Waukesha Gas Engine spares parts catalog

Page No: 1 Date: 05.12.2011 Material Code Short Description Long Description 17012223 Spear head sub Spear head sub Part No. 15686 of BOWEN TOOLS INC 17060104 Gear,Ring,L5790 & L7042 Waukesha G/Engin Gear, Ring for Engine Models L5790 & L7042 Part No. 153381 B 17060115 Crankshaft,L5790 & L7042 Waukesha G/Engn Crankshaft for Engine Model - L5790 & L7042 Part No. G-911-230 (911-230) 17060126 Kit,Main Brg,L5790/L7042 Waukesha G/Engn Main Bearing Kit-standard for Engine Model - L5790 & L7042 Part No. G-918-316 (918-284) of WAUKESHA ENGINE DIVISION Part No. G 918-332 17060137 Kit,Main Brg,0.020",L5790/L7042 WG Engn. Main Bearing Kit - 0.020" under size, for Engine Models - L5790 & L7042 Part No. G-918-290(G-918-275) 17060148 Kit,Main Brg,0.040",L5790/L7042 WG Engn. Main Bearing Kit - 0.040" under size for Waukesha engine model - L5790, L7042 Clevive Part No. MS-1068P-40 [Kit for main bearing shall include all main bearings and thrust washers for one engine] Part No. 918-276 17060172 Crankshaft-L5108G for model LS108G Crankshaft - L5108G for Model LS108G Part No. 911-272 of WAUKESHA ENGINE DIVISION Part No. G-911-263 17060183 Piston,Engine Model-L7042,Pt.no.205404J Piston(Compression Ratio 10 : 1)Engine Model - L7042 Part No. 205404J of WAUKESHA ENGINE DIVISION Part No. 205504G 17060239 Piston Ring Kit,L5790,Pt.no.907-146 Piston Ring Kit for Engine Models - L5790 Part No. 907-146 17060241 Kit,Ring,Piston,L7042 Waukesha Gas Engn. Piston Ring Kit for Engine Models - L7042 Part No. G-907-147 (907-147) 17060354 Bushing,Piston Pin,Pt.no.47108 Part No. 47108 17060376 Kit,Sleeve,S'gle Cyl,L5108G W/Gas Engin Single Cylinder Sleeve Kit for Model L5108G Part No. G-932-232 17060398 Kit,Sleeve,Single Cyl,L7042 W/Gas Engin Single Cylinder Sleeve Kit for Engine Model L7042 Part No. G-932-182 17060401 Kit,Sleeve,Single Cyl,L5790 W/Gas Engin Single Cylinder Sleeve Kit for Engine Model L5790 Part No. G-932-172 (932-172) 17060456 Rod,Connecting,L5790/L7042 W/Gas Engin Rod, Connection for Engine Model -L5790 & L7042 Part No. A205007-E 17060491 Kit,Conn.Rod Brg. Kit,L5790/L7042 Connecting Rod Bearing Kit - standard for Engine Models - L5790 & L7042

Page No: 2 Date: 05.12.2011 Material Code Short Description Long Description Part No. A205010K 17060514 Kit,Conn.Rod Brg,L5790/L7042 W/Gas Engin Connecting Rod Bearing Kit - 0.040" under size For Waukesha engine model - L5790, L7042 Part No. 910-194 17060547 Main Bearing Kit,T-drilled crankshaft Main Bearing Kit For T-Drilled Crankshaft Part No. G-918-344 of WAUKESHA ENGINE DIVISION 17060558 Bearing,Conn.Rod Assy.(12 Nos./Set) Bearing, Connecting Rod Assy.For T-Drilled Crankshaft Part No. A205210 of WAUKESHA ENGINE DIVISION 17060638 Kit,Packing Ring Cylinder Sleeve Kit Packing Ring Cylinder Sleeve for Engine Model - L7042 consisting of : a) 24 Nos. Ring Packing, Pt.No. 119397G b) 12 Nos. Ring Packing, Pt.No. 119397E c) 12 Nos. Gasket, Pt.No. 176375-D 17060649 Kit, Packing Ring, Cylinder Sleeve Kit, Packing Ring Cylinder Sleeve for Engine Models - L5790 & L5108G, consisting of : a) 24 Nos. Ring, Packing, Pt.No. 119396-D b) 12 Nos. Ring, Packing, Pt.No. 119396-B c) 12 Nos. Gasket, Pt.No. 176375-D 17060651 Crankshaft and Crankshaft Bearing Kit Crankshaft and Crankshaft Bearing Kit Part No. G-911-271 17060786 Rod,Push,L5790/L7042 Waukesha Gas Engin Rod, Push (Includes Hydraulic Lifter, Part No. 153752-A) for Engine Models - L5790 & L7042 Part No. A153754U of WAUKESHA ENGINE DIVISION Part No. A153754U 17060797 Lifter,Hydraulic,Pt.no.153752L Lifter, Hydraulic Part No. 153752L 17060798 Rod,Push for Waukesha Engine,Pt.153754U Push Rod Part No. 153754U of WAUKESHA ENGINE, DRESSER, INC 17060809 Cover,Push Rod,Assy.,Pt.no.A0153256 Part No. A0153256 17060811 O-Ring,Rubber,Shore hardness,L5790/L7042 `O' Ring, Rubber, Shore hardness 80 Deg. for Oil resistant services, Class I, as per SAE Specification 120R1, Size No. 218,ID 1.234" x O.D. 1.512" x Section dia 0.139" Engine Model : L5790 & L7042 17060855 O-Ring for L5790/L7042 Waukesha Gas Engn "O" Ring, Shore hardness 70 - 75 Deg. for oil resistant services, Class I as per SAE Specification 120R1, Size No. 221, ID 1.421" x O.D. 1.699" x Section dia 0.139 for Engine Models - L5790 & L7042 Part No. 211196 of WAUKESHA ENGINE, DRESSER, INC Part No. 211196 17060899 Lifter,Valve,L5790/L7042

Page No: 3 Date: 05.12.2011 Material Code Short Description Long Description Waukesha G/Engn Part No. E046033 17060902 Valve lifter kit,Pt.no.937-32 Part No. 937-32 17060924 Camshaft,L5790/L7042 Waukesha Gas Engin Camshaft Part No. AA204923E (A2048230) 17060946 Gear,Camshaft,Pt.no.200526 Gear,Camshaft. Part No. 200526D 17060957 Gear,Idler,Pt.no.200115,(2001152) Part No. 200115-G (2001152) 17061073 Kit,Camshaft Bushing,L5790/L7042 WG Engn Camshaft Bushing Kit for Engine Model - L5790 & L7042 Part No. G-927-7 of WAUKESHA ENGINE DIVISION Part No. G-927-7 17061153 Insert,Valve Seat,L5790/L7042 W/Gas Engn Insert, Valve Seat for Engine Models L5790 & L7042 Part No. 176352 P 17061164 Cylinder head wide bridge(Bare) Cylinder head wide bridge (Bare)For Engine Models no. L5790 & L7042 Part No. A 204702P of WAUKESHA ENGINE DIVISION Part No. K204702N Part No. A204702P SUPERCEEDED BY D204702P 17061175 Valve,Exh,L5790/L7042 Waukesha Gas Engin Valve, Exhaust for Engine Model - L5790 & L7042 SK.NO. OIL/2297 Part No. 204236N of WAUKESHA ENGINE DIVISION 17061186 Valve,Intake,L5790/L7042 Waukesha G/Engn Valve, Intake for Engine Models - L5790 & L7042 SK.NO. OIL/2297 Part No. 204236K of WAUKESHA ENGINE DIVISION 17061197 Insert,Vlv Seat,L5790/L7042 W/Gas Engine Insert, Valve Seat for Engine Models - L5790 & L7042 Part No. 176352-K (176352-H) 17061211 Guide,Vlv Intake,L5790/L7042 W/Gas Engin Part No. 204009-H 17061222 Guide,Vlv Exh.,L5790/L7042 W/Gas Engine Guide, Valve - Exhaust for Engine Models - L5790 & L7042 SK. No. OIL/2300 Part No. 204009-F of WAUKESHA ENGINE, DRESSER, INC Part No. 204109-C 17061233 Seal,Exh.Vlv.Guide,L5790/L7042 W/Gas Eng Seal, Exhaust Valve Guide for Engine Models - L5790 & L7042 Part No. 176450E 17061299 Taper,Vlv.Spring,L5790/L7042 W/Gas Engin Taper, Valve Spring for Engine Models - L5790 & L7042 Part No. 73629A 17061302 O-Ring,Intake Vlv,L5790/L7042 W/Gas Engn Part No. 168922 17061368 Shaft,Exh,Rocker Shaft Exhaust

Page No: 4 Date: 05.12.2011 Material Code Short Description Long Description ArmAssy,WaukeshaG/Engn Part No. CA204066J 17061379 Shaft,Intake,Rocker Assy,Waukesha G/Engn Shaft, Intake Rocker Assembly Part No. AA204065J 17061426 Screw, Rocker Arm Assembly Screw, Rocker Arm Assembly For Engine Models - L5790 & L7042 (Old Pt. No. A153889-C ) Part No. A 211820 17061437 Screw,Hydraulic Lifter Adjusting Screw, Hydraulic Lifter Adjusting Part No. 169080-A / 169080-W 17061461 Nut,Thin hex.,Pt.no.21227 Nut, thin hex. for Engine Models - L5790 & L7042 Part No. 21227 17061528 Gasket,Cyl.Head,L5790 Waukesha Gas Engin Gasket, Cylinder Head. for Engine Models - L5790 Part No. 204000V of WAUKESHA ENGINE, DRESSER, INC Part No. 204000V 17061539 Gasket,Cyl.Head,L7042 Waukesha Gas Engin Gasket, Cylinder Head for Engine Models - L7042 Part No. 205000M Part No. 205 100C 17061574 Gasket Set,Vlv.O/H,L7042 Waukesha G/Engn Valve O/H Gasket Set, Model : L-7042 Part No. 979-251 of WAUKESHA ENGINE DIVISION Part No. G-979-266 17061585 Gasket Set,Vlv.O/H,L5790 Waukesha G/Engn Valve O/H Gasket Set Model : L 5108 / L 5790 Part No. 979-249 of WAUKESHA ENGINE DIVISION Part No. G-979-263 17061654 Element,Oil Filter-Dual Density Element, Oil Filter-Dual Density, For Engine Models - L5790, L7042 Part No. 167602C 17061665 O-Ring,-Cover,Neopren Rubber,Pt.168053-A "O" Ring - Cover, Neopren Rubber, Size : 390 mm I.D. x 15 mm Cross Section dia, Shore Hardness 70 Deg. for Engine Models - L5790 & L7042. Part No. 168053-A 17061767 Seal,Oil,Rear,L5790/L7042 W/Gas Engine Seal, Oil - Rear for Engine Models L5790 & L7042 Part No. 153554-A 17062019 Pump,Water,L5790/L7042 Waukesha G/Engine Pump, Water (Deming 4001),for Engine Models - L5790 & L7042 Part No. 169561 17062021 Seal Assy,L5790/L7042 Waukesha G/Engine Seal Assembly (Deming items "B" to "H")(Sealol Drg. No. A4R 6860/A) for Mechanical type Stuffing Box. For Engine Models - L5790 & L7042

Page No: 5 Date: 05.12.2011 Material Code Short Description Long Description Part No. 496737 17062054 Shaft for L5790/L7042 Waukesha Gas Engin Shaft for Engine Models - L5790 & L7042 Part No. 496738 17062236 Pump,Oil Assy,L5790/L7042 W/Gas Engine Pump, Oil, Assembly for Engine Models - L5790 & L7042 Part No. CA200280B of WAUKESHA ENGINE DIVISION Part No. G-962-402 17062668 "O - Ring" ,oil pan door "O Ring", Oil Pan Door for Engine Model L7042 Part No. 153121 17062794 Manifold,Exhaust,Pt.no.A204442E Manifold, Exhaust No. 6RB Cyl. Turbocharged, For Engine L5790 Part No. A204442E of WAUKESHA ENGINE DIVISION 17062806 Manifold,Exhaust,Pt.no.A204542E Manifold, Exhaust, No. 6LB Cyl. Turbocharged For Engine L5790 Part No. A204542E of WAUKESHA ENGINE DIVISION 17062841 Gasket,Exh.Manifold,L5790/L7042 Gas Engn Gasket, Exhaust Manifold for Engine Model - L5790 & L7042 Part No. 153896A SUPERCEEDED BY 153896B of WAUKESHA ENGINE, DRESSER, INC Part No. 153896B 17062852 Connection,Exh.for Waukesha Gas Engine Connection Exhaust Part No. 168341C 17062863 Gasket,Exh.Conn.,L5790/L7042 W/Gas Engin Gasket, Exhaust Connection.for Engine Models - L5790 & L7042 Part No. 118878-A 17062874 Manifold,Exh.,L7042 Waukesha Gas Engine Manifold, Exhaust for Engine Model L7042 Part No. A 204342X 17062885 Elbow,Exh.,L7042 Waukesha Gas Engine Elbow, Exhaust for Engine Model L7042 together with HXHDSCR 1/2-13 x 3/4 (Pt.No. 21422) and Washer 33/64 x 3/4 x 1/32 (Pt.No. B2131) Part No. 168340-G (168340-F) 17062896 Seal,Ring,Sqr.Cut,L5790/L7052 W/Gas Engn Seal, Ring - Square Cut.for Engine Models - L5790 & L7042 Part No. 176883 17062932 Clamp,Hore for Waukesha Gas Engine Clamp, Hore Part No. 41236E 17062965 Pump,Water Assy,L5790/L7042 W/Gas Engine Pump, Water, Assy. for Engine Models-L5790 & L7042 Part No. AH200960D/ G200960D 17062998 Seal,Water Pumpshaft,L5790/L7042 Gas Eng Seal, Water Pump Shaft(Sealol Drg.No. A4R 6859/A) for Engine Models L5790 & L7042 Part No. 157475 J 17063079 Kit, Engine Water Pump Repair Water Pump Repair Kit, Part No. G-960-291 consisting of : a) 2 Nos. Gasket, Crankcase W in elbow,Part No. B 2793 D b) 2 Nos. Nut, Hex Jam, Part No. 21251,

Page No: 6 Date: 05.12.2011 Material Code Short Description Long Description c) 2 Nos. Washer, 1.03" x 1.88" x 13",Part No. 28758 d) 2 Nos. Cock, Drain and Vent,Part No. 76400 e) 1 No. Bearing Ball, Pt.No. 78843C f) 1 No. Ring Snap, Pt.No. 118925A g) 1 No. Gasket, Water Pump cover to gear,Part No. 153092A h) 2 Nos. Gasket, Crankcase W in flange,Part No. 153139A i) 1 No. Seal, Water Pump, Pt.No. 157475K j) 1 No. Gasket Water Pump,Part No. 159580 k) 1 No. Bearing Ball, Pt.No. 161309C l) 2 Nos. Gasket, By pass elbow,Part No. 167409 m) 2 Nos. O-Ring, 2.950 ID x 210SQ,Part No. 176883D n) 1 No. Sleeve, Wear-Pulley Hub,Part No. 199451E o) 1 No. Impeller, Pt.No. 200463C p) 1 No. Shaft, Pt.No. 200456C q) 1 No. Seal, Oil, Pt.No. 211442 r) 1 No. Seal, Oil, Pt.No. 211442a Part No. G-960-291 17063104 Kit,Repair,Waterpump,L5790/L7042 W/G Eng Water Pump Repair Kit.for Engine Models - L5790 & L7042 Part No. G-960-149 17063365 Bushing,Butterfly Valve Housing. Bushing, Butterfly Valve Housing. for Engine Models - L5790 & L7042 Part No. 168290-B 17063376 Seal,BUtterfly Valve Shaft,Pt.no153990-A Seal, Butterfly Valve Shaft for Engine Models - L5790 & L7042 Part No. 153990-A 17063456 Seal,Oil,Crankshaft,L5790/L7042 W/G Engn Seal,Oil-Crankshaft for Engine Models-L5790, L7042 Part No. 153097-A 17063638 Pin,1/8'' X 1/2'' Roll,Pt.no.26547 Part No. 26547 17063855 Governor-Wood Ward for W/Gas Engine Governor - Woodward `UG-8-LD' Engine Model - L5790 & L7042 Part No. 8520-0038 17063981 Kit,Pt.no.175335 Part No. 175335 17064038 Seal,Oil,1.379"OD for Waukesha Gas Engin Oil Seal, 1.379" O.D Part No. 1361-295 of WOODWARD GOVERNOR COMPANY Part No. 03032-54 17064107 Bearing,Thrust,Pt.no.180120 Part No. 180120 17064118 Speeder Rod & Pin assy,Pt.no.031482 Part No. 31482 17064313 Governor,Overspeed Assy,Waukesha Gas Eng Governor, Over Speed Assy Part No. N-153005A 17064483 Drive,Magneto,Assy,Pt.no.N153000 -C Drive, Magneto, Assembly.for Engine Models - L5790 & L7042 Part No. N153000-C of WAUKESHA ENGINE DIVISION

Page No: 7 Date: 05.12.2011 Material Code Short Description Long Description Part No. F153000M 17064539 Adapter,Magneto Assy,Waukesha Gas Engine Adapter Magneto Assembly, a/w Gear Marg Drive(Pt.No. 153287A) and adapter(Pt.No. A153286K) Part No. G-199390C (C199390A) of WAUKESHA ENGINE, DRESSER, INC Part No. E-199390C 17064654 Ring,Retaining,Pt.no.117488-K Part No. 117488-K 17064687 Seal,Oil,L5790/L7042 Waukesha Gas Engine Seal, Oil for Engine Models L5790 & L7042 Part No. 153291-B 17064734 Turbocharger, Garret T18A96,208350F Turbocharger, Garret T18A96 For Engine L5790 Part No. 208350F of WAUKESHA ENGINE DIVISION 17064745 Wastgate,Pt.no.208372H Wastgate For Engine L5790 Part No. 208372H of WAUKESHA ENGINE DIVISION 17064756 Intercooler Assy.,Pt.no.AE168282G Inter cooler Assy.(Modina, IA 012867)For Engine L5790 Part No. AE168282G of WAUKESHA ENGINE DIVISION 17064825 Element,Air Cleaner,L7042 W/Gas Engine Element, Air Cleaner for Model L7042 Part No. 169180L (169180F) 17064836 Element,Precleaner,Pt.no.208349 Element, Precleaner Engine Model : L7042 Part No. 208349 17064949 Valve,3 Way Vacuum Gauge,Pt.no.85091 Part No. 85091 17064951 Gauge,Oil Temp.,L5790/L7042 W/Gas Engine Gauge, Oil temeratureWaukesha Part no.169108 Part No. 169108 of WAUKESHA ENGINE, DRESSER, INC Part No. 169108D 17064962 Gauge,Oil Press.,L5790/L7042 W/Gas Engin Gauge, Oil Pressure & Safety Switch for Engine Models - L5 790 & L7042 Part No. 169742 17064984 Gauge,Water Temperature & Safety Switch Gauge, Water Temperature and Safety Switch. for Engine Models - L 5790 & L7042. Part No. 169741 17064995 Gauge,Vacuum-Non Turbocharged Engine Gauge, Vacuum-Non Turbocharged Engine. For Engine Model : L 5790 & L7042 Part No. 169107 17065008 Techometer,Digital,L5790/L7042 W/G Engin Tachometer Digital for Engine Models L5790 & L7042 Part No. 209377 17065019 Cable,Techometer,L5790/L7042 W/Gas Engin Cable, Tachometer for Engine Models L5790 & L7042 Part No. C209378 (A209378)

Page No: 8 Date: 05.12.2011 Material Code Short Description Long Description 17065178 O Ring,Pt.no.169616J Part No. 169616-J 17065293 Diaphragm,Impco Carburetor W/G Engn Diaphragm for Impco 600 Carburetor (Alternative Waukesha Pt. No. 499222) for Engine Models - L5790 & L7042 Part No. 499222 of WAUKESHA ENGINE, DRESSER, INC 17065453 Diaphragm,Buna-N,L5790/L7042 W/Gas Engin Diaphragm for Engine Models L5790 & L7042 (Material : Buna-N) Part No. 1H978102072 17065464 Holder Assy,Disc,L5790/L7042 W/Gas Engin Disc Holder Assy. for Engine Models-L5790, L7042. {Old Pt.No. 1P7349000A2 (FISHER)} Part No. 499252 17065817 Kit,Major O/H Package,L7042GU W/Gas Engn Major Overhaul Package Kit, comprising the following : a) 12 Nos. Single Cylinder Sleeve Kit, Part No. G-932-182 (932-182) b) 12 Nos. Bearing Conn. Rod Assy.,Part No A205010P c) 1 No. Seal Kit complete filter,Part No. 493029 d) 2 Nos. Diaphragm, Pt.No. 499222 e) 2 Nos. Gasket, Pt.No. 119035 f) 2 Nos. Diaphragm for Gas Control Regulator,Part No.499251 g) 2 Nos. Holder Disc Assembly, Pt.No. 499252 h) 2 Nos. `O' Ring, Pt.No. 499253 (499252) i) 1 Set Valve Overhaul Gasket Set,Part No.G-979-266(979-251) j) 7 Nos. `O' Ring, Pt.No. 118013N (118012N) k) 1 No. Seal Oil Rear, Pt.No. 153554A (15355AA) l) 1 No. Gasket Valve Lifter Housing,Part No. 163213A m) 2 Nos. Gasket Valve Lifter Housing Cover Part No. 153020B (1530208) n) 1 No. Seal Oil Pan, Pt.No. 166192C o) 12 Nos. Gasket Oil Pan Door, Pt.No.153121A p) 2 Nos. Seal Packing, Pt.No. 209095 q) 8 Nos. Ring Insulating, Pt.No. 199942 r) 10 Nos. Clamp House, Pt.No. 41236-E s) 1 No. Seal Crankshaft Oil Front,Part No. 153097A t) 1 Set Main Bearing Kit, Pt.No.G918-330 u) 1 No. 'O' Ring Lub Oil Filter Cover, 17 X 17.5 X 25 Part no. 168922N (168059A) v) 12 Nos. Valve Overhaul Kit,Part No. G936-1017 w) 4 Nos. Damper Governor Drive Gear,Part No. 164712 x) 24 Nos. Hydraulic Lifter, Pt.No. 153752 E y) 12 Nos. Connector Flex, Pt.No. 194769 E z) 24 Nos. Screw Rocker Arm Adjusting Screw, Part No. A 153889 K zi) 48 Nos. Nut for Rocker Arm Adjusting Screw,Pt.No. 21227 zii) 48 Nos. Connecting Rod Bolt, Part No. 28587D ziii) 2 Nos. Bearing, Camshaft, Front (upper and lower), Part No. 200027 ziv) 12 Nos. Bearing, Camshaft, Center, Intermediate and rear (upper and lower), Part No. 200050 zv) 2 Nos. Ring Insulating, Pt.No. 199942A zvi) 1 No. Oil Seal, Rear, Part No. 153554A zvii) 2 Nos. Ball Bearing, Rear, Part No. 78390

Page No: 9 Date: 05.12.2011 Material Code Short Description Long Description zviii) 2 Nos. Ball Bearing Front, Part No. 78391 zix) 28 Nos. Stud, ma;in bearing cap, Part No. 168514B zx) 28 Nos. Nut, main bearing cap stud, Part No. 28245 zxi) 96 Nos. Taper Valve Spring, Part No. 73629 z 17065828 Kit,Top O/H Package,L7042 W/GU Engine Kit, Top Overhaul Package, comprising the following : a) 12 Nos. Single Piston Ring Kit, Part No. G-907-147 (907147) b) 12 Nos. Sleeve Cylinder, Part No. 205130P (2051305) c) 24 Nos. Ring Packing Cylinder Sleeve, Part No. 119397G d) 12 Nos. Ring, Packing Cylinder Sleeve, Part No. 119397E (169212A) e) 12 Nos. Gasket Cylinder Sleeve, Part No. 176375D (1763750) f) 1 No. Valve Overhaul Gasket Set, Part No. G-979-266 (979-251) g) 12 Nos. Valve Overhaul Kit Part No. G936-1017 h) 12 Nos.Connecting Rod Bearing, Part No. A205010R (A205010Z) i) 1 No.Ò' Ring Lub Oil Filter, Pt.No. 168922N j) 12 Nos. Gasket, Oil Pan door, Pt.No. 153121A 17065841 Kit,Major O/H Package,L5108 G Gas Engin Major Overhaul Package Kit, comprising the following : a) 12 Nos. Single Cylinder Sleeve Kit,Part No. G932-232 b) 12 Nos. Bearing Connecting Rod Assembly, Part No. A205010R (A205010Z) c) 1 No. Seal Kit complete Filter, Pt.No. 493029 d) 2 Nos. Diaphragm, Pt.No. 499222 e) 2 Nos. Gasket, Pt.No. 119035 f) 2 Nos. Diaphragm for Gas Control Regulator,Part No.499251 g) 2 Nos. Holder Disc Assembly, Pt.No. 499252 h) 2 Nos. Ò' Ring, Pt.No. 499253 i) 1 Set Valve Overhaul Gasket Set,Part No.G-979-263(979-249) j) 7 Nos. Ò' Ring, Pt.No. 118013N k) 1 No. Seal Oil Rear, Pt.No. 153554A (15355AA) l) 1 No. Gasket Valve Lifter Housing,Part No.163213A m) 2 Nos. Gasket Valve Lifter Housing Cover, Part No. 153020B (1530208) n) 1 No. Seal Oil Pan, Pt.No. 166192C o) 12 Nos. Gasket Oil Pan Door, Pt.No. 153121A p) 2 Nos. Seal Packing, Pt.No. 208974 (208975) q) 8 Nos. Ring Insulating, Pt.No. 199942 r) 10 Nos. Clamp House, Pt.No. 41236-E s) 1 No. Seal Crankshaft Oil Front,Part No. 153097A t) 1 Set Main Bearing Kit,Part No. G918-330 (G-918-344) u) 1 No.Ò' Ring Lub Oil Filter, Pt.No. 168922A v) 4 Nos. Damper Governor Drive,Pt.No. 164712 w) 12 Nos. Valve Overhaul Kit,Part No. G936-1017

Page No: 10 Date: 05.12.2011 Material Code Short Description Long Description x) 24 Nos.Hydraulic Lifter,Pt.No.153752E(153752K) y) 12 Nos. Connector Flex, Pt.No. 194769 E z) 48 Nos. Rocker Arm Adjusting Screw, Part No. A 153889 K (A153889 L) zi) 48 Nos. Nut for Rocker Arm Adjusting Screw, Pt.No. 21227 zii) 48 Nos. Connecting Rod Bolt, Part No. 28587D ziii) 2 Nos. Bearing, Camshaft, Front (upper and lower), Part No. 200027 ziv) 12 Nos. Bearing, Camshaft, Center, Intermediate and rear (upper and lower), Part No. 200050 zv) 2 Nos. Ring Insulating, Pt.No. 199942A zvi) 1 No. Oil Seal, Rear, Part No. 153554A zvii) 2 Nos. Ball Bearing, Rear, Part No. 78390 zviii) 2 Nos. Ball Bearing Front, Part No. 78391 zix) 28 Nos. Stud, ma;in bearing cap, Part No. 168514B zx) 28 Nos. Nut, main bearing cap stud, Part No. 28245 zxi) 96 Nos. Taper Valve Spring, Part No. 73629 17065852 Major Overhaul Kit For Waukesha L5790 G Major Overhaul Kit, comprising the following : a) 12 Nos. Single Cylinder Sleeve Kit,Part No. G932-172 b) 12 Nos. Bearing Connecting Rod Assembly, Part No. A205010R (C205010K) c) 1 No. Seal Kit Complete Filter,Part No. 493029 d) 2 Nos. Diaphragm, Part No. 499222 e) 2 Nos. Gasket, Part No. 119035 f) 2 Nos. Diaphragm for Gas Control Regulator, Part No.499251 g) 2 Nos. Holder Disc Assembly, Part No. 499252 h) 2 Nos.Ò" Ring, Part No. 499253 i) 1 Set Valve Overhaul Gasket Set,Part No. G979-263 (979-249) j) 7 Nos. Ò' Ring, Part No. 118013N k) 1 No. Seal Oil Rear, Part No. 153554A (15355AA) l) 1 No. Gasket Valve Lifter Housing,Part No. 163213A m) 2 Nos. Gasket Valve Lifter Housing Cover, Part No. 153020B (1530208) n) 1 No. Seal Oil Pan, Part No. 166192C o) 12 Nos.Gasket Oil Pan Door, Part No. 153121A p) 2 Nos. Seal Packing, Part No. 208974 (208975) q) 8 Nos. Ring Insulating, Part No. 199942 r) 10 Nos. Clam House,Part No. 41236-E s) 1 No. Seal Crankshaft Oil Front, Part No. 153097A t) 1 Set. Main Bearing Kit, Part No. G918-330 u) 1 No. Ò' Ring Lub Oil Filter, Part No. 168922A v) 4 Nos.Damper Governor Drive, Part No. 164712 w) 12 Nos. Valve Overhaul Kit, Part No. G936-1017 x) 24 Nos. Hydraulic Lifter, Part No. 153752E y) 12 Nos. Connector Flex, Part No. 194769E z) 48 Nos. Rocker Arm Adjusting Screw,Part No.A153889L zi) 48 Nos. Nut for Rocker Arm Adjusting Screw, Pt.No.21227 zii) 48 Nos. Connecting Rod Bolt, Part No. 28587D ziii) 2 Nos. Bearing, Camshaft, Front (upper and lower), Part No. 200027 ziv) 12 Nos. Bearing, Camshaft, Center, Intermediate and rear (upper and lower), Part No. 200050 zv) 2 Nos. Ring Insulating, Pt.No. 199942A zvi) 1 No. Oil Seal, Rear, Part No. 153554A zvii) 2 Nos. Ball Bearing, Rear, Part No. 78390
