T1570A· T1670A' T1770A' WSM A SAFETY FIRST This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and decals on the machine itself to warn of the possibility of personal injury. Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to repair or use this unit. A DANGER : Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. A WARNING : Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. A CAUTION : Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. • IMPORTANT : Indicates that equipment or property damage could result if instructions are not followed . • NOTE : Gives helpful information. BEFORE SERVICING AND REPAIRING • Read all instructions and safety instructions in this manual and on your machine safety decals. • Clean the work area and machine. • Park the machine on a firm and level ground, and set the parking brake. • Lower the implement to the ground. • Stop the engine, and remove the key. • Disconnect the battery negative cable. • Hang a ''~O NOT OPERATE" tag in operator station. 1

T1570A' T1670A· T1770A' WSM • + - SAFETY STARTING • Do not start the engine by shorting across starter terminals or bypassing the safety start switch. • Do not alter or remove any part of machine safety system. • Before starting the engine, make sure that all shift levers are in neutral positions or in disengaged positions. • Never start the engine while standing on ground. Start the engine only from operator's seat. SAFETY WORKING • Do not work on the machine while under the influence of alcohol, medication, or other substances or while fatigued. • Wear close fitting clothing and safety equipment appropriate to the job. • Use tools appropriate to the work. Makeshift tools, parts, and procedures are not recommended. • When servicing is performed together by two or more persons, take care to perform all work safely. • Do not work under the machine that is supported solely by a jack. Always support the machine by safety stands. • Do not touch the rotating or hot parts while the engine is running. • Never remove the radiator cap while the engine is running, or immediately after stopping. Otherwise, hot water will spout out from radiator. Only remove radiator cap when cool enough to touch with bare hands. Slowly loosen the cap to first stop to relieve pressure before removing completely. • Escaping fluid (fuel or hydraulic oil) under pressure can penetrate the skin causing serious injury. Relieve pressure before disconnecting hydraulic or fuel lines. Tighten all connections before applying pressure. AVOID FIRES • Fuel is extremely flammable and explosive under certain conditions. Do not smoke or allow flames or sparks in your working area. • To avoid sparks from an accidental short circuit, always disconnect the battery negative cable first and connect it last. • Battery gas can explode. Keep sparks and open flame away from the top of battery, especially when charging the battery. • Mark sure that no fuel has been spilled on the engine. 2

T1570A· T1670A' T1770A· T1870A, WSM SAFETY INSTRUCTIONS VENTILATE WORK AREA • If the engine must be running to do some work, make sure the area is well ventilated. Never run the engine in a closed area. The exhaust gas contains poisonous carbon monoxide. PREVENT ACID BURNS • Sulfuric acid in battery electrolyte is poisonous. It is strong enough to burn skin, clothing and cause blindness if splashed into eyes. Keep electrolyte away from eyes, hands and clothing. If you spill electrolyte on yourself, flush with water, and get medical attention immediately. DISPOSE OF FLUIDS PROPERLY • Do not pour fluids into the ground, down a drain, or into a stream, pond, or lake. Observe relevant environmental protection regulations when disposing of oil, fuel, coolant, electrolyte and other harmful waste. PREPARE FOR EMERGENCIES • Keep a first aid kit and fire extinguisher handy at all times. • Keep emergency numbers for doctors, ambulance service, hospital and fire department near your telephone. 3

T1570A . T1670A . T1770A . T1870A, WSM SAFETY INSTRUCTIONS SAFETY DECALS The following safety decals are installed on the machine. If a decal becomes damaged, illegible or is not on the machine, replace it. The decal part number is listed in the parts list. (1) Part No. K1211-6581-1 (2) Part No. K1211-6582-1 A WARNING ::--~,,(3) (3) Part No. K5112-7312-2 00 NOT PUT HANDS OR FEET INTO MOWER WHEN ENGINE IS RUNNING. 3GLAAABCP001 B (4) Part No. K1122-6584-2 ROTATING BLADES CUT OFF ARMS AND LEGS ',EVER CARRY CHILDREN EVEN WITil THl RlAOrSOf1.. DO NOT MOVI WHEN CHILDREN OR OTHERS "'"10 AROUND LOOK DOVIN AND BEHIND BEFORE AND WHIL" BACKING 4

T1570A . T1670A . T1770A . T1870A. WSM SAFETY INSTRUCTIONS (1) Part No. Kl122-6583-1 (Under Hood) (2) Part No. K5112-7311-2 (3) Part No. K1221-6117-1 3GLAAACCP002A 5

T1570A . T1670A . T1770A . T1870A, WSM SAFETY INSTRUCTIONS (1) Part No. E7194·4719·1 AWARNING DO NOT TOUCH SCREEN WITH ENGINE RUNNING. 2511333 (2) Part No. K1122·6585·1 Gasoline fuel No fire em @fl \ ) CARE OF DANGER, WARNING AND CAUTION LABELS 1. Keep danger, warning and caution labels clean and free from obstructing material. 2. Clean danger, warning and caution labels with soap and water, and dry with a soft cloth. 3. Replace damaged or missing danger, warning and caution labels with new labels from your KUBOTA Dealer. 4. If a component with danger, warning and/or caution laOOI(s) affixed is replaced with new part, make sure the label(s) is (are) attached in the same location(s) as the replaced component. 5. Mount new danger. warning and caution labels by applying on a clean dry surlace and pressing any bubbles to outside edge. 3GLAAACCP001A 6

T1570A' T1670A' T1770A' T1870A, WSM SPECIFICATIONS Model T1570A T1670A T1770A T1870A Model GH430V GH570V GH630V Type Forced air-cooled, Vertical shaft OHV, 4-stroke gasoline engine Number of cylinders 1 2 (V-Twin) Bore and stroke 90 mm x 67 mm (3.55 in. x 2.64 in.) 73 mm x67 mm 77 mm x 67 mm (2.87 in. x 2.64 in.) (3.03 in. x 2.64 in.) Total displacement 426 cm 3 (26.0 cu.in.) 561 cm 3 (34.2 cu.in.) 624 cm 3 (38.1 cu.in.) Maximum horsepower 11.2 kW / 3600 min- 1 12.7 kW / 3600 min- 1 14.2 kW / 3600 min- 1 (15 HP! 3600 rpm) (17 HP / 3600 rpm) (19 HP / 3600 rpm) 33.22 N'm ! 2400 min- 1 42.9 N'm/2000 min- 1 44.2 N'm/2600 min- 1 Maximum torque (3.39 kgf·m / 2400 rpm, (4.4 kgf'm/2000 rpm, (4.5 kgf'm/2600 rpm, 24.6 ft-Ibs I 2400 rpm) 31.7 ft-lbs/2000 rpm) 32.6 ft-lbs!2600 rpm) Maximum bare speed 3350 ± 50 min- 1 (rpm) Minimum bare idling speed 1550 ± 100 min- 1 (rpm) ",. tation Counterclockwise facing the PTO shaft Engine Compression ratio 8.5: 1 8.2: 1 8.5: 1 Ignition system Flywheel magnet transistor type Spark plug Champion Premium Gold 2071 Champion RC12YC or platinum 3071 Carburetor Float type with fixed main jet Air cleaner Semi-cyclone type with dual element Dual stage element, dry type Governor Mechanical flyweight type Lubricating system Forced lubrication by oil pump Cooling system Forced air cooling Starting system Electric starter (12 V. 0.6 kW) Charging system Charging coil (12 V, 15 A) Charging coil (12 V, 13 A) Battery U1 L-9 (12 V, 300 CCA) Throttle system Manual Engine stop system Key stop 11.0 L Fuel lank (2.9 U.S.gals., 15.0 L (3.9 U.S.gals., 1.7 Imp.gals.) 2.4 Imp.gals.) Capacities Engine crankcase 1.9 L (2.0 U.S.qts., 1.7 Imp.qts.) Hydrostatic transmission 2.3 L (2.4 U.S.qts., 3.6 L (3.8 U.S.qts., 3.2 Imp.qts.) case 2.0 Imp.qts.) Overall length 1720 mm (67.7 in.) 1747 mm (68.8 in.) 1320 mm (52.0 in.) Overall width (with mower) 1320 mm (52.0 in.) 40 in. 1444 mm (56.9 in.) 1544 mm (60.8 in.) 1444 mm (56.9 in.) 44 in. Dimensions • Overall height 1065 mm (41.9 in.) 1115 mm (43.9 in.) Wheel base 1195 mm (47.0 in.) 1209 mm (47.6 in.) Front Tread 710 mm (28.0 in.) 723 mm (28.5 in.) Rear 660 mm (26.0 in.) 655 mm (25.8 in.) 270 kg (595 Ibs) Weight (with mower) 250 kg (551 Ibs) 40 in. 285 kg (628 Ibs) 40 inch 280 kg (617Ibs) 48 in. 44 in. W1028323 7

T1570A· T1670A· T1770A· T1 WSM Model T1570A I T1670A I T1770A I T1870A Tire size Front 15 x 6.00-6 ! Rear 18 9.50-8 I 20 x 10.00-8 Steering syslem Sector gear type i Transmission Hydrostatic transmission Brake Disk type Traveling speed Forward o to 9.0 km I h (0 to 5.6 mph) Reverse o to 4.0 km ! h (0 to 2.5 mph) PTOclutch Belt tension W1034130 Model T1570A I T1670A I T1770A T1870A ! Model RCK40LTB RCK44LTB RCK48LTB Overall 835 mm 793 mm (31.2 in.) 863mm length (32.9 in.) (34.0 in.) Overall width 1320 mm 1444 mm (56.9 in.) 1544 mm (52.0 in.) (60.8 in.) Overall 260mm 271 mm (10.7 in.) 289mm height (10.2 in.) (11.4 in.) i Mounting Parallel linkage method Adjustment Mower of cutting Dial gauge height Cutting width 1016mm 1118 mm (44 in.) 1219 mm (40 in.) (48 in.) Cutting 25 to 102 mm (1.0 to 4.0 in.) height Number of 2 3 blades Weight 40 kg (88.2 Ibs) 50 kg (110.2Ibs) 55 kg (121 Ibs) i (Approx.) Discharge Right side i W1036385 8

T1570A . T1670A . T1770A . T1 WSM DIMENSIONS mm (in.) .- III cO ~ C') ('II .... 1209 (47.6) 1747 (68.8) co ci ~ '<:I' '<:I' III ,... O! ~ III ,... ,... ,... 3GLAAACFP001A 9
