Timberjack 1263 Harvester Workshop Manual
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
1263
Harvester
WORKSHOP
MANUAL
John Deere Dubuque Works
TM1962(01JUL01)
Timberjack Issue 02/01-02 Page 0000-1
1270C Harvester
0000 General
Service Tools
1000 Power Unit
1100 Engine Mounting – Removal / Installation
1200 Fuel System
1300 Drive Coupling
1400 Exhaust System
1500 Intake System
1600 Cooling System
Cummins Shop Manual 1991 and 1994 Certification Levels –
See Bulletin 3666017-01
Cummins Troubleshooting and Repair Manual 1991 and 1994
Certification Levels – See Bulletin 3666003-01
2000 Hydraulic System
2100 Hydraulic Tank and Filters
2200 Working Hydraulics
2210 Working Pump - Rexroth A11VO Repair Instructions
2230 How to Check and Adjust Pressures
2240 Auxiliary Valve
2300 Hydrostatic Drive System
2310 How to Check and Adjust the Hydraulic System
Drive Pump – Rexroth A4VG Repair Instructions
Drive Motor – Rexroth A6VM Repair Instructions
Timberjack Issue 02/01-02 Page 0000-2
1270C Harvester
2400 Valves
2410 Crane Control Valve
VOAC K170LS Directional control valve
2600 Brake Hydraulics
Appendix 1 – Hydraulic Component Symbols
Appendix 2 – Hydraulic Schematics
3000 Electrical
3050 Main Electrical System
3100 Wiring Diagrams
3200 Control System TMC
3300 Measuring System TJ3000
4000 Power Train
4100 Transfer Case
4200 Prop Shafts
4300 Axles / Bogies
NAF Service Manual and Repair Instruction LOK87/1; Transfer case
NAF Service Manual and Repair Instruction LOK 97; Front Axle
NAF Service Manual and Repair Instruction LOK 98; Rear Axle
5000 Cabin
5100 Controls And Lights
5200 A/C And Heater System
5250 Inspecting The A/C System
Timberjack Issue 02/01-02 Page 0000-3
1270C Harvester
6000 Frames / Covers
6100 Front Frame
6200 Rear Frame
6300 Middle Joint
6320 Frame Brake
7000 Crane
7100 Crane
7100-1 A General Description of the Crane
7100-2 Technical Specifications
Appendix 1: Special Tools for the Crane
7150 Crane Cylinders
7150-1 Description and Operation
7150-2 Slewing Cylinders Servicing
7150-4 Main Boom Cylinder Removal & Installation
7150-6 Main Boom Cylinder Servicing
7150-8 Jib Boom Cylinder Removal & Install
7150-12 Jib Boom Cylinder Servicing
7150-14 Extension Boom Cylinder Removal & Install
7150-17 Extension Boom Cylinder Servicing
7200 Crane Maintenance
Indexator Rotators - Disassembly and Assembly Instructions
9000 Optional Equipments
Eberspächer Troubleshooting and Repair Manual
Timberjack Issue 02/01-02 Page 0000-4
1270C Harvester
All information, illustrations and specifications in this manual are based
on the latest information available at the time of publication. The right is
reserved to make changes at any time without notice.
COPYRIGHT © 2001
DEERE & COMPANY
Moline, Illinois
All rights reserved.
Service tools for 1263 Harvester
Base Machine Notes
F612884 Middle joint pivot pin nut tool
Boom
F617763 Lifting boom cylinder tool
F057655 Jib boom cylinder piston tool
F038312 Jib boom cylinder cover tool
F061007 Extension boom cylinder tool
F055827 Pivot nut spanner, d=80
F055828 Pivot nut spanner, d=100
Engine
F058071 Universal liner puller Needs also F058077
F058073 Engine barring tool Same in all Cummins engines
F058075 Blowby checking tool
F058076 Cylinder liner clamp set
F058077 Plate for universal liner puller
F058078 Cylinder liner driver
F058079 Injector puller Same in all Cummins engines
F058080 Turbocharger wastegate pressure set kit
F058081 Torque angle gauge
F058083 Piston ring expander
F058084 Piston ring compresser
F058086 Fuel pump drive gear puller Same in all Cummins engines
F058088 Water manometer for blowby checking Same in all Cummins engines
F058089 Blowby checking tool hose Same in all Cummins engines
F058093 Front oil seal installation tool
F058094 Tappet removal & installation tool kit Same in all Cummins engines
TMC
F057934 Etools, tool kit for TMC Computer required
F057938 Etools software program Included in kit F057934
F057935 PCMCIA card for Etools Included in kit F057934
F057937 Cable PC card / TMC Included in kit F057934
F057941 TMC programs Included in kit F057934
Timberjack Issue 02/01-02 Page 1000-1
1270C Harvester
1000 Power Unit
1100 Engine Mounting – Removal / Installation
1200 Fuel System
1300 Drive Coupling
1400 Exhaust System
1500 Intake System
1600 Cooling System
Cummins Shop Manual 1991 and 1994 Certification Levels –
See Bulletin 3666017-01
Cummins Troubleshooting and Repair Manual 1991 and 1994
Certification Levels – See Bulletin 3666087
Timberjack Issue 02/01-02 Page 1000-2
1270C Harvester
