Volvo EC210CL Excavator Full Service & Repair Manual

Service Information Document Title: Function Group: Information Type: Date: Product plates 000 Service Information 2014/11/4 Profile: EXC, EC210C L, EC160C L, EC180C L [GB] Product plates When ordering spare parts, and in all telephone enquiries or correspondence the model designation and the Product Identification Number (PIN) must always be quoted. Product plate The product plate on the machine shows the manufacturer's name and address, model designation, PIN, machine weight, engine output, production year and year of delivery. There is also room for the CE mark. The plate is positioned under the boom on the superstructure frame. Engine The engine product plate contains type designation and part and serial numbers and is positioned on the engine inside the rear engine cover on the right side of the machine. Attachment quick coupler The attachment quick coupler nameplate is attached on the outside of the attachment quick coupler. (shows part number and weight) Bucket The bucket nameplate is attached on the top of the bucket. (shows the bucket model order No, Serial number, bucket part number, rated capacity, weight, cutting width, tooth part number and adapted part number) Cab The nameplate is attached on the inside of the cab and indicates the product number, serial number, model type, and weight.

Service Information Document Title: Function Group: Information Type: Date: Machine view, waste handler 000 Service Information 2014/11/4 Profile: EXC, EC210C L [GB] Machine view, waste handler Waste handling machines have a variety of configurations to meet waste handling application needs. Specially, the machines are reinforced Dual stage pre-cleaner, Cab air filtering system, Emergency stop switch, Cab riser, Fire extinguisher system and Bucket cylinder guard to fulfill an excellent performance in waste handling application. Figure 1 Components position on machine 1. 2. 3. 4. 5. Dual stage pre-cleaner Cab air filtering system Emergency stop switch Cab riser: 1200 mm (47.2 in) Fire extinguisher system

Service Information Document Title: Function Group: Information Type: Date: Component locations 000 Service Information 2014/11/4 Profile: EXC, EC210C L, EC160C L, EC180C L [GB] Component locations Figure 1 Component position 1 Dipper arm cylinder 14 Main pump 2 Boom 15 Track motor and gearbox 3 Boom cylinder 16 Hydraulic tank 4 Operator cab 17 Fuel tank 5 Oil cooler 18 Center passage 6 Slew motor and gearbox 19 Top roller 7 Air cleaner 20 Bottom roller 8 Radiator and charge air cooler 21 Idler 9 Main control valve 22 Bucket 10 Engine 23 Link 11 Rear hood 24 Bucket cylinder 12 Muffler 25 Dipper arm 13 Counterweight

Service Information Document Title: Function Group: Information Type: Date: Machine view, waste handler 000 Service Information 2014/11/4 Profile: EXC, EC210C L [GB] Machine view, waste handler Figure 1 Components position on machine 1. 2. 3. 4. 5. 6. 7. 8. 9. Dual stage pre-cleaner Cab air filtering system Strobe beacon lamp Falling object protection structure (FOPS) DC-DC converter Emergency stop switch Emergency stop system Upper frame side protection Anti-slip protection

Service Information Document Title: Function Group: Information Type: Date: Measurement conversion tables 030 Service Information 2014/11/4 Profile: EXC, EC210C L [GB] Measurement conversion tables Length Unit cm m km in ft yd mile cm 1 0.01 0.00001 0.3937 0.03281 0.01094 0.000006 m 100 1 0.001 39.37 3.2808 1.0936 0.00062 km 100000 1000 1 39370.7 3280.8 1093.6 0.62137 in 2.54 0.0254 0.000025 1 0.08333 0.02777 0.000015 ft 30.48 0.3048 0.000304 12 1 0.3333 0.000189 yd 91.44 0.9144 0.000914 36 3 1 0.000568 mile 160930 1609.3 1.6093 63360 5280 1760 1 1 mm = 0.1 cm, 1 mm = 0.001 m Area Unit cm2 m2 km2 a ft2 yd2 in2 cm2 1 0.0001 - 0.000001 0.001076 0.000012 0.155000 m2 10000 1 0.000001 0.01 10.764 1.1958 1550.000 km2 - 1000000 1 10000 1076400 1195800 - a 0.01 100 0.0001 1 1076.4 119.58 - ft2 - 0.092903 - 0.000929 1 0.1111 144.000 yd2 - 0.83613 - 0.008361 9 1 1296.00 in2 6.4516 0.000645 - - 0.006943 0.000771 1 1 ha = 100 a, 1 mile2 = 259 ha = 2.59 km2 Volume Unit cm3 = cc m3 Liter in3 ft3 yd3 cm3 = m liter 1 0.000001 0.001 0.061024 0.000035 0.000001 m3 1000000 1 1000 61024 35.315 1.30796 Liter 1000 0.001 1 61.024 0.035315 0.001308 in3 16.387 0.000016 0.01638 1 0.000578 0.000021 ft3 28316.8 0.028317 28.317 1728 1 0.03704 yd3 764529.8 0.76453 764.53 46656 27 1 1 gal(US) = 3785.41 cm3 = 231 in3 = 0.83267 gal(US) Weight Unit g kg t oz lb g 1 0.001 0.000001 0.03527 0.0022 kg 1000 1 0.001 35.273 2.20459
