GENERAL INFORMATION Diagnostic Connector (DLC) Locations DOMESTIC CARS CHRYSLER GROUP LLC CHRYSLER GROUP LLC - DOMESTIC CARS NOTE: This table provides a quick reference for self-diagnostic connector locations, when available from manufacturer, that ARE NOT located at the lower left side of the dash, as mandated in 1996 by the Federal government. Application Connector Location Acclaim 1989-90 Under Left Side Of Dash 1991-92 On Left Front Fender Panel, Near Shock Tower 1993-94 Near Battery 1995 Behind Left Side Of Dash, Near Fuse Block Aries, Caravelle, Dynasty, E Class, Executive Sedan, LeBaron Sedan, New Yorker, Reliant, Town & Country, 400 & 600 1984-85 On Left Fender Apron, Behind Battery (2.2L Only) 1986-87 On Front Of Right Shock Tower (2.2L & 2.5L Only) 1988-89 On Left Fenderwell 1990 Under Left Side Of Dash 1991-92 On Left Front Fender Panel, Near Shock Tower 1993 (Except New Yorker) Near Battery 1993 (New Yorker) On Left Fender Panel Near PCM Avenger (1995-00) Under Center Of Dash, Near Center Console Breeze, Cirrus & Stratus (1995) Left Of Steering Column, On BCM Charger, Horizon, Omni, Rampage, Scamp & Turismo 1985-89 2.2L Carbureted On Left Fender Apron 2.2L Turbo On Front Of Right Shock Tower Concorde, Intrepid, LHS, New Yorker, Vision & 300M 1993-95 Behind Left Side Of Dash 1996-97 Under Left Side Of Dash, Near Center 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

Console Daytona 1984-87 On Front Of Right Shock Tower 1988-89 On Left Fenderwell 1990-92 On Left Front Fender Panel, Near Shock Tower 1993 On Left Front Inner Fender Or Under Steering Column Dynasty 1990 Under Left Side Of Dash 1991-93 On Left Fender Panel, Near SBEC/PCM Fifth Avenue 1990 Under Left Side Of Dash 1991-93 On Left Fender Panel Near SBEC/PCM Horizon & Omni (1989-90) Under Left Side Of Dash Imperial 1981-83 CCC Connector Left Of Air Cleaner 1990 Under Left Side Of Dash 1991-93 On Left Fender Panel Near SBEC/PCM LeBaron Coupe & Convertible 1985-87 On Right Front Shock Tower 1988-89 On Left Fenderwell 1990-92 On Left Front Fender Panel, Near Shock Tower 1993 On Left Front Inner Fender Or Under Steering Column 1994 Near Battery 1995 Behind Left Side Of Dash, Near Fuse Block Lancer 1985-87 On Right Front Shock Tower 1988-89 On Left Fenderwell Laser 1990-94 Above Left Kick Panel, Near Fuse Block 1995 Under Left Side Of Dash, Near Center Console Monaco & Premier 1990 On Right Front Fender Panel 1991-92 On Left Fender Panel, Next To SBEC Under Headlight Switch, Under Left Side 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

FORD MOTOR CO. FORD MOTOR CO. - DOMESTIC CARS Neon (1995) Of Dash Shadow 1985-87 On Right Front Shock Tower 1988 On Left Fenderwell 1989 Under Dash, To Right Of Steering Column 1990 On Left Fender Front Panel, Near SBEC 1991-92 On Left Front Fender Panel, Near Shock Tower 1993-94 Near Battery Spirit & Sundance 1985-87 On Right Front Shock Tower 1989-90 Under Left Side Of Dash 1991-92 On Left Front Fender Panel, Near Shock Tower 1993-94 Near Battery 1995 Behind Left Side Of Dash, Near Fuse Block Talon 1990-94 Above Left Kick Panel, Near Fuse Block 1995-98 Under Left Side Of Dash, Near Center Console NOTE: This table provides a quick reference for self-diagnostic connector locations, when available from manufacturer, that ARE NOT located at the lower left side of the dash, as mandated in 1996 by the Federal government. Application Connector Location Bobcat & Pinto On Center Of Right Fender Apron Capri 1980-85 On Center Of Left Front Fender Apron 1986 On Left Rear Corner Of Engine Compartment Continental 1984-89 On Right Rear Corner Of Engine Compartment 1990-91 On Right Rear Corner Of Firewall, On Electronic Assembly Cover 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

1992 On Right Fender Apron 1993-94 VIP Connectors (2) On Right Rear Of Engine Compartment, On PCM Cover Contour & Mystique 1995 On Left Rear Corner Of Engine Compartment Cougar & Thunderbird 1982-90 On Left Fender Apron 1991 On Rear Of Right Front Fender Panel 1992 Front Of Right Shock Tower 1993 2 Connectors In Right Rear Corner Of Engine Compartment 1994 On Right Side Of Engine Compartment & Below Glove Box 1995 3.8L On Right Side Of Engine Compartment & Below Glove Box 4.6L Behind Right Side Of Dash, Below Glove Box 1996 Lower Right Side Of Dash, Below Glove Box Crown Victoria, Grand Marquis & Lincoln Town Car 1983 & 1987 On Right Fender Apron 1985-86 & 1988-90 On Left Fender Apron 1992 On Left Front Fender Panel 1993-94 On Top Of Left Front Wheelwell Escort, EXP, Lynx & Tracer 1985-90 On Right Fender Apron Near Firewall 1991 On Left Rear Of Engine Compartment 1992 On Right Rear Of Engine Compartment, Near Cowl 1993-95 On Left Side Of Firewall LTD & Marquis 1983 On Left Fender Apron 1984-86 On Left Rear Corner Of Engine Compartment Mark VII 1984-87 On Right Rear Corner Of Engine Compartment 1988-90 Front Of Right Fender Apron 1991 On Right Side Of Engine Compartment, Near Thermactor Solenoids 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

GENERAL MOTORS GENERAL MOTORS - DOMESTIC CARS Mark VIII 1993-96 On Top Of Left Wheelwell Mustang 1980-85 On Center Of Left Front Fender Apron 1986-91 On Left Rear Corner Of Engine Compartment 1992 On Left Shock Tower, Near Ignition Coil 1993 2 Connectors On Right Front Strut Tower 1994-95 Behind Right Front Strut Tower & Right Of Steering Column Probe 1991-92 On Left Rear Corner Of Engine Compartment 1993 DLC - Behind Left Side Of Dash; STI Connector - On Left Inner Fender Panel 1994-95 On Left Front Inner Fender Panel Sable & Taurus 1986-87 (3.0L Only) Near Alternator 1988-90 2.5L On Engine Harness Near PCV Hose 3.0L On Right Rear Corner Of Engine Compartment 1991 On Right Rear Corner Of Engine Compartment, On ECA Cover 1992 On Right Rear Corner Of Engine Compartment, Below MAP Sensor 1993-95 Right Rear Of Engine Compartment Tempo & Topaz 1984-92 On Right Rear Corner Of Engine Compartment 1993-94 In Engine Compartment, On Left Strut Tower NOTE: This table provides a quick reference for self-diagnostic connector locations, when available from manufacturer, that ARE NOT located at the lower left side of the dash, as mandated in 1996 by the Federal government. Application Connector Location 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

Allante Enter Diagnostic Mode By Pressing OFF & WARM Buttons On Instrument Panel Bonneville (1980-81) ECU Connector On Upper Right Kick Panel Brougham (1987-92) Bottom Center Of Instrument Panel Camaro & Firebird (1980) Diagnostic Ground Lead Connector On Right Shroud Above ECM Caprice Classic 1980-81 ECU Connector On Upper Right Kick Panel 1982-88 Under Center Of Instrument Panel Catalina ECU Connector On Upper Right Kick Panel Cavalier (1982-88) On Side Of Fuse Block Cimarron On Side Of Fuse Block Century Under Left Of Dash Ashtray Corvette (1980-83) In Center Console, Under Ashtray Custom Cruiser 1980-81 ECU Connector On Upper Right Kick Panel 1982-88 Under Center Of Instrument Panel DeVille (1981-88) Enter Diagnostic Mode By Pressing OFF & WARMER Buttons On Instrument Panel Delta 88 ECU Connector On Upper Right Kick Panel Eldorado (1981-88) Enter Diagnostic Mode By Pressing OFF & WARMER Buttons On Instrument Panel Electra (1980-81) ECU Connector On Upper Right Kick Panel Estate Wagon ECU Connector On Upper Right Kick Panel Fiero Under Ashtray Or Cigar Lighter Panel Within Center Console Firenza On Side Of Fuse Block Fleetwood (1981-88) Enter Diagnostic Mode By Pressing OFF & WARMER Buttons On Instrument Panel Fleetwood Brougham On Bottom Center Of Dash, Near Ashtray Impala (1982-88) Under Center Of Instrument Panel LeMans ECM Connector On Right Kick Panel 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

DOMESTIC LIGHT TRUCKS & VANS CHRYSLER GROUP LLC Or Under Left Side Of Dash LeSabre (1980-81) ECU Connector On Upper Right Kick Panel LeSabre Wagon (1982-88) Under Center Of Instrument Panel Monza Under Right Side Of Dash Ninety-Eight (1980-81) ECU Connector On Upper Right Kick Pane Nova Behind Right Strut Tower Parisienne Under Center Of Instrument Panel Reatta 1988-92 (MFI) Enter Diagnostic Mode By Pressing OFF & WARM Buttons On Instrument Panel 1991-93 Above Parking Brake Pedal Riviera 1980-85 (Carbureted) Under Left Or Center Of Dash 1986-92 (MFI) Enter Diagnostic Mode By Pressing OFF & WARM Buttons On Instrument Panel Safari Under Center Of Instrument Panel Seville (1981-88) Enter Diagnostic Mode By Pressing OFF & WARMER Buttons On Instrument Panel Skyhawk Under Right Side Of Dash Starfire Under Right Side Of Dash Sunbird On Side Of Fuse Block, Under Right Side Of Dash Toronado 1980-85 (Carbureted) Under Left Or Center Of Dash 1986-92 (MFI) Enter Diagnostic Mode By Pressing OFF & WARM Buttons On Instrument Panel Trofeo 1988-92 (MFI) Enter Diagnostic Mode By Pressing OFF & WARM Buttons On Instrument Panel 1991-93 Above Parking Brake Pedal 2000 On Side Of Fuse Block 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

CHRYSLER GROUP LLC - DOMESTIC LIGHT TRUCKS & VANS FORD MOTOR CO. NOTE: This table provides a quick reference for self-diagnostic connector locations, when available from manufacturer, that ARE NOT located at the lower left side of the dash, as mandated in 1996 by the Federal government. Application Connector Location Caravan, Grand Caravan, Grand Voyager, Mini Ram Van, Town & Country, & Voyager 1984-92 On Left Side Fender Apron 1993 On Left Fender Front Fender Panel, Near SBEC 1994-95 On Wiring Harness, On Center Of Firewall Dakota 1987-88 On Right Side Fender Apron 1989 On Left Side Of Firewall 1990-92 On Right Side Of Firewall 1993-95 On Right Rear Corner Of Engine Compartment Jeep Cherokee (1992-95) On Left Front Fender Apron, Behind Air Cleaner Comanche On Left Front Fender Apron, Behind Air Cleaner Grand Cherokee & Wagoneer 1993-95 PCM On Right Rear Of Engine Compartment, Near PCM TCM Behind Left Side Of Instrument Panel Wrangler (1992-95) On Left Side Of Firewall, Near PCM Pickup & Ramcharger 1985-90 On Left Side Of Firewall 1991-93 On Left Front Fender Panel, Next To SBEC/PCM 1995 Pickup On Right Side Of Firewall Ram Wagon & Van 1985-90 On Left Side Of Firewall 1991-95 On Center Of Firewall, Near SBEC/PCM NOTE: This table provides a quick reference for self-diagnostic connector locations, when available from manufacturer, that ARE NOT located at the lower left side 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

FORD MOTOR CO. - DOMESTIC LIGHT TRUCKS & VANS of the dash, as mandated in 1996 by the Federal government. Application Connector Location Aerostar 1986-90 On Left Front Fender 1991 Near Starter Relay 1992 On Left Front Inner Fender Panel 1993-95 On Left Side Of Firewall Bronco 1982-85 6-Cylinder On Left Front Fender V8 On Right Inner Fender Panel 1986-87 On Right Front Fender, Near Starter Relay 1988-92 On Left Fender Apron 1993-95 2 Connectors In Left Rear Of Engine Compartment, On Bracket 1996- Below Glove Box Bronco II 1983-85 On Right Front Inner Fender Panel (2.3L Only) 1986-90 On Right Front Fender Apron Excursion Behind Center Of Dash Explorer & Mountaineer (1991-94) On Right Rear Of Engine Compartment, Near A/C-Heater Blower Pickup 1982-85 6-Cylinder On Left Front Fender V8 On Right Inner Fender Panel 1986-87 On Right Front Fender, Near Starter Relay 1988-92 On Left Fender Apron 1993-95 2 Connectors In Left Rear Of Engine Compartment, On Bracket 1996- Below Center Of Instrument Panel Pickup (F250 Heavy Duty & F350) Under Right Side Of Dash Ranger 1983-85 On Right Front Inner Fender Panel (2.3L Only) 1986-90 On Right Front Fender Apron 1991 Behind Engine Compartment 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations

GENERAL MOTORS GENERAL MOTORS - DOMESTIC LIGHT TRUCKS & VANS IMPORTED CARS & TRUCKS ACURA Fuse/Relay Block 1992 On Left Front Inner Fender Panel 1993-95 On Rear Of Engine Compartment Fuse/Relay Block Van 1986-92 On Right Fender Apron 1993-95 On Left Front Corner Of Engine Compartment 1996 5.8L (49 State, Over 8600 GVW) & 7.5L (Except Calif.) On Left Front Corner Of Engine Compartment All Others Under Left Side Of Dash 1997-98 Diesel Under Left Side Of Dash All Others Left Front Corner Of Engine Compartment Villager (1993) On Left Side Of Engine Compartment, Below Coolant Reservoir NOTE: This table provides a quick reference for self-diagnostic connector locations, when available from manufacturer, that ARE NOT located at the lower left side of the dash, as mandated in 1996 by the Federal government. Application Connector Location Astro & Safari Van (1986-87) Under Left Corner Of Cowl "S" & "T" Series Blazer, Bravada, Envoy, Jimmy, Pickup & Sonoma 1982-85 1.9L Under Left Side Of Dash, Behind ECM 2.0L & 2.8L Under Ashtray 2.5L Under Left Side Of Dash 1986-87 Under Ashtray Van ("G" Series) (1982-87) Under Driver's Seat NOTE: This table provides a quick reference for self-diagnostic connector locations, when available from manufacturer, that ARE NOT located at the lower left side 2007 Lexus SC 430 GENERAL INFORMATION Diagnostic Connector (DLC) Locations
