Indmar General Engine Specifications & Capacities Sheet
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
See page ii for engine models 5.7L Carbureted 5.7L MPI 383 LSA LS2/LY6/L96 8.1L MPI
Number of Cylinders
Displacement 383 CID (6.3L) 376 CID (6.2L) 364 CID (6.0L) 496 CID (8.1L)
Bore/Stroke 4.0012 x 3.8 in
( 101.63 x 96.52 mm)
(103.25X 92mm) 3.898 x 3.622 in.
(101.6 x 92 mm)
4.25 x 4.37 in. (108
x 111 mm)
Compression Ratio 9.7:1 9.1:1 9.6:1 9.1:1
Compression Pressure
Idle RPM in Neutral
Operating Range at WOT 4400-4800 RPM 5000-5400 RPM
Oil Pressure at Idle 5 PSI (34 kPa) Min
Oil Pressure at 2000 RPM 10 PSI (69 kPa) Min
Fuel Pump Pressure 8 PSI Max (55.2 KpA)
Electrical System
Minimum Battery Requirements
Firing Order
Spark Plug Type AC 41-983
Spark Plug Gap .030 in. (.76 mm)
Base Timing at 1000 RPM 10 Degrees BTDC
Thermostat
Fluid Capacities
Crankcase (With Filter) 8.5 Quarts (8.0L) 6.0 Quarts (5.7L) 10 Quarts (9.5L)
Closed Cooling Systen 14-16 Quarts (13.2-15.1L)
In-Line 1:1 Transmission 4.2 Quarts (4L) 15W40
In-Line Reduction Gear 4.2 Quarts (4L) 15W40
ZF Ski Vee Transmission
ZF V-Drive Transmission
Walter V-Drive
V-8
350 CID (5.7L)
9.4:1
4.0012 x 3.480 in.
(101.63 x 88.39 mm)
4 PSI (41 kPa) Minimum Hot
18 PSI (124 kPa) Minimum Hot
650 cca/700 mca/120Ah
AC-PF454 (on engine)
Pennzoil PZ52 (remote)
Pennzoil PZ52
Minimum 100 PSI (690 kPa)
650 +_ 50 RPM
4600-5200 RPM 5200-5600 RPM
.040 in. (1.02 mm)
Oil Filter
12 Volt DC Negative (-) Ground
60 PSI Min at Keyup (414 kPa)
1-8-4-3-6-5-7-2 1-8-7-2-6-5-4-3
AC 41-101 AC 41-110
.040 in. (1.02 mm)
Pennzoil PZ167
Non Adjustable
160 Degrees F (71 Degrees C)
4.2 Quarts (4 L) Pennzoil 15W40
.5 Quart (.5 L) Pennzoil SAE 30 Motor Oil
12-14 Quarts (11.4-13.3 L)
1.7 Quarts (1.6 L) Dexron 3 ATF
2.12 Quarts (2 L) Pennzoil 15W40
2.12 qt (2 L) Main Gearbox, 1.0 qt (1.06 L) V-drive - Dexron 3
5.5 Quarts (5.25 L)
