugal
AU Australia
If the remarks column says for example EXCEPT [FR] this part works in all countries except France.
That means it will work here in the USA.
|ALL PRODUCT INDEX
L3410DT/GST/HST
Ref. L3410DT/GST/HST Page 12058
ELECTRICAL SYSTEM
CLUTCH/TRANSMISSION/REAR AXLE
COOLING WATER SYSTEM
SPEED CHANGE LEVER/BRAKE
FRONT AXLE/CHASSIS
STEERING
HYDRAULIC SYSTEM
HITCH/DRAWBAR
HOOD(BONNET)/ROPS
FRONT WHEEL/REAR WHEEL
LABELS
ACCESSORIES
OPTION
ENGINE
FUEL SYSTEM
Ref. L3410DT/GST/HST Page 12058
Item Part No. Description Book
ENGINE 010001 CRANKCASE 100K0469
010002 OIL PAN 100K0469
010003 CYLINDER HEAD 100K0469
010004 GEAR CASE 100K0469
010005 HEAD COVER 100K0469
010100 MAIN BEARING CASE 100K0469
010101 CAMSHAFT AND IDLE GEAR SHAFT 100K0469
010102 PISTON AND CRANKSHAFT 100K0469
01010301 FLYWHEEL [W/O IND-PTO] 100K0469
01010303 FLYWHEEL [WITH IND-PTO] 100K0469
010105 FUEL CAMSHAFT AND GOVERNOR
SHAFT
100K0469
010200 ENGINE STOP LEVER 100K0469
010202 INJECTION PUMP 100K0469
010203 INJECTION PUMP [COMPONENT PARTS] 100K0469
010204 GOVERNOR 100K0469
010205 SPEED CONTROL PLATE 100K0469
010206 NOZZLE HOLDER AND GLOW PLUG 100K0469
010207 NOZZLE HOLDER [COMPONENT PARTS] 100K0469
010500 WATER FLANGE AND THERMOSTAT 100K0469
010501 WATER PUMP 100K0469
010600 VALVE AND ROCKER ARM 100K0469
010601 INLET MANIFOLD 100K0469
01090102 UPPER GASKET KIT 100K0469
010902 LOWER GASKET KIT 100K0469
010603 EXHAUST MANIFOLD/MUFFLER 100K0469
010604 AIR CLEANER 100K0469
01A002 STOP SOLENOIDE/ENGINE STOP WIRE 100K0469
01A01001 ACCELERATOR LEVER [EXCEPT HST
TYPE]
100K0469
01A01002 ACCELERATOR LEVER [HST TYPE] 100K0469
01A025 ACCELERATOR LINKAGE [EXCEPT HST
TYPE]
100K0469
01A03001 ACCELERATOR ROD [EXCEPT HST
TYPE]
100K0469
01A03002 ACCELERATOR ROD [HST TYPE] 100K0469
FUEL SYSTEM 01A101 FUEL TANK 100K0469
01A110 FUEL PIPE AND FUEL FILTER 100K0469
01A130 FUEL FILTER [COMPONENT PARTS] 100K0469
COOLING WATER SYSTEM 01A401 FAN 100K0469
01A410 WATER PIPE 100K0469
01A420 RADIATOR 100K0469
01A430 RESERVE TANK 100K0469
ELECTRICAL SYSTEM 01A515 ALTERNATOR 100K0469
01A520 ALTERNATOR [COMPONENT PARTS] 100K0469
01A525 STARTER 100K0469
01A530 STARTER [COMPONENT PARTS] 100K0469
01A535 BATTERY 100K0469
01B10201 SWITCH 1 [EXCEPT HST TYPE] 100K0469
01B10202 SWITCH 1 [HST TYPE] 100K0469
01B10301 SWITCH 2 [EXCEPT HST TYPE] 100K0469
01B10302 SWITCH 2 [HST TYPE] 100K0469
01B115 PANEL BOARD 100K0469
01B120 PANEL BOARD [COMPONENT PARTS] 100K0469
01B301 LIGHT [OLD TYPE] 100K0469
01B30101 LIGHT [NEW TYPE] 100K0469
Ref. L3410DT/GST/HST Page 12058
Item Part No. Description Book
ELECTRICAL SYSTEM 01B50101 ELECTRICAL WIRING [EXCEPT HST
TYPE]
100K0469
01B50102 ELECTRICAL WIRING [HST TYPE] [OLD
TYPE]
100K0469
01B50103 ELECTRICAL WIRING [HST TYPE] [NEW
TYPE]
100K0469
CLUTCH/TRANSMISSION/REAR AXLE 01C101 CLUTCH 100K0469
01C201 CLUTCH LEVER 100K0469
01C301 CLUTCH PEDAL [EXCEPT HST TYPE] 100K0469
01C30101 CLUTCH PEDAL [HST TYPE] 100K0469
01C40102 CLUTCH HOUSING [MANUAL T/M TYPE] 100K0469
01C40103 CLUTCH HOUSING [GST TYPE] 100K0469
01C40104 CLUTCH HOUSING [HST TYPE] 100K0469
01C405 GST VALVE [GST TYPE] 100K0469
01C406 GST VALVE [GST TYPE] [COMPONENT
PARTS]
100K0469
01C407 GST VALVE [GST TYPE] [COMPONENT
PARTS]
100K0469
01C408 GST VALVE [GST TYPE] [COMPONENT
PARTS]
100K0469
01C41001 MID CASE [MANUAL T/M TYPE] [WITH
IND-PTO]
100K0469
01C41002 MID CASE [GST TYPE] [W/O IND-PTO ] 100K0469
01C41003 MID CASE [HST TYPE] [OLD TYPE] 100K0469
01C41004 MID CASE [HST TYPE] [NEW TYPE] 100K0469
01C415 HST [COMPONENT PARTS] 100K0469
01C42002 TRANSMISSION CASE [MANUAL T/M
TYPE]
100K0469
01C42003 TRANSMISSION CASE [GST TYPE] 100K0469
01C42004 TRANSMISSION CASE [HST TYPE] 100K0469
01D10101 MAIN SHAFT [EXCEPT HST TYPE] [W/O
IND-PTO]
100K0469
01D10102 MAIN SHAFT [EXCEPT HST TYPE] [WITH
IND-PTO]
100K0469
01D10103 MAIN SHAFT [HST TYPE] 100K0469
01D103 INPUT SHAFT [HST TYPE] 100K0469
01D10501 COUNTERSHAFT [MANUAL T/M TYPE] 100K0469
01D10502 COUNTERSHAFT [GST TYPE] 100K0469
01D107 OUTPUT SHAFT [HST TYPE] 100K0469
01D110 HYDRAULIC CLUTCH [GST TYPE] 100K0469
01D11501 SHUTTLE SHAFT [MANUAL T/M TYPE] 100K0469
01D11502 SHUTTLE SHAFT [GST TYPE] 100K0469
01D11701 RANGE GEAR SHAFT [MANUAL T/M
TYPE]
100K0469
01D11702 RANGE GEAR SHAFT [GST TYPE] 100K0469
01D12503 SPIRAL BEVEL PINION [EXCEPT HST
TYPE] [W/O CREEP]
100K0469
01D12504 SPIRAL BEVEL PINION [EXCEPT HST
TYPE] [WITH CREEP]
100K0469
01D12505 SPIRAL BEVEL PINION [HST TYPE] 100K0469
01D127 REAR DIFFERENTIAL 100K0469
01D13001 PTO COUNTERSHAFT [EXCEPT HST
TYPE] [WITH IND-PTO]
100K0469
01D13002 PTO COUNTERSHAFT [EXCEPT HST
TYPE] [W/O IND-PTO]
100K0469
01D13201 PTO CLUTCH [EXCEPT HST TYPE] [WITH
IND-PTO]
100K0469
Ref. L3410DT/GST/HST Page 12058
Item Part No. Description Book
CLUTCH/TRANSMISSION/REAR AXLE 01D13202 PTO CLUTCH [EXCEPT HST TYPE] [W/O
IND-PTO]
100K0469
01D13203 PTO CLUTCH [HST TYPE] [W/O IND-PTO] 100K0469
01D13502 PTO SHAFT [EXCEPT HST TYPE] 100K0469
01D13503 PTO SHAFT [HST TYPE] 100K0469
01D13702 MID PTO [EXCEPT HST TYPE] 100K0469
01D13703 MID PTO [HST TYPE] 100K0469
01D20101 MAIN GEAR SHIFT FORK [MANUAL T/M
TYPE]
100K0469
01D20102 MAIN GEAR SHIFT FORK [GST TYPE] 100K0469
01D20501 SHUTTLE SHIFT FORK [MANUAL T/M
TYPE]
100K0469
01D20502 SHUTTLE SHIFT FORK [GST TYPE] 100K0469
01D21501 RANGE GEAR SHIFT FORK/CREEP GEAR
SHIFT FORK
100K0469
01D21502 RANGE GEAR SHIFT FORK/CREEP GEAR
SHIFT FORK
100K0469
01D217 RANGE GEAR SHIFT FORK [HST TYPE] 100K0469
01D22501 DIFFERENTIAL LOCK SHIFT FORK
[EXCEPT HST TYPE]
100K0469
01D22502 DIFFERENTIAL LOCK SHIFT FORK [HST
TYPE]
100K0469
01D301 REAR AXLE 100K0469
SPEED CHANGE LEVER/BRAKE 01D401 BRAKE 100K0469
01D40501 BRAKE ROD 1 [EXCEPT HST TYPE] 100K0469
01D40502 BRAKE ROD 1 [HST TYPE] 100K0469
01D41001 BRAKE ROD 2 [MANUAL T/M TYPE] 100K0469
01D41002 BRAKE ROD 2 [GST TYPE] 100K0469
01D41003 BRAKE ROD 2 [HST TYPE] 100K0469
01E10101 MAIN GEAR SHIFT LEVER [MANUAL T/M
TYPE]
100K0469
01E10102 MAIN GEAR SHIFT LEVER [GST TYPE] 100K0469
01E105 SHUTTLE SHIFT LEVER [EXCEPT HST
TYPE]
100K0469
01E106 CRUISE CONTROL LEVER [HST TYPE] 100K0469
01E107 CRUISE CONTROL CABLE [HST TYPE] 100K0469
01E108 NEUTRAL HOLDER LINK [HST TYPE] 100K0469
01E109 SPEED CONTROL PEDAL [HST TYPE] 100K0469
01E11001 RANGE GEAR SHIFT LEVER [MANUAL
T/M TYPE]
100K0469
01E11002 RANGE GEAR SHIFT LEVER [HST TYPE] 100K0469
01E111 RANGE GEAR SHIFT LEVER/CREEP
GEAR SHIFT LEVER
100K0469
01E112 RANGE GEAR SHIFT ROD [HST TYPE]
[OLD TYPE]
100K0469
01E11201 RANGE GEAR SHIFT ROD [HST TYPE]
[NEW TYPE]
100K0469
01E115 CREEP GEAR SHIFT LEVER [GST TYPE] 100K0469
01E122 PTO CLUTCH CONTROL LEVER
[MANUAL T/M TYPE]
100K0469
01E12501 PTO GEAR SHIFT LEVER [GST TYPE]
[W/O IND-PTO]
100K0469
01E12502 PTO GEAR SHIFT LEVER [HST TYPE]
[W/O IND-PTO]
100K0469
01E127 PTO CLUTCH VALVE [COMPONENT
PRTS] [WITH IND-PTO]
100K0469
Ref. L3410DT/GST/HST Page 12058
Item Part No. Description Book
SPEED CHANGE LEVER/BRAKE 01E12901 MID PTO SHIFT LEVER [EXCEPT HST
TYPE]
100K0469
01E12902 MID PTO SHIFT LEVER [HST TYPE] 100K0469
01E140 FRONT WHEEL DRIVE LEVER 100K0469
01E20101 BRAKE PEDAL [EXCEPT HST TYPE] 100K0469
01E20102 BRAKE PEDAL [HST TYPE] 100K0469
FRONT AXLE/CHASSIS 01F10502 FRONT AXLE FRAME 100K0469
01F120 PROPELLER SHAFT 100K0469
01F122 FRONT WHEEL DRIVE SHAFT 100K0469
01F125 FRONT DIFFERENTIAL CASE 100K0469
01F135 FRONT DIFFERENTIAL 100K0469
01F140 FRONT AXLE CASE 100K0469
01F145 DIFFERENTIAL GEAR SHAFT 100K0469
01F150 FRONT AXLE 100K0469
STEERING 01G10101 STEERING HANDLE [EXCEPT HST TYPE] 100K0469
01G10102 STEERING HANDLE [HST TYPE] 100K0469
01G110 STEERING CONTOLLER 100K0469
01G12002 STEERING LINKAGE 100K0469
01H11002 STEERING CYLINDER 100K0469
01H115 STEERING CYLINDER [COMPONENT
PARTS]
100K0469
HYDRAULIC SYSTEM 01H12001 HYDRAULIC PUMP [EXCEPT HST TYPE] 100K0469
01H12002 HYDRAULIC PUMP [HST TYPE] 100K0469
01H12501 HYDRAULIC PUMP [COMPONENT
PARTS] [EXCEPT HST TYPE]
100K0469
01H12502 HYDRAULIC PUMP [COMPONENT
PARTS] [HST TYPE]
100K0469
01H145 REGULATOR VALVE [EXCEPT HST TYPE] 100K0469
01H20501 HYDRAULIC OIL LINE(INLET) [EXCEPT
HST TYPE]
100K0469
01H20502 HYDRAULIC OIL LINE(INLET) [HST TYPE] 100K0469
01H21001 HYDRAULIC OIL LINE(DELIVERY)
[EXCEPT HST TYPE]
100K0469
01H21002 HYDRAULIC OIL LINE(DELIVERY) [HST
TYPE]
100K0469
01H21501 HYDRAULIC OIL LINE(PS) [EXCEPT HST
TYPE]
100K0469
01H21502 HYDRAULIC OIL LINE(PS) [HST TYPE] 100K0469
01H23001 PTO HYDRAULIC OIL LINE [MANUAL T/M
TYPE]
100K0469
01H23002 PTO HYDRAULIC OIL LINE [GST TYPE]
[W/O IND-PTO]
100K0469
01H23501 HYDRAULIC OUTLET BLOCK [EXCEPT
HST TYPE]
100K0469
01H23502 HYDRAULIC OUTLET BLOCK [HST TYPE] 100K0469
01H240 HYDRAULIC PIPE [HST TYPE] 100K0469
01H245 OIL COOLER [HST TYPE] [OLD TYPE] 100K0469
01H24501 OIL COOLER [HST TYPE] [NEW TYPE] 100K0469
01H301 HYDRAULIC CYLINDER 100K0469
01H320 LIFT ARM 100K0469
01H330 FEED BACK LEVER 100K0469
01H405 CONTROL VALVE 100K0469
01H410 CONTROL VALVE [COMPONENT PARTS]
[OLD TYPE]
100K0469
01H41001 CONTROL VALVE [COMPONENT PARTS]
[NEW TYPE]
100K0469
01H440 POSITION CONTROL LEVER 100K0469
Ref. L3410DT/GST/HST Page 12058
Item Part No. Description Book
HYDRAULIC SYSTEM 01J105 TOP LINK 100K0469
01J110 3-POINT LINKAGE 1(LOWER LINK) [OLD
TYPE]
100K0469
01J11001 3-POINT LINKAGE 1 (LOWER LINK) [NEW
TYPE]
100K0469
01J115 3-POINT LINKAGE 2(LIFT ROD) 100K0469
HITCH/DRAWBAR 01K105 DRAWBAR 100K0469
01K125 PTO PROTECTOR 100K0469
HOOD(BONNET)/ROPS 01L101 FRONT GRILLE 100K0469
01L10301 FRONT GRILLE SUPPORT [EXCEPT HST
TYPE]
100K0469
01L10302 FRONT GRILLE SUPPORT [HST TYPE] 100K0469
01L105 BONNET 100K0469
01L111 HOOD(BONNET) SIDE RH 100K0469
01L113 HOOD(BONNET) SIDE LH 100K0469
01L115 SIDE COVER LOWER 100K0469
01L130 SHUTTER PLATE 100K0469
01L20101 PANEL FRAME [EXCEPT HST TYPE] 100K0469
01L20102 PANEL FRAME [HST TYPE] 100K0469
01L21001 FENDER [MANUAL T/M TYPE] 100K0469
01L21002 FENDER [GST TYPE] 100K0469
01L21003 FENDER [HST TYPE] 100K0469
01L21501 FLOOR SEAT [EXCEPT HST TYPE] 100K0469
01L21502 FLOOR SEAT [HST TYPE] 100K0469
01L220 SEAT 100K0469
01L221 SEAT SUSPENSION [COMPONENT
PARTS]
100K0469
01L22501 STEP [EXCEPT HST TYPE] 100K0469
01L22502 STEP [HST TYPE] 100K0469
01L301 ROPS [OLD TYPE] 100K0469
01L30101 ROPS [NEW TYPE] 100K0469
01L501 SMV EMBLEM 100K0469
FRONT WHEEL/REAR WHEEL 01P10104 FRONT WHEEL (7.2-16) 100K0469
01P10105 FRONT WHEEL (10-16.5) 100K0469
01P10106 FRONT WHEEL (25*8.50-14) 100K0469
01P10107 FRONT WHEEL (27*8.50-15) 100K0469
01P10108 FRONT WHEEL (27*10.50-15) 100K0469
01P10109 FRONT WHEEL (29*12.50-15) 100K0469
01P11002 REAR WHEEL (12.4-24) 100K0469
01P11003 REAR WHEEL (420/70-24) 100K0469
01P11004 REAR WHEEL (13.6-16) 100K0469
01P11005 REAR WHEEL (41*14.00-20) 100K0469
01P11006 REAR WHEEL (21.5L-16.1) 100K0469
LABELS 01R10501 LABEL 1 [A] [MANUAL T/M TYPE] 100K0469
01R10502 LABEL 1 [CA] [MANUAL T/M TYPE] 100K0469
01R10503 LABEL 1 [A] [GST TYPE] 100K0469
01R10504 LABEL 1 [CA] [GST TYPE] 100K0469
01R10505 LABEL 1 [A] [HST TYPE] 100K0469
01R10506 LABEL 1 [CA] [HST TYPE] 100K0469
01R11001 LABEL 2 [A] [MANUAL T/M TYPE] 100K0469
01R11002 LABEL 2 [CA] [MANUAL T/M TYPE] 100K0469
01R11003 LABEL 2 [A] [GST TYPE] 100K0469
01R11004 LABEL 2 [CA] [GST TYPE] 100K0469
01R11005 LABEL 2 [A] [HST TYPE] 100K0469
01R11006 LABEL 2 [CA] [HST TYPE] 100K0469
ACCESSORIES 01S105 ACCESSORIES AND SERVICE PARTS 100K0469
OPTION 01T103 AIR CLEANER COVER KIT [OPTION] 100K0469
Ref. L3410DT/GST/HST Page 12058
Item Part No. Description Book
OPTION 01T108 SWITCH KIT [OPTION] 100K0469
01T120 FRONT GUARD STAY KIT [OPTION] 100K0469
01T130 DRAFT AND POSITION CONTROL LEVER
1 [OPTION]
100K0469
01T135 DRAFT AND POSITION CONTROL LEVER
2 [OPTION]
100K0469
01T140 TOP LINK HOLDER [OPTION] 100K0469
01T145 SWINGING DRAWBAR/CLEVIS DRAWBAR
[OPTION]
100K0469
01T15001 REMOTE CONTROL VALVE LEVIER 1
[OPTION]
100K0469
01T15002 REMOTE CONTROL VALVE LEVIER 2
[OPTION]
100K0469
01T15003 REMOTE CONTROL VALVE LEVIER 3
[OPTION]
100K0469
01T15501 REMOTE CONTROL VALVE COUPLER 1
[OPTION]
100K0469
01T15502 REMOTE CONTROL VALVE COUPLER 2
[OPTION]
100K0469
01T15503 REMOTE CONTROL VALVE COUPLER 3
[OPTION]
100K0469
01T160 ROPS [OPTION] [OLD TYPE] 100K0469
01T16001 ROPS [OPTION] [NEW TYPE] 100K0469
CRANKCASE
Reference: 010001 Page: 1
010
020
020
030
030
040
040
050
060
070
070
080
080
090
090
100
100
110
120
130
140
150
160
170
180
190
200
210
220
230
CRANKCASE
Reference: 010001 Page: 1
REF.No Part No. Description Q'ty S.No. I/C REMARKS Weight
(kgf)
Weight
(lb)
010 16487-01010 COMP.CRANKCASE 1 <=1Y0497 54 118.8
010 16487-01016 COMP.CRANKCASE 1 >=2A0001 ← 54 118.8
020 15521-96020 PLUG 5 0.003 0.0066
030 15521-96030 PLUG 2 0.007 0.0154
040 17391-96160 PLUG EXPANSION 3 0.003 0.0066
050 06311-75045 PLUG EXPANSION 1 0.026 0.0572
060 15221-03380 CAP SEALING 5 0.017 0.0374
070 15221-03390 CAP SEALING 2 0.03 0.066
080 05012-00408 PIN STRAIGHT 2 0.001 0.0022
090 05012-00609 PIN STRAIGHT 2 0.003 0.0066
100 05012-00612 PIN STRAIGHT 2 0.003 0.0066
110 05012-01018 PIN STRAIGHT 1 0.012 0.0264
120 15221-33650 PIN PIPE 1 0.004 0.0088
130 15321-73340 PIPE WATER RETURN 1 0.016 0.0352
140 15221-33610 PLUG 1 0.009 0.0198
150 15021-33660 GASKET 1 0.001 0.0022
160 15221-33700 O RING 1 0.001 0.0022
170 15471-35012 ASSY PUMP OIL 1 0.55 1.21
180 15296-35150 GASKET OIL PUMP 1 0 0
180 1A021-35150 GASKET OIL PUMP 1 ↔ 0.001 0.0022
190 01053-50650 BOLT 4 0.011 0.0242
200 04512-60060 WASHER SPRING 4 0.001 0.0022
210 19202-35660 GEAR OIL PUMP DRIVE 1 0.23 0.506
220 05712-00410 KEY FEATHER 1 0.001 0.0022
230 15221-35682 NUT FLANGE 1 0.014 0.0308
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$41.99
Viewed 12 Times Today
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$41.99
- This is an illustrated parts list manual for the Kubota L3410DT, L3410GST, and L3410HST L-Series Tractors.
- The manual contains detailed parts explosions, exploded views, and breakdowns of all part numbers for various aspects of these tractors, including the engine parts.
- It is essential for both professional mechanics and DIY enthusiasts for tractor parts lookup, servicing, rebuilding, teardowns, overhauls, repairs, and adjustments.
- Easy-to-read exploded views aid in part number identification, accurate ordering, and correct repairs.
- This manual is identical to the original manual for these tractors, but it is in digital format, eliminating the need for shipping. It can be instantly accessed, zoomed, printed, and saved for future use.
- Upon purchase, a link to the manual will be immediately provided via email for viewing, printing, and saving to a computer for future use.
- All sections are bookmarked and fully text searchable for quick and simple navigation.
- The manual is 567 pages long and is divided into sections covering various aspects of the tractor, including the engine, fuel system, cooling water system, electrical system, clutch, transmission, rear axle, and more.
- It provides detailed parts lookup data for components such as the crankcase, fuel tank, fan, alternator, electrical wiring, clutch, brake, front axle frame, steering handle, hydraulic pump, and more.
- Kubota Corporation, established in 1890, has a long history of manufacturing agricultural machinery in Japan and has a strong presence in the North American market.
- The company's compact tractors are essential for smaller farms, and it has been a key player in the American marketplace since 1969.
- Kubota Tractor Corporation was formed in 1972 in Torrance, California, and the company has expanded its manufacturing facilities in the United States over the years.
- The popularity and affordability of Kubota tractors led to grey market imports of Japanese models into North America, which resulted in a lawsuit in 1997 to make it illegal to distribute these tractors in the USA.
- This parts manual is number 100K0469 and covers the Kubota L3410DT, L3410GST, and L3410HST Tractor models designed for small farm, landscaping, estate maintenance, equestrian operations, horse farms, and commercial use.
For more information about Kubota tractors, please visit www.kubota.com.
