DESCRIPTION AND OPERATION Certification Label  The English certification label is attached to the door latch edge on the driver side door. The French certification label is attached to the door latch edge on the passenger side door.  The label contains the name of the manufacturer, the month and year of manufacture, the certification statement, and the vehicle identification number (VIN).  The label also contains gross vehicle weight ratings, wheel and tire data, and information codes for additional vehicle data. Certification Label Certification Label Codes Section 00-01: Identification Codes 1997 Aerostar, Ranger Workshop Manual Page 1 of 3 1997 Aerostar/Ranger 2011-04-27 file://C:\TSO\tsocache\VDTOM_3244\SVK~us~en~file=SVK01002.HTM~gen~ref.HTM

Item Part Number Description 1 — Name of Manufacturer 2 — Date of Manufacturer 3 — Front Gross Vehicle Weight in Pounds (lb.) and Kilograms (kg) 4 — Front Tire Size 5 — Front Rim Size 6 — Front Tire Pressure Cold PSI, kpa 7 — Gross Vehicle Rating in Pounds (lb.) and Kilograms 8 — Rear Gross Vehicle in Pounds (lb.) and Kilograms (kg) 9 — Rear Tire Size 10 — Rear Rim Size 11 — Rear Tire Pressure Cold PSI, kpa 12 — Vehicle Identification Number 13 — Vehicle Type 14 — Exterior Paint Code 15 — Wheelbase in Inches 16 — Brake System Code 17 — Interior Trim Type and Color Code 18 — Tape and Paint Stripe Code 19 — Radio and Sound System Code 20 — Axle Codes 21 — Transmission Code Page 2 of 3 1997 Aerostar/Ranger 2011-04-27 file://C:\TSO\tsocache\VDTOM_3244\SVK~us~en~file=SVK01002.HTM~gen~ref.HTM

22 — Suspension Spring Identification Code 23 — Sales Region Code 24 — Special Order Code 25 — Front Axle Accessory Reserve Capacity in Pounds 26 — Total Accessory Reserve Capacity in Pounds Page 3 of 3 1997 Aerostar/Ranger 2011-04-27 file://C:\TSO\tsocache\VDTOM_3244\SVK~us~en~file=SVK01002.HTM~gen~ref.HTM
