Replacement Parts for Detroit Diesel ® Engines - Engine Index - Engine Parts Listing This is a list of our most popular models. We have parts for other applications not listed in catalog. Call for availability and pricing.

Endurance Power Products (800) 467-5545

Detroit Diesel - Engines PAGE LITER CID ENGINE MODEL CYL NOTES DET53-1 1.7 106 2-53 Inline 2 3.875 bore x 4.500 stroke DET53-2 2.6 159 3-53 Inline 3 3.875 bore x 4.500 stroke DET53-3 3.5 212 4-53 Inline 4 3.875 bore x 4.500 stroke DET53-4 5.2 318 6V53 5 3.875 bore x 4.500 stroke DET53-5 7.0 424 8V53 8 3.875 bore x 4.500 stroke DET71-1 2.3 142 2-71 Inline 2 4.250 bore x 5.000 stroke DET71-2 3.5 213 3-71 Inline 3 4.250 bore x 5.000 stroke DET71-3 4.7 284 4-71 Inline 4 4.250 bore x 5.000 stroke DET71-4 7.0 426 6-71 Inline 6 4.250 bore x 5.000 stroke DET71-5 7.0 426 6V71 6 4.250 bore x 5.000 stroke DET71-6 9.3 568 8V71 8 4.250 bore x 5.000 stroke DET71-7 14.0 852 12V71 12 4.250 bore x 5.000 stroke DET71-8 18.6 1136 16V71 16 4.250 bore DET82-1 8.2 500 8.2L, V8 Fuel Pincher 8 4.252 bore x 4.409 stroke DET92-1 9.0 552 6V92 6 4.840 bore x 5.000 stroke DET92-2 12.1 736 8V92 8 4.840 bore x 5.000 stroke DET92-3 18.0 1104 12V92 12 4.840 bore DET92-4 24.1 1472 16V92 16 4.840 bore DET149-1 19.6 1195 8V149 8 5.75 bore x 5.75 stroke DET149-2 29.4 1792 12V149 12 5.75 bore x 5.75 stroke DET149-3 39.2 2389 16V149 16 5.75 bore x 5.75 stroke DET400-1 6.7 408 40 Series 6 4.3005 bore x 4.68 stroke DET400-2 7.6 466 40 Series 6 4.3005 bore x 5.35 stroke DET400-3 8.7 530 40 Series 6 4.5866 bore x 5.35 stroke DET500-1 8.5 519 50 Series 4 130mm bore x 160mm stroke DET600-1 11.1 677 60 Series 6 130mm bore x 139mm stroke DET600-2 12.7 774 60 Series 6 130mm bore x 160mm stroke DET600-3 14.0 855 60 Series 6 133mm bore x 168mm stroke Arranged by Engine Series Endurance Power Products (800) 467-5545

Endurance Power Products (800) 467-5545

53 SERIES ENGINE IDENTIFICATION Endurance Power Products (800) 467-5545 5 04 5 5 2 00 53 Series # of Cyl Application Basic Arrangement Design Variation Specific Model # 2 2 - Marine 1 - LA 0 - "N" engine (see below) 3 3 - Industrial 2 - LB 1 - 2 valve engine 4 4 - Power base 3 - LC 2 - 4 valve engine 5 - Generator 4 - LD 3 - Turbocharged 7 - Automotive 5 - RA 6 - RB 7 - RC 8 - RD 53 SERIES In-Line Engines Option Plate Example: 5045 - 5200 R (1st letter) Right hand rotation (viewed from front) L (1st letter) Left hand rotations (viewed from front) A (2nd letter) Blower on left, exhaust manifold on right (viewed from rear) B (2nd letter) Blower on left, exhaust manifold on left (viewed from rear) C (2nd letter) Blower on right, exhaust manifold on left (viewed from rear) D (2nd letter) Blower on right, exhaust manifold on right (viewed from rear) Model Number: Last digit odd - Starter is located opposite of blower Model Number: Last digit odd - Starter is located on same side as blower 53 SERIES Vee Engines Option Plate Example: 5062 - 7200 5 06 2 7 2 00 53 Series # of Cyl Application Basic Arrangement Design Variation Specific Model # 6 2 - Marine 1 - LA 0 - "N" engine (see below) 8 3 - Industrial 3 - LC 1 - 2 valve engine 4 - Power base 5 - RA 2 - 4 valve engine 5 - Generator 7 - RC 3 - Turbocharged 7 - Automotive 5 - RA 9 - Special 6 - RB 7 - RC 8 - RD R (1st letter) Right hand rotation (viewed from front) L (1st letter) Left hand rotations (viewed from front) A (2nd letter) Blower on left, exhaust manifold on right (viewed from rear) C (2nd letter) Blower on right, exhaust manifold on left (viewed from rear) Model Number: Last digit odd - Starter is located opposite of blower Model Number: Last digit odd - Starter is located on same side as blower
