FAULT CODE IDENTIFICATION TABLE - VMACIII - 1998 & NEWER
1-1 Engine Oil Pressure Sensor 5-9 (ASET CEGR) EGR Mass Flow
1-2 Barometric Pressure Sensor 6-1 Fuel Level
1-3 Fuel Temperature Sensor 6-2 (ASET CEGR) Turbocharger Speed
1-4 Ambient Air Temp Sensor 6-3 J1708/J1587 Link
1-6 Starter Input 6-4 J1939 Link
1-7 Engine Coolant Level 6-5
All Communication Lost –
Engine Shutdown
1-8 (ASET CEGR) Estimated % Fan Speed 6-6 Fuel Control Module
1-10 Aux. Cooling Relay Output 6-7 Power Relay
2-1 Engine Coolant Temp Sensor 6-8 J1939 Link
2-2 (ASET IEGR) Boost Air Pressure Sensor 6-9
Other ECU Affecting
Operation
2-2 (ASET CEGR) Boost Air Pressure 7-1 Service Brake Switch
2-3 Intake Air Temp Sensor 7-2 Parking Brake Switch
2-4 Trans Oil Temp Sensor 7-3 Speed Control SET Switch
2-5
Front Drive Axle Oil Temp
Sensor 7-4
Speed Control RESUME
Switch
2-6
Rear Drive Axle Oil Temp
Sensor 7-5 Battery / Alternator Voltage
2-7 Engine Oil Temp Sensor 7-6 Switched Voltage
2-8 (ASET CEGR) Combustion Air Temperature 7-7 Exhaust Temp Reference
2-9 (ASET CEGR) Combustion Air Temp Sensor 7-9 VTG Actuator
3-1 Exhaust Temperature Sensor 8-1 Electronic Unit Pump #1
3-2 Engine Speed Sensor 8-2 Electronic Unit Pump #2
3-3 Redundant Engine Speed 8-3 Electronic Unit Pump #3
3-4 Engine Position Sensor 8-4 Electronic Unit Pump #4
3-5 Engine Brake Output #1 8-5 Electronic Unit Pump #5
3-6 Engine Brake Output #2 8-6 Electronic Unit Pump #6
3-8 Trans Splitter Position 8-9 Solenoid Boost Voltage
3-10 (ASET CEGR) Engine Brake Output #3 9-1 Transport Protocol
4-1 Vehicle Speed Sensor (VSS) 9-2
Power Reset Without Key
Switch
4-2 Fan Clutch Output 9-3 (ASET CEGR)
Aftercooler Outlet
Temperature
4-3 Auxiliary Output #1 9-5 (ASET CEGR) Compressor Discharge Temp
4-4 Auxiliary Output #2 9-8 (ASET CEGR) Auxiliary Output Device #1
4-5 (ASET IEGR) Wastegate Output 9-9 (ASET CEGR) Auxiliary Output Device #2
4-5 (ASET CEGR) VTG Position Sensor 9-10 (ASET CEGR) Auxiliary Output Device #3
4-6 Tachometer Output 10-1 (ASET CEGR) Internal Sensor Voltage
4-7 Speedometer Output 10-2 (ASET CEGR) 5 Bolt Supply
4-8 Customer Defined Statement 10-3 (ASET CEGR) Sensor Supply Voltage #1
4-9 (ASET CEGR) EGR Valve Mechanism 10-4 (ASET CEGR) Sensor Supply Voltage #2
5-1 Throttle Position Sensor 10-5 (ASET CEGR)
Fuel Filter Differential
Pressure
5-2
Throttle Position Sensor
Reference Voltage 10-6 (ASET CEGR) Fuel Delivery Pressure
5-3 Engine Shutdown Lamp/Alarm 10-7 (ASET CEGR) Odometer Save Area Failure
5-5 Electronic Malfunction Lamp 10-8 (ASET CEGR)
GPS Position Data Not
Received
5-6 Spare Relay #3 10-9 (ASET CEGR) Watchdog Timer Reset
5-7 Engine Oil Level
5-8 (ASET CEGR) EGR Temperature
