DAEWOO M-150 BL2
SECTION 2A
SUSPENSION DIAGNOSIS
TABLE OF CONTENTS
Diagnostic Information and Procedures 2A-1 . . . . .
General Diagnosis 2A-1 . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Bearing Diagnosis 2A-6 . . . . . . . . . . . . . . . . . . .
DIAGNOSTIC INFORMATION AND PROCEDURES
GENERAL DIAGNOSIS
Problems in the steering, the suspension, the tires, and
the wheels involve several systems. Consider all sys-
tems when you diagnose a complaint. Some problems,
such as abnormal or excessive tire wear and scuffed
tires, may be the result of hard driving. Always road test
the vehicle first. If possible, do this road test with the
customer.
Proceed with the following preliminary checks. Correct
any substandard conditions.
Application Checks Correction
Preliminary Checks D Inspect the tires for improper pressure
and uneven wear.
D Inflate the tires to the proper pressure.
D Inspect the joint from the steering
column to the intermediate shaft for
loose connections or wear.
D Inspect the joint from the intermediate
shaft to the steering gear for loose
connections or wear.
D Tighten the coupling flange pinch
bolts.
D Replace the intermediate shaft as
needed.
D Inspect the front and the rear
suspension, the steering gear, and the
linkage for loose or damaged parts.
D Tighten the front and the rear
suspension.
D Tighten the steering gear mounting
bracket bolts.
D Replace the front and the rear
suspension as needed.
D Replace the steering gear as needed.
D Replace the coupling flange as
needed.
D Inspect for out–of–round tires. D Perform free runout test.
D Match–mount the tires.
D Inspect for out–of–balance tires, bent
wheels, and worn or loose wheel
bearings.
D Balance the wheels.
D Replace the wheels.
D Replace the wheel bearings.
D Check the power steering pump drive
belt tension.
D Tighten the power steering pump drive
belt.
D Inspect the power steering system.
Also, check the power steering fluid
level.
D Repair any leaks.
D Perform a power steering gear test.
D Add power steering fluid.
2A–2 SUSPENSION DIAGNOSIS
DAEWOO M-150 BL2
Condition Probable Cause Correction
Car Lead/Pull D Mismatched or uneven tires. D Replace the tires.
D A broken or a sagging coil spring. D Replace the coil spring.
D A improperly radial tire lateral force. D Check the wheel alignment.
D Switch the tire and wheel assemblies.
D Replace the tires as needed.
D The front–wheel alignment is
out–of–align.
D Align the front wheels.
D Off–center steering gear. D Reseat the pinion valve assembly.
D Replace the pinion valve assembly as
needed.
D Front–brake dragging. D Adjust the front brakes.
Abnormal or Excessive
Tire Wear
D The front–wheel and rear–wheel
alignment is out–of–align.
D Align the front and the rear wheels.
D Excessive toe. D Adjust the toe.
D A broken or a sagging coil spring. D Replace the coil spring.
D Out–of–balance tires. D Balance the tires.
D Worn strut dampeners. D Replace the strut dampeners.
D A failure to rotate tires. D Rotate the tires.
D Replace the tires as needed.
D Overloaded vehicle. D Maintain the proper load weight.
D Low tire inflation. D Inflate the tires to the proper pressure.
Scuffed Tires D Incorrect toe. D Adjust the toe.
D A twisted or a bent suspension arm. D Replace the suspension arm.
Wheel Tramp D An out–of–balance tire or wheel. D Balance the tire or the wheel.
D Improper strut dampener action. D Replace the strut dampeners.
Shimmy, Shake, or D An out–of–balance tire or wheel. D Balance the tire or the wheel.
Vibration
D Excessive wheel hub runout. D Measure the hub flange runout.
D Replace the hub as needed.
D Excessive brake drum or brake rotor
imbalance.
D Adjust the brakes.
D Replace the brake rotor or the brake
drum as needed.
D Worn tie rod ends. D Replace the tie rod ends.
D Wheel trim imbalance. D Balance the wheel.
D A worn ball joint. D Replace the control arm and ball joint
assembly.
D Excessive wheel runout. D Measure the wheel runout.
D Replace the wheel as needed.
D Excessive loaded radial runout on the
tire and wheel assembly.
D Match–mount the tire and wheel
assembly.
SUSPENSION DIAGNOSIS 2A–3
DAEWOO M-150 BL2
Condition Probable Cause Correction
Hard Steering (Manual) D A lack of lubrication of the ball joints,
the tie rods and the steering gear.
D Lubricate the ball joints, the tie rods,
and the steering gear.
D Replace the control arm and ball joint
assembly, the tie rods, and the
steering gear as needed.
D The front–wheel alignment is
out–of–align.
D Align the front wheels.
D Steering gear adjustment is
out–of–adjustment.
D Adjust the steering gear.
Hard Steering (Power) D The steering preload adjustment is
out–of–adjustment.
D Perform a rack bearing preload
on–vehicle adjustment.
D The leaked hydraulic system. D Test the power steering system
pressure with a gauge.
D Replace the seals and the hoses as
needed.
D A loose steering gear mounting. D Tighten the steering gear mounting
bracket bolts.
Too Much Play in
Steering.
D Worn or loose wheel bearings. D Tighten the drive axle nut.
D Replace the wheel bearing as needed.
D A loose steering gear mounting. D Tighten the steering gear mounting
bracket bolts.
D The steering preload adjustment is
out–of–adjustment.
D Perform a rack bearing preload
on–vehicle adjustment.
D Loose connections or wear of the joint
from the steering column to the
intermediate shaft.
D Loose connections or wear of the joint
from the intermediate shaft to the
steering gear.
D Tighten the coupling pinch bolts.
D Replace the intermediate shaft as
needed.
Poor Returnability D Binding in the ball joints. D Replace the control arm and ball joint
assembly.
D Binding in the steering column. D Lubricate the steering column.
D Replace the steering column as
needed.
D The front–wheel alignment is
out–of–align.
D Align the front wheels.
D The steering preload adjustment is
out–of–adjustment.
D Perform a rack bearing preload
on–vehicle adjustment.
D A sticking valve. D Lubricate the pinion valve assembly.
D Replace the pinion valve assembly as
needed.
D Binding in the coupling on the
intermediate shaft.
D Replace the intermediate shaft.
Abnormal Noise, Front
Suspension
D Damaged suspension components. D Replace the damaged suspension
components.
D Worn control arm bushings or tie rod
ends.
D Replace the control arm bushings or
the tie rods.
2A–4 SUSPENSION DIAGNOSIS
DAEWOO M-150 BL2
Condition Probable Cause Correction
Abnormal Noise, Front D A loose stabilizer shaft link. D Tighten the stabilizer shaft link.
Suspension
D Loose wheel nuts. D Tighten the wheel nuts.
D Loose suspension bolts or nuts. D Tighten the suspension bolts or the
nuts.
D Loose wheel covers. D Tighten the wheel covers.
D Worn strut dampeners or strut
mountings.
D Replace the strut dampeners.
D Tighten the strut mounting nuts.
D An improperly positioned strut spring. D Adjust the strut spring to the proper
position.
Wander or Poor D Mismatched or uneven tires. D Replace the tires.
Steering Ability
D Worn strut dampeners. D Replace the strut dampeners.
D A loose stabilizer shaft link. D Tighten the stabilizer shaft link.
D A broken or a sagging coil spring. D Replace the coil spring.
D The steering preload adjustment is
out–of–adjustment.
D Perform a rack bearing preload
on–vehicle adjustment.
D The front–wheel and the rear–wheel
alignment are out–of–align.
D Align the front and the rear end
wheels.
Erratic Steering when D Worn or loose wheel bearings. D Replace the wheel bearings.
Braking
D A broken or a sagging coil spring. D Replace the coil spring.
D A leaking caliper. D Replace the caliper.
D Warped rotors. D Replace the rotors.
D An incorrect or an uneven caster. D If the caster is beyond specifications,
check the frame and repair it as
needed.
Low or Uneven Trim D A broken or a sagging coil spring. D Replace the coil spring.
Height
D An overloaded vehicle. D Maintain the proper load weight.
D An incorrect or weak coil spring. D Replace the coil spring.
Ride Too Soft D Worn strut dampeners. D Replace the strut dampeners.
D A broken or a sagging coil spring. D Replace the coil spring.
Ride Too Harsh D Incorrect strut dampeners. D Replace the strut dampeners.
D An incorrect coil spring. D Replace the coil spring.
Body Leans or Sways D A loose stabilizer shaft link. D Tighten the stabilizer shaft link.
in Corners
D Worn strut dampeners or strut
mountings.
D Replace the strut dampeners.
D Tighten the strut assembly mounting
nuts.
D an overloaded vehicle. D Maintain the proper load weight.
D A broken or a sagging coil spring. D Replace the coil spring.
Suspension Bottoms D Worn strut dampeners. D Replace the strut dampeners.
D An overloaded vehicle. D Maintain the proper load weight.
D A broken or a sagging coil spring. D Replace the coil spring.
SUSPENSION DIAGNOSIS 2A–5
DAEWOO M-150 BL2
Condition Probable Cause Correction
Steering Wheel D Air in the power steering system. D Bleed the power steering system.
Kickback (Power)
D A loose steering gear mounting. D Tighten the steering gear mounting
bracket bolts.
D Loose connections or wear of the joint
from the steering column to the
intermediate shaft.
D Loose connections or wear of the joint
from the intermediate shaft to the
steering gear.
D Tighten the coupling pinch bolts.
D Replace the intermediate shaft as
needed.
D Loose tie rod ends. D Tighten the tie rod ends.
D Replace the tie rods as needed.
D Loose or worn wheel bearings. D Tighten the drive axle nut.
D Replace the wheel bearing as needed.
Steering Wheel Surges
or Jerks (Power)
D Low pressure in the power steering
system.
D Replace the seals and the hoses as
needed.
D A sluggish steering gear valve. D Clean the pinion valve assembly.
D Replace the pinion valve assembly as
needed.
D A loose power steering pump drive
belt.
D Adjust the power steering pump drive
belt.
Cupped Tires D The front–wheel and the rear–wheel
alignment are out–of–align.
D Align the front and the rear wheels.
D Worn strut dampeners. D Replace the strut dampeners.
D Worn or loose wheel bearing. D Tighten the drive axle nut.
D Replace the wheel bearings as
needed.
D Excessive tire or wheel runout. D Match–mount the tires.
D Replace the tires as needed.
D Replace the wheels as needed.
D A worn ball joints. D Replace the control arm and ball joint
assembly.
D The steering gear preload adjustment
is out–of–adjustment.
D Perform a rack bearing preload
on–vehicle adjustment.
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Offline Viewing
Access Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$31.99
$41.99
Viewed 18 Times Today
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Offline Viewing
Access Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$31.99
$41.99
The Chevrolet Spark 2000-2005 Factory Service Repair Manual is a comprehensive guide that provides detailed information and instructions for maintaining and repairing your Chevrolet Spark. Whether you are a professional mechanic or a DIY enthusiast, this manual is a valuable resource for ensuring the optimal performance and longevity of your vehicle.
Featuring a user-friendly format, this manual covers all aspects of the Chevrolet Spark from 2000 to 2005, including engine specifications, electrical system, transmission, suspension, brakes, and more. It includes step-by-step procedures, illustrations, diagrams, and explanations to help you successfully diagnose and fix any issues that may arise.
Designed specifically for the Chevrolet Spark models produced between 2000 and 2005, this factory service repair manual is an essential tool for anyone who wants to save time and money by performing their own maintenance and repairs. It provides you with the knowledge and confidence to tackle a wide range of tasks, from simple oil changes to complex engine overhauls.
With the Chevrolet Spark 2000-2005 Factory Service Repair Manual, you can trust that you are accessing accurate and reliable information directly from the manufacturer. Invest in this manual today and empower yourself with the expertise needed to keep your Chevrolet Spark running smoothly for years to come.
- Models Covered:
- - Chevrolet Spark 2000
- - Chevrolet Spark 2001
- - Chevrolet Spark 2002
- - Chevrolet Spark 2003
- - Chevrolet Spark 2004
- - Chevrolet Spark 2005
