Perkins Engine Number Guide

Engine Type Position Engine Type Position Engine Type Position 3.152 M 4.236 C or L V8.640 P 4.108 A 4.318 F 700/800 Series K 4.154 / 200 Series B 4.41 H Perama/100/400 Series O 4.165 B or G 6.247 C or F Prima/500 Series E 4.203 J or N 6.354 D Phaser/1000/1100(A/B/C) Series H or J 4.212/4.248/900 Series C V8540 Q 1104D S 1106D including PK R Peregrine/1300 Series I or O Engine Number Guide This code indicates the country in which the basic engine was manufactured. A Argentina B Brazil C Australia D Germany E Spain F France G Greece H Group HC China HMIndonesia HK Iraq HU Uruguay J Japan K Korea L Italy M Mexico MX Mexico N USA P Poland S India SA South Africa T Turkey U UK V Pakistan W Iran X Peru Y Yugoslavia Country of Manufacture Code This code indicates the calendar year of manufacture. The letters I, O, Q, R and Z will not be used. A 1974 B 1975 C 1976 D 1977 E 1978 F 1979 G 1980 H 1981 J 1982 K 1983 L 1984 M 1985 N 1986 P 1987 S 1988 T 1989 U 1990 V 1991 W 1992 X 1993 Y 1994 A 1995 B 1996 C 1997 D 1998 E 1/1/99–31/3/99 F 1/4/99–31/12/99 G 2000 H 2001 J 2002 K 2003 L 2004 M 2005 N 2006 P 2007 S 2008 Year of Manufacture Code Engines < 2 litre/Cylinder (Produced Post 1974) Engine Number Guide Example: PJ 12345 U 123456P Engine family and type code PJ 1106D-E66TA Parts list number or SOS order reference number 12345 Country of manufacture code U UK Engine serial number 123456 Year of manufacture code P 2007 AB C D E F G H I (Left Side View) J (Rear View) M O N L K (Right Side View) Q P (V8 Top View) S R © Perkins Engines Company Ltd Peterborough PE1 5NA UK. Parts Publication Number PP827(E)/08/07 Page 1 of 3

Engine Family and Type Code A Air to Air charge cooling C Compensated CC Charged Cooled D Direct Injection E Electronic F Federal Emissions FF Federal G Gasoline/Gas H Horizontal N Narrow Front End P Timing Chain S Spark Ignition T Turbocharged U Unit Injection V V Form W Water to Air Charge Cooling Engine Number Guide © Perkins Engines Company Ltd Peterborough PE1 5NA UK. Parts Publication Number PP827(E)/08/07 Page 2 of 3 Notes 1. Peterborough products may show a finishing list on the engine plate e.g. F1895. It is very important to quote this when spare parts are required. 2. 1300 Series engines have a different serial number format. They have 7 digits after the middle letter, which is an N or a P. There is no year letter at the end e.g. WS4486P1354691. 3. PK Series engines are derived from the 1106D Series platform but are only stage II EU 2007 genset emissions compliant. A Phaser/1004 Series AA 1004-4 AB 1004-4T AC 1004-4T AD 1004e-4TW AE Fed. CC AF 1004-40S AG 1004-4 AH 1004-4T New 1000 Series AJ 1004-40 AK 1004-40T AL 1004-40TA AM 1004-40T AP 1004-40 AQ 1004-40T AR 1004-42 AS 1004-42 AT 1004-40TA B Prima/500 Series BA 504-2 BB 504-2T C 3.152 Series CA P3 CB 3.144 CC P3.144 CD 3.152 CE D3.152 CF G3.152 CG P3.152 CJ 3.1522 CM 3.1524 CN T3.1524 900 Series CP 903-27 CR 903-27T CS 903-25 CT 903-27S D 1103C Series DC 1103C-33 DD 1103C-33T DE 1103C-33TA 1103B Series DF 1103B-33 DG 1103B-33T 1103A Series DJ 1103A-33 DK 1103A-33T E 4.108 Series ED 4.108 G 4.154/200 Series GA 4.154 GB 4.135 GC 4.182 GD 4.25 GE 4.3 400D Series GG 402D-05 GH 403D-07 GJ 403D-11 GK 403D-15 GL 403D-15T GM 404D-15 GN 404D-22 GP 404D-22T GR 404D-22TA GS 403D-17 H 4.165 Series HA 4.165 400C Series HB 402C-05 HD 403C-07 HH 403C-11 HL 403C-15 HN 404C-15 HP 404C-22 HR 404C-22T J 4.203 Series JD 4.203 JE D4.203 JF G4.203 JG 4.2032 K Perama/100 Series KD 103.10 KE 103.15 KF 104.19 KH 103.13 KL 103.07 KN 102.05 KR 104.22 KS 103.11 L 4.236 Series LA 4.212 LD 4.236 LE G4.236 LF 4.248 LG 4.2482 LH C4.236 LJ T4.236 LM 4.41 N 4.318 Series NC 4.318 ND 4.3182 1104D Series NH 1104D-E44T NJ 1104D-E44TA NK 1104D-44 NL 1104D-44T NM 1104D-44TA P 1106D Series PJ 1106D-E66TA PK 1106C-E66TA* R 6.247 Series RA 6.247 1104C Series RE 1104C-44 RF 1104C-E44 RG 1104C-44T RH 1104C-E44T RJ 1104C-44TA RK 1104C-E44TA 1104A Series RR 1104A-44 RS 1104A-44T RT 1104A-44TA SD Sabre CC6.68 T 6.354 Series TC 6.354 TD H6.354 TE T6.354 TF HT6.354 TG 6.3541 TH T6.3541 TJ 6.3542 TK C6.3542 TP T6.3543 TR 6.372 TT TC6.3541 TU T6.3544 TV 6.3724 TW 6.3544 TX C6.3544 TY H6.3544 TZ HT6.3544 U 700 Series UA 704-30 UB 704-26 UC 704-30 800 Series UE 804C-33 UF 804C-33T 800D Series UK 804D-33 UL 804D-33T UM 804D-33TA V 1106C Series VK 1106C-E60TA W 1300 Series Peregrine WB 1306-8T WC 1306-8TA WD 1306-7T WE 1306-7TA WF 1306-8T NGD WG 1306-8TA NGD WH 1306-9T NGD WJ 1306-9TA NGD 1300 Series EDi WK 1306-E76T WL 1306-E76TA WM 1306-E87T WN 1306-E87TA WP 1306-E76T WQ 1306-E76TA WR 1306-E87T WS 1306-E87TA X V8.540 Series XA V8.510 XB TV8.510 XC V8.540 XE TV8.540 1103D Series XG 1103D-E33 XH 1103D-E33T XJ 1103D-E33TA XK 1103D-33 XL 1103D-33T XM 1103D-33TA Y Phaser / 1006 Series YA 1006-6 YB 1006-6T YC 1006-6T YD 1006e-6TW YE Fed. CC YF 1006-60S New 1000 Series YG 1006-60 YH 1006-60T YJ 1006-60TA YK 1006-60TW Z V8.640 Series ZA V8.640 ZB TV8.640

Family: 2800 Series E16TAG1 HGA E16TAG2 HGB E18TAG1 JGA E18TAG2 JGB E18TAG3 JGD Family: 2300 Series E14TAG1 FGA E14TAG2 FGB E14TAG3 FGD Family: 2500 Series E15TAG1 MGA E15TAG2 MGB E15TAG3 MGD E15TAG4 MGE Eagle 8BT, 8CTA, 8DTW Eagle TX 8CTA 2000 Series 8BT,8CTA/TTA, 8DTW, 8ESI, 8GTW-H 3008 / CV8 4AT, 4BTA, 4ESI Condor Marine 4CTi 3012 / CV12 6ATA, 6CTW, 6DT, 6ESI A Air to Air Charge Cooled CHP Combined Heat & Power E Externally Charge Cooled G Genset Engine H Horizontal Engine I Intercooled M Marine N Jacket Water Charge Cooled P Pumping Duties H 16 Litre (2800 Series) SI Spark Ignition T Turbocharged TT Twin Turbocharged W Water Cooled K Keel Cooled E* Electronic/Litres R Remote Cooled Large Engines (Produced Pre 1994) Engine Family & Type Code: 8C Engine Specification Number: 27655 Country of Manufacture: U Build Line Number: 88900 Year of Manufacture: W The 2000 & 3000 series engine numbers look like this: 8C 27655 U 88900 W Engine Number Guide Engine Family and Type Codes (Left Side View) T R S (Right Side View) W (Left Side View) X U (Right Side View) Eagle/2000 Series R 3008 Series T 3012 Series S 2300/2500/2800Series W 4006 Series U 4008 Series U 4012 Series V or X 4016 Series V or X Engine Type Position V (Right Side View) © Perkins Engines Co Ltd Peterborough PE1 5NA UK. Parts Publication Number PP827(E)/08/07 Page 3 of 3 Engine Family and Type Codes 2000 & 3000 Series Engine Number Guide Engine Family & Type Code: A Number of Cylinders: 06 Engine Specification Number: 0010 Country of Manufacture: U Build Line Number: 0001 Year of Manufacture: Y The 2000/3000 and 2300/2800 series engine numbers look like this:SG A 06 0010 U 0001 Y Engine Application: SG Engine Family and Type Code 2300, 2500 & 2800 Series Engines > 2 litre/Cylinder (Produced Post 1994) Stafford D Application Code (Genset) G Engine Type B Number of Cylinders 06 United Kingdom U 17th Engine This Year 0017 Year Letter (B=1996) B Engine Number Guide A 4000 series engine number looks like this: DGB 06 0081 U 0017 B Fixed Bill Number (0000 means Configured Product) 0081 Code: 4000 Series DGF TG DGL TAG DGA TAG1 DGB TAG2 DGD TAG3 DGM TWG DGK TWG2 DGN TWG3 DGV TWG2TC DGP TEG DGR TEG2 DGS TEG3 DIE SI GAS UNIT DIF TES1 GAS UNIT DIE TES1 CHP UNIT DMD M4000T DME M4000T1 DMF M4000TK DGE TAG4 DIG E * TRS DIH TRS CHP UNIT DIJ TRS GAS UNIT Code: 4006 Series 23TAG1A - 23TAG2A - 23TAG3A - Engine Family and Type Codes 4000 Series Engine Number Guide Family: SA Automotive 300TX SAA 320MX SAB 335TX SAC 350E SAE 375TX SAG 340TX2 SAJ 380TX2 SAK 410TX2 SAL Family: SB Short Block TX SBA 2000 Series SBB 3008 Series SBC 3012 Series SBD Family: SL Long Engine TX / Euro 2 SLA 2000 Series SLB 3008 Series SLC 3012 Series SLD 3008 Marine SLE 3008 / 3012SI SLG Family: SI Gas SI SIA SI Gas Unit SIB TSI CHP SIC TSI Gas Unit SID TWSICHP SIE TWSI Gas Unit SIF Family: SM Marine M600T1 SMA M700T1 SMB M800T1 SMC Family: SF Forklift T1 SFA T2 SFB TA SFC TW SFD Family: SG Genset TAGIA SGA TAG2 SGB TAG2A SGC TAG3A SGD TAG4 SGE TG SGF TGIA SGG TG2A SGH TTAG SFJ TWG2 SGK TAG SGL TAG5 SGM Family: SH Horizontal TWH SHA Family: SP Plant T SPA T1 SPB T2 SPC TA SPD TAP SPE TP SPJ TTA SPK TTAP SPL TW SPM TW1 SPP
