Sony Playstation 2 PS2 SCPH-39000 30001 30002 30003 30004 Service Repair Manual
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
SCPH-30000 series Reproduction Prohibited NOTICE Copyright by Sony Computer Entertainment Inc. All rights reserved. No reproduced and transferred required except permission by Sony Computer Entertainment Inc. No commercial use and rental required. REVISIONS. This manual compiled by first edition of SCPH-30000, 30001, 30002, 30003, 30004 B, B’, C, C’, D type design data. Design and Specification will be subject to changed without notice. The latest versions of service manual, Technical memo, Technical information should be used together. SAFETY-RELATED COMPONENT WARNING !! COMPONENTS IDENTIFIED BY MARK OR DOTTED LINE WITH MARK ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE PERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS UBLIÉS PAR SONY. CAUTION Replace the battery with a Sony CR2032 battery. Use of any other type of battery may present the risk of fire or explosion. The battery may explode if mistreated. Do not recharge, disassemble, or dispose of in fire. CAUTION The use of optical instruments with this product will increase eye Hazard. As the laser beam used in this CD/DVD player is harmful To eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only. WARNING !! WHEN SERVICING, DO NOT APPROACH THE LASER EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO CONFIRM LASER BEAM EMISSION, BE SURE TO OBSERVE FROM A DISTANCE OF MORE THAN 25cm FROM THE SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. CAUTION for electric shock When power is ON, Don’t touch to Power supply block, AC-inlet, Power switch and so on, not to get an electric shock at repair. CAUTION for burning When current is supplied, Some of part surface temperature like EE, GS, Regulater-IC, power supply, Optical device and so on. These part surface is become high temperature condition. When it repair, Don’t touch them at a time during it surface is high temperature condition to take prevent against burning. Do repair after it is cooled down enough. CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. ADVARSEL! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. ADVARSEL Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten. Brukte batterier kasseres i henhold til fabrikantens instruksjoner. VARNING Explosionsfara vid felaktigt batteribyte. Använt samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion. VAROITUS Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan valmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. SAFETY CHECK-OUT After correcting the original service problem, perform the following safety checks before releasing the set to the customer: 1. Check the area of your repair for unsoldered or cold-soldered connections. Check the entire board surface for solder splashes and bridges. 2. Check the inter board wiring to ensure that no wires are “pinched” or contact high-wattage resistors. 3. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement. 4. Look for parts which, though functioning, show obvious signs of deterioration. Point them out of the customer and recommend their replacement. 5. Check the line cord for cracks and abrasion. Recommend the replacement of any such line cord to the customer. 6. Check the b+ voltage to see it is at the values specified. 7. Check the antenna terminals, metal trim, “metalized” knobs, screws, and all other exposed metal parts for ac leakage. Check leakage as described below. LEAKAGE The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a Return to chassis, must not exceed 0.5 mA (500 micro-ampers). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the SIMPSON 229 or RCA WT-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milli-ammeter. The Data Precision 245 digital multi-meter is suitable for this job 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated ac voltmeter. The “limit” indication is 0.75V, so analog meters must have an accurate low-voltage scale. The SIMPSON 250 and SANWA SH-63TRD are examples of a passive VOM that is suitable. Nearly all battery operated digital multi-meters that have a 2V AC range are suitable. Fig A. Using AC voltmeter to check AC leakage To Exposed Metal Parts on Set 1.5 kΩ 0.15 μF AC voltmeter (0.75V) Earth Ground NOTIFICATION for environmental assessment This model is CR2032 lithium battery onboard inside on the GD MOUNT as Timer backup power. CR2032 life may be about 5 to 8 years so you have very few need for changing to new one. But if you have necessary to replaced to new one or disassemble for scrapping, you have to keep your country low, regulation, standard, etc. of environmental assessment and safty.
— 139 — SCPH-30002D/30003D/30004D Reproduction Prohibited TABLE OF CONTENTS SCPH-30001 (B, B’) ..................................................................................... 4-38 SCPH-30001 (C) ......................................................................................... 39-70 SCPH-30002/30003/30004 (C, C’) ........................................................... 71-115 SCPH-30001D ........................................................................................ 116-138 SCPH-30002/30003/30004 (D, D’) 1. Table of Contents and Specifications ................... 139 2. Exploded Views Overall and Main Block ............................................................. 140 MD Block ................................................................................... 141 GH-010/GH-012 Block .............................................................. 142 GB-003/GB-004 and Plate Assy Block ..................................... 142 Shield (A) Assy Block ............................................................... 142 Shield (B) Block ......................................................................... 142 Fan and Rear Panel Block .......................................................... 142 Switch Block .............................................................................. 142 3. Block Diagram for D type ....................................... 143 4. Printed Wiring Boards and Schematic Diagrams for SCPH-30002D/30003D/30004D This Note is Common for Printed Wiring boards and Schematic diagrams ................................................................... 144 GH-010 ....................................................................................... 145 GB-003 ....................................................................................... 154 SW-358 ...................................................................................... 155 5. Electrical Parts List for SCPH-30002D/30003D/30004D ......................... 156 6. Printed Wiring Boards and Schematic Diagrams for SCPH-30003D’/30004D’ This Note is Common for Printed Wiring boards and Schematic diagrams ................................................................... 162 GH-012 ....................................................................................... 163 GB-004 ....................................................................................... 172 SW-363 ...................................................................................... 173 7. Electrical Parts List for SCPH-30003D’/30004D’ ..................................... 174 SCPH-30000 ........................................................................................... 180-202 SECTION 1 SPECIFICATIONS General Power requirements 220-240 V AC, 50/60 Hz Power consumption 50 W Dimensions 301 × 78 × 182 mm (w/h/d) Mass 2.4 kg Inputs/ Outputs on the front Controller ports (2) Memory card slots (2) USB ports (2) S400 (i-Link) port (1) Inputs/Outputs on the rear HDD bay slot (1) Outputs on the rear AV Multi out port (1) RGB, Ycbcr, Y/C, Composite-video, Audio-L/R, XGA Digital out port (1) Optical audio Supplied accessories AC power cord (1) Euro-AV connector (1) (for SCPH-30003, 30004) A/V connecting cable (1) Dualshock2 Analog controller (1)
— 140 — SCPH-30002D/30003D/30004D Reproduction Prohibited SECTION 2 EXPLODED VIEWS The components identified by mark ! or dotted line with mark. ! are critical for safety. Replace only with part number specified. CAUTION : Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. CAUTION Overall and Main Block ---------------------- OVERALL AND MAIN BLOCK ---------------------- Ref-No. Part No. Description Remark Place code 60 1-468-605-21 POWER BLOCK #00 62 1-694-676-21 TERMINAL BOARD (FRONT) #17 71 3-069-119-01 LABEL, MODEL NUMBER (AU) for SCPH-30002D #87 71 3-069-120-01 LABEL, MODEL NUMBER (CEK) for SCPH-30003D/30003D’ #87 71 3-069-121-01 LABEL, MODEL NUMBER (CEL) for SCPH-30004D/30004D’ #87 75 3-059-626-03 COVER, SCREW #22 76 3-059-627-01 CAP #22 84 3-067-170-01 TAPE (20X20), HARNESS STOPPER #87 91 A-6705-342-A MD BLOCK ASSY #10 92 A-6705-401-A SWITCH BLOCK ASSY #87 93 X-3951-722-1 COVER ASSY, LOWER #87 94 X-3951-721-1 COVER ASSY, UPPER #87 106 X-3951-317-1 LID ASSY #87 112 3-066-498-01 TAPE, VOID #87 135 3-988-711-02 LABEL, LASER COUTION #87 151 1-757-934-11 CABLE, FLAT (FFC-011) #12 152 1-757-935-11 CABLE, FLAT (FFC-012) #12 153 1-961-160-21 HARNESS (HS-059) #12 156 3-068-669-02 SHIELD B #16 157 3-068-674-01 SHEET,INSULATING #16 158 3-068-675-02 SHIELD HDD #87 161 3-070-120-01 SHEET, INTERCEPTION #87 162 3-069-212-01 TAPE, HARNESS STOPPER #16 B265 3-069-170-01 TAPPING (B2X6.5) #87 BV312 3-325-679-21 SCREW, TAPPING +BV 3X12 #87 BV316 3-325-679-91 SCREW (2 LOCK), +BV TAPPING #87 GH010 A-6712-954-A GH-010 MOUNT (32M M) Block for SCPH-30003D/30004D #25GB GH010 A-6712-957-A GH-010 MOUNT (64M M) Block for SCPH-30002D #25GB GH010 A-6712-955-A GH-010 MOUNT (64M M) Block for SCPH-30003D/30004D #25GB GH010 A-6712-958-A GH-010 MOUNT (64M R) Block for SCPH-30002D #25GB GH010 A-6712-956-A GH-010 MOUNT (64M R) Block for SCPH-30003D/30004D #25GB GH012 A-6712-985-A GH-012 MOUNT (32M R) Block for SCPH-30003D’/30004D’ #25GH GH012 A-6712-986-A GH-012 MOUNT (64M R) Block for SCPH-30003D’/30004D’ #25GH M225 3-069-169-01 SCREW (M2X2.5) #87 M354 3-059-622-02 SCREW (M3X54), HEAD TAPPING #87 M360 3-069-168-01 TITE (CZN), M3X6 +BV S #87 GH010 : for SCPH-30002D/30003D/30004D model GH012 : for SCPH-30003D’/30004D’ model 153 151 E 62 93 76 76 76 75 M354 M354 B265 B265 B265 M225 156 151 152 158 161 106 A C B D D 94 112 A 71 60 M360 M360 162 BV312 BV312 BV316 BV316 84 91 C B E 92 152 135 157 CAUTION Don't lose the insulating sheet when assemble the console.
— 142 — SCPH-30002D/30003D/30004D Reproduction Prohibited Switch Block ------------ SWITCH BLOCK ------------ Ref-No. Part No. Description Place code 50 3-059-665-03 BUTTON, SWITCH #25SW 51 3-059-666-05 BRACKET, SWITCH #25SW 52 7-685-105-11 TPG +P 2X8, TYPE 2, NON-SLIT #25SW 53 A-6712-922-A SW-358 MOUNT for SCPH-30002D/30003D/30004D #25SW 53 A-6712-983-A SW-363 MOUNT for SCPH-30003D’/30004D’ #25SW 51 53 50 52 ------------------------ FAN AND REAR PANEL BLOCK ------------------------ Ref-No. Part No. Description Place code 63 1-763-480-22 DC. FAN #74 64 1-771-995-31 SWITCH, POWER (WITH AC INLET) #00 159 3-068-676-11 PANEL, REAR #87 BV312 3-325-679-21 SCREW, TAPPING +BV 3X12 #87 GH-010/GH-012 Block 87 GH010 153 151 : for SCPH-30002D/30003D/30004D model GH012 : for SCPH-30003D’/30004D’ model ------------------- GH-010/GH-012 BLOCK ------------------- Ref-No. Part No. Description Place code 87 3-068-806-01 SHEET (DRIVER), ELECTRIC HEAT #25GH 151 1-757-934-11 CABLE, FLAT (FFC-011) #12 153 1-961-160-21 HARNESS (HS-059) #12 GH010 A-6712-954-A GH-010 MOUNT (32M M) for SCPH-30003D/30004D #25GH GH010 A-6712-957-A GH-010 MOUNT (64M M) for SCPH-30002D #25GH GH010 A-6712-955-A GH-010 MOUNT (64M M) for SCPH-30003D/30004D #25GH GH010 A-6712-958-A GH-010 MOUNT (64M R) for SCPH-30002D #25GH GH010 A-6712-956-A GH-010 MOUNT (64M R) for SCPH-30003D/30004D #25GH GH012 A-6712-985-A GH-012 MOUNT (32M R) for SCPH-30003D’/30004D’ #25GH GH012 A-6712-986-A GH-012 MOUNT (64M R) for SCPH-30003D’/30004D’ #25GH Shield (A) Assy Block --------------------- SHIELD (A) ASSY BLOCK --------------------- Ref-No. Part No. Description Place code 97 X-3951-707-2 SHIELD (A) ASSY #87 120 3-059-652-01 SHEET (A), ELECTRIC HEAT for SCPH-30002D/30003D/30004D #16 143 3-066-277-01 SHEET (P), ELECTRIC HEAT for SCPH-30003D’/30004D’ #16 144 3-066-278-01 SHEET (Q), ELECTRIC HEAT for SCPH-30003D’/30004D’ #16 97 120 144 143 for SCPH-30003D’/30004D’ model Shield (B) Block ---------------- SHIELD (B) BLOCK ---------------- Ref-No. Part No. Description Place code 156 3-068-669-02 SHIELD B #16 157 3-068-674-01 SHEET, INSULATING #16 156 157 Fan and Rear Panel Block 64 63 159 BV312 CAUTION Don't lose the insulating sheet when assemble the console. GB-003/GB-004 and Plate Assy Block 95 61 GB003 153 91 : for SCPH-30002D/30003D/30004D model GB004 : for SCPH-30003D’/30004D’ model ---------------------------------- GB-003/GB-004 AND PLATE ASSY BLOCK ---------------------------------- Ref-No. Part No. Description Place code 61 1-528-174-41 BATTERY, LITHIUM (CR2032 TYPE) #25GB 91 A-6705-342-A MD BLOCK ASSY #10 95 X-3951-099-1 PLATE ASSY, ORNAMENTAL #87 153 1-961-160-21 HARNESS (HS-059) #12 GB003 A-6712-923-A GB-003 MOUNT for SCPH-30002D/30003D/30004D #25GB GB004 A-6712-984-A GB-004 MOUNT for SCPH-30003D’/30004D’ #25GB
— 143 — SCPH-30002D/30003D/30004D Reproduction Prohibited SECTION 3 BLOCK DIAGRAM for D type µCON+DSP RF-AMP+DRIVER BOOT ROM DVD ROM IOP EE+RDRAM GS+VIDEO SPU2+AUDIO+HDD CN108 RF-AMP AUL AUR MD BLOCK CN801-806 PD1 PD2 A-F / 6 CONTROL BUS EVER3.3V BT101 IC801 2 1 5-10 43 42 44 47 FE TE CE RFD0 TS_SI RF AMP CONTROL BUS TIMER EEP ROM IC405 IC406 X402 32.768MHz EEP-CE EEP-SCK EEP-SO EEP-SI STEP(±A, ±B), TRAY(CNT, DRVF, DRVR) 43-46 3,10,11 SP_GAINSW/ SP_PS/ SP_SB/ DRIVER H (±), H1 (±) H2 (±), H3 (±) A1, 2, 3 STD (±A, ±B) TD _OFST LOADING (±) TRK (±) FCS (±) IC802 IC803 SPINDLE CONTROL FORCUS/TRACKING/ SLIDE/LOADING 16,18 22-23 26 SP_GAINSW/, SP_PS/SPDL/, SP_SB/SP_BR (FF,FR,TF,TR)DR (FF,FR,TF,TR) DR 71-73 75,29 61 4 MECHA-CON PB2 99 /POFF_RDY SYS_SRST TRAY_REQ MCON_ACK SYSTEM CONTROL CD/DVD DSP HDD_SW, SW1.5, SW1.9/SW2.5 SW5.1/SW3.3, SW12, FAN_PWM PWR_SW,/GREEN_ON,OP/CL_SW,/RED_ON DIG +3.5V/DIG +5V REG (USB DRIVE) IC409, Q407, 408 (DC-DC CONVERTER) IC403 : EVER 3.3V REG IC407 : DIG +1.8V REG IC411 : DIG +1.8V REG IC412 : DIG +2.5V REG IC413 : SER +3.5V REG IC414 : CON +8V REG Q409-411, 414 : HDD +5V/+12V REG DRAM WE RAS CAS OE 21 22 23 24 17 18 34,35 33 PG5 PG6 PG7 PG4 48 49 50 47 TRAY_LED-ON /BLUE_ON SPMA0-9 SPMD0-15 SPU2 RST SYSTEM POWER REGURATOR/FAN DRIVE/USB DRIVE/HDD DRIVE IC415,Q415 :+8.5V (FAN DRIVE) Q401,402,404,IC404 : DIG +1.5V REG IC408 : DIG +1.8V REG IC410 : DIG +2.5V REG SYSTEM POWER SUPPLY POWER SW OPEN/CLOSE SW SW-358 OPTICAL DIGTAL OUT CN501 DIGITAL OUT Q506 MUTE AUDIO D/A CONVERTER /RST 105 42 47 48 41 40 49 DAD OUT DABCK OUT DALRCK OUT DACCK SPMUTE Q505 IC517 IC504 IC502 IC402 IC604 /SSRST,/RST SLEEP,POFF_REQ,OP_DISC GSTBY,LCLK,/GRST SD0-15 SA0-15,24-26 SPUDI,SPUDATI SPUBCKI,SPULRCKI PWRUP_EE,/ESTBY,/ERST SUB ADDRESS BUS SYSTEM CONTROL BUS SA0-26 SD0-15 X101 18.432MHz IC101 CLOCK GENERATOR / DRAMC PLL 400MHz PHY 55,57 59,61 TPA/TPAn/TPB/TPBn / 4 / 2 X301 24.576MHz 179-182 (DATA+,DATA_)X2 / 4X2 CN303 FL301, 302 CN301 IC503, 506 : for GH-010-32M/GH-012-32M IC505 : for GH-010-64M/GH-012-64M BOOT ROM DVD ROM IC105 SD0-15 17-24,26-33 1-11,15,40-49 SA0-21 /CS1,/CS2 IC605 FE TE CE RFD0 207 205 204 38 LOW POWER THERMOSTAT T1;70.6dC T2;76.7dC i LINK / 4 / 4X2 USB PORTX2 MEMORY CARD 2 DATA (Magic Gate) CONTROLLER 1 DATA MEMORY CARD 1 DATA CONTROLLER 2 DATA (Magic Gate) FRONT TERMINAL CN002 CN001, CN302 MEMORY CARD 2 DATA CONTROLLER 1 DATA MEMORY CARD 1 DATA CONTROLLER 2 DATA IC303 IOP /BE0-3 IC306 +2.5V X302 16.9344MHz VREF 72 50 51 74 75 IC305 EDO RAM MD0-31 MA0-9 CAS0-3 WE 44 AD0-31 3-34 394-425 35-38 384-387 /BE0-3 / 4 /RDAC /WRAC /RDY /BREQ /BGNT DREQ0 DREQ1 DACK /SGINT /SINT /SRST 39 40 41 42 43 44 45 46 47 48 49 1 2 388 389 383 426 427 393 392 391 429 428 430 431 390 MSCLK PGCLK 128bit BUS RQ_A0-7/RQ_B0-7 DQB_A0-7/DQB_B0-7 DQA_A0-7/DQA_B0-7 SIF DMAC IPU EMOTION ENGINE IC104 CPU VU0 VU1 GIF TIMER SIO INTC GD0-63 11-74 1-64 IC202 IC205 GRAPHICS SYNTHESIZER ARED AGEN ABLU GA0-6 4-10 71-77 CLKCG CLKGC /VLDCG /VLDGC /RDYCG /RDYGC GRW /GACK /GREQ /GINT 66 65 70 69 68 67 80 78 79 81 75 76 77 78 79 80 81 82 83 84 RGB to YCrCB MATRIX SYNC_GEN,HD0,1 CONTROL REGISTER M-Bus Control Module DAC DAC DAC C Y COMPONENT DIGITAL DATA MODE0-2 IC206 ANALOG VIDEO ENCODER DIGITAL VIDEO ENCODER 14 15 16 20 22 24 COUT YOUT CVBS-OUT BOUT/CbOUT/PbOUT GOUT/YOUT ROUT/CbOUT/PbOUT R G B 38 40 42 RIN1 GIN1 BIN1 D0-2 AUL AUR 6 8 7 4 1 2 11 9 CN201 CN504 HDD DATA (CD0-15) HDD ADDRESS (CA0-25) CONTROL HDD CONTROLLER 60-71,74 76-78 38,40-53 56-59 SCL SDA RT /POFF_RDY SLEEP PO_DISC POFF_REQ SCL SDA /DVRST 12 13 10 IC501 5,6,7 SPCLK X202 54MHz X401 4MHz 266 REF.V GEN. 6 5 MCD0-7 MCA0-8 CONTROL BUS 1 2 3 4 11 12 15 16 GREEN_ON RED_ON Q405 Q601 AV MULTI OUT to HDD 79-88 91-96 97-104,106,107 110-115 RDRAM (16MB) 4.5 4.5 CTMN CTM IC103 IC102 Cr Cb Y Mod. + + HSYNC, VSYNC, CSYNC, PAL/NTSC, CLOCK, RGBYC 220 218 219 SA0-15 SPUDI,SPUDATI SPUBCKI,SPULRCKI 8 5 11 9 7 30.31 34-36 9 5 1 71,72 68-70 SC 23 5 29,30,31 / 2 / 3 DD+SYSTEM CONTROL SUB DATA BUS SPUDATI/SPUBCKI/SPULRCKI CD-ROM PlayStation Format PlayStation2 Format AC12V IN CN401 GH-010 SD0-15 RO0-7 299-306 37-44 GO0-7 291-298 47-54 BO0-7 283-290 55-62 DVD VIDEO DVD ROM PlayStation2 Format AUDIO CD SD0-15 SA1-10 SPU(DI, DATI,BCKI, LRCKI) GB-003 85, 88, 117, 118 12, 13 4
— 144 — SCPH-30002D/30003D/30004D SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS for SCPH-30002D/30003D/30004D THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. Note on Printed Wiring Boards : • • Through hole is omitted. : Pattern on the side which is seen. Note on Schematic Diagram : • • • • Use caution when replacing chip parts. New parts must be attached after removal of chip. Be careful not to heat the minus side of tantalum capacitor, because it is damaged by the heat. All capacitors are in μF unless otherwise noted. pF : μμF 50 WV or less are not indicated except for electrolytics and tantalums. All resistors are in and 1/4 W (Chip resisters : 1/10W) unless otherwise specified. Chip resistors are 1/8 W or 1/10 W unless otherwise noted. k : 1000 , M : 1000 k . Note : The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Note : Les composants identifies par une marque ! sont critiques pour la securite. Ne les remplacer que par une piece portant le nubero specifie. Unit of voltage is V (volt) • • • • • • • +12V : +8.0V : +5.0V : +3.5V : +3.4V : IN : OUT : • • • • • • +3.3V : +2.5V : +1.8V : +1.7V : +1.5V : Main Signal Line : , Note on DC Power line : Reproduction Prohibited
Get your hands on the comprehensive and detailed service repair manual for the Sony Playstation 2 (PS2) models SCPH-39000, 30001, 30002, 30003, and 30004. This manual is an invaluable resource for both professional technicians and DIY enthusiasts, providing step-by-step instructions and highly detailed exploded pictures to assist you in servicing or repairing your PS2 console.
It covers a wide range of topics including assembly, disassembly, specifications, exploded views, block diagrams, printed wiring boards, schematic diagrams, electrical parts list, and much more. This manual is designed for easy viewing on your Windows PC, Mac, tablet, or smartphone, and can be printed for reference. It is the only PS2 service manual you will ever need, offering instant access without any shipping costs.
If you are in need of a specific manual, our customer support team is available to assist you in finding it. Join the ranks of thousands of satisfied customers worldwide who have benefited from this manual. Keep your PS2 console in optimal condition with this indispensable resource.
