SHARP CORPORATION
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
q
PARTS GUIDE
本書はサービス活動用に作成した資料です｡
一部内容が製品の改良・改善等により予告
なしに変わることがあります。
CODE:00ZARM205/P2/
デジタル複合機
DIGITAL COPIER
CONTENTS
1 MCU PWB
2 CCD PWB
3 COPY OPE PWB
4 I/F PWB
5 SCAN OPE PWB
6 TRAY PWB
7 SPF/RSPF INTERFACE PWB(Option AR-SP6/RP6)
8 SPF SENSOR PWB(Option AR-SP6/RP6)
9 CASETTE PWB(Option AR-D24/D25)
F IMC2 PWB(Option AR-EB7)
■ 索引 (Index)
AR-200M
AR-160M
AR-M205
AR-M160
AR-5220
AR-SP6/RP6
AR-D24/D25
AR-EB7
[Japan only]
[Japan only]
[Except Japan]
[Except Japan]
[Except Japan]
[Option]
[Option]
[Option]
MODEL
– 1 –
補修部品のランク付
市場における補修部品の在庫管理が、適正に運営出来る手助けとなることを、目的とします。
A ランク : メンテナンスパーツ、メンテナンスパーツには入っていないがメンテナンスパーツに近い消耗パーツ。
B ランク : 性能・機能パーツ（センサー、クラッチ等の電気パーツ）、消耗パーツ。
E ランク : 基板含むユニットパーツ。
D ランク : 整備パーツ（外装、パッキング、同梱パーツ）。
C ランク : 上記ランク以外のパーツ（基板の子部品を除いたもの）。
DEFINITION
Rank A : Maintenance parts, and consumable parts which are not included in but closely related to maintenance parts
Rank B : Performance/function parts (sensors, clutches, and other electrical parts), consumable parts
Rank E : Unit parts including PWB
Rank D : Preparation parts (External fitting, packing, parts packed together)
Rank C : Parts other than the above (excluding sub components of PWB)
安全性・信頼性確保のため部品は、必ず正規のものをご使用下さい。
! 印の商品は、安全上重要な部品です。交換をする時は、安全及び性能維持のため必ず指定の部品をご使用下さい。
Because parts marked with "!" is indispensable for the machine safety maintenance and operation, it must be replaced with
the parts specific to the product specification.
F 当モデルのサービス資料には、この資料以外にサービスマニュアル ( 回路図含む ) があります。合わせてご利用下さい。
F Other than this Parts Guide, please refer to documents Service Manual(including Circuit Diagram)of this model.
F Please use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
F For U.S. only-Use order codes provided in advertising literature. Do not order from parts department.
1
MCU PWB
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
2 VHI29L0800BQS BD GJ B Frash ROM [AR-M205/AR-5220][IC10] Frash ROM
3 VHI29L0800CQS BD GJ B Frash ROM [AR-200M][IC10] Frash ROM
4 QCNCM0017QSZZ AC DJ C Connector(4pin) [AR-M160/AR-M205/AR-5220][CN29] ｺﾈｸﾀｰ
8 QCNCM0877FCZZ AF DS C Connector(20pin) [CN36] ｺﾈｸﾀｰ
9 QCNCM0923FC12 AE DJ C Connector(12pin) [CN2] ｺﾈｸﾀｰ
10 QCNCM1005MCZZ AB DD C Connector(2pin) [CN30] ｺﾈｸﾀｰ
11 QCNCM1006MCZZ AB DD C Connector(3pin) [CN28] ｺﾈｸﾀｰ
12 QCNCM2334SC0B AB DD C Connector(2pin) [CN22] ｺﾈｸﾀｰ
13 QCNCM2401SC0C AB DJ C Connector(3pin) [CN10,CN20] ｺﾈｸﾀｰ
14 QCNCM2401SC0D AC DJ C Connector(4pin) [CN32] ｺﾈｸﾀｰ
15 QCNCM7014SC0C AA DD C Connector(3pin) [CN14,CN25] ｺﾈｸﾀｰ
16 QCNCM7014SC0D AB DD C Connector(4pin) [CN12,CN17,CN27] ｺﾈｸﾀｰ
17 QCNCM7014SC0E AB DJ C Connector(5pin) [AR-M205 only][CN13] ｺﾈｸﾀｰ
18 QCNCM7014SC0F AB DD C Connector(6pin) [CN19] ｺﾈｸﾀｰ
19 QCNCM7014SC1C AC DD C Connector(13pin) [CN35] ｺﾈｸﾀｰ
21 QCNCW0024QSZZ AF DS C Connector(32pin) [CN5] ｺﾈｸﾀｰ
22 QCNCW0077QSZZ AK DX C Connector(25pin) [CN9] ｺﾈｸﾀｰ
23 QCNCW0078QSZZ AF DS C Connector(35Pin) [CN4] ｺﾈｸﾀｰ
26 QCNCW0885FCZZ AG DX C Connector(12Pin) [CN37] ｺﾈｸﾀｰ
27 QCNCW1124LC0D AB DJ C Connector(4pin) [CN8] ｺﾈｸﾀｰ
28 QCNCW1124LC0H AC DJ C Connector(8pin) [CN24] ｺﾈｸﾀｰ
29 QCNCW1124LC1C AC DJ C Connector(13pin) [CN26] ｺﾈｸﾀｰ
31 QSOCZ0002QSZZ AD DJ C IC socket(CICO-083-S8-T) [IC3] IC ｿｹｯﾄ
32 RCRSP0016QSZZ AD DJ B Crystal(19.6608MHz) [X1] ｸﾘｽﾀﾙ
35 RFILZ0004QSZZ AM EG C Filter(ZJSR5101-223) [L1,L2,L3,L5,L6,L7] ﾌｨﾙﾀ -
36 RH-DZ0016FCZZ AB DD B Diode(MA700) [D2] ﾀﾞｲｵｰﾄﾞ
37 RH-IX0001QSZZ BD GN B
SDRAM(MT48LC8M16ATG-8E) SDRAM
[AR-M160/AR-5220/AR-200M/AR-160M][IC9]
39 RH-IX7001XCZZ AQ EQ B SRAM(IS63LV1024L-12J-TR) [IC8,IC11] SRAM
40
RMPTW4100QCJJ AA DD B Block resistor(10Ω×4) [BR16,BR18,BR19,BR20,BR22] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTW4100QCJJ AA DD B Block resistor(10Ω×4) [BR25,BR26,BR28,BR46,BR50] ﾌﾞﾛｯｸﾃｲｺｳ
41 RMPTW4101QCJJ AB DD B Block resistor(100Ω×4) [BR7,BR38,BR57,BR58,BR63] ﾌﾞﾛｯｸﾃｲｺｳ
42
RMPTW4103QCJJ AB DD B Block resistor(10KΩ×4) [BR1,BR2,BR3,BR4,BR5] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTW4103QCJJ AB DD B Block resistor(10KΩ×4) [BR6,BR8,BR9,BR10,BR11] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTW4103QCJJ AB DD B Block resistor(10KΩ×4) [BR12,BR13,BR14,BR15,BR17] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTW4103QCJJ AB DD B Block resistor(10KΩ×4) [BR21,BR23,BR24,BR27,BR32] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTW4103QCJJ AB DD B Block resistor(10KΩ×4) [BR34,BR36,BR37,BR39,BR40] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTW4103QCJJ AB DD B Block resistor(10KΩ×4) [BR41,BR42,BR43,BR44,BR45] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTW4103QCJJ AB DD B Block resistor(10KΩ×4) [BR51,BR52,BR59,BR60,BR61] ﾌﾞﾛｯｸﾃｲｺｳ
43 RMPTW4221QCJJ AA DD B Block resistor(220Ω×4) [BR53,BR54,BR55,BR56] ﾌﾞﾛｯｸﾃｲｺｳ
44 RMPTW4330QCJJ AB DD B Block resistor(33Ω×4) [BR29,BR30,BR31,BR33,BR35] ﾌﾞﾛｯｸﾃｲｺｳ
45
VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C4,C5,C25,C28,C96] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C97,C98,C104,C105,C106] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C107,C108,C109,C112,C113] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C114,C115,C116,C117,C118] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C250,C73,C225,C288,C289] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C290,C291,C292,C293,C294] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C285,C286,C287,C17,C20] ｺﾝﾃﾞﾝｻｰ
– 2 –
1 MCU PWB
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
45 VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C21,C22] ｺﾝﾃﾞﾝｻｰ
46
VCCCCZ1HH120J AA DD C Capacitor(50WV 12pF) [C6,C29,C30,C42,C43] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH120J AA DD C Capacitor(50WV 12pF) [C44,C55,C56,C72,C78] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH120J AA DD C Capacitor(50WV 12pF) [C79,C81,C84,C93,C94] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH120J AA DD C Capacitor(50WV 12pF) [C283,C284] ｺﾝﾃﾞﾝｻｰ
47 VCCCCZ1HH150J AA DD C Capacitor(50WV 15pF) [C74,C75] ｺﾝﾃﾞﾝｻｰ
48 VCCCCZ1HH220J AA DD C Capacitor(50WV 22pF) [C1,C3] ｺﾝﾃﾞﾝｻ
49
VCCCCZ1HH330J AA DD C Capacitor(50WV 33pF) [C100,C102,C120,C265,C316] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH330J AA DD C Capacitor(50WV 33pF) [C317,C318,C319,C320,C321] ｺﾝﾃﾞﾝｻｰ
50 VCEAGA1CW106M AA DD C Capacitor(16WV 10µF) [C9,C151] ｺﾝﾃﾞﾝｻｰ
51 VCEAGA1CW226M AB DD C Capacitor(16WV 22µF) [C80,C221,C222] ｺﾝﾃﾞﾝｻｰ
52 VCEAGA1CW476M AB DD C Capacitor(16WV 47µF) [C41] ｺﾝﾃﾞﾝｻ -
53 VCEAGA1VW106M AA DD C Capacitor(35WV 10µF) [C154] ｺﾝﾃﾞﾝｻｰ
54 VCEAGA1VW476M AB DD C Capacitor(35WV 47µF) [C142,C200,C206,C240] ｺﾝﾃﾞﾝｻｰ
55
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C2,C8,C11,C12,C13] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C14,C15,C23,C26,C27] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C31,C32,C34,C36,C38] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C39,C46,C49,C50,C52] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C53,C54,C58,C59,C60] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C62,C63,C65,C67,C71] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C76,C77,C83,C85,C86] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C87,C88,C89,C90,C91] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C92,C95,C99,C101,C103] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C111,C119,C121,C122,C123] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C124,C125,C126,C129,C131] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C132,C133,C134,C135,C138] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C139,C140,C141,C143,C144] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C145,C146,C152,C153,C155] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C160,C161,C162,C163,C164] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C165,C166,C167,C168,C169] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C170,C171,C172,C173,C174] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C175,C176,C177,C178,C179] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C180,C181,C182,C183,C184] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C185,C186,C187,C188,C189] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C190,C191,C192,C193,C194] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C195,C196,C201,C223,C224] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C231,C232,C233,C234,C241] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C245,C246,C247,C248,C261] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C262,C266,C281,C282,C315] ｺﾝﾃﾞﾝｻｰ
56 VCKYCY1HB102K AA DD C Capacitor(50WV 1000pF) [C267,C268] ｺﾝﾃﾞﾝｻｰ
57 VCKYCY1HB104K AA DD C Capacitor(50WV 0.10µF) [C127,C130,C207,C244] ｺﾝﾃﾞﾝｻｰ
58 VCKYCY1HB222K AA DD C Capacitor(50WV 2200pF) [C269,C270] ｺﾝﾃﾞﾝｻｰ
59 VCKYCY1HB473K AA DD C Capacitor(50WV 0.047µF) [C229] ｺﾝﾃﾞﾝｻｰ
60 VCKYCZ1CB223K AB DD C Capacitor(16WV 0.022µF) [C70,C128,C136] ｺﾝﾃﾞﾝｻｰ
62
VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C24,C197,C198,C199,C202] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C203,C204,C205,C208,C209] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C210,C211,C212,C213,C214] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C215,C216,C217,C218,C219] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C220,C227,C249,C258,C259] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C260,C263,C264,C311,C312] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1HB102K AA DD C Capacitor(50WV 1000pF) [C313,C314] ｺﾝﾃﾞﾝｻｰ
63 VCKYCZ1HB271K AA DD C Capacitor(50WV 270pF) [C272] ｺﾝﾃﾞﾝｻｰ
64
VCKYCZ1HB471K AA DD C Capacitor(50WV 470pF) [C303,C304,C305,C306,C307] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1HB471K AA DD C Capacitor(50WV 470pF) [C308,C309,C310] ｺﾝﾃﾞﾝｻｰ
65 VCKYCZ1HB821K AC DD C Capacitor(50WV 820pF) [C147,C148,C149,C150] ｺﾝﾃﾞﾝｻｰ
66 VHD1SS355//-1 AB DJ B Diode(1SS355) [D1,D14,D15,D16,D20] ﾀﾞｲｵｰﾄﾞ
67 VHDDSS133//-1 AA DD B Diode(1SS133) [D36,D37,D38] ﾀﾞｲｵｰﾄﾞ
68
VHDKDS120++-1 AC DJ B diode(KDS120) [D6,D19,D23,D28] ﾀﾞｲｵｰﾄﾞ
VHDKDS120++-1 AC DJ B diode(KDS120) [D29,D32,D34] ﾀﾞｲｵｰﾄﾞ
69
VHDKDS121++-1 AC DJ B Diode(KDS121) [D3,D4,D18,D22,D26] ﾀﾞｲｵｰﾄﾞ
VHDKDS121++-1 AC DJ B Diode(KDS121) [D27,D31,D33] ﾀﾞｲｵｰﾄﾞ
70
VHDKDS226++-1 AC DJ B Diode(KDS226) [D5,D13,D17,D21,D24] ﾀﾞｲｵｰﾄﾞ
VHDKDS226++-1 AC DJ B Diode(KDS226) [D25,D30,D35] ﾀﾞｲｵｰﾄﾞ
71 VHEMTZJ22B/-1 AA DD B Zener diode(MTZJ22B) [AR-M205 only][D11] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
72 VHEUDZ3.9B/-1 AC DJ B Zener diode(UDZ3.9B) [ZD1,ZD2,ZD3,ZD4] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
73 VHEUDZ5.6B/-1 AC DJ B Zener diode(UDZ5.6B) [ZD5] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
74 VHI74HC151M-1 AD DJ B IC(74HC151M) [IC13,IC15,IC17,IC38] IC
76 VHI74LCX32M-1 AE DJ B IC(74LCX32M) [IC29] IC
77 VHID65001AF-1 AG DS B IC(D65001AF) [IC21,IC24,IC25] IC
78 VHID65503F+-1 AG DS B IC(D65503F) [IC22,IC26] IC
79 VHIEES04L400P AG DX B IC(EES04L400P) [IC3] IC
80 VHIH8S2321+-1 AX FG B IC(HD6412321VF25) [IC2] IC
82 VHIKA7805AP-1 AE DS B IC(KIA7805API) [IC35] IC
84 VHIKIA358F+-1 AE DS B IC(KIA358F) [IC27] IC
85 VHIKIA393F+-1 AE DS B IC(KIA393F) [IC23] IC
86 VHIL6219DS+-1 AN EQ B IC(L6219DS) [IC32] IC
87 VHILCX16244-1 AM EG B IC(LCX16244) [IC19] IC
88 VHILCX16374-1 AM EG B IC(74LCX16374MEA) [IC30,IC28] IC
89 VHILCX244WM-1 AG DX B IC(74LCX244WM) [IC20] IC
91 VHILVX4245M-1 AL EB B IC(74LVX4245MT) [AR-M160/AR-M205/AR-5220][IC31] IC
– 3 –
1 MCU PWB
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
92 VHIM51957BFP1 AH DX B IC(M51957BFP1) [IC4] IC
93 VHIP2010ASR-1 AN EQ B IC(P2010ASR) [IC1] IC
94 VHITA7291AS-1 AF DX B IC(TA7291S) [IC34] IC
95 VHITD62064AF/ AM EG B IC(TD62064AF) [AR-M205 only][IC33] IC
96 VHIVHCT244M-1 AG DX B IC(VHCT244M) [IC12,IC14,IC16,IC18,IC37] IC
97 VRD-HT2EY472J AA DD C Resistor(1/4W 4.7KΩ ±5%) [R84,R102,R103] ﾃｲｺｳ
98 VRN-VT3ATR68J AC DD C Resistor(1W 0.68Ω ±5%) [R119,R120] ﾃｲｺｳ
99
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R2,R5,R6,R11,R12,R13] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R14,R15,R16,R17,R49,R50] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R54,R56,R59,R63,R64,R213] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R226,R233,R212,R227] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [AR-M205 only][R62] ﾃｲｺｳ
100
VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R37,R38,R51,R66,R70] ﾃｲｺｳ
VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R71,R149,R150,R151,R152] ﾃｲｺｳ
VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R225,R195] ﾃｲｺｳ
101 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R110,R232,R235] ﾃｲｺｳ
102 VRS-CZ1JD102F AA DD C Resistor(1/16W 1KΩ ±1%) [R86,R123] ﾃｲｺｳ
103
VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R89,R116,R145,R146,R147] ﾃｲｺｳ
VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R166,R167,R168,R169,R170] ﾃｲｺｳ
VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R171,R172,R173,R174,R175] ﾃｲｺｳ
VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R176,R177,R178,R182,R217] ﾃｲｺｳ
VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R218,R219,R223,R222,R181] ﾃｲｺｳ
VRS-CZ1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R179] ﾃｲｺｳ
104 VRS-CZ1JD103F AA DD C Resistor(1/16W 10KΩ ±1%) [R18,R21,R97,R115] ﾃｲｺｳ
105
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R8,R9,R19,R22,R24] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R30,R32,R34,R35,R36] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R42,R46,R47,R53,R58] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R61,R67,R68,R69,R72] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R74,R76,R114,R118,R142] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R143,R144,R183,R184,R185] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R202,R203,R204,R234,R236] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R180,R197] ﾃｲｺｳ
106 VRS-CZ1JD105F AA DD C Resistor(1/16W 1.0MΩ ±1%) [R87] ﾃｲｺｳ
107 VRS-CZ1JD122F AA DD C Resistor(1/16W 1.2KΩ ±1%) [R113] ﾃｲｺｳ
108 VRS-CZ1JD133F AA DD C Resistor(1/16W 13KΩ ±1%) [R126] ﾃｲｺｳ
109
VRS-CZ1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R77,R78,R80,R81,R82] ﾃｲｺｳ
VRS-CZ1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R83,R85,R90,R91,R92] ﾃｲｺｳ
VRS-CZ1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R95,R96,R99,R100,R104] ﾃｲｺｳ
VRS-CZ1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R105,R106,R107,R108,R111] ﾃｲｺｳ
VRS-CZ1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R112,R121,R122] ﾃｲｺｳ
110
VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R137,R138,R153,R154,R155] ﾃｲｺｳ
VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R156,R157,R158,R159,R160] ﾃｲｺｳ
VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R161,R162,R163,R164,R165] ﾃｲｺｳ
VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R193,R200,R214,R215,R216] ﾃｲｺｳ
VRS-CZ1JD203J AA DD C Resistor(1/16W 20KΩ ±5%) [R220,R221] ﾃｲｺｳ
111 VRS-CZ1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R7] ﾃｲｺｳ
112 VRS-CZ1JD241J AA DD C Resistor(1/16W 240KΩ ±5%) [R94,R93] ﾃｲｺｳ
114 VRS-CZ1JD272J AA DD C Resistor(1/16W 2.7KΩ ±5%) [R139] ﾃｲｺｳ
115 VRS-CZ1JD301J AA DD C Resistor(1/16W 300Ω ±5%) [R109,R117,R198,R199] ﾃｲｺｳ
116 VRS-CZ1JD302F AA DD C Resistor(1/16W 3KΩ ±1%) [R127] ﾃｲｺｳ
117 VRS-CZ1JD303J AA DD C Resistor(1/16W 30KΩ ±5%) [R124,R125] ﾃｲｺｳ
118
VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R25,R26,R27,R28,R29] ﾃｲｺｳ
VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R31,R33,R40,R48,R39] ﾃｲｺｳ
119 VRS-CZ1JD470J AA DD C Resistor(1/16W 47Ω ±5%) [R20,R23] ﾃｲｺｳ
120
VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R186,R188,R189,R190,R191] ﾃｲｺｳ
VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R192,R205,R206,R207,R208] ﾃｲｺｳ
VRS-CZ1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R209,R210] ﾃｲｺｳ
121 VRS-CZ1JD473J AA DD C Resistor(1/16W 47KΩ ±5%) [R79,R101,R132,R133] ﾃｲｺｳ
122 VRS-CZ1JD752F AA DD C Resistor(1/16W 7.5KΩ ±1%) [R88] ﾃｲｺｳ
124 VRS-HT3DA102J AA DD C Resistor(2W 1.0KΩ ±5%) [R141] ﾃｲｺｳ
126 VRS-HT3DAR22J AA DD C Resistor(2W 0.22Ω ±5%) [R140] ﾃｲｺｳ
127 VS2SB1197//-1 AC DJ B Transistor(2SB1197) [Q3] ﾄﾗﾝｼﾞｽﾀｰ
128 VSKRA119S++-1 AB DJ B Transistor(KRA119S) [Q2] ﾄﾗﾝｼﾞｽﾀｰ
129 VSKTA1505S+-1 AC DJ B Transistor(KTA1505S) [Q1] ﾄﾗﾝｼﾞｽﾀｰ
130 VSUPA502T//-1 AD DJ B Transistor(UPA502T) [Q4] ﾄﾗﾝｼﾞｽﾀｰ
(Unit)
901
CPWBX0128QS31 CA TR E MCU PWB [AR-M160] MCU 基板
CPWBX0128QS32 CA TV E MCU PWB [AR-M205] MCU 基板
CPWBX0128QS33 CA TR E MCU PWB [AR-5220] MCU 基板
CPWBX0128QS34 CA TV E MCU PWB [AR-200M] MCU 基板
CPWBX0128QS36 CA TV E MCU PWB [AR-160M] MCU 基板
– 4 –
2
CCD PWB
3
COPE OPE PWB
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 QCNCW0024QSZZ AF DS C Connector(32pin) [CN1] ｺﾈｸﾀｰ
2 RFILZ0004QSZZ AM EG C Filter(ZJSR5101-223) [L1,L2,L3,L4] ﾌｨﾙﾀ -
3 RMPTW4100QCJJ AA DD B Block resistor(10Ω×4) [BR101,BR102] ﾌﾞﾛｯｸﾃｲｺｳ
4 VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C107,C108,C109] ｺﾝﾃﾞﾝｻｰ
6
VCCCCZ1HH470J AA DD C Capacitor(50WV 47pF) [C126,C128,C122,C124] ｺﾝﾃﾞﾝｻｰ
VCCCCZ1HH470J AA DD C Capacitor(50WV 47pF) [C125,C127,C121,C123] ｺﾝﾃﾞﾝｻｰ
7 VCEAJA1CW226M AB DD C Capacitor(16WV 22µF) [C5,C4,C1,C8,C7,C6,C3] ｺﾝﾃﾞﾝｻｰ
8 VCEAJA1EW226M AB DD C Capacitor(25WV 22µF [C2] ｺﾝﾃﾞﾝｻｰ
9
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C111,C110,C139,C112,C114] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C115,C138,C137,C141,C140] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C129,C116,C132,C145,C130] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C105,C104,C102,C131,C103] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C133,C134,C106,C135,C136] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C144,C143,C118] ｺﾝﾃﾞﾝｻｰ
11 VHI74VHCT04FT AF DS B IC(74VHCT04FT) [IC104] IC
15 VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R138] ﾃｲｺｳ
16
VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R153,R111,R154] ﾃｲｺｳ
VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R112,R155,R113] ﾃｲｺｳ
17 VRS-CZ1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R148,R145,R143,R150,R151] ﾃｲｺｳ
18 VRS-CZ1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R146,R142,R140] ﾃｲｺｳ
19
VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R128,R119,R152,R110,R156] ﾃｲｺｳ
VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R114,R118,R157,R115,R125] ﾃｲｺｳ
VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R109,R122,R134,R133,R132] ﾃｲｺｳ
VRS-CZ1JD330J AA DD C Resistor(1/16W 33Ω ±5%) [R131,R130,R129] ﾃｲｺｳ
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
2 QSW-P0001ESZZ AC DJ B Tact swtch(SKQNAB010) [KEY16∼44] ﾀｸﾄ SW
4 RH-TX0003ESZZ AC DJ B Transistor(KRA225S) [Q2,Q3,Q4] ﾄﾗﾝｼﾞｽﾀｰ
6 VCCCCY1HH201J AA DD C Capacitor(50WV 200pF) [C4,C5,C7,C8] ｺﾝﾃﾞﾝｻｰ
7 VCEAJU1CW476M AB DD C Capacitor(16WV 47µF) [C1,C2] ｺﾝﾃﾞﾝｻｰ
8
VCKYCY1CB104K AB DD C Capacitor(16WV 0.1µF) [C3,C6,C9,C11] ｺﾝﾃﾞﾝｻｰ
VCKYCY1CB104K AB DD C Capacitor(16WV 0.1µF) [C20,C22] ｺﾝﾃﾞﾝｻｰ
9
VHDDSS133//-1 AA DD B Diode(1SS133) [D1,D2,D3,D4] ﾀﾞｲｵｰﾄﾞ
VHDDSS133//-1 AA DD B Diode(1SS133) [D5,D6] ﾀﾞｲｵｰﾄﾞ
10 VHI74HC151M-1 AD DJ B IC(74HC151M) [IC1] IC
11 VHILC7935//-1 AN EQ B IC(LC7935) [IC2] IC
12 VHINE555///-1 AG DX B IC(NE555) [IC3] IC
13
VHP1LHEE-002A AC DJ B LED (Red)(1LHEE-002A) [LED28,LED29,LED30,LED32] LED ｱｶ
VHP1LHEE-002A AC DJ B LED (Red)(1LHEE-002A) [LED33,LED35,LED36,LED41] LED ｱｶ
VHP1LHEE-002A AC DJ B LED (Red)(1LHEE-002A) ()[LED64] LED ｱｶ
14
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[LED16,LED17,LED18,LED19,LED20]
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[LED21,LED22,LED23,LED24,LED25]
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[LED26,LED27,LED31,LED34,LED37]
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[LED38,LED39,LED40,LED42,LED43]
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[LED44,LED45,LED46,LED47,LED48]
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[LED50,LED51,LED52,LED53,LED54]
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[LED56,LED57,LED58,LED59,LED60]
VHP1LHLE-002A AC DJ B LED(Green)(LTL-1LHLE-002A) [LED61,LED62] LED ﾐﾄﾞﾘ
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[Except AR-160M/AR-M160(Other Countries)][LED49,LED55]
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
[Except AR-M205(U.S.A,Canada,U.kingdom,Europe)][LED63]
15 VHP3650AG2J-1 AL EB B LED(7SEGMENT)(LTC-3650AG-02J) [LEDM] LED(7SEGMENT)
16 VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R44] ﾃｲｺｳ
17 VRS-CY1JD101J AA DD C Resistor(1/16W 100Ω ±5%) [R52∼55,R60∼63] ﾃｲｺｳ
18
VRS-CY1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R7,R10,R27,R30,R42] ﾃｲｺｳ
VRS-CY1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R45,R57,R58,R59] ﾃｲｺｳ
19 VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R8,R11,R28,R31,R41] ﾃｲｺｳ
20
VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R1,R2,R3,R5,R6,R9] ﾃｲｺｳ
VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R12,R13,R14,R15,R16] ﾃｲｺｳ
VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R17,R18,R19,R20,R21] ﾃｲｺｳ
VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R22,R23,R24,R25,R26] ﾃｲｺｳ
VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R29,R32,R33,R34,R35] ﾃｲｺｳ
VRS-CY1JD151J AA DD C Resistor(1/16W 150Ω ±5%) [R36,R37,R38,R39,R68] ﾃｲｺｳ
21
VRS-CY1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R48,R49,R50,R51,R64] ﾃｲｺｳ
VRS-CY1JD202J AA DD C Resistor(1/16W 2.0KΩ ±5%) [R65,R66,R67] ﾃｲｺｳ
22 VRS-CY1JD244J AA DD C Resistor(1/16W 240KΩ ±5%) [R40] ﾃｲｺｳ
– 5 –
3 COPE OPE PWB
4
I/F PWB
5
SCAN OPE PWB
6
TRAY PWB
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
23 VRS-CY1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R4,R47] ﾃｲｺｳ
24 VRS-CY1JD511J AA DD C Resistor(1/16W 510Ω ±5%) [R56] ﾃｲｺｳ
25 VSDTC143ZKA-1 AC DJ B Transistor(DTC143ZKA) [Q5] ﾄﾗﾝｼﾞｽﾀｰ
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 DHAI-0310QSZZ AB DJ C IF GND harness IF GND ﾊｰﾈｽ
2 QCNCW0078QSZZ AF DS C Connector(35Pin) [CN403] ｺﾈｸﾀｰ
3 QSOCN0002ESZZ AH DX C Connector(36Pin)(RBE42-36K1153) [CN401] ｺﾈｸﾀｰ
4 QSOCN0005ESZZ AE DS C Connector(4Pin)(UBR23-4K2200) [CN402] ｺﾈｸﾀｰ
5 RH-DX0001ESZZ AC DJ B Diode(11EQS06-TA1B2) [D401] ﾀﾞｲｵﾄﾞ
6 RH-IX0005ESZZ AE DS B IC(IX0005ES) [IC402] IC
7
VCCCCY1HH101J AA DD C Capacitor(50WV 100pF) [C404,C405,C406,C407,C408] ｺﾝﾃﾞﾝｻｰ
VCCCCY1HH101J AA DD C Capacitor(50WV 100pF) [C409,C410,C411,C412,C413] ｺﾝﾃﾞﾝｻｰ
VCCCCY1HH101J AA DD C Capacitor(50WV 100pF) [C414,C415,C417,C418,C419] ｺﾝﾃﾞﾝｻｰ
VCCCCY1HH101J AA DD C Capacitor(50WV 100pF) [C422,C426] ｺﾝﾃﾞﾝｻｰ
8 VCCCCY1HH331J AB DD C Capacitor(50WV 330pF) [C416] ｺﾝﾃﾞﾝｻｰ
9 VCCCCY1HH471J AA DD C Capacitor(50WV 470pF) [C435∼C440] ｺﾝﾃﾞﾝｻ
10 VCEAGA1CW476M AB DD C Capacitor(16WV 47µF) [C401,C402] ｺﾝﾃﾞﾝｻ -
11
VCKYCY1CF104Z AA DD C Capacitor(16WV 0.1µF) [C403,C420,C421,C423,C424] ｺﾝﾃﾞﾝｻｰ
VCKYCY1CF104Z AA DD C Capacitor(16WV 0.1µF) [C425,C427] ｺﾝﾃﾞﾝｻｰ
12 VHEUDZS6.2B-1 AC DJ B Zener diode(UDZS6.2B) [D402] ﾂｪﾅﾀﾞｲｵｰﾄﾞ
13 VHI74LVX16128 AP EQ B IC(74LVX16128) [IC403] IC
14 VHIUSB11AMX-1 AH DX B IC(USB1T11AMX) [IC401] IC
15 VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R432] ﾃｲｺｳ
16
VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R424,R425,R426] ﾃｲｺｳ
VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R427,R428,R429] ﾃｲｺｳ
17 VRS-CY1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R423] ﾃｲｺｳ
18
VRS-CY1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R405,R406,R407,R408,R409] ﾃｲｺｳ
VRS-CY1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R410,R411,R412,R413,R414] ﾃｲｺｳ
VRS-CY1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R415,R416,R417,R418,R419] ﾃｲｺｳ
VRS-CY1JD220J AA DD C Resistor(1/16W 22Ω ±5%) [R421,R422] ﾃｲｺｳ
19 VRS-CY1JD240J AA DD C Resistor(1/16W 24Ω ±5%) [R402,R403,R430] ﾃｲｺｳ
20 VRS-CY1JD332J AA DD C Resistor(1/16W 3.3KΩ ±5%) [R420] ﾃｲｺｳ
(Unit)
901 CPWBF0114QSE3 BA FX E I/F PWB I/F PWB
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
2
QSW-P0001ESZZ AC DJ B Tact swtch(SKQNAB010) [KEY1,KEY2,KEY3,KEY4,KEY5] ﾀｸﾄ SW
QSW-P0001ESZZ AC DJ B Tact swtch(SKQNAB010) [KEY6,KEY7,KEY8,KEY10,KEY11] ﾀｸﾄ SW
QSW-P0001ESZZ AC DJ B Tact swtch(SKQNAB010) [KEY12,KEY13,KEY14,KEY15] ﾀｸﾄ SW
QSW-P0001ESZZ AC DJ B Tact swtch(SKQNAB010) (AR-M205 only)[KEY9] ﾀｸﾄ SW
3
VHP1LHLE-002A AC DJ B LED(Green)(LTL-1LHLE-002A) [LED1,LED2,LED6,LED7,LED8] LED ﾐﾄﾞﾘ
VHP1LHLE-002A AC DJ B LED(Green)(LTL-1LHLE-002A) [LED9,LED10,LED11,LED12] LED ﾐﾄﾞﾘ
VHP1LHLE-002A AC DJ B LED(Green)(LTL-1LHLE-002A) [LED13,LED14,LED15] LED ﾐﾄﾞﾘ
VHP1LHLE-002A AC DJ B
LED(Green)(LTL-1LHLE-002A) LED ﾐﾄﾞﾘ
(AR-M205 only)[LED3,LED4,LED5]
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 QCNCM2401SC0F AB DJ C Connector(6pin) [CN3] ｺﾈｸﾀｰ
2 QCNCM7014SC0C AA DD C Connector(3pin) [CN4,CN5] ｺﾈｸﾀｰ
3 QCNCP0340QCZZ AC DJ C Connector(3pin) [CN2] ｺﾈｸﾀｰ
4 QCNCW1124LC1C AC DJ C Connector(13pin) [CN1] ｺﾈｸﾀｰ
5 VCEAGA1VW476M AB DD C Capacitor(35WV 47µF) [C1] ｺﾝﾃﾞﾝｻｰ
6 VHEMTZJ22B/-1 AA DD B Zener diode(MTZJ22B) [D1] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
8 VRD-HT2EY221J AA DD C Resistor(1/4W 220Ω ±5%) [R1] ﾃｲｺｳ
(Unit)
901 CPWBF0129QSE1 AQ EQ E Tray PWB ﾄﾚｲ PWB
– 6 –
7
SPF/RSPF INTERFACE PWB(Option AR-SP6/RP6)
8
SPF SENSOR PWB(Option AR-SP6/RP6)
9
CASETTE PWB(Option AR-D24/D25)
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
2 QCNCM0804FCZZ AE DS C Connector(20pin) [CN6] ｺﾈｸﾀｰ
3 QCNCM0809FCZZ AE DS C Connector(26pin) [CN5] ｺﾈｸﾀｰ
4 QCNCM2401SC0C AB DJ C Connector(3pin) [CN1] ｺﾈｸﾀｰ
5 QCNCM7014SC0B AD DJ C Connector(2pin) [AR-RP6 only][CN4] ｺﾈｸﾀｰ
6 QCNCM7014SC0C AA DD C Connector(3pin) [CN7] ｺﾈｸﾀｰ
7 QCNCM7014SC0G AB DD C Connector(7pin) [CN3] ｺﾈｸﾀｰ
8 QCNCP0341QCZZ AC DJ C Connector(3pin) [CN2] ｺﾈｸﾀｰ
9 VCEAGA1CW106M AA DD C Capacitor(16WV 10µF) [C2,C3] ｺﾝﾃﾞﾝｻｰ
10 VCEAZA1VW476M AC DD C Capacitor(35WV 47µF) [C1] ｺﾝﾃﾞﾝｻｰ
11
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C101,C102 ､ C108,C109,C112] ｺﾝﾃﾞﾝｻｰ
VCKYCY1EF104Z AA DD C Capacitor(25WV 0.1µF) [C116,C120,C127,C128] ｺﾝﾃﾞﾝｻｰ
12
VCKYCY1HB102K AA DD C Capacitor(50WV 1000pF) [C117,C118,C119,C121,C122] ｺﾝﾃﾞﾝｻｰ
VCKYCY1HB102K AA DD C Capacitor(50WV 1000pF) [C123,C124,C125 ､ C126] ｺﾝﾃﾞﾝｻｰ
13 VCKYCY1HB222K AA DD C Capacitor(50WV 2200pF) [C107,C113] ｺﾝﾃﾞﾝｻｰ
14 VCKYCY1HB332K AA DD C Capacitor(50WV 3300pF) [C110,C111] ｺﾝﾃﾞﾝｻｰ
15
VCKYCY1HF473Z AA DD C Capacitor(50WV 0.047µF) [C103,C104,C105,C106] ｺﾝﾃﾞﾝｻｰ
VCKYCY1HF473Z AA DD C Capacitor(50WV 0.047µF) [C114,C115] ｺﾝﾃﾞﾝｻｰ
16 VHEUDZS5.6B-1 AC DJ B Zener diode(UDZS5.6B) [ZD101,ZD102,ZD103,ZD104] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
17 VHI74HC151M-1 AD DJ B IC(74HC151M) [IC101] IC
18 VHIMTD13611-1 AR EQ B IC(MTD1361-4101) [IC1] IC
19 VHITD62003AP1 AG DX B IC(TD620003AP1) [IC2] IC
20 VHVICPN38//-1 AF DS B IC protector(ICPN38) [F1] IC ﾌﾟﾛﾃｸﾀｰ
21 VRS-CY1JD102J AA DD C Resistor(1/16W 1.0KΩ ±5%) [R104,R105] ﾃｲｺｳ
22
VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R111,R112,R113,R114,R115,R116] ﾃｲｺｳ
VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R117] ﾃｲｺｳ
23 VRS-CY1JD111F AA DD C Resistor(1/16W 110Ω ±1%) [R110] ﾃｲｺｳ
24 VRS-CY1JD242J AA DD C Resistor(1/16W 2.4KΩ ±5%) [R102,R106] ﾃｲｺｳ
25 VRS-CY1JD391F AA DD C Resistor(1/16W 390Ω ±1%) [R108] ﾃｲｺｳ
26 VRS-CY1JD431F AA DD C Resistor(1/16W 430Ω ±1%) [R109] ﾃｲｺｳ
27 VRS-CY1JD471J AA DD C Resistor(1/16W 470Ω ±5%) [R118,R119] ﾃｲｺｳ
28 VRS-CY1JD621F AA DD C Resistor(1/16W 620Ω ±1%) [R103] ﾃｲｺｳ
29 VRS-CY1JD752J AA DD C Resistor(1/16W 7.5KΩ ±5%) [R101,R107] ﾃｲｺｳ
30 VRS-RE3AA1R5J AB DD C Resistor(1W 1.5Ω ±5%) [R1,R2] ﾃｲｺｳ
31 VSDTC114EKA-1 AC DJ B Transistor(DTC114EKA) [Q101,Q102] ﾄﾗﾝｼﾞｽﾀｰ
(Unit)
901
CPWBF0084QSE3 BA FX E SPF interface PWB [AR-SP6] SPF 中継基板
CPWBF0084QSE4 BA FX E RSPF interface PWB [AR-RP6] RSPF 中継基板
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 QCNCM7014SC0G AB DD C Connector(7pin) [CN101] ｺﾈｸﾀｰ
2 VCKYPA1HF223Z AA DD C Capacitor(50WV 22000pF) [C101] ｺﾝﾃﾞﾝｻｰ
3 VHPGP1S58V/-1 AE DS B Photo transistor(GP1S58V) [PT101,PT102,PT103,PT104,PT105] ﾌｫﾄﾄﾗﾝｼﾞｽﾀｰ
4 VRD-HT2EY121J AA DD C Resistor(1/4W 120Ω ±5%) [R101,R102] ﾃｲｺｳ
5 VRD-HT2EY241J AA DD C Resistor(1/4W 240Ω ±5%) [R103] ﾃｲｺｳ
(Unit)
901 CPWBF0017QSE2 AR EQ E SPF Sensor PWB SPF ｾﾝｻｰ基板
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 QCNCM0877FCZZ AF DS C Connector(20pin) [AR-D24 only][CN∼C] ｺﾈｸﾀｰ
2 QCNCM0923FC16 AF DS C Connector(16pin) [CN∼B] ｺﾈｸﾀｰ
3 QCNCM0923FC22 AF DS C Connector(22pin) [CN∼A] ｺﾈｸﾀｰ
4 VCEAGA1VW476M AB DD C Capacitor(35WV 47µF) [C1∼3] ｺﾝﾃﾞﾝｻｰ
5 VCKYTV1HB102K AA ZZ C Capacitor(50WV 1000PF) [C22∼24] ｺﾝﾃﾞﾝｻｰ
6
VCKYTV1HB222K AA DD C Capacitor(50WV 2200pF) [C4∼7,C12∼14,C19∼21] ｺﾝﾃﾞﾝｻｰ
VCKYTV1HB222K AA DD C Capacitor(50WV 2200pF) [AR-D25 only][C8∼10] ｺﾝﾃﾞﾝｻｰ
7 VCKYTV1HF104Z AA DD C Capacitor(50WV 0.10µF) [C11,C15,C16∼18] ｺﾝﾃﾞﾝｻｰ
8 VHDDAN202K/-1 AB DD B Diode(DAN202K) [D1,2] ﾀﾞｲｵｰﾄﾞ
9 VHDDAN217//-1 AC DD B Diode(DAN217) [AR-D25 only][D5] ﾀﾞｲｵｰﾄﾞ
10 VHDDAP202K/-1 AB DD B Diode(DAP202K) [D3,4] ﾀﾞｲｵｰﾄﾞ
11
VHITC74HC151F AG DS B IC(TC74H151F) [IC1] IC
VHITC74HC151F AG DS B IC(TC74H151F) [AR-D25 only][IC3] IC
12 VHIULN2003AN1 AE DJ B IC(ULN2003A) [IC2] IC
13 VHVICPN38//-1 AF DS B IC protector(ICPN38) [ICP1] IC ﾌﾟﾛﾃｸﾀｰ
14 VRS-TP2BD000J AA DD C Resistor(1/8W 0Ω ±5%) [J1∼23,J25,J26] ﾃｲｺｳ
15
VRS-TS2AD103J AA DD C Resistor(1/10W 10KΩ ±5%) [R1∼4] ﾃｲｺｳ
VRS-TS2AD103J AA DD C Resistor(1/10W 10KΩ ±5%) [AR-D25 only][R5∼8] ﾃｲｺｳ
(Unit)
901
CPWBF0019QSE5 AV FG E 1ST tray interface PWB [AR-D24] 1 段ﾄﾚｲ中継基板
CPWBF0019QSE6 AW FG E 2ND tray interface PWB [AR-D25] 2 段ﾄﾚｲ中継基板
– 7 –
F
IMC2 PWB(Option AR-EB7)
NO. PARTS CODE
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
Ex. Ja.
1 QCNCM0877FCZZ AF DS C Connector(20pin) [CN1] ｺﾈｸﾀｰ
3 QSOCN0005ESZZ AE DS C Connector(UBR23-4K2200) [CN8] ｺﾈｸﾀｰ
4 QSOCZ0001QSZZ AL EB C Connector(DMM168-FLAA2-3A133) [CN6] ｺﾈｸﾀｰ
5 RCILF1097ACZZ AG DS C Coil(DLW21SN900SQ2L) [L5] ｺｲﾙ
6 RCILF2049HCZZ AB DJ C Coil(BLM21P600SG) [L6,L4] ｺｲﾙ
11 RH-IX0027QSZZ AM EG B IC(74VCX16244) [IC28,IC29] IC
12 RH-IX0028QSZZ AM EG B IC(74VCX16245) [IC26] IC
13
RMPTR4000ACZZ AB DD B Block resistor(0Ω×4) [BR12,BR13,BR14,BR15,BR16] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTR4000ACZZ AB DD B Block resistor(0Ω×4) [BR17,BR36,BR37,BR38,BR42] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTR4000ACZZ AB DD B Block resistor(0Ω×4) [BR400,BR401,BR402,BR403] ﾌﾞﾛｯｸﾃｲｺｳ
RMPTR4000ACZZ AB DD B Block resistor(0Ω×4) [BR404,BR405] ﾌﾞﾛｯｸﾃｲｺｳ
14 RMPTR4100ACZZ AB DD B Block resistor(10Ω×4) [BR1,BR2,BR3,BR4,BR5] ﾌﾞﾛｯｸﾃｲｺｳ
15 RMPTR4103ACZZ AB DD B Block resistor(10KΩ×4) [BR39,BR40,BR41,BR43] ﾌﾞﾛｯｸﾃｲｺｳ
16 RMPTR4330ACZZ AB DD B Block resistor(33Ω×4) [BR11] ﾌﾞﾛｯｸﾃｲｺｳ
17 TLABZ4201FCZZ AC DJ D Version label [for IC2] ﾊﾞｰｼﾞｮﾝﾗﾍﾞﾙ
18 VCCCCZ1HH101J AA DD C Capacitor(50WV 100pF) [C60] ｺﾝﾃﾞﾝｻｰ
19 VCCCCZ1HH120J AA DD C Capacitor(50WV 12pF) [C44,C50] ｺﾝﾃﾞﾝｻｰ
21 VCCCCZ1HH390J AA DD C Capacitor(50WV 39pF) [C66] ｺﾝﾃﾞﾝｻ
22 VCCCCZ1HH680J AA DD C Capacitor(50WV 68p) [C401,C402,C403,C404,C405] ｺﾝﾃﾞﾝｻｰ
23 VCCUCY1AJ105Z AC DD C Capacitor(10WV 1.0µF) [C8,C5] ｺﾝﾃﾞﾝｻｰ
24
VCEAGA1CW106M AA DD C Capacitor(16WV 10µF) [C11,C21,C26,C35,C45] ｺﾝﾃﾞﾝｻｰ
VCEAGA1CW106M AA DD C Capacitor(16WV 10µF) [C87,C89,C119] ｺﾝﾃﾞﾝｻｰ
25 VCEAGA1CW476M AB DD C Capacitor(16WV 47µF) [C3,C6,C54,C56,C69,C70] ｺﾝﾃﾞﾝｻ -
26
VCKYCZ1CB103K AA DD C Capacitor(16WV 0.010µF) [C4,C7,C58,C59,C81,C82] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CB103K AA DD C Capacitor(16WV 0.010µF) [C83,C84,C85,C86,C98] ｺﾝﾃﾞﾝｻｰ
27
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C2,C12,C13,C14,C15] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C16,C17,C18,C19,C20] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C22,C23,C24,C25,C27] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C28,C29,C30,C31,C32] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C33,C34,C36,C37,C38] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C39,C40,C41,C42,C43] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C46,C47,C48,C49,C55] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C57,C64,C71,C72,C73] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C74,C75,C76,C77,C78] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C79,C80,C88,C90,C91] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C92,C93,C94,C95,C120] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C121,C122,C123,C124,C125] ｺﾝﾃﾞﾝｻｰ
VCKYCZ1CF104Z AB DD C Capacitor(16WV 0.1µF) [C128,C129,C130,C131] ｺﾝﾃﾞﾝｻｰ
28 VCKYCZ1HB222K AA DD C Capacitor(50WV 2200pF) [C65] ｺﾝﾃﾞﾝｻｰ
29 VHICY2305SC-1 AU EZ B IC(CY2305SC) [IC6] IC
33 VRS-CY1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [L1,L2,L3] ﾃｲｺｳ
34 VRS-CY1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R420] ﾃｲｺｳ
35 VRS-CY1JD1R0J AA DD C Resistor(1/16W 1.0Ω ±5%) [R11,R14] ﾃｲｺｳ
36
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R4,R20,R29,R30,R31] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R32,R33,R34,R35,R36] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R37,R38,R39,R40,R42] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R43,R44,R45,R46,R47] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R48,R50,R51,R53,R54] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R55,R58,R61,R62,R66] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R67,R69,R70,R71,R83] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R84,R85,R133,R136,R137] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R138,R139,R140,R144,R400] ﾃｲｺｳ
VRS-CZ1JD000J AA DD C Resistor(1/16W 0Ω ±5%) [R405,R406,R415,R416] ﾃｲｺｳ
37
VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R1,R2,R3,R8,R9] ﾃｲｺｳ
VRS-CZ1JD100J AA DD C Resistor(1/16W 10Ω ±5%) [R56,R57,R59,R60,R63] ﾃｲｺｳ
38
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R21,R22,R24,R25,R26] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R122,R123,R124,R125,R127] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R128,R129,R131,R132,R407] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R408,R409,R410,R411,R412] ﾃｲｺｳ
VRS-CZ1JD103J AA DD C Resistor(1/16W 10KΩ ±5%) [R413,R414,R417,R419,R402] ﾃｲｺｳ
39 VRS-CZ1JD123F AA DD C Resistor(1/16W 12KΩ ±1%) [R143] ﾃｲｺｳ
40 VRS-CZ1JD152J AA DD C Resistor(1/16W 1.5KΩ ±5%) [R134] ﾃｲｺｳ
41 VRS-CZ1JD472J AA DD C Resistor(1/16W 4.7KΩ ±5%) [R5,R10,R17,R18,R19,R418] ﾃｲｺｳ
42 VRS-CZ1JD680J AA DD C Resistor(1/16W 68Ω ±5%) [R41] ﾃｲｺｳ
43 VRS-CZ1JD752F AA DD C Resistor(1/16W 7.5KΩ ±1%) [R401] ﾃｲｺｳ
– 8 –
■
索引 (Index)
PARTS CODE
JAPAN ONLY
ORDER CODE
NO.
PRICE R.
NEW P/R
Ex. Ja.
[C]
CPWBF0017QSE2 578 684 1119 8- 901 AR EQ E
CPWBF0019QSE5 578 684 1103 9- 901 AV FG E
CPWBF0019QSE6 578 684 1114 9- 901 AW FG E
CPWBF0084QSE3 578 684 1120 7- 901 BA FX E
CPWBF0084QSE4 578 684 1121 7- 901 BA FX E
CPWBF0114QSE3 578 684 1122 4- 901 BA FX E
CPWBF0129QSE1 578 684 1123 6- 901 AQ EQ E
CPWBX0128QS31 578 684 1105 1- 901 CA TR E
CPWBX0128QS32 578 684 1108 1- 901 CA TV E
CPWBX0128QS33 578 684 1135 1- 901 CA TR E
CPWBX0128QS34 578 684 1106 1- 901 CA TV E
CPWBX0128QS36 578 684 1128 1- 901 CA TV E
[D]
DHAI-0310QSZZ 578 542 0277 4- 1 AB DJ C
[Q]
QCNCM0017QSZZ 572 510 1051 1- 4 AC DJ C
QCNCM0804FCZZ 572 510 0127 7- 2 AE DS C
QCNCM0809FCZZ 572 510 0672 7- 3 AE DS C
QCNCM0877FCZZ 572 510 0842 10- 1 AF DS C
" 572 510 0842 1- 8 AF DS C
" 572 510 0842 9- 1 AF DS C
QCNCM0923FC12 572 510 0939 1- 9 AE DJ C
QCNCM0923FC16 572 510 0868 9- 2 AF DS C
QCNCM0923FC22 572 510 0869 9- 3 AF DS C
QCNCM1005MCZZ 589 510 0004 1- 10 AB DD C
QCNCM1006MCZZ 589 510 0020 1- 11 AB DD C
QCNCM2334SC0B 595 510 0234 1- 12 AB DD C
QCNCM2401SC0C 595 510 0762 1- 13 AB DJ C
" 595 510 0762 7- 4 AB DJ C
QCNCM2401SC0D 595 510 0090 1- 14 AC DJ C
QCNCM2401SC0F 595 510 0782 6- 1 AB DJ C
QCNCM7014SC0B 595 510 0337 7- 5 AD DJ C
QCNCM7014SC0C 595 510 0338 1- 15 AA DD C
" 595 510 0338 6- 2 AA DD C
" 595 510 0338 7- 6 AA DD C
QCNCM7014SC0D 595 510 0345 1- 16 AB DD C
QCNCM7014SC0E 595 510 0744 1- 17 AB DJ C
QCNCM7014SC0F 595 510 0346 1- 18 AB DD C
QCNCM7014SC0G 595 510 0347 7- 7 AB DD C
" 595 510 0347 8- 1 AB DD C
QCNCM7014SC1C 595 510 0355 1- 19 AC DD C
QCNCP0340QCZZ 572 510 0921 6- 3 AC DJ C
QCNCP0341QCZZ 572 510 0922 7- 8 AC DJ C
QCNCW0024QSZZ 572 510 1056 1- 21 AF DS C
" 572 510 1056 2- 1 AF DS C
QCNCW0077QSZZ 578 510 0330 1- 22 AK DX C
QCNCW0078QSZZ 578 510 0335 1- 23 AF DS C
" 578 510 0335 4- 2 AF DS C
QCNCW0885FCZZ 572 510 0834 1- 26 AG DX C
QCNCW1124LC0D 572 510 1032 1- 27 AB DJ C
QCNCW1124LC0H 594 510 0507 1- 28 AC DJ C
QCNCW1124LC1C 594 510 0508 1- 29 AC DJ C
" 594 510 0508 6- 4 AC DJ C
QSOCN0002ESZZ 578 527 0030 4- 3 AH DX C
QSOCN0005ESZZ 578 527 0032 10- 3 AE DS C
" 578 527 0032 4- 4 AE DS C
QSOCZ0001QSZZ 578 527 0024 10- 4 AL EB C
QSOCZ0002QSZZ 578 527 0027 1- 31 AD DJ C
QSW-P0001ESZZ 578 530 0104 3- 2 AC DJ B
" 578 530 0104 5- 2 AC DJ B
[R]
RCILF1097ACZZ 596 614 0611 10- 5 AG DS C
RCILF2049HCZZ 567 614 0106 10- 6 AB DJ C
RCRSP0016QSZZ 578 616 0063 1- 32 AD DJ B
RFILZ0004QSZZ 578 621 0030 1- 35 AM EG C
" 578 621 0030 2- 2 AM EG C
RH-DX0001ESZZ 578 570 0169 4- 5 AC DJ B
RH-DZ0016FCZZ 572 570 0001 1- 36 AB DD B
RH-IX0001QSZZ 578 573 1147 1- 37 BD GN B
RH-IX0005ESZZ 578 573 1162 4- 6 AE DS B
RH-IX0027QSZZ 578 573 1352 10- 11 AM EG B
RH-IX0028QSZZ 578 573 1353 10- 12 AM EG B
RH-IX7001XCZZ 578 573 1347 1- 39 AQ EQ B
RH-TX0003ESZZ 578 576 0131 3- 4 AC DJ B
RMPTR4000ACZZ 567 631 0098 10- 13 AB DD B
RMPTR4100ACZZ 567 631 0099 10- 14 AB DD B
RMPTR4103ACZZ 567 631 0100 10- 15 AB DD B
RMPTR4330ACZZ 567 631 0109 10- 16 AB DD B
PARTS CODE
JAPAN ONLY
ORDER CODE
NO.
PRICE R.
NEW P/R
Ex. Ja.
RMPTW4100QCJJ 572 631 0264 1- 40 AA DD B
" 572 631 0264 2- 3 AA DD B
RMPTW4101QCJJ 521 631 0027 1- 41 AB DD B
RMPTW4103QCJJ 571 631 0147 1- 42 AB DD B
RMPTW4221QCJJ 523 631 0016 1- 43 AA DD B
RMPTW4330QCJJ 567 631 0058 1- 44 AB DD B
[T]
TLABZ4201FCZZ 572 917 3231 10- 17 AC DJ D
[V]
VCCCCY1HH101J 507 591 5030 4- 7 AA DD C
VCCCCY1HH201J 594 593 0050 3- 6 AA DD C
VCCCCY1HH331J 594 593 0052 4- 8 AB DD C
VCCCCY1HH471J 571 593 0210 4- 9 AA DD C
VCCCCZ1HH101J 521 593 0028 10- 18 AA DD C
" 521 593 0028 1- 45 AA DD C
" 521 593 0028 2- 4 AA DD C
VCCCCZ1HH120J 567 593 0312 10- 19 AA DD C
" 567 593 0312 1- 46 AA DD C
VCCCCZ1HH150J 521 593 0029 1- 47 AA DD C
VCCCCZ1HH220J 521 593 0023 1- 48 AA DD C
VCCCCZ1HH330J 521 593 0034 1- 49 AA DD C
VCCCCZ1HH390J 567 593 0313 10- 21 AA DD C
VCCCCZ1HH470J 521 593 0025 2- 6 AA DD C
VCCCCZ1HH680J 567 593 0316 10- 22 AA DD C
VCCUCY1AJ105Z 596 593 0899 10- 23 AC DD C
VCEAGA1CW106M 541 591 5281 10- 24 AA DD C
" 541 591 5281 1- 50 AA DD C
" 541 591 5281 7- 9 AA DD C
VCEAGA1CW226M 541 591 5282 1- 51 AB DD C
VCEAGA1CW476M 541 591 5090 10- 25 AB DD C
" 541 591 5090 1- 52 AB DD C
" 541 591 5090 4- 10 AB DD C
VCEAGA1VW106M 572 594 0093 1- 53 AA DD C
VCEAGA1VW476M 572 594 0091 1- 54 AB DD C
" 572 594 0091 6- 5 AB DD C
" 572 594 0091 9- 4 AB DD C
VCEAJA1CW226M 578 594 0012 2- 7 AB DD C
VCEAJA1EW226M 595 594 0103 2- 8 AB DD C
VCEAJU1CW476M 596 594 0062 3- 7 AB DD C
VCEAZA1VW476M 578 594 0149 7- 10 AC DD C
VCKYCY1CB104K 567 593 0198 3- 8 AB DD C
VCKYCY1CF104Z 571 593 0054 4- 11 AA DD C
VCKYCY1EF104Z 507 591 5036 1- 55 AA DD C
" 507 591 5036 7- 11 AA DD C
VCKYCY1HB102K 594 593 0044 1- 56 AA DD C
" 594 593 0044 7- 12 AA DD C
VCKYCY1HB104K 595 593 1684 1- 57 AA DD C
VCKYCY1HB222K 595 593 0027 1- 58 AA DD C
" 595 593 0027 7- 13 AA DD C
VCKYCY1HB332K 595 593 1209 7- 14 AA DD C
VCKYCY1HB473K 594 593 0330 1- 59 AA DD C
VCKYCY1HF473Z 594 593 0207 7- 15 AA DD C
VCKYCZ1CB103K 595 593 1450 10- 26 AA DD C
VCKYCZ1CB223K 595 593 1451 1- 60 AB DD C
VCKYCZ1CF104Z 521 593 0017 10- 27 AB DD C
" 521 593 0017 2- 9 AB DD C
VCKYCZ1HB102K 521 593 0030 1- 62 AA DD C
VCKYCZ1HB222K 521 593 0032 10- 28 AA DD C
VCKYCZ1HB271K 596 593 1668 1- 63 AA DD C
VCKYCZ1HB471K 521 593 0033 1- 64 AA DD C
VCKYCZ1HB821K 578 593 0389 1- 65 AC DD C
VCKYPA1HF223Z 572 593 0029 8- 2 AA DD C
VCKYTV1HB102K 588 593 0008 9- 5 AA ZZ C
VCKYTV1HB222K 596 593 0080 9- 6 AA DD C
VCKYTV1HF104Z 578 593 0038 9- 7 AA DD C
VHD1SS355//-1 595 570 0304 1- 66 AB DJ B
VHDDAN202K/-1 500 570 5005 9- 8 AB DD B
VHDDAN217//-1 500 570 5021 9- 9 AC DD B
VHDDAP202K/-1 500 570 0037 9- 10 AB DD B
VHDDSS133//-1 500 570 5006 1- 67 AA DD B
" 500 570 5006 3- 9 AA DD B
VHDKDS120++-1 578 570 0175 1- 68 AC DJ B
VHDKDS121++-1 578 570 0171 1- 69 AC DJ B
VHDKDS226++-1 578 570 0172 1- 70 AC DJ B
VHEMTZJ22B/-1 567 571 0006 1- 71 AA DD B
" 567 571 0006 6- 6 AA DD B
VHEUDZ3.9B/-1 596 571 0169 1- 72 AC DJ B
VHEUDZ5.6B/-1 567 571 0089 1- 73 AC DJ B
VHEUDZS5.6B-1 594 571 0179 7- 16 AC DJ B
VHEUDZS6.2B-1 567 571 0103 4- 12 AC DJ B
VHI29L0800BQS 578 573 1355 1- 2 BD GJ B
– 9 –
PARTS CODE
JAPAN ONLY
ORDER CODE
NO.
PRICE R.
NEW P/R
Ex. Ja.
VHI29L0800CQS 578 573 1356 1- 3 BD GJ B
VHI74HC151M-1 578 573 1185 1- 74 AD DJ B
" 578 573 1185 3- 10 AD DJ B
" 578 573 1185 7- 17 AD DJ B
VHI74LCX32M-1 578 573 1177 1- 76 AE DJ B
VHI74LVX16128 578 573 1048 4- 13 AP EQ B
VHI74VHCT04FT 593 573 3301 2- 11 AF DS B
VHICY2305SC-1 572 573 2019 10- 29 AU EZ B
VHID65001AF-1 578 573 1315 1- 77 AG DS B
VHID65503F+-1 578 573 1316 1- 78 AG DS B
VHIEES04L400P 572 573 2414 1- 79 AG DX B
VHIH8S2321+-1 578 573 1323 1- 80 AX FG B
VHIKA7805AP-1 578 573 1159 1- 82 AE DS B
VHIKIA358F+-1 578 573 1317 1- 84 AE DS B
VHIKIA393F+-1 578 573 1318 1- 85 AE DS B
VHIL6219DS+-1 578 573 1314 1- 86 AN EQ B
VHILC7935//-1 572 573 0454 3- 11 AN EQ B
VHILCX16244-1 578 573 1219 1- 87 AM EG B
VHILCX16374-1 578 573 1164 1- 88 AM EG B
VHILCX244WM-1 578 573 1146 1- 89 AG DX B
VHILVX4245M-1 578 573 1181 1- 91 AL EB B
VHIM51957BFP1 567 573 0126 1- 92 AH DX B
VHIMTD13611-1 578 573 1140 7- 18 AR EQ B
VHINE555///-1 541 573 1156 3- 12 AG DX B
VHIP2010ASR-1 578 573 1322 1- 93 AN EQ B
VHITA7291AS-1 572 573 2570 1- 94 AF DX B
VHITC74HC151F 572 573 1792 9- 11 AG DS B
VHITD62003AP1 595 573 1747 7- 19 AG DX B
VHITD62064AF/ 572 573 1832 1- 95 AM EG B
VHIULN2003AN1 572 573 0829 9- 12 AE DJ B
VHIUSB11AMX-1 578 573 1319 4- 14 AH DX B
VHIVHCT244M-1 578 573 1179 1- 96 AG DX B
VHP1LHEE-002A 578 574 0042 3- 13 AC DJ B
VHP1LHLE-002A 578 574 0043 3- 14 AC DJ B
" 578 574 0043 5- 3 AC DJ B
VHP3650AG2J-1 578 574 0051 3- 15 AL EB B
VHPGP1S58V/-1 572 568 0002 8- 3 AE DS B
VHVICPN38//-1 585 577 0022 7- 20 AF DS B
" 585 577 0022 9- 13 AF DS B
VRD-HT2EY121J 507 581 5011 8- 4 AA DD C
VRD-HT2EY221J 507 581 5014 6- 8 AA DD C
VRD-HT2EY241J 593 581 0088 8- 5 AA DD C
VRD-HT2EY472J 507 581 5018 1- 97 AA DD C
VRN-VT3ATR68J 578 581 0712 1- 98 AC DD C
VRS-CY1JD000J 507 581 5050 10- 33 AA DD C
" 507 581 5050 3- 16 AA DD C
" 507 581 5050 4- 15 AA DD C
VRS-CY1JD101J 596 581 0257 3- 17 AA DD C
VRS-CY1JD102J 571 581 0007 3- 18 AA DD C
" 571 581 0007 7- 21 AA DD C
VRS-CY1JD103J 500 581 5097 10- 34 AA DD C
" 500 581 5097 3- 19 AA DD C
" 500 581 5097 4- 16 AA DD C
" 500 581 5097 7- 22 AA DD C
VRS-CY1JD111F 578 581 0329 7- 23 AA DD C
VRS-CY1JD151J 500 581 5110 3- 20 AA DD C
VRS-CY1JD152J 571 581 0003 4- 17 AA DD C
VRS-CY1JD1R0J 567 581 0423 10- 35 AA DD C
VRS-CY1JD202J 594 581 0151 3- 21 AA DD C
VRS-CY1JD220J 507 581 5055 4- 18 AA DD C
VRS-CY1JD240J 578 581 0285 4- 19 AA DD C
VRS-CY1JD242J 596 581 2169 7- 24 AA DD C
VRS-CY1JD244J 594 581 0684 3- 22 AA DD C
VRS-CY1JD332J 500 581 5112 4- 20 AA DD C
VRS-CY1JD391F 521 581 0079 7- 25 AA DD C
VRS-CY1JD431F 578 581 0331 7- 26 AA DD C
VRS-CY1JD471J 571 581 0002 3- 23 AA DD C
" 571 581 0002 7- 27 AA DD C
VRS-CY1JD511J 595 581 0110 3- 24 AA DD C
VRS-CY1JD621F 594 581 0820 7- 28 AA DD C
VRS-CY1JD752J 596 581 0258 7- 29 AA DD C
VRS-CZ1JD000J 521 581 0082 10- 36 AA DD C
" 521 581 0082 1- 99 AA DD C
" 521 581 0082 2- 15 AA DD C
VRS-CZ1JD100J 567 581 0524 10- 37 AA DD C
" 567 581 0524 1- 100 AA DD C
" 567 581 0524 2- 16 AA DD C
VRS-CZ1JD101J 521 581 0137 1- 101 AA DD C
" 521 581 0137 2- 17 AA DD C
VRS-CZ1JD102F 521 581 0187 1- 102 AA DD C
VRS-CZ1JD102J 521 581 0093 1- 103 AA DD C
PARTS CODE
JAPAN ONLY
ORDER CODE
NO.
PRICE R.
NEW P/R
Ex. Ja.
VRS-CZ1JD103F 521 581 0127 1- 104 AA DD C
VRS-CZ1JD103J 521 581 0085 10- 38 AA DD C
" 521 581 0085 1- 105 AA DD C
VRS-CZ1JD105F 578 581 0716 1- 106 AA DD C
VRS-CZ1JD122F 578 581 0717 1- 107 AA DD C
VRS-CZ1JD123F 521 581 0128 10- 39 AA DD C
VRS-CZ1JD133F 572 581 2079 1- 108 AA DD C
VRS-CZ1JD152J 521 581 0175 10- 40 AA DD C
" 521 581 0175 1- 109 AA DD C
VRS-CZ1JD202J 567 581 0695 2- 18 AA DD C
VRS-CZ1JD203J 567 581 0530 1- 110 AA DD C
VRS-CZ1JD220J 567 581 0532 1- 111 AA DD C
VRS-CZ1JD241J 578 581 0718 1- 112 AA DD C
VRS-CZ1JD272J 567 581 0634 1- 114 AA DD C
VRS-CZ1JD301J 572 581 2154 1- 115 AA DD C
VRS-CZ1JD302F 521 581 0106 1- 116 AA DD C
VRS-CZ1JD303J 572 581 2074 1- 117 AA DD C
VRS-CZ1JD330J 521 581 0202 1- 118 AA DD C
" 521 581 0202 2- 19 AA DD C
VRS-CZ1JD470J 521 581 0170 1- 119 AA DD C
VRS-CZ1JD471J 567 581 0617 1- 120 AA DD C
VRS-CZ1JD472J 521 581 0088 10- 41 AA DD C
VRS-CZ1JD473J 521 581 0109 1- 121 AA DD C
VRS-CZ1JD680J 572 581 2065 10- 42 AA DD C
VRS-CZ1JD752F 521 581 0114 10- 43 AA DD C
" 521 581 0114 1- 122 AA DD C
VRS-HT3DA102J 588 581 0145 1- 124 AA DD C
VRS-HT3DAR22J 572 581 0135 1- 126 AA DD C
VRS-RE3AA1R5J 578 581 0316 7- 30 AB DD C
VRS-TP2BD000J 507 581 5003 9- 14 AA DD C
VRS-TS2AD103J 501 581 5009 9- 15 AA DD C
VS2SB1197//-1 571 576 0349 1- 127 AC DJ B
VSDTC114EKA-1 595 576 0491 7- 31 AC DJ B
VSDTC143ZKA-1 594 576 0231 3- 25 AC DJ B
VSKRA119S++-1 578 576 0132 1- 128 AB DJ B
VSKTA1505S+-1 578 576 0134 1- 129 AC DJ B
VSUPA502T//-1 572 576 0512 1- 130 AD DJ B
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$24.99
$32.99
Viewed 89 Times Today
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$24.99
$32.99
The SHARP AR-200M, AR-160M, AR-M205, AR-M160, AR-5220, AR-SP6/RP6, AR-D24/D25, AR-EB7 Copier Parts Guide is a comprehensive resource for maintaining and repairing your copier. It includes detailed information on components such as MCU PWB, CCD PWB, COPY OPE PWB, I/F PWB, SCAN OPE PWB, TRAY PWB, and optional parts like SPF/RSPF INTERFACE PWB, SPF SENSOR PWB, CASETTE PWB, and IMC2 PWB.
This professional-grade guide is designed to provide step-by-step instructions and detailed images, making it a trusted tool for both professionals and DIY enthusiasts. It is compatible with all versions of Windows, Mac, and mobile devices, ensuring you have access to the information you need, wherever you are.
With this guide, you can save time and money on repairs, thanks to its easy-to-follow instructions and comprehensive coverage of all repair areas. Secure your copy today and ensure your copier remains in optimal working condition.
