KUBOTA L3710 DT GST HST Tractor Parts Manual LIST IPL

Instructions for Parts Books The heading at the top of the page will be the same for the picture of the parts at it is for the page with the part numbers. Definition of column headings on part number pages: REF.No  The number refering to the part on the picture page of the parts book. Part No.  The number assigned to this part at the time of printing the parts book. Description  Discription of part. Q'ty  Quanity of part used on that page. S.No.  Serial number range of the equipment that this part will fit. >= Your serial number should be greater than or equal to the number shown. <= Your serial number should be lesser than or equal to the serial number shown. I/C  Interchangeability of part shown.  The part shown will work for the older and later serial number. # The part shown is not interchangable with the other serial number.  new for old  old for new Remarks  Notes about this particulart part. Sometimes this may say except [FR] or [CA] Note about Country Codes: The parts books we use in the United States of America may also contain information about a part that would be different in another country. It is important that you are aware of the country codes in some instances. Symbol Country A United States of America CA Canada FR France GR Greece PO Portugal AU Australia If the remarks column says for example EXCEPT [FR] this part works in all countries except France. That means it will work here in the USA.

|ALL PRODUCT INDEX L3710DT/GST/HST Ref. L3710DT/GST/HST Page 12076 COOLING WATER SYSTEM ELECTRICAL SYSTEM CLUTCH/TRANSMISSION/REAR AXLE SPEED CHANGE LEVER/BRAKE FRONT AXLE/CHASSIS STEERING HYDRAULIC SYSTEM HITCH/DRAWBAR HOOD(BONNET)/ROPS/CAB FRONT WHEEL/REAR WHEEL LABELS FUEL SYSTEM ACCESSORIES OPTION ENGINE

Ref. L3710DT/GST/HST Page 12076 Item Part No. Description Book ENGINE 010001 CRANKCASE 100K0489 010002 OIL PAN 100K0489 010003 CYLINDER HEAD 100K0489 010004 GEAR CASE 100K0489 010005 HEAD COVER 100K0489 010100 MAIN BEARING CASE 100K0489 010101 CAMSHAFT AND IDLE GEAR SHAFT 100K0489 010102 PISTON AND CRANKSHAFT 100K0489 01010301 FLYWHEEL [W/O IND-PTO] 100K0489 01010303 FLYWHEEL [WITH IND-PTO] 100K0489 010105 FUEL CAMSHAFT 100K0489 010200 ENGINE STOP LEVER 100K0489 010202 INJECTION PUMP 100K0489 010203 INJECTION PUMP [COMPONENT PARTS] 100K0489 010204 GOVERNOR 100K0489 010205 SPEED CONTROL PLATE 100K0489 010206 NOZZLE HOLDER AND GLOW PLUG 100K0489 010207 NOZZLE HOLDER [COMPONENT PARTS] 100K0489 01050001 WATER FLANGE AND THERMOSTAT [ROPS TYPE] 100K0489 010501 WATER PUMP 100K0489 010600 VALVE AND ROCKER ARM 100K0489 01060101 INLET MANIFOLD [ROPS TYPE] 100K0489 01090101 UPPER GASKET KIT 100K0489 010902 LOWER GASKET KIT 100K0489 010603 EXHAUST MANIFOLD/MUFFLER 100K0489 01060401 AIR CLEANER [ROPS TYPE] [OLD TYPE] 100K0489 01060402 AIR CLEANER [ROPS TYPE] [NEW TYPE] 100K0489 01A002 STOP SOLENOIDE/ENGINE STOP WIRE 100K0489 01A01001 ACCELERATOR LEVER [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01A01002 ACCELERATOR LEVER [HST TYPE] [ROPS TYPE] 100K0489 01A025 ACCELERATOR LINKAGE [EXCEPT HST TYPE] 100K0489 01A03001 ACCELERATOR ROD [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01A03003 ACCELERATOR ROD [HST TYPE] 100K0489 FUEL SYSTEM 01A10101 FUEL TANK [ROPS TYPE] 100K0489 01A110 FUEL PIPE AND FUEL FILTER 100K0489 01A130 FUEL FILTER [COMPONENT PARTS] 100K0489 COOLING WATER SYSTEM 01A401 FAN 100K0489 01A41001 WATER PIPE [ROPS TYPE] 100K0489 01A420 RADIATOR 100K0489 01A43001 RESERVE TANK [ROPS TYPE] 100K0489 ELECTRICAL SYSTEM 01A51501 ALTERNATOR [ROPS TYPE] 100K0489 01A52001 ALTERNATOR [COMPONENT PARTS] [ROPS TYPE] 100K0489 01A525 STARTER 100K0489 01A530 STARTER [COMPONENT PARTS] 100K0489 01A53501 BATTERY [ROPS TYPE] 100K0489 01B10201 SWITCH 1 [EXCEPT HST TYPE] [ROPS TYPE] [OLD TYPE] 100K0489 01B10202 SWITCH 1 [EXCEPT HST TYPE] [ROPS TYPE] [NEW TYPE] 100K0489 01B10203 SWITCH 1 [HST TYPE] [ROPS TYPE] [OLD TYPE] 100K0489 01B10204 SWITCH 1 [HST TYPE] [ROPS TYPE] [NEW TYPE] 100K0489 01B10301 SWITCH 2 [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01B10302 SWITCH 2 [HST TYPE] [ROPS TYPE] 100K0489 01B115 PANEL BOARD 100K0489 01B120 PANEL BOARD [COMPONENT PARTS] 100K0489 01B30401 LIGHT 1 [ROPS TYPE] [OLD TYPE] 100K0489

Ref. L3710DT/GST/HST Page 12076 Item Part No. Description Book ELECTRICAL SYSTEM 01B30402 LIGHT 1 [ROPS TYPE] [NEW TYPE] 100K0489 01B50101 ELECTRICAL WIRING [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01B50102 ELECTRICAL WIRING [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01B50103 ELECTRICAL WIRING [HST TYPE] [ROPS TYPE][OLD TYPE] 100K0489 01B50104 ELECTRICAL WIRING [HST TYPE] [ROPS TYPE][OLD TYPE] 100K0489 01B50105 ELECTRICAL WIRING [HST TYPE] [ROPS TYPE][NEW TYPE] 100K0489 CLUTCH/TRANSMISSION/REAR AXLE 01C101 CLUTCH 100K0489 01C201 CLUTCH LEVER 100K0489 01C30101 CLUTCH PEDAL [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01C30102 CLUTCH PEDAL [HST TYPE] [ROPS TYPE] 100K0489 01C40101 CLUTCH HOUSING [MANUAL T/M TYPE] 100K0489 01C40103 CLUTCH HOUSING [GST TYPE] 100K0489 01C40104 CLUTCH HOUSING [HST TYPE] 100K0489 01C405 GST VALVE [GST TYPE] 100K0489 01C406 GST VALVE [GST TYPE] [COMPONENT PARTS] 100K0489 01C407 GST VALVE [GST TYPE] [COMPONENT PARTS] 100K0489 01C408 GST VALVE [GST TYPE] [COMPONENT PARTS] 100K0489 01C41001 MID CASE [MANUAL T/M TYPE] [WITH IND-PTO]] 100K0489 01C41002 MID CASE [GST TYPE] [W/O IND-PTO] 100K0489 01C41004 MID CASE [HST TYPE] [OLD TYPE] 100K0489 01C41005 MID CASE [HST TYPE] [NEW TYPE] 100K0489 01C415 HST [COMPONENT PARTS] [HST TYPE] 100K0489 01C42001 TRANSMISSION CASE [MANUAL T/M TYPE] [W/O MID PTO] 100K0489 01C42003 TRANSMISSION CASE [GST TYPE] [W/O MID PTO] 100K0489 01C42004 TRANSMISSION CASE [HST TYPE] [WITH MID PTO] 100K0489 01D10101 MAIN SHAFT [EXCEPT HST TYPE] [W/O IND-PTO] 100K0489 01D10102 MAIN SHAFT [EXCEPT HST TYPE] [WITH IND-PTO] 100K0489 01D10103 MAIN SHAFT [HST TYPE] 100K0489 01D103 INPUT SHAFT [HST TYPE] 100K0489 01D10501 COUNTERSHAFT [MANUAL T/M TYPE] 100K0489 01D10502 COUNTERSHAFT [GST TYPE] 100K0489 01D107 OUTPUT SHAFT [HST TYPE] 100K0489 01D11001 HYDRAULIC CLUTCH [GST TYPE] [W/O IND-PTO] 100K0489 01D11501 SHUTTLE SHAFT [MANUAL T/M TYPE] 100K0489 01D11502 SHUTTLE SHAFT [GST TYPE] 100K0489 01D11701 RANGE GEAR SHAFT [MANUAL T/M TYPE] 100K0489 01D11702 RANGE GEAR SHAFT [GST TYPE] 100K0489 01D12503 SPIRAL BEVEL PINION [EXCEPT HST TYPE] [W/O CREEP] 100K0489 01D12504 SPIRAL BEVEL PINION [EXCEPT HST TYPE][WITH CREEP] 100K0489 01D12505 SPIRAL BEVEL PINION [HST TYPE] 100K0489 01D127 REAR DIFFERENTIAL 100K0489 01D13001 PTO COUNTERSHAFT [EXCEPT HST TYPE] [WITH IND-PTO] 100K0489 01D13002 PTO COUNTERSHAFT [EXCEPT HST TYPE] [W/O IND-PTO] 100K0489 01D13201 PTO CLUTCH [EXCEPT HST TYPE] [WITH IND-PTO] 100K0489 01D13202 PTO CLUTCH [EXCEPT HST TYPE] [W/O IND-PTO] 100K0489

Ref. L3710DT/GST/HST Page 12076 Item Part No. Description Book CLUTCH/TRANSMISSION/REAR AXLE 01D13203 PTO CLUTCH [HST TYPE] [W/O IND-PTO] 100K0489 01D13502 PTO SHAFT [EXCEPT HST TYPE] [W/O MID PTO] 100K0489 01D13503 PTO SHAFT [HST TYPE] [WITH MID PTO] 100K0489 01D137 MID PTO [WITH MID PTO] 100K0489 01D20101 MAIN GEAR SHIFT FORK [MANUAL T/M TYPE] 100K0489 01D20102 MAIN GEAR SHIFT FORK [GST TYPE] 100K0489 01D20501 SHUTTLE SHIFT FORK [MANUAL T/M TYPE] 100K0489 01D20502 SHUTTLE SHIFT FORK [GST TYPE] 100K0489 01D21501 RANGE GEAR SHIFT FORK/CREEP GEAR SHIFT FORK 100K0489 01D21502 RANGE GEAR SHIFT FORK/CREEP GEAR SHIFT FORK 100K0489 01D217 RANGE GEAR SHIFT FORK [HST TYPE] 100K0489 01D22501 DIFFERENTIAL LOCK SHIFT FORK [EXCEPT HST TYPE] 100K0489 01D22502 DIFFERENTIAL LOCK SHIFT FORK [HST TYPE] 100K0489 01D30101 REAR AXLE [ROPS TYPE] 100K0489 SPEED CHANGE LEVER/BRAKE 01D401 BRAKE 100K0489 01D40501 BRAKE ROD 1 [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01D40502 BRAKE ROD 1 [HST TYPE] [ROPS TYPE] 100K0489 01D41001 BRAKE ROD 2 [MANUAL T/M TYPE] 100K0489 01D41002 BRAKE ROD 2 [GST TYPE] 100K0489 01D41003 BRAKE ROD 2 [HST TYPE] 100K0489 01E10101 MAIN GEAR SHIFT LEVER [MANUAL T/M TYPE] 100K0489 01E10102 MAIN GEAR SHIFT LEVER [GST TYPE] [ROPS TYPE] 100K0489 01E10501 SHUTTLE SHIFT LEVER [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01E106 CRUISE CONTROL LEVER [HST TYPE] 100K0489 01E107 CRUISE CONTROL CABLE [HST TYPE] 100K0489 01E108 NEUTRAL HOLDER LINK [HST TYPE] 100K0489 01E10901 SPEED CONTROL PEDAL [HST TYPE] [ROPS TYPE] 100K0489 01E11001 RANGE GEAR SHIFT LEVER [MANUAL T/M TYPE] 100K0489 01E11002 RANGE GEAR SHIFT LEVER [HST TYPE] [ROPS TYPE] 100K0489 01E111 RANGE GEAR SHIFT LEVER/CREEP GEAR SHIFT LEVER 100K0489 01E11201 RANGE GEAR SHIFT ROD [HST TYPE] [OLD TYPE] 100K0489 01E11202 RANGE GEAR SHIFT ROD [HST TYPE] [NEW TYPE] 100K0489 01E115 CREEP GEAR SHIFT LEVER [GST TYPE] [WITH CREEP] 100K0489 01E122 PTO CLUTCH CONTROL LEVER [WITH IND-PTO] 100K0489 01E12501 PTO GEAR SHIFT LEVER [EXCEPT HST TYPE] 100K0489 01E12502 PTO GEAR SHIFT LEVER [HST TYPE] 100K0489 01E127 PTO CLUTCH VALVE [COMPONENT PARTS] [WITH IND-PTO] 100K0489 01E129 MID PTO SHIFT LEVER [MID PTO TYPE] 100K0489 01E140 FRONT WHEEL DRIVE LEVER 100K0489 01E20101 BRAKE PEDAL [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01E20102 BRAKE PEDAL [HST TYPE] [ROPS TYPE] 100K0489 FRONT AXLE/CHASSIS 01F10502 FRONT AXLE FRAME 100K0489 01F120 PROPELLER SHAFT 100K0489 01F12201 FRONT WHEEL DRIVE SHAFT [W/O MID PTO] 100K0489 01F12202 FRONT WHEEL DRIVE SHAFT [WITH MID PTO] 100K0489 01F125 FRONT DIFFERENTIAL CASE 100K0489 01F135 FRONT DIFFERENTIAL 100K0489

Ref. L3710DT/GST/HST Page 12076 Item Part No. Description Book FRONT AXLE/CHASSIS 01F140 FRONT AXLE CASE 100K0489 01F145 DIFFERENTIAL GEAR SHAFT 100K0489 01F150 FRONT AXLE 100K0489 STEERING 01G10101 STEERING HANDLE [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01G10102 STEERING HANDLE [HST TYPE] [ROPS TYPE] 100K0489 01G110 STEERING CONTROLLER 100K0489 01G12002 STEERING LINKAGE 100K0489 01H11002 STEERING CYLINDER 100K0489 01H115 STEERING CYLINDER [COMPONENT PARTS] 100K0489 HYDRAULIC SYSTEM 01H12001 HYDRAULIC PUMP [EXCEPT HST TYPE] 100K0489 01H12002 HYDRAULIC PUMP [HST TYPE] 100K0489 01H12501 HYDRAULIC PUMP [COMPONENT PARTS] [EXCEPT HST TYPE] 100K0489 01H12502 HYDRAULIC PUMP [COMPONENT PARTS] [HST TYPE] 100K0489 01H145 REGULATOR VALVE [EXCEPT HST TYPE] 100K0489 01H20501 HYDRAULIC OIL LINE(INLET) [EXCEPT HST TYPE] 100K0489 01H20502 HYDRAULIC OIL LINE(INLET) [HST TYPE] 100K0489 01H21001 HYDRAULIC OIL LINE(DELIVERY) [EXCEPT HST TYPE] 100K0489 01H21002 HYDRAULIC OIL LINE(DELIVERY) [HST TYPE] 100K0489 01H21501 HYDRAULIC OIL LINE(PS) [EXCEPT HST TYPE] 100K0489 01H21502 HYDRAULIC OIL LINE(PS) [HST TYPE] 100K0489 01H23001 PTO HYDRAULIC OIL LINE [MANUAL T/M TYPE] 100K0489 01H23002 PTO HYDRAULIC OIL LINE [GST TYPE] [W/O IND-PTO] 100K0489 01H23501 HYDRAULIC OUTLET BLOCK [EXCEPT HST TYPE] 100K0489 01H23502 HYDRAULIC OUTLET BLOCK [HST TYPE] 100K0489 01H240 HYDRAULIC PIPE [HST TYPE] 100K0489 01H24501 OIL COOLER [HST TYPE] [OLD TYPE] 100K0489 01H24502 OIL COOLER [HST TYPE] [NEW TYPE] 100K0489 01H301 HYDRAULIC CYLINDER 100K0489 01H320 LIFT ARM 100K0489 01H330 FEED BACK LEVER 100K0489 01H405 CONTROL VALVE 100K0489 01H410 CONTROL VALVE [COMPONENT PARTS] [OLD TYPE] 100K0489 01H41001 CONTROL VALVE [COMPONENT PARTS] [NEW TYPE] 100K0489 01H44001 POSITION CONTROL LEVER [ROPS TYPE] 100K0489 01J105 TOP LINK 100K0489 01J11001 3-POINT LINKAGE 1(LOWER LINK) [OLD TYPE] 100K0489 01J11002 3-POINT LINKAGE 1(LOWER LINK) [NEW TYPE] 100K0489 01J115 3-POINT LINKAGE 2(LIFT ROD) 100K0489 HITCH/DRAWBAR 01K105 DRAWBAR 100K0489 01K12501 PTO PROTECTOR [ROPS TYPE] 100K0489 HOOD(BONNET)/ROPS/CAB 01L101 FRONT GRILLE 100K0489 01L10301 FRONT GRILLE SUPPORT [EXCEPT HST TYPE] 100K0489 01L10302 FRONT GRILLE SUPPORT [HST TYPE] [ROPS TYPE] 100K0489 01L10501 HOOD(BONNET) [ROPS TYPE] 100K0489 01L111 HOOD(BONNET) SIDE RH 100K0489 01L113 HOOD(BONNET) SIDE LH 100K0489 01L11501 SIDE COVER LOWER [ROPS TYPE] 100K0489 01L13001 SHUTTER PLATE [ROPS TYPE] 100K0489 01L20101 PANEL FRAME [EXCEPT HST TYPE] [ROPS TYPE] 100K0489

Ref. L3710DT/GST/HST Page 12076 Item Part No. Description Book HOOD(BONNET)/ROPS/CAB 01L20102 PANEL FRAME [HST TYPE] [ROPS TYPE] 100K0489 01L21001 FENDER [MANUAL T/M TYPE] 100K0489 01L21002 FENDER [GST TYPE] [ROPS TYPE] 100K0489 01L21003 FENDER [HST TYPE] [ROPS TYPE] 100K0489 01L21501 FLOOR SEAT [EXCEPT HST TYPE] [ROPS TYPE] 100K0489 01L21502 FLOOR SEAT [HST TYPE] [ROPS TYPE] 100K0489 01L22001 SEAT [ROPS TYPE] 100K0489 01L221 SEAT SUSPENSION [COMPONENT PARTS] 100K0489 01L22501 STEP [EXCEPT HST TYPE] 100K0489 01L22502 STEP [HST TYPE] 100K0489 01L301 ROPS [ROPS TYPE] [OLD TYPE] 100K0489 01L30101 ROPS [ROPS TYPE] [NEW TYPE] 100K0489 01L501 SMV EMBLEM 100K0489 FRONT WHEEL/REAR WHEEL 01P10102 FRONT WHEEL (7.2-16) 100K0489 01P10103 FRONT WHEEL (8.3-16) 100K0489 01P10104 FRONT WHEEL (10-16.5) 100K0489 01P10105 FRONT WHEEL (27*8.5-15) 100K0489 01P10106 FRONT WHEEL (27*10.50-15) 100K0489 01P10107 FRONT WHEEL (29*12.50-15) 100K0489 01P11001 REAR WHEEL (12.4-24) 100K0489 01P11002 REAR WHEEL (13.6-24) 100K0489 01P11003 REAR WHEEL (14.9-24) 100K0489 01P11004 REAR WHEEL (17.5-24) 100K0489 01P11005 REAR WHEEL (41*14.00-20) 100K0489 01P11006 REAR WHEEL (21.5L-16.1) [OLD TYPE] 100K0489 01P11007 REAR WHEEL (21.5L-16.1) [NEW TYPE] 100K0489 LABELS 01R10501 LABEL 1 [A] [MANUAL T/M TYPE] [ROPS TYPE] 100K0489 01R10502 LABEL 1 [CA] [MANUAL T/M TYPE] [ROPS TYPE] 100K0489 01R10503 LABEL 1 [A] [GST TYPE] [ROPS TYPE] 100K0489 01R10504 LABEL 1 [CA] [GST TYPE] [ROPS TYPE] 100K0489 01R10505 LABEL 1 [A] [HST TYPE] [ROPS TYPE] 100K0489 01R10506 LABEL 1 [CA] [HST TYPE] [ROPS TYPE] 100K0489 01R11001 LABEL 2 [A] [MANUAL T/M TYPE] [ROPS TYPE] 100K0489 01R11002 LABEL 2 [CA] [MANUAL T/M TYPE] [ROPS TYPE] 100K0489 01R11003 LABEL 2 [A] [GST TYPE] [ROPS TYPE] 100K0489 01R11004 LABEL 2 [CA] [GST TYPE] [ROPS TYPE] 100K0489 01R11005 LABEL 2 [A] [HST TYPE] [ROPS TYPE] 100K0489 01R11006 LABEL 2 [CA] [HST TYPE] [ROPS TYPE] 100K0489 ACCESSORIES 01S105 ACCESSORIES AND SERVICE PARTS 100K0489 OPTION 01T103 AIR CLEANER COVER KIT [OPTION] 100K0489 01T108 SWITCH KIT [OPTION] 100K0489 01T120 FRONT GUARD STAY KIT [OPTION] 100K0489 01T130 POSITION CONTROL LEVER (WITH DRAFT) [OPTION] 100K0489 01T135 DRAFT CONTROL LEVER (WITH DRAFT) [OPTION] 100K0489 01T140 TOP LINK HOLDER (WITH DRAFT) [OPTION] 100K0489 01T145 SWINGING DRAWBAR/CLEVIS DRAWBAR [OPTION] 100K0489 01T15001 REMOTE CONTROL VALVE LEVER 1 [ROPS TYPE] [OPTION] 100K0489 01T15003 REMOTE CONTROL VALVE LEVER 2 [ROPS TYPE] [OPTION] 100K0489 01T15005 REMOTE CONTROL VALVE LEVER 3 [ROPS TYPE] [OPTION] 100K0489 01T15501 REMOTE CONTROL VALVE COUPLER 1 [OPTION] 100K0489 01T15502 REMOTE CONTROL VALVE COUPLER 2 [OPTION] 100K0489 01T15503 REMOTE CONTROL VALVE COUPLER 3 [OPTION] 100K0489 01T160 ROPS [ROPS TYPE] [OPTION] [OLD TYPE] 100K0489 01T16001 ROPS [ROPS TYPE] [OPTION] [NEW TYPE] 100K0489

CRANKCASE Reference: 010001 Page: 1 010 020 020 030 030 040 040 050 060 070 070 080 090 090 100 100 110 120 130 140 150 160 170 180 190 200 210 220 230

CRANKCASE Reference: 010001 Page: 1 REF.No Part No. Description Q'ty S.No. I/C REMARKS Weight (kgf) Weight (lb) 010 16493-01010 COMP.CRANKCASE 1 <=1Y0374 54.5 119.9 010 16493-01014 COMP.CRANKCASE 1 >=2A0001 ← 61 134.2 020 15521-96020 PLUG 6 0.003 0.0066 030 15521-96030 PLUG 2 0.007 0.0154 040 17391-96160 PLUG EXPANSION 3 0.003 0.0066 050 06311-75045 PLUG EXPANSION 1 0.026 0.0572 060 15221-03380 CAP SEALING 6 0.017 0.0374 070 15221-03390 CAP SEALING 2 0.03 0.066 080 05012-00408 PIN STRAIGHT 2 0.001 0.0022 090 05012-00609 PIN STRAIGHT 2 0.003 0.0066 100 05012-00612 PIN STRAIGHT 2 0.003 0.0066 110 05012-01018 PIN STRAIGHT 1 0.012 0.0264 120 15221-33650 PIN PIPE 1 0.004 0.0088 130 15321-73340 PIPE WATER RETURN 1 0.016 0.0352 140 15221-33610 PLUG 1 0.009 0.0198 150 15021-33660 GASKET 1 0.001 0.0022 160 15221-33700 O RING 1 0.001 0.0022 170 15471-35012 ASSY PUMP OIL 1 0.55 1.21 180 15296-35150 GASKET OIL PUMP 1 0 0 180 1A021-35150 GASKET OIL PUMP 1 ↔ 0.001 0.0022 190 01053-50650 BOLT 4 0.011 0.0242 200 04512-60060 WASHER SPRING 4 0.001 0.0022 210 19202-35660 GEAR OIL PUMP DRIVE 1 0.23 0.506 220 05712-00410 KEY FEATHER 1 0.001 0.0022 230 15221-35682 NUT FLANGE 1 0.014 0.0308

OIL PAN Reference: 010002 Page: 2 010 020 030 040 050 060 070 080 090 100 110 120 130
