1998-2002 KTM 60SX/65SX Engines OEM Service & Repair Manual

60 SX / 65 SX REPAIR MANUAL ENGINE KTM SPORTMOTORCYCLE AG 5230 Mattighofen Austria www.ktm.at

REPAIR MANUAL ENGINE 60 SX/65 SX

1 SERVICE-INFORMATIONS 2 GENERAL INFORMATION 3 REMOVING AND REFITTING ENGINE 4 DISASSEMBLING ENGINE 5 SERVICING INDIVIDUAL COMPONENTS 6 ASSEMBLING ENGINE 7 TROUBLE SHOOTING 8 TECHNICAL SPECIFICATIONS 9 PERIODIC MAINTENANCE SCHEDULE 10 11 12 13 14 15 16

Remove page (s) Replace by page (s) Insert page (s) after page 2-3 to 2-6 2-3d to 2-6d 3-4 3-4d 4-1 to 4-8 4-1d to 4-9d 5-2 to 5-7 5-2d to 5-7d 6-1 to 6-9 6-1d to 6-10d 7-1 7-1d 7-4 7-4d 8-1 to 8-13 8-1d to 8-12d 9-1 9-1d 9-6 9-6d to 9-8d I MPORTANT I NFORMATION /U PDATING INSTRUCTIONS To be able to continue using the existing loose-leaf repair instructions, simply print the following pages and insert them in the existing repair instructions: 7, 9, 17-20, 25, 26, 29-38, 41-46, 51-61, 63, 67-81, 83, 89-91 KTM REPAIR MANUAL IN LOOSE-LEAF FORM STORING THE REPAIR MANUAL IN THE BINDER – Put the index into the binder. – Put the front page of the repair manual (210x297 mm) into the transparent pocket provided for this purpose on the outside of the binder. – Put the spine label (170x45 mm) into the transparent pocket provided for this purpose on the spine of the binder. – Put the summary list of contents (150x297 mm) into the transparent pocket provided for this purpose on the inside of the binder or insert this page on the beginning of the manual. – Then insert the individual chapters of the manual between the sheets of the index according to the page number printed in the right bottom corner of each page. Example: page no. 3-5 3 = chapter 3 5 = page 5 All pages with a page number that begins with the digit 3, for example, must be put under the index heading „Chapter 3“. – Index sheets that have not been marked with a certain chapter are for your personal convenience. The respective headings can be entered in the list of contents.

E XPLANATION - U PDATING Edition 6/2002 This repair manual contains the following supplements: 3.205.46-E Repair Manual 60 SX / 65 SX Basicversion Modelyear 1998 3/1998 3.205.75-E Updating of Rep.Manual 3.205.46-E Modelyear 1999 5/1999 3.210.05-E Updating of Rep.Manual 3.205.46-E Modelyear 2000/2001 2/2001 2000: from engine number B60 000 001 from engine number B65 000 001 2001: from engine number B65 100 001 3.210.36-E Updating of Rep.Manual 3.205.46-E Modelyear 2002 11/2001 from engine number B65 200 001 3.210.66-E Updating of Rep.Manual 3.205.46-E Modelyear 2003 6/2002 from engine number B65 300 001 Modification / Updating: Special tools, technical details model 2003, ignition, measurements with PVA, technical specification, periodic maintenance schedule
